CS148 Introduction to Computer Graphics and
Imaging Scanline Rendering
Electric Sheep screensaver by Scott Draves Image
created collectively by users on the internet
2
Human Eye
Light comes from light sources, is absorbed and
reflected off of objects, and goes through the
pupil of the eye.
3
Without the pupil light scatters everywhere and
does not make a coherent image
4
With a pinhole model of the pupil light makes a
coherent image inside the eye
5
Human Retina Rods and cones

• Retina contains rods and cones
• Rods are responsible for light intensity
• Cones are responsible for color vision

6
Three Types of Cones
From http//webvision.med.utah.edu/imageswv/fovmos
7
Rods Capture Intensities
8
Color Matching Experiment

• Adjust brightness of three primaries
• Lasers R 700 nm, G 546 nm, B 435 nm
• until a human mistakenly thinks it matches
  another color C x nm
• Result all colors can be matched with three
  colors
• Therefore humans have trichromatic color vision

C R G B
9
Trichromatic Theory

• Since the human eye works in this fashion, we
  work this way with images, printers, and
  displays.
• Image formats store values in the R, G, and B
  channels.
• The values are between 0 and 255.
• The relative values give the color, and the
  overall values give the intensity.
• This is similar to the cones of the human eye.
• The monitor can be used to increase or decrease
  the image intensities (brightness/darkness).
• This is similar to the rods of the human eye.

10
Cameras

• A camera works similarly to the eye.
• Light passes through the lens, bends to come to a
  point of focus, and makes an upside-down image on
  the film.

11
Pinhole Camera

• Linear perspective with viewpoint at pinhole

12
Laws of Pinhole Cameras

• Common assumptions
• Light leaving an object travels in straight lines
• These lines converge to a point (e.g. pinhole)
• Infinite depth of field which means everything is
  in focus
• Perspective image is formed by the intersection
  of these lines with an image plane
• More distant objects subtend smaller visual
  angles and appear smaller
• Objects in front occlude the objects behind them

13
OpenGL Camera

• OpenGL uses a pinhole camera.
• In OpenGL the image plane is in front of the
  focal point which means the image is right side
  up.
• The frustum is the volume of our view (shown in
  blue below).
• The image plane is the plane of the frustum
  nearest to the camera.

14
Specifying the Camera in OpenGL
void gluLookAt(eye.x, eye.y, eye.z, at.x, at.y,
at.z, up.x, up.y, up.z)
- gluLookAt creates a camera from an eye point, a
reference point indicating the center of the
scene, and an up vector.
15
Specifying the Frustum in OpenGL
void gluPerspective(fovy, aspect, near, far)

• gluPerspective specifies a viewing frustum for
  the camera into the world coordinate system.
• fovy specifies the field of view angle.
• aspect specifies the aspect ratio of the
  associated image plane.
• near/far specify the distance from the camera to
  the new/far clipping plane.

16
Drawing a Triangle in front of your Camera
glColor3f(1.f,0.f,0.f) glBegin(GL_TRIANGLES) glV
ertex3f(0.f,0.f,0.f) glVertex3f(1.f,0.f,0.f) glV
ertex3f(.5f,.86f,0.f) glEnd()

• void glBegin(Glenum mode)
• glBegin delimits the vertices of a primitive.
• mode specifies the primitive that will be created
  from vertices presented between glBegin and
  glEnd.

• void glVertex(x,y,z)
• glVertex specifies a vertex to form the
  primitive.

17
Fundamental Primitive Triangles

• Why triangles?
• Lowest common denominator
• Easily break convex polygons into triangles
• Optimize the implementation of one primitive
• Triangles have unique properties
• Guaranteed to be planar
• Guaranteed to have a well-defined
• interior
• Well-defined method (barycentric interpolation)
  for interpolating values in the interior

18
Triangle Meshes
Stanford Bunny 69,451 triangles
David, Digital Michelangelo Project 28,184,526
vertices, 56,230,343 triangles
19
OpenGL Drawing Primitives

• Geometric Shapes

Bitmaps
Images
20
Graphics Rendering Pipeline
Commands Processor
triangles, lines, points images
Vertices
Transformed vertices
Primitives
Fragments
Shaded fragments
pixels in the framebuffer
Display
21
Command Processor

• Command queue
• Command interpretation
• Unpack and perform format conversion
• Maintain graphics state

glBegin(GL_TRIANGLE_STRIP) glColor3f(.0f, 1.f,
.0f) glVertex3f( .0f, .0f, .0f ) glVertex3f(
0.f, 1.f, .0f ) glColor3f(1.f, .0f,
.0f) glVertex3f( 1.f, .0f, .0f ) glVertex3f(
1.f, 1.f, .0f ) glEnd()

22
Per-vertex Operations

• Vertex transformation
• Normal transformation
• Texture coordinate generation
• Texture coordinate transformation
• Lighting (light sources and surface reflection)
• Projection

World-space triangles
Screen-space shaded triangles
23
Primitive Assembly

• Combine transformed/shaded vertices into
  primitives
• 1 vert -gt point
• 2 verts -gt line
• 3 verts -gt triangle
• Clipping
• Transform to window coordinates (viewport)
• Determine orientation (CW/CCW)
• Back-face cull

24
Rasterization

• Setup (per-triangle)
• Sampling (triangle fragments)
• Interpolation (interpolate colors and coordinates)

Triangles
Fragments
25
Texturing

• Textures are arrays indexed by floats (Sampler)
• Texture address calculation
• Texture bilinear interpolation and filtering

Texture Fragments
Fragments
26
Per-fragment Operations

• Combine texture sampler outputs
• Per-fragment shading

Fragments
Textured Fragments
27
Frame buffer Operations

• Operation
• Test window ownership
• Test scissor and stencil mask
• Test alpha
• Test depth
• Blending or compositing

Textured Fragments
Framebuffer Pixels
28
Testing Depth using Z-Buffer

• Initialize z-buffer to zmax
• Interpolate z across the triangle
• Draw fragment if closer
• if(frag.ZltZfrag.Xfrag.Y)
• Zfrag.Xfrag.Yfrag.Z
• Cfrag.Xfrag.Yfrag.C

http//en.wikipedia.org/wiki/FileZ_buffer.svg
29
Frame Buffering

• Frame Buffer
• Store image in a buffer to separate refresh rate
  from drawing rate
• Single-buffer
• Draw into display buffer directly
• May see picture being drawn
• Double-buffer
• Display front buffer
• Draw into back buffer (cant see drawing)
• Swap front and back (wait until vertical sync)
• Triple buffer
• Avoid waiting for vertical sync

30
Framebuffer
Example Framebuffer 1440 x 900
All coordinates are integers they refer to
pixel locations in the framebuffer
31
Window
Example Framebuffer 1440 x 900
The window is the portion of the display usable
by the application (under control of the window
system)
Window (512 x 512)
All coordinates are integers they refer to
pixel locations in the framebuffer
32
Viewport
Example Framebuffer 1440 x 900
The viewport is the portion of the window that
can be drawn in, no pixels will appear outside
the viewport
Viewport (256x256)
Window (512 x 512)
All coordinates are integers they refer to
pixel locations in the framebuffer
33
Specifying the Viewport in OpenGL
void glViewport(x, y, w, h)

• glViewport specifies the location and the size of
  the viewport in the screen coordinate system.
  Here x, y, w, and h are all integers.
• x and y specify the lower left corner of the
  viewport rectangle.
• w and h specify the width and height of the
  viewport. w/h should agree with the aspect ratio
  you set in gluPerspective.

34
Windows Virtual Framebuffers

• Like virtual memory enables us to share the
  physical memory,
• virtual framebuffers allows us to share the
  physical framebuffer
• Abstract properties
• Location and size on the screen
• Stacking order

35
Window Coordinate Systems
top 1.0
Window (512 x 512)
right 1.0
left -1.0
bottom -1.0
Each window has a user coordinate system A 2D
coordinate system is specified by assigning
coordinates to the edges of the window left need
not be less than right ...
36
Exposure

• Parts of the window that are not visible can
  become visible
• When opening
• When unhiding
• When brought to front
• How do you update the visible parts of the
  window?
• Redraw entire window (or a part of it)
• Save the drawn window in a backing store, and
  copy onto screen when needed

37
Display

• Gamma correction
• Analog to digital conversion
• Display

Light
Framebuffer Pixels
38
CPU
glBegin(GL_TRIANGLES) glVertex3fv(v1)
glVertex3fv(v2) glVertex3fv(v3) glEnd()
-90
GPU
OpenGL
-90
39
Graphics processing unit
A graphics processing unit (GPU), also
occasionally called visual processing unit (VPU),
is a specialized electronic circuit designed to
rapidly manipulate and alter memory to accelerate
the building of images in a frame buffer intended
for output to a display.
NVIDIAs GeForce GTX 690
VisionTek Radeon 7970
40
Whats in a GPU?
Primitive Assembly
Tex
Tex
Tex
Work Distributor
Tex
41
Modern PC
System board (Intel D975)
12.8 GB/sec
PCIe Bus (v1 4 GB/sec)
84 GB/sec
NVIDIA 8800GTX
42
Game Machines Xbox 360
controllers/ethernet/ audio/DVD/etc.
Display (TV)
43
Game Machines PS3
controllers/ethernet/ audio/DVD/etc.
Display (TV)
44
Hybrid CPU-GPUs
Intel Sandybridge
Apple A5
45
NVIDIA GPU Performance
Year Product Triangle/s Fragment/s
1998 Riva ZX 3m 100m
1999 Riva TNT2 9m 350m
2000 GeForce2 GTS 25m 664m
2001 GeForce3 30m 800m
2002 GeForce Ti 4600 60m 1200m
2003 GeForce FX 167m 2000m
2004 GeForce 6800 Ultra 170m 6800m
2005 GeForce 7800 GTX 940m 10300m
2006 GeForce 7900 GTX 1400m 15600m
2007 GeForce 8800 GTX 1800m 36800m
2008 GeForce GTX 280 48160m
2010 GeForce GTX 480 42000m
2011 GeForce GTX 580 49400m
