Chapter 15 Enzymes

1
Chapter 15 Enzymes
2
Enzymes

• Ribbon diagram of cytochrome c oxidase, the
  enzyme that directly uses oxygen during
  respiration.

3
Enzyme Catalysis

• Enzyme A biological catalyst.
• With the exception of some RNAs that catalyze
  their own self-cleavage, all enzymes are
  proteins.
• Enzymes can increase the rate of a reaction by a
  factor of 109 to 1020 over an uncatalyzed
  reaction.
• Some catalyze the reaction of only one compound.
• Others are stereoselective for example, enzymes
  that catalyze the reactions of only L-amino
  acids.
• Others catalyze reactions of specific types of
  compounds or bonds for example, trypsin
  catalyzes hydrolysis of peptide bonds formed by
  the carboxyl groups of Lys and Arg.

4
Enzyme Catalysis

• Figure 15.1 Trypsin catalyzes the hydrolysis of
  peptide bonds formed by the carboxyl group of
  lysine and arginine.

5
Classification of Enzymes

• Enzymes are commonly named after the reaction or
  reactions they catalyze.
• Example lactate dehydrogenase, acid phosphatase.
• Enzymes are classified into six major groups
  according to the type of reaction catalyzed
• Oxidoreductases Oxidation-reduction reactions.
• Transferases Group transfer reactions.
• Hydrolases Hydrolysis reactions.
• Lyases Addition of two groups to a double bond,
  or removal of two groups to create a double bond.
• Isomerases Isomerization reactions.
• Ligases The joining to two molecules.

6
Classification of Enzymes

• 1. Oxidoreductase
• 2. Transferase

7
Classification of Enzymes
3. Hydrolase
4. Lyase
8
Classification of Enzymes

• 5. Isomerase
• 6. Ligase

9
Enzyme Terminology

• Apoenzyme The protein part of an enzyme.
• Cofactor A nonprotein portion of an enzyme that
  is necessary for catalytic function examples are
  metallic ions such as Zn2 and Mg2.
• Coenzyme A nonprotein organic molecule,
  frequently a B vitamin, that acts as a cofactor.
• Substrate The compound or compounds whose
  reaction an enzyme catalyzes.
• Active site The specific portion of the enzyme
  to which a substrate binds during reaction.

10
Schematic of an Active Site

• Figure 15.2 Schematic diagram of the active site
  of an enzyme and the participating components.

11
Terms in Enzyme Chemistry

• Activation Any process that initiates or
  increases the activity of an enzyme.
• Inhibition Any process that makes an active
  enzyme less active or inactive.
• Competitive inhibitor A substance that binds to
  the active site of an enzyme thereby preventing
  binding of substrate.
• Noncompetitive inhibitor Any substance that
  binds to a portion of the enzyme other than the
  active site and thereby inhibits the activity of
  the enzyme.

12
Enzyme Activity

• Enzyme activity A measure of how much a
  reaction rate is increased.
• We examine how the rate of an enzyme-catalyzed
  reaction is affected by
• Enzyme concentration.
• Substrate concentration.
• Temperature.
• pH.

13
Enzyme Activity

• Figure 15.3 The effect of enzyme concentration
  on the rate of an enzyme-catalyzed reaction.
  Substrate concentration, temperature, and pH are
  constant.

14
Enzyme Activity

• Figure 15.4 The effect of substrate
  concentration on the rate of an enzyme-catalyzed
  reaction. Enzyme concentration, temperature, and
  pH are constant.

15
Enzyme Activity

• Figure 23.5 The effect of temperature on the
  rate of an enzyme-catalyzed reaction. Substrate
  and enzyme concentrations and pH are constant.

16
Enzyme Activity

• Figure 23.6 The effect of pH on the rate of an
  enzyme-catalyzed reaction. Substrate and enzyme
  concentrations and temperature are constant.

17
Mechanism of Action

• Figure 15.7 Lock-and-key model of enzyme
  mechanism.
• The enzyme is a rigid three-dimensional body.
• The enzyme surface contains the active site.

18
Mechanism of Action

• Figure 15.8 The Induced-fit model of an enzyme
  mechanism.
• The active site becomes modified to accommodate
  the substrate.

19
Mechanism of Action

• Figure 23.9 The mechanism of competitive
  inhibition.
• When a competitive inhibitor enters the active
  site, the substrate cannot enter.

20
Mechanism of Action

• Figure 15.10 Mechanism of noncompetitive
  inhibition. The inhibitor binds itself to a site
  other than the active site (allosterism), thereby
  changing the conformation of the active site.
  The substrate still binds but there is no
  catalysis.

21
Mechanism of Action

• Figure 15.11 Enzyme kinetics in the presence and
  the absence of inhibitors.

22
Mechanism of Action

• Both the lock-and-key model and the induced-fit
  model emphasize the shape of the active site.
• However, the chemistry of the active site is the
  most important.
• Just five amino acids participate in the active
  site in more than 65 of the enzymes studied to
  date.
• These five are His gt Cys gt Asp gt Arg gt Glu.
• Four of these amino acids have either acidic or
  basic side chains the fifth has a sulfhydryl
  group (-SH).

23
Catalytic Power

• Figure 23.12 Enzymes provide an alternative
  pathway for reaction. (a) The activation energy
  profile for a typical reaction. (b) A comparison
  of the activation energy profiles for a catalyzed
  and uncatalyzed reactions.

24
Enzyme Regulation

• Feedback control An enzyme-regulation process
  where the product of a series of
  enzyme-catalyzed reactions inhibits an earlier
  reaction in the sequence.
• The inhibition may be competitive or
  noncompetitive.

25
Enzyme Regulation

• Proenzyme (zymogen) An inactive form of an
  enzyme that must have part of its polypeptide
  chain hydrolyzed and removed before it becomes
  active.
• An example is trypsin, a digestive enzyme.
• It is synthesized and stored as trypsinogen,
  which has no enzyme activity.
• It becomes active only after a six-amino acid
  fragment is hydrolyzed and removed from the
  N-terminal end of its chain.
• Removal of this small fragment changes not only
  the primary structure but also the tertiary
  structure, allowing the molecule to achieve its
  active form.

26
Enzyme Regulation

• Allosterism Enzyme regulation based on an event
  occurring at a place other than the active site
  but that creates a change in the active site.
• An enzyme regulated by this mechanism is called
  an allosteric enzyme.
• Allosteric enzymes often have multiple
  polypeptide chains.
• Negative modulation Inhibition of an allosteric
  enzyme.
• Positive modulation Stimulation of an allosteric
  enzyme.
• Regulator A substance that binds to an
  allosteric enzyme.

27
Enzyme Regulation

• Figure 15.14 The allosteric effect. Binding of
  the regulator to a site other than the active
  site changes the shape of the active site.

28
Enzyme Regulation

• Figure 15.15 Effects of binding activators and
  inhibitors to allosteric enzymes. The enzyme has
  an equilibrium between the T form and the R form.

29
Enzyme Regulation

• Protein modification The process of affecting
  enzyme activity by covalently modifying it.
• The best known examples of protein modification
  involve phosphorylation/dephosphorylation.
• Example Pyruvate kinase (PK) is the active form
  of the enzyme it is inactivated by
  phosphorylation to pyruvate kinase phosphate
  (PKP).

30
Enzyme Regulation

• Isoenzyme (Isozymes) An enzyme that occurs in
  multiple forms each catalyzes the same reaction.
• Example lactate dehydrogenase (LDH) catalyzes
  the oxidation of lactate to pyruvate.
• The enzyme is a tetramer of H and M chains.
• H4 is present predominately in heart muscle.
• M4 is present predominantly in the liver and in
  skeletal muscle.
• H3M, H2M2, and HM3 also exist.
• H4 is allosterically inhibited by high levels of
  pyruvate while M4 is not.
• H4 in serum correlates with the severity of heart
  attack.

31
Enzyme Regulation

• Figure 15.16 The isozymes of lactate
  dehydrogenase (LDH). The electrophoresis gel
  depicts the relative isozyme types found in
  different tissues.

32
p649
33
Enzymes Used in Medicine
Table 15.2 Enzyme Assays useful in Medical
Diagnosis
Insert Table 23.2, page 648
34
Transition-State Analogs

• Transition state analog A molecule whose shape
  mimics the transition state of a substrate.
• Figure 15.17 The proline racemase reaction.
  Pyrrole-2-carboxylate mimics the planar
  transition state of the reaction (next screen).

35
Transition-State Analog
36
Transition-State Analogs

• Abzyme An antibody that has catalytic activity
  because it was created using a transition state
  analog as an immunogen. (a) The molecule below is
  a transition analog for the reaction of an amino
  acid with pyridoxal-5-phosphate. (b) The abzyme
  is then used to catalyze the reaction on the next
  screen.

37
Transition-State Analogs
38
Catalytic Antibodies Against Cocaine
p652
39
Catalytic Antibodies Against Cocaine
p652
