Title: AMI-Enterprise


1
AMI-Enterprise
  • UML Modeling using Enterprise Architect

Note the presentation material is provided by
Sparx Systems.
2
Review of Concepts UML
  • UML Unified Modeling Language
  • provides system architects, software
    engineers, and software developers with tools for
    analysis, design, and implementation of software
    based systems as well as for modeling business
    and similar processes. UML Specification
  • Graphical language, not a methodology!
  • Has syntax rules
  • Profiles provide extensibility
  • Current version 2.2
  • First UML spec in 1997
  • Object Management Group (OMG)
  • More Info
  • UML, OMG http//www.uml.org, www.omg.org
  • Sparx Tutorials http//www.sparxsystems.com/resou
    rces

3
Review of Concepts Value of UML
  • Manage complexity
  • Plan and mitigate risk
  • Facilitate communication

4
Review of Concepts UML
  • UML supports 13 diagrams to visualize
  • Structure (Package, Class, Component etc.)
  • Behavior (Use Case, Activity, State Machine)
  • Interaction (Sequence, Timing etc.)
  • For Example
  • Class Package Component

5
Enterprise Architect
6
Enterprise Architect UML Support
  • UML 2 modeling platform
  • Supports standard 13 UML 2 diagrams
  • Intuitive interface. Easy to use and get started
  • Customization framework for Domain Specific
    Modeling (UML profiles, patterns, templates)
  • XML Meta-data Interchange (XMI) for
    interoperability and model serialization
  • Supports large models, versioning, collaboration
    and sharing
  • Extensions for SysML, BPMN, Database,
    Architecture Frameworks (Zachman, TOGAF, DoDAF,
    MODAF)
  • Current Version 7.5
  • Available from http//www.sparxsystems.com

7
Enterprise Architect SDLC Support
  • General-purpose modeling platform supports the
    SDLC
  • Visual Requirements Modeling and Management
  • Customizable Reporting Engines for RTF
    (Word-compatible) and HTML
  • Code Engineering Framework (10 programming
    languages out-of-the-box)
  • Deployment and Test specification
  • Integrated modeling platform
  • IDE and PLM Integration Visual Studio, Eclipse
    and TcSE
  • API and extension frameworks for scripting,
    add-ins etc

8
Enterprise Architect Team Modeling
  • Team Modeling platform supports multiple,
    concurrent users
  • Scalable database driven repository
  • Version Control (CVS, Subversion, SCC, TFS
    integration)
  • Model Merge (from Package Baselines)
  • Security and Locking mechanism
  • Detailed, near real-time Auditing capability

9
Enterprise Architecture Frameworks
10
The Zachman Framework
11
(No Transcript)
12
Sharing Model Information
  • A fundamental value proposition behind modeling
    Improves communication!
  • Not everyone consumes models directly yet
  • Models also realize value when used to generate
    useful artifacts.

13
Sharing Models XMI
  • XMI XML Metadata Interchange
  • Primary mechanism for exchanging models
  • Export occurs at the Package, View and Model
    levels
  • Round-trip Enterprise Architect models using XMI
    1.1 most stable version. (UML 2.1 model data
    included)
  • Ensure shared packages are self-contained and
    set round-trip options on export or
  • Apply version control to help manage dependencies
    across distributed, shared packages
  • Forms basis for Enterprise Architect
    compare/merge
  • 3rd party tools consume, post-process XMI eg.
    CIMTool

14
Sharing Models HTML
  • Enterprise Architect HTML generation replicates
    model structure, diagrams and project info for
    online distribution (internet or secured
    intranet)
  • Model navigation via project explorer frame and
    diagram hot-spots
  • Doesnt require Enterprise Architect client,
    browser only
  • Generation process can be automated using API to
    update online doco regularly (HTML model data not
    synched real-time)
  • Numerous orgs publish standards models in HTML
    form
  • ISO/TC 211 http//www.isotc211.org/hmmg/HTML
  • GIEM/Govdex https//www.govdex.gov.au/pub/
  • DMV http//www.dmv.virginia.gov/csi/eahtml/index.
    htm
  • Datex II http//www.datex2.eu/?qnode/23

15
Sharing Models RTF Reports
  • Rich-Text Format (RTF) reports provide
    traditional means of delivering model info in
    document form
  • RTF MS Word compatible
  • Provides conversion path to obtain PDF
    documentation (MS Word ? PDF)
  • Template-driven ? Customizable
  • Apply meta-data filters to selectively
    include/exclude model elements and sub-element
    information

16
Team based modeling the challenges
  • Widely distributed teams
  • Shared development of standards
  • Big models and wide scope
  • Change control, merging work, revisions etc
  • There are tools that help

17
Collaborative modeling tools
  • Version Control
  • Model Baseline Merge
  • Shared (DBMS) Repositories
  • Role-based security
  • Model Auditing

18
Versions in Enterprise Architect models
  • Two Basic Approaches
  • Entire Model Repository Simple, coarse, no
    concurrency
  • Package-based Supports concurrent work
  • Package-Based Versions
  • Packages serialized as XMI (XML Metadata
    Interchange) file
  • 1 Package Version 1 XMI file
  • Applies to Root (Model), View, Parent or Child
    Packages

19
Versions in Enterprise Architect models
  • Enterprise Architect allows version comparisons
  • Compare utility operates on Baseline vs Current
    State
  • Current State The live Package in the model
    repository
  • Baseline (snapshot) XMI-based version of the
    same package
  • Baseline may take one of these physical forms
  • Model Baseline (Snapshot stored in the model)
  • XMI exported file (Snapshot exists on disk)
  • Version controlled Package (Snapshot in VC
    Repository)

20
Version Controlled Packages
  • Basic concepts of version control apply
  • A mechanism for managing concurrent work
  • Maintain a history of changes
  • Changes can be rolled back
  • Revisions stored in XMI format
  • Note Default is XMI 1.1 (includes UML 2.1 info!)

21
Model Merge
  • When its needed
  • Concurrent work on a single package needs
    synchronization
  • Offline work needs to be uploaded
  • Selective roll-back of changes
  • Selective inclusion of changes (Phase based
    development)
  • Occurs at the package level
  • Between versions of a package
  • 1-way merge of Model Baseline to live Package
  • Baseline may exist in another model, file (eg.
    version control)
  • Requires same starting Package
  • Think version, not ad-hoc model merge

22
Shared Repositories
  • How DBMS repositories help
  • Concurrent users edit/view the same model
    instance
  • No need for synchronization
  • DBMS server can support large teams, large models
  • Host a single Master View
  • Requires some DB administration to setup
  • Commonly used for DBMS based repositories
  • MySQL
  • MS SQL Server
  • Oracle

23
Role-Based Security
  • Shared models, concurrent editors
  • Access controls needed!
  • Individual user permissions
  • Group permission (Analysts/BAs, Architects, QA
    etc)
  • Role-based security
  • Require individuals or groups to login to the
    model repository
  • Restricted editing privileges based on role
  • Locking granularity View, Package or Element
    level
  • Different locking/security modes available
    Require user lock to edit, Optional Lock
  • Not to be confused with operating system or DBMS
    security!

24
Model Auditing
  • Do we need to track model changes in real-time?
  • Large enterprises have strict governance rules
  • Changes to specifications can be expenive
  • Need to know Who changed What and When
  • Model Auditing capability provides
  • A fine-grained change log for model elements
  • Change log is continuous vs point-in-time
    snapshot (c/f version control baseline)
  • Filtering and highlighting of model differences
  • Accountability for model changes made over time
  • Exportable as a permanent record of change

25
AMI-ENT Modeling Design Approach
Use Case Diagram, Activity Diagram
Requirements List, Sequence Diagram
Class Diagram
