Brain Structure and Function

1
Brain Structure and Function
2

• If the human brain were so simple that we could
  understand it, we would be so simple that we
  couldnt
• -Emerson Pugh, The Biological Origin of Human
  Values (1977)

3
Phineas Gage

• September 13th, 1848
• Phineas 25 years old
• Rutland Burlington Railroad, Cavendish, VT
• Paving the way for new RR tracks
• Tamping Iron
• 1.25in x 3ft

4
(No Transcript)
5
Phineas Gage

• Accident
• Quick Recovery
• Months later No longer Gage
• Before capable, efficient, best foreman,
  well-balanced mind
• After extravagant, anti-social, liar, grossly
  profane
• Stint with P.T Barnum
• Died 12 years later

6
Evolution of the Brain

• Reptilian ? Paleomammalian ? Neomammalian

7
The Brain

• Brainstem
• responsible for automatic survival functions
• Medulla
• controls heartbeat and breathing

8
Parts of the Brain
THALAMUS ? Relays messages
amygdala
hippocampus
pituitary
CEREBELLUM ? Coordination and balance

• BRAINSTEM ? Heart rate and breathing

9
Reticular Formation

• Widespread connections
• Arousal of the brain as a whole
• Reticular activating system (RAS)
• Maintains consciousness and alertness
• Functions in sleep and arousal from sleep

10
The Cerebellum

• helps coordinate voluntary movement and balance

11
The Limbic System

• Hypothalamus, pituitary, amygdala, and
  hippocampus all deal with basic drives, emotions,
  and memory
• Hippocampus ? Memory processing
• Amygdala ? Aggression (fight) and fear (flight)
• Hypothalamus ? Hunger, thirst, body temperature,
  pleasure regulates pituitary gland (hormones)

12
The Limbic System

• Hypothalamus
• neural structure lying below (hypo) the thalamus
  directs several maintenance activities
• eating
• drinking
• body temperature
• helps govern the endocrine system via the
  pituitary gland
• linked to emotion

13
The Limbic System

• Amygdala
• two almond-shaped neural clusters that are
  components of the limbic system and are linked to
  emotion and fear

14
The Brain

• Thalamus
• the brains sensory switchboard, located on top
  of the brainstem
• it directs messages to the sensory receiving
  areas in the cortex and transmits replies to the
  cerebellum and medulla

15
The Cerebral Cortex

• Cerebral Cortex
• the bodys ultimate control and information
  processing center

16
The lobes of the cerebral hemispheres
17
The lobes of the cerebral hemispheres
Planning, decision making speech
Sensory
Vision
Auditory
18
The Cerebral Cortex

• Frontal Lobes
• involved in speaking and muscle movements and in
  making plans and judgments
• the executive
• Parietal Lobes
• include the sensory cortex

19
The Cerebral Cortex

• Occipital Lobes
• include the visual areas, which receive visual
  information from the opposite visual field
• Temporal Lobes
• include the auditory areas, each of which
  receives auditory information primarily from the
  opposite ear

20
The Cerebral Cortex

• Frontal (Forehead to top) ? Motor Cortex
• Parietal (Top to rear) ? Sensory Cortex
• Occipital (Back) ? Visual Cortex
• Temporal (Above ears) ? Auditory Cortex

21
Motor/Sensory Cortex

• Contralateral
• Homunculus
• Unequal representation

22
Sensory Areas Sensory Homunculus
Figure 13.10
23
The Cerebral Cortex

• Aphasia
• impairment of language, usually caused by left
  hemisphere damage either to Brocas area
  (impairing speaking) or to Wernickes area
  (impairing understanding) see clips
• Brocas Area
• an area of the left frontal lobe that directs the
  muscle movements involved in speech
• Wernickes Area
• an area of the left temporal lobe involved in
  language comprehension and expression

24
Language Areas

• Broca ? Expression
• Wernicke ? Comprehensionand reception
• Aphasias

LEFT HEMISPHERE
25
Paul Broca 1800s

• Suggested localization

26
Techniques to examine functions of the brain
1. Remove part of the brain see what effect it
has on behavior
2. Examine humans who have suffered brain damage
27
3. Stimulate the brain
4. Record brain activity
28
(No Transcript)
29
Brain Lateralization
30
Our Divided Brains

• Corpus collosum large bundle of neural fibers
  (myelinated axons, or white matter) connecting
  the two hemispheres

31
Hemispheric Specialization

• LEFT
• Symbolic thinking
• (Language)
• Detail
• Literal meaning

RIGHT Spatial perception Overall
picture Context, metaphor
32
Contra-lateral division of labor

• Right hemisphere controls left side of body and
  visual field
• Left hemisphere controls right side of body and
  visual field

33
Split Brain Patients

• Epileptic patients had corpus callosum cut to
  reduce seizures in the brain
• Lives largely unaffected, seizures reduced
• Affected abilities related to naming objects in
  the left visual field

34
Brain Plasticity
35
Brain Plasticity

• The ability of the brain to reorganize neural
  pathways based on new experiences
• Persistent functional changes in the brain
  represent new knowledge
• Age dependent component
• Brain injuries

36
Environmental influences on neuroplasticity
37
Sensation and Perception
38
Sensation

• The process by which the central nervous system
  receives input from the environment via sensory
  neurons
• Bottom up processing

39
Perception

• The process by which the brain interprets and
  organizes sensory information
• Top-down processing

40
The psychophysics of sensation

• Absolute threshold ? the minimum stimulation
  needed to detect a stimulus with 50 accuracy
• Subliminal stimulation ? below the absolute
  threshold for conscious awareness
• May affect behavior without conscious awareness
• Sensory adaptation/habituation ? diminished
  sensitivity to an unchanging stimulus

41
The five major senses

• Vision electromagnetic
• Occipital lobe
• Hearing mechanical
• Temporal lobe
• Touch mechanical
• Sensory cortex
• Taste chemical
• Gustatory insular cortex
• Smell chemical
• Olfactory bulb
• Orbitofrontal cortex
• Vomeronasal organ?

42
The sixth sense
And the seventhand eighthand ninth

• Vestibular ? balance and motion
• Inner ear
• Proprioceptive ? relative position of body parts
• Parietal lobe
• Temperature ? heat
• Thermoreceptors throughout the body, sensory
  cortex
• Nociception ? pain
• Nociceptors throughout the body, sensory cortex

43
Thresholds of the five major senses
44
The Retina

• The retina at the back of the eye is actually
  part of the brain!

• Rods brightness
• Cones color
