Reconfigurable Low Profile Antenna

1
Reconfigurable Low Profile Antenna

• James Soon
• Advisor Dr. Prasad Shastry

2
Topics

• Introduction
• Inputs/Outputs
• Modes of Operation
• Methods
• Diagrams
• Equipment List
• Schedule

3

• Why reconfigurable antennas?
• Cost
• Reliability
• Cost
• One is cheaper than two
• Reliability
• Two are better than one

4

• Diversity
• Time
• Space
• Frequency
• Polarization

5

• Project objectives
• Design
• Simulation
• Manufacture
• Analysis

6

• Single port frequency diverse device

7

• Dual port polarization diverse device

8
Modes of Operation

• Transmit mode
• Applied rf signal converted to radiated signal
• Receive mode
• Radiated signal converted to received rf signal

9

• Microstrip construction

10

• Microstrip antennas

11

• Coplanar waveguide construction

12

• Radiation characteristics

13
Research

• Several antenna research articles
• SUNG, Y.J., JANG, T.U., KIM, Y.S., A
  Reconfigurable Antenna for Switchable
  Polarization, IEEE Microwave and Wireless
  Letters, Volume 14, Number 11,
  November 2004, pp. 534 - 536.

14

• Antenna with switchable polarization

15
(No Transcript)
16
Undetermined Design Characteristics

• Antenna construction
• Coplanar
• Microstrip
• Antenna feed structure
• Microstrip line
• Probe
• Diode biasing
• Independent
• Single point

17
Data sheet

• Gain gt 5dBi
• Frequency Range 1.5 1.6 GHz range
• Return Loss lt -15 dB
• Radiation pattern
• Polarization Linear, RHCP, LHCP
• Bandwidth approx. 2
• VSWR 2.01

18
Methods

• CAD tools - SONNET, PCAAD, ADS, Momentum
• Microwave Integrated Circuit Fab Lab
• Network Analyzer, Aneochoic Chamber
• Labview, VEE Pro

19
Equipment List

• PIN diodes
• Varactor diodes
• Fabrication lab
• Anechoic chamber

20
Schedule

• RF Labs Jan 1
• Get Married Jan 8
• Honeymoon Jan 22 - 30
• Preliminary Design Feb 26
• Fabrication Mar 19
• Analysis Apr 9
• Presentation Final Report May 3

21

• Questions?
