Lexical and Syntax Analysis Chapter 4

1
Lexical and Syntax AnalysisChapter 4
2

• Compilation

• Translating from high-level language to machine
  code is organized into several phases or passes.
• In the early days passes communicated through
  files, but this is no longer necessary.

3

• Language Specification

• We must first describe the language in question
  by giving its specification.
• Syntax
• Defines symbols (vocabulary)
• Defines programs (sentences)
• Semantics
• Gives meaning to sentences.
• The formal specifications are often the input to
  tools that build translators automatically.

4

• Compiler passes

String of characters
String of tokens
Abstract syntax tree
Abstract syntax tree
Abstract syntax tree
Abstract syntax tree
Medium-level intermediate code
Low-level intermediate code
Medium-level intermediate code
Low-level intermediate code
Low-level intermediate code
Executable/object code
5

• Compiler passes

source program
front end
Lexical scanner
Parser
semantic analyzer
symbol table manager
error handler
Translator
Optimizer
back end
Final assembly
target program
6

• Lexical analyzer

• Also called a scanner or tokenizer
• Converts stream of characters into a stream of
  tokens
• Tokens are
• Keywords such as for, while, and class.
• Special characters such as , -, (, and lt
• Variable name occurrences
• Constant occurrences such as 1, 0, true.

7
Comparison with Lexical Analysis
Phase Input Output
Lexer Sequence of characters Sequence of tokens
Parser Sequence of tokens Parse tree
8

• Lexical analyzer

• The lexical analyzer is usually a subroutine of
  the parser.
• Each token is a single entity. A numerical code
  is usually assigned to each type of token.

9

• Lexical analyzer

• Lexical analyzers perform
• Line reconstruction
• delete comments
• delete white spaces
• perform text substitution
• Lexical translation translation of lexemes -gt
  tokens
• Often additional information is affiliated with a
  token.

10

• Parser

• Performs syntax analysis
• Imposes syntactic structure on a sentence.
• Parse trees are used to expose the structure.
• These trees are often not explicitly built
• Simpler representations of them are often used
• Parsers, accepts a string of tokens and builds a
  parse tree representing the program

11

• Parser

• The collection of all the programs in a given
  language is usually specified using a list of
  rules known as a context free grammar.

12
Parser

• A grammar has four components
• A set of tokens known as terminal symbols
• A set of variables or non-terminals
• A set of productions where each production
  consists of a non-terminal, an arrow, and a
  sequence of tokens and/or non-terminals
• A designation of one of the nonterminals as the
  start symbol.

13
Symbol Table Management

• The symbol table is a data structure used by all
  phases of the compiler to keep track of user
  defined symbols and keywords.
• During early phases (lexical and syntax analysis)
  symbols are discovered and put into the symbol
  table
• During later phases symbols are looked up to
  validate their usage.

14
Symbol Table Management

• Typical symbol table activities
• add a new name
• add information for a name
• access information for a name
• determine if a name is present in the table
• remove a name
• revert to a previous usage for a name (close a
  scope).

15
Symbol Table Management

• Many possible Implementations
• linear list
• sorted list
• hash table
• tree structure

16
Symbol Table Management

• Typical information fields
• print value
• kind (e.g. reserved, typeid, varid, funcid, etc.)
• block number/level number
• type
• initial value
• base address
• etc.

17

• Abstract Syntax Tree

• The parse tree is used to recognize the
  components of the program and to check that the
  syntax is correct.
• As the parser applies productions, it usually
  generates the component of a simpler tree (known
  as Abstract Syntax Tree).
• The meaning of the component is derived out of
  the way the statement is organized in a subtree.

18

• Semantic Analyzer

• The semantic analyzer completes the symbol table
  with information on the characteristics of each
  identifier.
• The symbol table is usually initialized during
  parsing.
• One entry is created for each identifier and
  constant.
• Scope is taken into account. Two different
  variables with the same name will have different
  entries in the symbol table.
• The semantic analyzer completes the table using
  information from declarations.

19

• Semantic Analyzer

• The semantic analyzer does
• Type checking
• Flow of control checks
• Uniqueness checks (identifiers, case labels,
  etc.)
• One objective is to identify semantic errors
  statically. For example
• Undeclared identifiers
• Unreachable statements
• Identifiers used in the wrong context.
• Methods called with the wrong number of
  parameters or with parameters of the wrong type.

20

• Semantic Analyzer

• Some semantic errors have to be detected at run
  time. The reason is that the information may not
  be available at compile time.
• Array subscript is out of bonds.
• Variables are not initialized.
• Divide by zero.

21
Error Management

• Errors can occur at all phases in the compiler
• Invalid input characters, syntax errors, semantic
  errors, etc.
• Good compilers will attempt to recover from
  errors and continue.

22

• Translator

• The lexical scanner, parser, and semantic
  analyzer are collectively known as the front end
  of the compiler.
• The second part, or back end starts by generating
  low level code from the (possibly optimized) AST.

23
Translator

• Rather than generate code for a specific
  architecture, most compilers generate
  intermediate language
• Three address code is popular.
• Really a flattened tree representation.
• Simple.
• Flexible (captures the essence of many target
  architectures).
• Can be interpreted.

24
Translator

• One way of performing intermediate code
  generation
• Attach meaning to each node of the AST.
• The meaning of the sentence the meaning
  attached to the root of the tree.

25

• XIL

• An example of Medium level intermediate language
  is XIL. XIL is used by IBM to compile FORTRAN, C,
  C, and Pascal for RS/6000.
• Compilers for Fortran 90 and C have been
  developed using XIL for other machines such as
  Intel 386, Sparc, and S/370.

26
Optimizers

• Intermediate code is examined and improved.
• Can be simple
• changing aa1 to increment a
• changing 35 to 15
• Can be complicated
• reorganizing data and data accesses for cache
  efficiency
• Optimization can improve running time by orders
  of magnitude, often also decreasing program size.

27
Code Generation

• Generation of real executable code for a
  particular target machine.
• It is completed by the Final Assembly phase
• Final output can either be
• assembly language for the target machine
• object code ready for linking
• The target machine can be a virtual machine
  (such as the Java Virtual Machine, JVM), and the
  real executable code is virtual code (such as
  Java Bytecode).

28
Compiler Overview
Source Program
IF (altb) THEN c1d
Lexical Analyzer
IF
(
ID a
lt
ID b
THEN
ID c

CONST 1

ID d
Token Sequence
a
Syntax Analyzer
cond_expr
lt
b
Syntax Tree
IF_stmt
lhs
c
list
1
assign_stmt
rhs
Semantic Analyzer

d
GE a, b, L1 MUlT 1, d, c L1
3-Address Code
GE a, b, L1 MOV d, c L1
Code Optimizer
loadi R1,a cmpi R1,b jge L1 loadi R1,d storei
R1,c L1
Optimized 3-Addr. Code
Code Generation
Assembly Code
29
Lexical Analysis
30
What is Lexical Analysis?

• The lexical analyzer deals with small-scale
  language constructs, such as names and numeric
  literals. The syntax analyzer deals with the
  large-scale constructs, such as expressions,
  statements, and program units.
• - The syntax analysis portion consists of two
  parts
• 1. A low-level part called a lexical analyzer
  (essentially a pattern matcher).
• 2. A high-level part called a syntax analyzer,
  or parser.
• The lexical analyzer collects characters into
  logical groupings and assigns internal codes to
  the groupings according to their structure.

31
Lexical Analyzer in Perspective
32
Lexical Analyzer in Perspective

• LEXICAL ANALYZER
• Scan Input
• Remove white space,
• Identify Tokens
• Create Symbol Table
• Insert Tokens into AST
• Generate Errors
• Send Tokens to Parser

• PARSER
• Perform Syntax Analysis
• Actions Dictated by Token Order
• Update Symbol Table Entries
• Create Abstract Rep. of Source
• Generate Errors

33
Lexical analyzers extract lexemes from a given
input string and produce the corresponding tokens.

• Sum oldsum value /100
• Token Lexeme
• IDENT sum
• ASSIGN_OP
• IDENT oldsum
• SUBTRACT_OP -
• IDENT value
• DIVISION_OP /
• INT_LIT 100
• SEMICOLON

34
Basic Terminology

• What are Major Terms for Lexical Analysis?
• TOKEN
• A classification for a common set of strings
• Examples Include ltIdentifiergt, ltnumbergt, etc.
• PATTERN
• The rules which characterize the set of strings
  for a token
• LEXEME
• Actual sequence of characters that matches
  pattern and is classified by a token
• Identifiers x, count, name, etc

35
Basic Terminology
36
Token Definitions
Suppose S ts the string banana
Prefix ban, banana Suffix ana,
banana Substring nan, ban, ana,
banana Subsequence bnan, nn
37
Token Definitions
letter ? A B C Z a b
z digit ? 0 1 2 9 id ? letter (
letter digit )
Shorthand Notation one or more
r r ? r r r ? zero or
one r?r ? range set range of
characters (replaces )
A-Z A B C Z
id ? A-Za-zA-Za-z0-9
38
Token Recognition
Assume Following Tokens if, then,
else, re-loop, id, num
What language construct are they used for ?
Given Tokens, What are Patterns ?
Grammarstmt ? if expr then stmt if expr
then stmt else stmt ?expr ? term re-loop term
termterm ? id num
if ? if then ? then else ?
else Re-loop ? lt lt gt gt ltgt id
? letter ( letter digit ) num ? digit (.
digit ) ? ( E( -) ? digit ) ?
What does this represent ?
39
What Else Does Lexical Analyzer Do?
Scan away b, nl, tabs Can we Define Tokens For
These?
blank ? b tab ? T newline ?
M delim ? blank tab newline ws ?
delim
40
Symbol Tables
Note Each token has a unique token identifier
to define category of lexemes
41
Building a Lexical Analyzer

• There are three approaches to building a lexical
  analyzer
• 1. Write a formal description of the token
  patterns of the language using a descriptive
  language. Tool on UNIX system called lex
• 2. Design a state transition diagram that
  describes the token patterns of the language and
  write a program that implements the diagram.
• 3. Design a state transition diagram and
  hand-construct a table-driven implementation of
  the state diagram.

42
Diagrams for Tokens

• Transition Diagrams (TD) are used to represent
  the tokens
• Each Transition Diagram has
• States Represented by Circles
• Actions Represented by Arrows between states
• Start State Beginning of a pattern
  (Arrowhead)
• Final State(s) End of pattern (Concentric
  Circles)
• Deterministic - No need to choose between 2
  different actions

43
Example Transition Diagrams
44
State diagram to recognize names, reserved words,
and integer literals
45
Reasons to use BNF to Describe Syntax

• Provides a clear syntax description
• The parser can be based directly on the BNF
• Parsers based on BNF are easy to maintain

46
Reasons to Separate Lexical and Syntax Analysis

• Simplicity - less complex approaches can be used
  for lexical analysis separating them simplifies
  the parser
• Efficiency - separation allows optimization of
  the lexical analyzer
• Portability - parts of the lexical analyzer may
  not be portable, but the parser always is portable

47
Summary of Lexical Analysis

• A lexical analyzer is a pattern matcher for
  character strings
• A lexical analyzer is a front-end for the
  parser
• Identifies substrings of the source program that
  belong together - lexemes
• Lexemes match a character pattern, which is
  associated with a lexical category called a token
• - sum is a lexeme its token may be IDENT

48
Semantic AnalysisIntro to Type Checking
49
The Compiler So Far

• Lexical analysis
• Detects inputs with illegal tokens
• Parsing
• Detects inputs with ill-formed parse trees
• Semantic analysis
• The last front end phase
• Catches more errors

50
Whats Wrong?

• Example 1
• int in x
• Example 2
• int i 12.34

51
Why a Separate Semantic Analysis?

• Parsing cannot catch some errors
• Some language constructs are not context-free
• Example All used variables must have been
  declared (i.e. scoping)
• Example A method must be invoked with arguments
  of proper type (i.e. typing)

52
What Does Semantic Analysis Do?

• Checks of many kinds
• All identifiers are declared
• Types
• Inheritance relationships
• Classes defined only once
• Methods in a class defined only once
• Reserved identifiers are not misused
• And others . . .
• The requirements depend on the language

53
Scope

• Matching identifier declarations with uses
• Important semantic analysis step in most
  languages

54
Scope (Cont.)

• The scope of an identifier is the portion of a
  program in which that identifier is accessible
• The same identifier may refer to different things
  in different parts of the program
• Different scopes for same name dont overlap
• An identifier may have restricted scope

55
Static vs. Dynamic Scope

• Most languages have static scope
• Scope depends only on the program text, not
  run-time behavior
• C has static scope
• A few languages are dynamically scoped
• Lisp, COBOL
• Current Lisp has changed to mostly static scoping
• Scope depends on execution of the program

56
Class Definitions

• Class names can be used before being defined
• We cant check this property
• using a symbol table
• or even in one pass
• Solution
• Pass 1 Gather all class names
• Pass 2 Do the checking
• Semantic analysis requires multiple passes
• Probably more than two

57
Types

• What is a type?
• The notion varies from language to language
• Consensus
• A set of values
• A set of operations on those values
• Classes are one instantiation of the modern
  notion of type

58
Why Do We Need Type Systems?

• Consider the assembly language fragment
• addi r1, r2, r3
• What are the types of r1, r2, r3?

59
Types and Operations

• Certain operations are legal for values of each
  type
• It doesnt make sense to add a function pointer
  and an integer in C
• It does make sense to add two integers
• But both have the same assembly language
  implementation!

60
Type Systems

• A languages type system specifies which
  operations are valid for which types
• The goal of type checking is to ensure that
  operations are used with the correct types
• Enforces intended interpretation of values,
  because nothing else will!
• Type systems provide a concise formalization of
  the semantic checking rules

61
What Can Types do For Us?

• Can detect certain kinds of errors
• Memory errors
• Reading from an invalid pointer, etc.
• Violation of abstraction boundaries
• class FileSystem
• open(x String) File

class Client f(fs FileSystem)
File fdesc lt- fs.open(foo) -- f
cannot see inside fdesc !
62
Type Checking Overview

• Three kinds of languages
• Statically typed All or almost all checking of
  types is done as part of compilation (C and Java)
• Dynamically typed Almost all checking of types
  is done as part of program execution (Scheme)
• Untyped No type checking (machine code)

63
The Type Wars

• Competing views on static vs. dynamic typing
• Static typing proponents say
• Static checking catches many programming errors
  at compile time
• Avoids overhead of runtime type checks
• Dynamic typing proponents say
• Static type systems are restrictive
• Rapid prototyping easier in a dynamic type system

64
The Type Wars (Cont.)

• In practice, most code is written in statically
  typed languages with an escape mechanism
• Unsafe casts in C, Java
• Its debatable whether this compromise represents
  the best or worst of both worlds

65
Type Checking and Type Inference

• Type Checking is the process of verifying fully
  typed programs
• Type Inference is the process of filling in
  missing type information
• The two are different, but are often used
  interchangeably

66
Rules of Inference

• We have seen two examples of formal notation
  specifying parts of a compiler
• Regular expressions (for the lexer)
• Context-free grammars (for the parser)
• The appropriate formalism for type checking is
  logical rules of inference

67
Why Rules of Inference?

• Inference rules have the form
• If Hypothesis is true, then Conclusion is true
• Type checking computes via reasoning
• If E1 and E2 have certain types, then E3 has a
  certain type
• Rules of inference are a compact notation for
  If-Then statements

68
From English to an Inference Rule

• The notation is easy to read (with practice)
• Start with a simplified system and gradually add
  features
• Building blocks
• Symbol Ù is and
• Symbol Þ is if-then
• xT is x has type T

69
From English to an Inference Rule (2)

• If e1 has type Int and e2 has type Int,
  then e1 e2 has type Int
• (e1 has type Int Ù e2 has type Int) Þ
  e1 e2 has type Int
• (e1 Int Ù e2 Int) Þ e1 e2 Int

70
From English to an Inference Rule (3)

• The statement
• (e1 Int Ù e2 Int) Þ e1 e2 Int
• is a special case of
• ( Hypothesis1 Ù . . . Ù Hypothesisn ) Þ
  Conclusion
• This is an inference rule

71
Notation for Inference Rules

• By tradition inference rules are written
• Type rules can also have hypotheses and
  conclusions of the form
• e T
• means it is provable that . . .

Hypothesis1 Hypothesisn
Conclusion
72
Two Rules
i is an integer
i Int
Int
e1 Int e2 Int
e1 e2 Int
Add
73
Two Rules (Cont.)

• These rules give templates describing how to type
  integers and expressions
• By filling in the templates, we can produce
  complete typings for expressions

74
Example 1 2
1 is an integer 2 is an integer
1 Int 2 Int
1 2 Int 1 2 Int 1 2 Int
75
Soundness

• A type system is sound if
• Whenever e T
• Then e evaluates to a value of type T
• We only want sound rules
• But some sound rules are better than others

i is an integer
i Object
76
Type Checking Proofs

• Type checking proves facts e T
• Proof is on the structure of the AST
• Proof has the shape of the AST
• One type rule is used for each kind of AST node
• In the type rule used for a node e
• Hypotheses are the proofs of types of es
  sub-expressions
• Conclusion is the proof of type of e
• Types are computed in a bottom-up pass over the
  AST

77
Rules for Constants

false Bool
Bool
s is a string constant
s String
String
78
Two More Rules
e Bool
not e Bool
Not
e1 Bool e2 T
while e1 loop e2 pool Object
Loop
79
A Problem

• What is the type of a variable reference?
• The local, structural rule does not carry enough
  information to give x a type.

x is an identifier
x ?
Var
80
Notes

• The type environment gives types to the free
  identifiers in the current scope
• The type environment is passed down the AST from
  the root towards the leaves
• Types are computed up the AST from the leaves
  towards the root

81
Expressiveness of Static Type Systems

• A static type system enables a compiler to detect
  many common programming errors
• The cost is that some correct programs are
  disallowed
• Some argue for dynamic type checking instead
• Others argue for more expressive static type
  checking
• But more expressive type systems are also more
  complex

82
Dynamic And Static Types

• The dynamic type of an object is the class C that
  is used in the new C expression that creates
  the object
• A run-time notion
• Even languages that are not statically typed have
  the notion of dynamic type
• The static type of an expression is a notation
  that captures all possible dynamic types the
  expression could take
• A compile-time notion

83
Dynamic And Static Types

• The typing rules use very concise notation
• They are very carefully constructed
• Virtually any change in a rule either
• Makes the type system unsound
• (bad programs are accepted as well typed)
• Or, makes the type system less usable
• (perfectly good programs are rejected)
• But some good programs will be rejected anyway
• The notion of a good program is undecidable

84
Type Systems

• Type rules are defined on the structure of
  expressions
• Types of variables are modeled by an environment
• Types are a play between flexibility and safety

85
End of Lecture 6
