Experiences Building a Multi-platform Compiler
for Co-array Fortran

• John Mellor-Crummey
• Cristian Coarfa, Yuri Dotsenko
• Department of Computer Science
• Rice University

AHPCRC PGAS Workshop September, 2005
2
Goals for HPC Languages

• Expressiveness
• Ease of programming
• Portable performance
• Ubiquitous availability

3
PGAS Languages

• Global address space programming model
• one-sided communication (GET/PUT)
• Programmer has control over performance-critical
  factors
• data distribution and locality control
• computation partitioning
• communication placement
• Data movement and synchronization as language
  primitives
• amenable to compiler-based communication
  optimization

simpler than msg passing
4
Co-array Fortran Programming Model

• SPMD process images
• fixed number of images during execution
• images operate asynchronously
• Both private and shared data
• real x(20, 20) a private 20x20 array in each
• real y(20, 20) a shared 20x20 array in each
• Simple one-sided shared-memory communication
• x(,jj2) y(,pp2)r copy columns from
  image r into local columns
• Synchronization intrinsic functions
• sync_all a barrier and a memory fence
• sync_mem a memory fence
• sync_team(team members to notify, team members
  to wait for)
• Pointers and (perhaps asymmetric) dynamic
  allocation
• Parallel I/O

5
One-sided Communication with Co-Arrays
image 1
image 2
image N
image 1
image 2
image N
6
CAF Compilers

• Cray compilers for X1 T3E architectures
• Rice Co-Array Fortran Compiler (cafc)

7
Rice cafc Compiler

• Source-to-source compiler
• source-to-source yields multi-platform
  portability
• Implements core language features
• core sufficient for non-trivial codes
• preliminary support for derived types
• soon support for allocatable components
• Open source

Performance comparable to that of hand-tuned MPI
codes
8
Implementation Strategy

• Goals
• portability
• high performance on a wide range of platforms
• Approach
• source-to-source compilation of CAF codes
• use Open64/SL Fortran 90 infrastructure
• CAF ? Fortran 90 communication operations
• communication
• ARMCI and GASNet one-sided comm libraries for
  portability
• load/store communication on shared-memory
  platforms

9
Key Implementation Concerns

• Fast access to local co-array data
• Fast communication
• Overlap of communication and computation

10
Accessing Co-Array Data

• Two Representations
• SAVE and COMMON co-arrays as Fortran 90 pointers
• F90 pointers to memory allocated outside Fortran
  run-time system
• original references accessing local co-array data
• rhs(1,i,j,k,c) u(1,i-1,j,k,c) -
• transformed references
• rhsptr(1,i,j,k,c) uptr(1,i-1,j,k,c) -
• Procedure co-array arguments as F90
  explicit-shape arrays
• CAF language requires explicit shape for co-array
  arguments

real a(10,10,10) type CAFDesc_real_3
real, pointer ptr(,,) ! F90 pointer to local
co-array data end Type CAFDesc_real_3 type(CAFDesc
_real_3) a
11
Performance Challenges

• Problem
• Fortran 90 pointer-based representation does not
  convey
• the lack of co-array aliasing
• contiguity of co-array data
• co-array bounds information
• lack of knowledge inhibits important code
  optimizations
• Approach procedure splitting

12
Procedure Splitting
subroutine f() real, save c(100) interface
subroutine f_inner(, c_arg) real
c_arg end subroutine f_inner end
interface call f_inner(,c(1)) end subroutine
f subroutine f_inner(, c_arg) real
c_arg(100) ... c_arg(50) ... end
subroutine f_inner
CAF to CAF optimization
subroutine f() real, save c(100) ...
c(50) ... end subroutine f

• Benefits
• better alias analysis
• contiguity of co-array data
• co-array bounds information
• better dependence analysis

result back-end compiler can generate better code
13
Implementing Communication

• x(1n) a(1n)p
• General approach use buffer to hold off
  processor data
• allocate buffer
• perform GET to fill buffer
• perform computation x(1n) buffer(1n)

• deallocate buffer
• Optimizations
• no buffer for co-array to co-array copies
• unbuffered load/store on shared-memory systems

14
Strided vs. Contiguous Transfers

• Problem
• CAF remote reference might induce many small data
  transfers
• a(i,1n)p b(j,1n)
• Solution
• pack strided data on source and unpack it on
  destination
• Constraints
• cant express both source-level packing and
  unpacking for a one-sided transfer
• two-sided packing/unpacking is awkward for users
• Preferred approach
• have communication layer perform packing/unpacking

15
Pragmatics of Packing

• Who should implement packing?
• CAF programmer
• difficult to program
• CAF compiler
• must convert PUTs into two-sided communication to
  unpack
• difficult whole-program transformation
• Communication library
• most natural place
• ARMCI currently performs packing on Myrinet (at
  least)

16
Synchronization

• Original CAF specification team synchronization
  only
• sync_all, sync_team
• Limits performance on loosely-coupled
  architectures
• Point-to-point extensions
• sync_notify(q)
• sync_wait(p)

• Point to point
  synchronization semantics
• Delivery of a notify to q from p ?
• all communication from p to q issued before the
  notify has been delivered to q

17
Hiding Communication Latency

• Goal enable communication/computation overlap
• Impediments to generating non-blocking
  communication
• use of indexed subscripts in co-dimensions
• lack of whole program analysis
• Approach support hints for non-blocking
  communication
• overcome conservative compiler analysis
• enable sophisticated programmers to achieve good
  performance today

18
Questions about PGAS Languages

• Performance
• can performance match hand-tuned msg passing
  programs?
• what are the obstacles to top performance?
• what should be done to overcome them?
• language modifications or extensions?
• program implementation strategies?
• compiler technology?
• run-time system enhancements?
• Programmability
• how easy is it to develop high performance
  programs?

19
Investigating these Issues

• Evaluate CAF, UPC, and MPI versions of NAS
  benchmarks
• Performance
• compare CAF and UPC performance to that of MPI
  versions
• use hardware performance counters to pinpoint
  differences
• determine optimization techniques common for both
  languages as well as language specific
  optimizations
• language features
• program implementation strategies
• compiler optimizations
• runtime optimizations
• Programmability
• assess programmability of the CAF and UPC variants

20
Platforms and Benchmarks

• Platforms
• Itanium2Myrinet 2000 (900 MHz Itanium2)
• AlphaQuadrics QSNetI (1 GHz Alpha EV6.8CB)
• SGI Altix 3000 (1.5 GHz Itanium2)
• SGI Origin 2000 (R10000)
• Codes
• NAS Parallel Benchmarks (NPB 2.3) from NASA Ames
• MG, CG, SP, BT
• CAF and UPC versions were derived from
  Fortran77MPI versions

21
MG class A (2563) on Itanium2Myrinet2000
Higher is better
22
MG class C (5123) on SGI Altix 3000
Fortran compiler linearized array subscripts 30
slowdown compared to multidimensional subscripts
64
Higher is better
23
MG class B (2563) on SGI Origin 2000
Higher is better
24
CG class C (150000) on SGI Altix 3000
Higher is better
25
CG class B (75000) on SGI Origin 2000
Higher is better
26
SP class C (1623) on Itanium2Myrinet2000
Higher is better
27
SP class C (1623) on AlphaQuadrics
Higher is better
28
BT class C (1623) on Itanium2Myrinet2000
Higher is better
29
BT class B (1023) on SGI Altix 3000
Higher is better
30
Performance Observations

• Achieving highest performance can be difficult
• need effective optimizing compilers for PGAS
  languages
• Communication layer is not the problem
• CAF with ARMCI or GASNet yields equivalent
  performance
• Scalar code optimization of scientific code is
  the key!
• SPBT SGI Fortran unrolljam, SWP
• MG SGI Fortran loop alignment, fusion
• CG Intel Fortran optimized sum reduction
• Linearized subscripts for multidimensional arrays
  hurt!
• measured 30 performance gap with Intel Fortran

31
Performance Prescriptions

• For portable high performance, we need
• Better language support for CAF synchronization
• point-to-point synchronization is an important
  common case!
• currently only a Rice extension outside the CAF
  standard
• Better CAF UPC compiler support
• communication vectorization
• synchronization strength reduction important for
  programmability
• Compiler optimization of loops with complex
  dependences
• Better run-time library support
• efficient communication support for strided array
  sections

32
Programmability Observations

• Matching MPI performance required using bulk
  communication
• communicating multi-dimensional array sections is
  natural in CAF
• library-based primitives are cumbersome in UPC
• Strided communication is problematic for
  performance
• tedious programming of packing/unpacking at src
  level
• Wavefront computations
• MPI buffered communication easily decouples
  sender/receiver
• PGAS models buffering explicitly managed by
  programmer
