Digital Image Processing

• Image Enhancement
• Spatial Filtering

2
Image Enhancement Spatial Filtering

• Image enhancement in the spatial domain can be
  represented as
• g(m,n) T(f)(m,n)
• The transformation T maybe linear or nonlinear.
  We will mainly study linear operators T but
  will see one important nonlinear operation.

Transformation
Enhanced Image
Given Image
3
How to specify T

• If the operator T is linear and shift
  invariant (LSI), characterized by the
  point-spread sequence (PSS) h(m,n) , then
  (recall convolution)

4
How to specify T

• In practice, to reduce computations, h(m,n)
  is of finite extent
• h(k,l) 0 for (k,l) ? ?
• where D is a small set (called neighborhood). D
  is also called as the support of h.
• In the frequency domain, this can be represented
  as
• G(u,v) He(u,v) Fe(u,v)
• where He(u,v) and Fe(u,v) are obtained after
  appropriate zeropadding.

5
How to specify T

• Many LSI operations can be interpreted in
  the frequency domain as a filtering operation.
  It has the effect of filtering frequency
  components (passing certain frequency components
  and stopping others).
• The term filtering is generally associated
  with such operations.

6
How to specify T

• Examples of some common filters (1-D case)

Lowpass filter
Highpass filter
7

• If h(m, n) is a 3 by 3 mask given by
• then

w1 w2 w3
h w4 w5 w6
w7 w8 w9
8

• The output g(m, n) is computed by sliding the
  mask over each pixel of the image f(m, n).
  This filtering procedure is sometimes referred
  to as moving average filter.
• Special care is required for the pixels at
  the border of image f(m, n). This depends on
  the so-called boundary condition. Common
  choices are
• The mask is truncated at the border (free
  boundary)
• The image is extended by appending extra
  rows/columns at the boundaries. The extension
  is done by repeating the first/last
  row/column or by setting them to some
  constant (fixed boundary).
• The boundaries wrap around (periodic boundary).

9

• In any case, the final output g(m, n) is
  restricted to the support of the original image
  f(m, n).
• The mask operation can be implemented in MATLAB
  using the filter2 command, which is based
  on the conv2 command.

10
Smoothing Filters

• Image smoothing refers to any image-to-image
  transformation designed to smooth or
  flatten the image by reducing the rapid
  pixel-to-pixel variation in grayvalues.
• Smoothing filters are used for
• Blurring This is usually a preprocessing step
  for removing small (unwanted) details before
  extracting the relevant (large) object,
  bridging gaps in lines/curves,
• Noise reduction Mitigate the effect of noise
  by linear or nonlinear operations.

11
Image smoothing by averaging (lowpass
spatial filtering)

• Smoothing is accomplished by applying an
  averaging mask.
• An averaging mask is a mask with positive
  weights, which sum to 1. It computes a weighted
  average of the pixel values in a neighborhood.
  This operation is sometimes called
  neighborhood averaging.
• Some 3 x 3 averaging masks
• This operation is equivalent to lowpass
  filtering.

12
Example of Image Blurring
Original Image
Avg. Mask
13
Example of Image Blurring
N 3
N 7
14
Example of Image Blurring
N 11
N 21
15
Example of noise reduction
Noise-free Image
16
Example of noise reduction
Zero-mean Gaussian noise, Variance 0.01
17
Example of noise reduction
Zero-mean Gaussian noise, Variance 0.05
18
Median Filtering

• The averaging filter is best suited for noise
  whose distribution is Gaussian
• The averaging filter typically blurs edges and
  sharp details.
• The median filter usually does a better job of
  preserving edges.
• Median filter is particularly suited if the noise
  pattern exhibits strong (positive and negative)
  spikes. Example salt and pepper noise.

19
Median Filtering

• Median filter is a nonlinear filter, that also
  uses a mask. Each pixel is replaced by the median
  of the pixel values in a neighborhood of the
  given pixel.
• Suppose A a1, a2, , ak are the pixel values
  in a neighborhood of a given pixel with a1 ? a2 ?
  ? ak. Then
• Note Median of a set of values is the center
  value, after sorting.
• For example If A 0,1,2,4,6,6,10,12,15 then
  median(A) 6.

20
Example of noise reduction
Gaussian noise s 0.2 Salt Pepper noise
prob. 0.2
MSE 0.0337
MSE 0.062
21
Example of noise reduction
Output of 3x3 Averaging filter
MSE 0.0075
MSE 0.0125
22
Example of noise reduction
Output of 3x3 Median filter
MSE 0.0042
MSE 0.0089
23
Image Sharpening

• This involves highlighting fine details or
  enhancing details that have been blurred.

Before
After Sharpening
24
Basic highpass spatial filtering

• This can be accomplished by a linear
  shift-invariant operator, implemented by means of
  a mask, with positive and negative coefficients.
• This is called a sharpening mask, since it tends
  to enhance abrupt graylevel changes in the image.
• The mask should have a positive coefficient at
  the center and negative coefficients at the
  periphery. The coefficients should sum to zero.

25
Basic highpass spatial filtering

• Example
• This is equivalent to highpass filtering.
• A highpass filtered image g can be thought of as
  the difference between the original image f and a
  lowpass filtered version of f
• g(m,n) f(m,n) lowpass(f(m,n))

26
Example
Original Image
Highpass filtering
27
High-boost filtering

• This is a filter whose output g is produced by
  subtracting a lowpass (blurred) version of f from
  an amplified version of f
• g(m,n) Af(m,n) lowpass(f(m,n))
• This is also referred to as unsharp masking.

28
High-boost filtering

• Observe that
• g(m,n) Af(m,n) lowpass(f(m,n))
• (A-1)f(m,n) f(m,n) lowpass(f(m,n))
• (A-1)f(m,n) hipass(f(m,n))
• For 1 gt A , part of the original image is added
  back to the highpass filtered version of f.
• The result is the original image with the edges
  enhanced relative to the original image.

29
Example
Original Image
Highpass filtering
High-boost filtering
30
Derivative filter

• Averaging tends to blur details in an image.
  Averaging involves summation or integration.
• Naturally, differentiation or differencing
  would tend to enhance abrupt changes, i.e.,
  sharpen edges.
• Most common differentiation operator is the
  gradient

31
Derivative filter

• The magnitude of the gradient is
• Discrete approximations to the magnitude of the
  gradient is normally used.

32
Derivative filter

• Consider the following image region
• We may use the approximation

z1 z2 z3
z4 z5 z6
z7 z8 z9
33
Derivative filter

• This can implemented using the masks
• As follows

34
Derivative filter

• Alternatively, we may use the approximation
• This can implemented using the masks
• As follows

35
Derivative filter

• The resulting maks are called Roberts
  cross-gradient operators.
• The Roberts operators and the Prewitt/Sobel
  operators (described later) are used for edge
  detection and are sometimes called edge detectors.

36
Example Roberts cross-gradient operator
37
Example Roberts cross-gradient operator
38
Prewitt operators

• Better approximations to the gradient can be
  obtained by
• This can be implemented using the masks
• as follows

39
Sobel operators

• Another approximation is given by the masks
• The resulting masks are called Sobel operators.

40
Example
Prewitt
Sobel
