ROC curve estimation

1
ROC curve estimation
2
Index

• Introduction to ROC
• ROC curve
• Area under ROC curve
• Visualization using ROC curve

3
ROC curve

• Originally stands for Receiver Operating
  Characteristic curve.
• It is used widely in biomedical applications like
  radiology and imaging.
• An important utility here is to assess
  classifiers in machine learning.

4
Example situation

• Consider diagnostic test for a disease
• Test has 2 possible outcomes
• Positive or negative.
• Now based on this we will explain the various
  notations used in ROC curves in the next slide.

5
Data distribution available
Pts without the disease
Pts with disease
Test Result
6
Threshold
Test Result
7
Some definitions ...
True Positives
Test Result
without the disease
with the disease
8
False Positives
Test Result
without the disease
with the disease
9
True negatives
Test Result
without the disease
with the disease
10
False negatives
Test Result
without the disease
with the disease
11
Confusion Matrix

• Confusion matrix is defined as a matrix
  consisting of two rows and two columns.
• The orientation of entries in the confusion
  matrix is as follows if say the confusion matrix
  is called CMat.
• Then CMat11True Positives CMat12False
  Positives.
• Similarly CMat21False Negatives and
  CMat22True Negatives.

12
2-class Confusion Matrix
True class Predicted class Predicted class
True class positive negative
positive (P) TP P - TP
negative (N) FP N - FP

• Reduce the 4 numbers to two rates
• true positive rate TP (TP)/(P)
• false positive rate FP (FP)/(N)
• Rates are independent of class ratio

13
Comparing classifiers using Confusion Matrix
True Predicted Predicted
True pos neg
pos 60 40
neg 20 80
True Predicted Predicted
True pos neg
pos 70 30
neg 50 50
True Predicted Predicted
True pos neg
pos 40 60
neg 30 70
Classifier 1 TP 0.4 FP 0.3
Classifier 2 TP 0.7 FP 0.5
Classifier 3 TP 0.6 FP 0.2
14
Interpretations from the Confusion matrix

• The following metrics for a classifier can be
  calculated using the confusion matrix. These can
  be used for evaluating the classifier.
• Accuracy (TPTN)
• Precision TP/(TPFP)
• Recall TP/(TPFN)
• F-Score 2recallprecision/(recall precision)

15
ROC curve
16
ROC curve comparison
A poor test
A good test
17
Area under ROC curve (AUC)

• Overall measure of test performance
• Comparisons between two tests based on
  differences between (estimated) AUC
• For continuous data, AUC equivalent to
  Mann-Whitney U-statistic (nonparametric test of
  difference in location between two populations)
• Determines the accuracy of a classifier in
  machine learning.

18
AUC for ROC curves
AUC 100
AUC 50
AUC 90
AUC 65
19
Further Evaluation methods

• ROC curve based visualization
• The visualization of the ROC curve is a very good
  method of evaluating the classifier.
• Tools like Matlab, Weka and Orange provide
  facilities to support visualization of the ROC
  curve.

20

• ROCR is one such tool which provides effective
  visualization.
