Lecture 3: Computer Architectures

1
Lecture 3Computer Architectures
2
Basic Computer Architecture

• Von Neumann Architecture

Memory
instruction
data
Input unit
Output unit
ALU
Processor
CU
Reg.
3
Levels of Parallelism

• Bit level parallelism
• Within arithmetic logic circuits
• Instruction level parallelism
• Multiple instructions execute per clock cycle
• Memory system parallelism
• Overlap of memory operations with computation
• Operating system parallelism
• More than one processor
• Multiple jobs run in parallel on SMP
• Loop level
• Procedure level

4
Levels of Parallelism

• Bit Level Parallelism
• Within arithmetic logic circuits

5
Levels of Parallelism

• Instruction Level Parallelism (ILP)
• Multiple instructions execute per clock cycle
• Pipelining (instruction - data)
• Multiple Issue (VLIW)

6
Levels of Parallelism

• Memory System Parallelism
• Overlap of memory operations with computation

7
Levels of Parallelism

• Operating System Parallelism
• There are more than one processor
• Multiple jobs run in parallel on SMP
• Loop level
• Procedure level

8
Flynns Taxonomy

• Single Instruction stream - Single Data stream
  (SISD)
• Single Instruction stream - Multiple Data stream
  (SIMD)
• Multiple Instruction stream - Single Data stream
  (MISD)
• Multiple Instruction stream - Multiple Data
  stream (MIMD)

9
Single Instruction stream - Single Data stream
(SISD)

• Von Neumann Architecture

Memory
instruction
data
ALU
CU
Processor
10
Flynns Taxonomy

• Single Instruction stream - Single Data stream
  (SISD)
• Single Instruction stream - Multiple Data stream
  (SIMD)
• Multiple Instruction stream - Single Data stream
  (MISD)
• Multiple Instruction stream - Multiple Data
  stream (MIMD)

11
Single Instruction stream - Multiple Data stream
(SIMD)

• Instructions of the program are broadcast to more
  than one processor
• Each processor executes the same instruction
  synchronously, but using different data
• Used for applications that operate upon arrays of
  data

data
PE
data
PE
instruction
CU
Memory
data
PE
data
PE
instruction
12
Flynns Taxonomy

• Single Instruction stream - Single Data stream
  (SISD)
• Single Instruction stream - Multiple Data stream
  (SIMD)
• Multiple Instruction stream - Single Data stream
  (MISD)
• Multiple Instruction stream - Multiple Data
  stream (MIMD)

13
Multiple Instruction stream - Multiple Data
stream (MIMD)

• Each processor has a separate program
• An instruction stream is generated for each
  program on each processor
• Each instruction operates upon different data

14
Multiple Instruction stream - Multiple Data
stream (MIMD)

• Shared memory
• Distributed memory

15
Shared vs Distributed Memory

• Distributed memory
• Each processor has its own local memory
• Message-passing is used to exchange data between
  processors
• Shared memory
• Single address space
• All processes have access to the pool of shared
  memory

16
Distributed Memory

• Processors cannot directly access another
  processors memory
• Each node has a network interface (NI) for
  communication and synchronization

M
M
M
M
P
P
P
P
NI
NI
NI
NI
Network
17
Distributed Memory

• Each processor executes different instructions
  asynchronously, using different data

data
instr
PE
CU
M
data
instr
PE
CU
M
Network
data
instr
PE
CU
M
data
instr
PE
CU
M
18
Shared Memory

• Each processor executes different instructions
  asynchronously, using different data

data
PE
CU
data
PE
CU
Memory
data
PE
CU
data
PE
CU
instruction
19
Shared Memory

• Uniform memory access
• (UMA)
• Each processor has uniform access to memory
  (symmetric multiprocessor - SMP)
• Non-uniform memory access (NUMA)
• Time for memory access depends on the location of
  data
• Local access is faster than non-local access
• Easier to scale than SMPs

P
P
P
P
Bus
Memory
Network
20
Distributed Shared Memory

• Making the main memory of a cluster of computers
  look as if it is a single memory with a single
  address space
• Shared memory programming techniques can be used

21
Multicore Systems

• Many general purpose processors
• GPU (Graphics Processor Unit)
• GPGPU (General Purpose GPU)
• Hybrid

• The trend is
• Board composed of multiple manycore chips sharing
  memory
• Rack composed of multiple boards
• A room full of these racks

22
Distributed Systems

• Clusters
• Individual computers, that are tightly coupled by
  software, in a local environment, to work
  together on single problems or on related
  problems
• Grid
• Many individual systems, that are geographically
  distributed, are tightly coupled by software, to
  work together on single problems or on related
  problems
