Cell Division and Mitosis

1
Cell Division and Mitosis
2
Cell Division

• GROWTH of AN ORGANISM
• BUILD and REPAIR OLDER CELLS
• For the total number of cells to increase cells
  must undergo CELL DIVISION!!!
• Cell Divisionwhen a parent cell produces
  identical daughter cells.
• Each second another 25 million cells have just
  finished dividing to create 2 cells.

3
Cell DivisionAn Amazing Process!!!

• Involves the duplication and sorting of
  chromosomes into two identical sets
• Occurs in 6 continuous stages interphase,
  prophase, metaphase, anaphase, telophase, and
  cytokinesis
• IPMATC

4
Life Spans of Different Human Cells







BRAIN CELLS
30-50 YEARS
RED BLOOD CELLS
120 DAYS
STOMACH LINING
10 DAYS
2 DAYS
PLATELETS
LIVER CELLS
200 DAYS
INTESTINAL CELLS
3 DAYS
SKIN CELLS
20 DAYS
5
Cell Cyclesequence of growth and division of a
cell
6
Interphase Gap 1 Stage

• Chromosomes not visible
• Cell growth/protein production
• Cell development

7
What is this DNA stuff?
8
Interphase S Stage (DNA synthesis)

• Chromosomes copied (sister chromatids held
  together by centromere)

9
Interphase Gap 2 Stage

• Chromosomes coil
• Protein synthesis needed for cell division
• Centrioles replicate

10
Mitotic Stage

• Formation of two identical nuclei
• 4 stages
• Prophase
• Metaphase
• Anaphase
• Telophase
• Cytoplasm divides after mitosis (cytokinesis)

11
Regular cell before division

• Nucleus

• Chromatin (coiled DNA) (fancy name for
  chromosome!!!)

• Centriole

How many chromosomes?
6
12
First Stage of Cell Division--Interphase

• No chromosomes visible yet just thread-like
  coils called chromatin
• Centrioles present outside the nucleus
• Chromatin duplicates (copy of DNA is produced)
• Chromatin condensesforms chromatid
• Duplicate is called sister chromatid
• Is attached to centromere creating a chromosome

13
Interphase

• Centromere

• Double-stranded chromosome (made of 2 sister
  chromatids

• Centriole

How many chromatids?
12
14
Photo of cell in interphase
15
Beginning of Mitosis--Prophase

• Centrioles move to opposite poles (ends) of the
  cell
• Mesh-like spindle forms (bridge between ends of
  cells)
• Nuclear membrane dissolves

16
Prophase

• Centriole

• Centromere

• Spindle fibers

• Chromosome (chromatids)

• Aster

How many chromosomes?
6-doubled stranded
17
Photo of cell in prophase
18
Metaphase

• Chromosomes line up at the equator and attach
  to spindle fibers at the centromere

19
Metaphase
How many chromosomes?
6 double-stranded
20
Photo of cell in metaphase
21
Anaphase

• Centromere splits, allows chromosome to separate
  into 2 sister chromatids
• Chromosomes pulled towards centrioles along
  spindle fibers.

22
Anapahse

• Chromosome (chromatids) being pulled away from
  each other towards opposite poles

How many chromosomes?
12, but 6 going opposite direction
23
TelophaseEnd of Mitosis

• Chromosomes coil again, begin to resemble
  chromatin cannot be seen under microscope
• Nuclear membrane forms around chromatin
• Nucleolus reappears

24
Photo of cell in anaphase
25
Telophase
How many chromosomes?
6 in each new nucleus
26
Photo of cell in telophase
27
Cytokinesis2 new cells

• Cytokinesisthe actual division of the cells
• Cell membrane moves inward, pinches the cytoplasm
  into 2 equal parts
• Each part contains a nucleus with IDENTICAL
  CHROMOSOMES

28
Regular cells after division
Regular cells after division
2 new identical cells!!!
29
Phases of mitosisI(PMAT)C
30
Mitosis Can you name the stages?
31
Animal vs. Plant Cell Division

• ANIMAL CELL
• Centriole and aster present
• Daughter cells separated by cleavage furrow

• PLANT CELL
• No visible centriole or aster
• Daughter cells separated by cell plate

32
Duplicated Chromosome
