CSCI-4320/6360: Parallel Programming

1
CSCI-4320/6360 Parallel Programming
ComputingTues./Fri. 12-120 p.m.MPI File I/O

• Prof. Chris Carothers
• Computer Science Department
• MRC 309a
• chrisc_at_cs.rpi.edu
• www.cs.rpi.edu/chrisc/COURSES/PARALLEL/SPRING-201
  0
• Adapted from people.cs.uchicago.edu/asiegel/cour
  ses/cspp51085/.../mpi-io.ppt

2
Common Ways of Doing I/O in Parallel Programs

• Sequential I/O
• All processes send data to rank 0, and 0 writes
  it to the file

3
Pros and Cons of Sequential I/O

• Pros
• parallel machine may support I/O from only one
  process (e.g., no common file system)
• Some I/O libraries (e.g. HDF-4, NetCDF, PMPIO)
  not parallel
• resulting single file is handy for ftp, mv
• big blocks improve performance
• short distance from original, serial code
• Cons
• lack of parallelism limits scalability,
  performance (single node bottleneck)

4
Another Way

• Each process writes to a separate file

• Pros
• parallelism, high performance
• Cons
• lots of small files to manage
• LOTS OF METADATA stress parallel filesystem
• difficult to read back data from different number
  of processes

5
What is Parallel I/O?

• Multiple processes of a parallel program
  accessing data (reading or writing) from a common
  file

FILE
P(n-1)
P0
P1
P2
6
Why Parallel I/O?

• Non-parallel I/O is simple but
• Poor performance (single process writes to one
  file) or
• Awkward and not interoperable with other tools
  (each process writes a separate file)
• Parallel I/O
• Provides high performance
• Can provide a single file that can be used with
  other tools (such as visualization programs)

7
Why is MPI a Good Setting for Parallel I/O?

• Writing is like sending a message and reading is
  like receiving.
• Any parallel I/O system will need a mechanism to
• define collective operations (MPI communicators)
• define noncontiguous data layout in memory and
  file (MPI datatypes)
• Test completion of nonblocking operations (MPI
  request objects)
• i.e., lots of MPI-like machinery

8
MPI-IO Background

• Marc Snir et al (IBM Watson) paper exploring MPI
  as context for parallel I/O (1994)
• MPI-IO email discussion group led by J.-P. Prost
  (IBM) and Bill Nitzberg (NASA), 1994
• MPI-IO group joins MPI Forum in June 1996
• MPI-2 standard released in July 1997
• MPI-IO is Chapter 9 of MPI-2

9
Using MPI for Simple I/O
Each process needs to read a chunk of data from a
common file
10
Using Individual File Pointers
includeltstdio.hgt includeltstdlib.hgt include
"mpi.h" define FILESIZE 1000 int main(int argc,
char argv) int rank, nprocs MPI_File
fh MPI_Status status int bufsize, nints
int bufFILESIZE MPI_Init(argc, argv)
MPI_Comm_rank(MPI_COMM_WORLD, rank)
MPI_Comm_size(MPI_COMM_WORLD, nprocs)
bufsize FILESIZE/nprocs nints
bufsize/sizeof(int) MPI_File_open(MPI_COMM_W
ORLD, "datafile", MPI_MODE_RDONLY,
MPI_INFO_NULL, fh) MPI_File_seek(fh, rank
bufsize, MPI_SEEK_SET) MPI_File_read(fh, buf,
nints, MPI_INT, status) MPI_File_close(fh)
11
Using Explicit Offsets
includeltstdio.hgt includeltstdlib.hgt include
"mpi.h" define FILESIZE 1000 int main(int argc,
char argv) int rank, nprocs MPI_File
fh MPI_Status status int bufsize, nints
int bufFILESIZE MPI_Init(argc, argv)
MPI_Comm_rank(MPI_COMM_WORLD, rank)
MPI_Comm_size(MPI_COMM_WORLD, nprocs)
bufsize FILESIZE/nprocs nints
bufsize/sizeof(int) MPI_File_open(MPI_COMM_W
ORLD, "datafile", MPI_MODE_RDONLY, MPI_INFO_NULL,
fh) MPI_File_read_at(fh, rankbufsize, buf,
nints, MPI_INT, status) MPI_File_close(fh)
12
Function Details
MPI_File_open(MPI_Comm comm, char file, int
mode, MPI_Info info, MPI_File fh) (note mode
MPI_MODE_RDONLY, MPI_MODE_RDWR,
MPI_MODE_WRONLY,
MPI_MODE_CREATE, MPI_MODE_EXCL,
MPI_MODE_DELETE_ON_CLOSE, MPI_MODE_UNIQUE_OPEN,
MPI_MODE_SEQUENTIAL,
MPI_MODE_APPEND) MPI_File_close(MPI_File
fh) MPI_File_read(MPI_File fh, void buf, int
count, MPI_Datatype type, MPI_Status
status) MPI_File_read_at(MPI_File fh, int
offset, void buf, int count,
MPI_Datatype type, MPI_Status
status) MPI_File_seek(MPI_File fh, MPI_Offset
offset, in whence) (note whence
MPI_SEEK_SET, MPI_SEEK_CUR, or MPI_SEEK_END) MPI_
File_write(MPI_File fh, void buf, int count,
MPI_Datatype datatype, MPI_Status
status) MPI_File_write_at( same as read_at
) (Note Many other functions to get/set
properties (see Gropp et al))
13
Writing to a File

• Use MPI_File_write or MPI_File_write_at
• Use MPI_MODE_WRONLY or MPI_MODE_RDWR as the flags
  to MPI_File_open
• If the file doesnt exist previously, the flag
  MPI_MODE_CREATE must also be passed to
  MPI_File_open
• We can pass multiple flags by using bitwise-or
  in C, or addition in Fortran

14
MPI Datatype Interlude

• Datatypes in MPI
• Elementary MPI_INT, MPI_DOUBLE, etc
• everything weve used to this point
• Contiguous
• Next easiest sequences of elementary types
• Vector
• Sequences separated by a constant stride

15
MPI Datatypes, cont

• Indexed more general
• does not assume a constant stride
• Struct
• General mixed types (like C structs)

16
Creating simple datatypes

• Lets just look at the simplest types contiguous
  and vector datatypes.
• Contiguous example
• Lets create a new datatype which is two ints
  side by side. The calling sequence is
• MPI_Type_contiguous(int count, MPI_Datatype
  oldtype, MPI_Datatype newtype)
• MPI_Datatype newtype
• MPI_Type_contiguous(2, MPI_INT, newtype)
• MPI_Type_commit(newtype) / required /

17
Using File Views

• Processes write to shared file

• MPI_File_set_view assigns regions of the file to
  separate processes

18
File Views

• Specified by a triplet (displacement, etype, and
  filetype) passed to MPI_File_set_view
• displacement number of bytes to be skipped from
  the start of the file
• etype basic unit of data access (can be any
  basic or derived datatype)
• filetype specifies which portion of the file is
  visible to the process
• This is a collective operation and so all
  processors/ranks must use the same data rep,
  etypes in the group determined when the file was
  open..

19
File Interoperability

• Users can optionally create files with a portable
  binary data representation
• datarep parameter to MPI_File_set_view
• native - default, same as in memory, not portable
• internal - impl. defined representation providing
  an impl. defined level of portability
• external32 - a specific representation defined in
  MPI, (basically 32-bit big-endian IEEE format),
  portable across machines and MPI implementations

20
File View Example
MPI_File thefile for (i0 iltBUFSIZE i)
bufi myrank BUFSIZE i MPI_File_open(MPI_
COMM_WORLD, "testfile", MPI_MODE_CREATE
MPI_MODE_WRONLY, MPI_INFO_NULL,
thefile) MPI_File_set_view(thefile, myrank
BUFSIZE, MPI_INT, MPI_INT, "native",
MPI_INFO_NULL) MPI_File_write(thefi
le, buf, BUFSIZE, MPI_INT,
MPI_STATUS_IGNORE) MPI_File_close(thefile)
21
Ways to Write to a Shared File

• MPI_File_seek
• MPI_File_read_at
• MPI_File_write_at
• MPI_File_read_shared
• MPI_File_write_shared
• Collective operations

like Unix seek
combine seek and I/O for thread safety
use shared file pointer good when order doesnt
matter
22
Collective I/O in MPI

• A critical optimization in parallel I/O
• Allows communication of big picture to file
  system
• Framework for 2-phase I/O, in which communication
  precedes I/O (can use MPI machinery)
• Basic idea build large blocks, so that
  reads/writes in I/O system will be large

Small individual requests
Large collective access
23
Collective I/O

• MPI_File_read_all, MPI_File_read_at_all, etc
• _all indicates that all processes in the group
  specified by the communicator passed to
  MPI_File_open will call this function
• Each process specifies only its own access
  information -- the argument list is the same as
  for the non-collective functions

24
Collective I/O

• By calling the collective I/O functions, the user
  allows an implementation to optimize the request
  based on the combined request of all processes
• The implementation can merge the requests of
  different processes and service the merged
  request efficiently
• Particularly effective when the accesses of
  different processes are noncontiguous and
  interleaved

25
Collective non-contiguousMPI-IO examples
define mpi.h define FILESIZE 1048576 define
INTS_PER_BLK 16 int main(int argc, char
argv) int buf, rank, nprocs, nints,
bufsize MPI_File fh MPI_Datatype
filetype MPI_Init(argc, argv)
MPI_Comm_rank(MPI_COMM_WORLD, rank)
MPI_Comm_size(MPI_COMM_WORLD, nprocs)
bufsize FILESIZE/nprocs buf (int )
malloc(bufsize) nints bufsize/sizeof(int)
MPI_File_open(MPI_COMM_WORLD, filename,
MPI_MODE_RD_ONLY, MPI_INFO_NULL, fh)
MPI_Type_vector(nints/INTS_PER_BLK, INTS_PER_BLK,
INTS_PER_BLKnprocs, MPI_INT, filetype)
MPI_Type_commit(filetype) MPI_File_set_view(fh
, INTS_PER_BLKsizeof(int)rank, MPI_INT,
filetype, native, MPI_INFO_NULL)
MPI_File_read_all(fh, buf, nints, MPI_INT,
MPI_STATUS_IGNORE) MPI_Type_free(filetype)
free(buf) MPI_Finalize() return(0)
26
More on MPI_Read_all

• Note that the _all version has the same argument
  list
• Difference is that all processes involved in
  MPI_Open must call this the read
• Contrast with the non-all version where any
  subset may or may not call it
• Allows for many optimizations

27
Split Collective I/O

• A restricted form of nonblocking collective I/O
• Only one active nonblocking collective operation
  allowed at a time on a file handle
• Therefore, no request object necessary

MPI_File_write_all_begin(fh, buf, count,
datatype) // available on Blue Gene/L, but may
not improve // performance for (i0 ilt1000
i) / perform computation
/ MPI_File_write_all_end(fh, buf, status)
28
Passing Hints to the Implementation
MPI_Info info MPI_Info_create(info) / no.
of I/O devices to be used for file striping
/ MPI_Info_set(info, "striping_factor",
"4") / the striping unit in bytes
/ MPI_Info_set(info, "striping_unit",
"65536") MPI_File_open(MPI_COMM_WORLD,
"/pfs/datafile", MPI_MODE_CREATE
MPI_MODE_RDWR, info, fh) MPI_Info_free(info)
29
Examples of Hints (used in ROMIO)

• striping_unit
• striping_factor
• cb_buffer_size
• cb_nodes
• ind_rd_buffer_size
• ind_wr_buffer_size
• start_iodevice
• pfs_svr_buf
• direct_read
• direct_write

MPI-2 predefined hints
New Algorithm Parameters
Platform-specific hints
30
I/O Consistency Semantics

• The consistency semantics specify the results
  when multiple processes access a common file and
  one or more processes write to the file
• MPI guarantees stronger consistency semantics if
  the communicator used to open the file accurately
  specifies all the processes that are accessing
  the file, and weaker semantics if not
• The user can take steps to ensure consistency
  when MPI does not automatically do so

31
Example 1

• File opened with MPI_COMM_WORLD. Each process
  writes to a separate region of the file and reads
  back only what it wrote.

• MPI guarantees that the data will be read
  correctly

32
Example 2

• Same as example 1, except that each process wants
  to read what the other process wrote (overlapping
  accesses)
• In this case, MPI does not guarantee that the
  data will automatically be read correctly

Process 0
Process 1
/ incorrect program / MPI_File_open(MPI_COMM_WOR
LD,) MPI_File_write_at(off0,cnt100) MPI_Barrier
MPI_File_read_at(off100,cnt100)
/ incorrect program / MPI_File_open(MPI_COMM_WOR
LD,) MPI_File_write_at(off100,cnt100) MPI_Barri
er MPI_File_read_at(off0,cnt100)

• In the above program, the read on each process is
  not guaranteed to get the data written by the
  other process!

33
Example 2 contd.

• The user must take extra steps to ensure
  correctness
• There are three choices
• set atomicity to true
• close the file and reopen it
• ensure that no write sequence on any process is
  concurrent with any sequence (read or write) on
  another process/MPI rank
• Can hurt performance.

34
Example 2, Option 1Set atomicity to true
35
Example 2, Option 2Close and reopen file
Process 0
Process 1
MPI_File_open(MPI_COMM_WORLD,) MPI_File_write_at(
off0,cnt100) MPI_File_close MPI_Barrier MPI_File
_open(MPI_COMM_WORLD,) MPI_File_read_at(off100,c
nt100)
MPI_File_open(MPI_COMM_WORLD,) MPI_File_write_at(
off100,cnt100) MPI_File_close MPI_Barrier MPI_Fi
le_open(MPI_COMM_WORLD,) MPI_File_read_at(off0,c
nt100)
36
Example 2, Option 3

• Ensure that no write sequence on any process is
  concurrent with any sequence (read or write) on
  another process
• a sequence is a set of operations between any
  pair of open, close, or file_sync functions
• a write sequence is a sequence in which any of
  the functions is a write operation

37
Example 2, Option 3
38
General Guidelines for Achieving High I/O
Performance

• Buy sufficient I/O hardware for the machine
• Use fast file systems, not NFS-mounted home
  directories
• Do not perform I/O from one process only
• Make large requests wherever possible
• For noncontiguous requests, use derived datatypes
  and a single collective I/O call

39
Optimizations

• Given complete access information, an
  implementation can perform optimizations such as
• Data Sieving Read large chunks and extract what
  is really needed
• Collective I/O Merge requests of different
  processes into larger requests
• Improved prefetching and caching

40
Summary

• MPI-IO has many features that can help users
  achieve high performance
• The most important of these features are the
  ability to specify noncontiguous accesses, the
  collective I/O functions, and the ability to pass
  hints to the implementation
• Users must use the above features!
• In particular, when accesses are noncontiguous,
  users must create derived datatypes, define file
  views, and use the collective I/O functions
