Title: Assessment of Diagnostics for the Presence of Seasonality


1
Assessment of Diagnosticsfor the Presence of
Seasonality
  • Catherine C. H. Hood
  • Catherine Hood Consulting
  • Auburntown, TN

2
Acknowledgements
  • Roxanne Feldpausch
  • X-12-Data, programming assistance
  • Kathy McDonald-Johnson
  • X-12-Rvw, programming and proof-reading
    assistance
  • Brian Monsell
  • Modifications to X-12-ARIMA
  • David Findley

3
Motivation
  • Wanted to check for seasonality in quarterly
    series, some with only 8 years of data
  • For series that are not too short, the spectral
    graph is the most sensitive test for residual
    seasonality
  • However, 60 points recommended (15 years for a
    quarterly series)
  • Other diagnostics for residual seasonality can
    also be difficult for short series, and also can
    be model-dependent

4
New Options in X-12-ARIMA
  • Ability to change the spectrum used to test for
    the presence of seasonality
  • spectrumseries a1 (or a19, b1)
  • Ability to change the estimator for the spectrum
  • maxspecar10 (default is 30)

5
Spectral Analysis
  • Allows us to see the relationships between the
    frequencies
  • In a quarterly time series with a significant
    seasonal component, the amplitudes that dominate
    are at the two seasonal frequencies
  • An annual effect at ¼ cycles per quarter and
  • A biannual effect at ½ cycles per quarter

6
  • G.0 10LOG(SPECTRUM) of the differenced,
    transformed Original Series
  • (Table A1). Spectrum estimated from 1991.1
    to 2005.2.
  • I
    I
  • -7.37I
    I -7.37
  • I
    SI
  • I
    SI
  • I
    SI
  • -10.39I
    SI -10.39
  • I
    SI
  • I
    SI
  • I
    SI
  • -13.41I
    SI -13.41
  • I
    SI
  • I
    SI
  • I
    SI
  • -16.44I
    SI -16.44
  • I
    SI
  • I S
    SI
  • I S
    SI

7
Evaluating the Estimator
  • For the estimate of the spectrum, X-12-ARIMA uses
    an AR(30) model fit to each output series and
    evaluated at 61 frequencies
  • In Version 0.3, the order of the AR model for the
    spectral estimate can be changed from the default

8
Reading the Peaks
  • For X-12-ARIMA to flag a seasonal peak
  • The frequency must be six stars or asterisks
    higher than either neighboring frequency
  • The higher the peak is above its neighbors, the
    more important the peak
  • A seasonal peak also must be higher than the
    median of the frequencies

9
  • G.0 10LOG(SPECTRUM) of the differenced,
    transformed Original Series
  • (Table A1). Spectrum estimated from 1991.1
    to 2005.2.
  • I
    I
  • -7.37I
    I -7.37
  • I
    SI
  • I
    SI
  • I
    SI
  • -10.39I
    SI -10.39
  • I
    SI
  • I
    SI
  • I
    SI
  • -13.41I
    SI -13.41
  • I
    SI
  • I
    SI
  • I
    SI
  • -16.44I
    SI -16.44
  • I
    SI
  • I S
    SI
  • I S
    SI

10
Example First Peak
  • I
  • I
  • -16.44I
  • I
  • I S
  • I S
  • -19.46I S
  • I S
  • I S
  • I S
  • -22.48I S
  • I S
  • I S
  • I S

11
Peak Strength
  • X-12-ARIMAs diagnostics file tells us exactly
    how many stars are in a given peak
  • Original Series
  • S1 4.4 S2 6.1

12
Other Diagnostics
  • M7 and D8 F-test
  • Chi-square test for seasonal dummies
  • regression variables( seasonal )

13
D8 F-test of X-12-ARIMA
  • After Table D8 is an F-test for stable
    seasonality
  • Sometimes referenced as FS
  • Has come to be known as the D8 F
  • For time series, a cut-off value of 7.0 is
    recommended by Lothian and Morry (1978)

14
M7
  • A function of F-values derived from two different
    ANOVA tables to assess the amount of moving
    seasonality present in a series relative to the
    amount of stable seasonality
  • Interpretation a value greater than 1.0
    indicates no identifiable seasonality

15
Tests for Seasonal Regressors
  • In SEATS, Agustín Maravall has used a
    significance test on the individual months or
    quarters to determine if there is significant
    seasonality in the original series
  • X-12-ARIMA has a chi-square test to test for the
    significance of the set of seasonal regressors

16
Potential Problems
  • Changes in the model can affect the stability of
    the diagnostics, especially M7, D8 F, and the
    Chi-square test for the seasonal regressors
  • Some users run the seasonally adjusted series
    back through X-12-ARIMA to look at the values for
    M7 and the D8 F, however, M7 was not designed for
    this purpose

17
Series for Study
  • 314 National Accounts and Retail quarterly
    seasonal series with 10 years of data
  • 432 simulated quarterly series with 15 years of
    data
  • 72 simulated monthly series
  • Simulated series computed from seasonal factors,
    trends, and irregular from different series (see
    Hood, Ashley, Findley 2000)

18
Series Used for the Spectrum
  • Assuming that the AR order is held constant, the
    results were almost identical for
  • The outlier-adjusted original series
  • The prior-adjusted original series
  • This held true for the simulated series also
  • So well focus on the outlier-adjusted original
    series

19
Spectral Estimators Seasonal Quarterly Series
  • With the AR(30) estimator (because there are less
    than 60 points) the peaks were often very short
    and flat and difficult to distinguish
  • With the AR(10) estimator, the seasonal peaks are
    much easier to distinguish

20
Real Series Results for the S1 Peak
  • Model AR of Series with Peak
  • (2 1 0) 10 71 (25)
  • (2 1 0) 30 9 ( 3)

21
Real Series Results for the S1 Peak (2)
  • Model AR Average of Stars
  • (2 1 0) 10 5.3
  • (2 1 0) 30 2.6

22
Spectral Diagnostic Results from the Models Used
  • Spectral diagnostic results suffer when using the
    model (0 0 0) with seasonal dummies (generally
    inappropriate for these series) due to the
    outlier sets chosen automatically by the program

23
Real Series Results for the S1 or S2 Peak
  • Model AR of Series with Peak
  • (2 1 0) 10 98 (31)
  • (2 1 0) 30 29 ( 9)
  • (0 0 0) 10 69 (22)
  • (0 0 0) 30 28 ( 9)

24
Results from the Models Used
  • Most models gave very similar results
  • The diagnostics were inadequate using the model
    (0 0 0) with seasonal dummies, which we expect
    would be inappropriate for these seasonal series

25
Real Series Results for D8 F-test
  • Model seasonal (D8F gt 7)
  • (2 1 0) 273 (87)
  • (2 1 2) 269 (86)
  • (0 1 2) 271 (86)
  • (0 1 0) 271 (86)
  • (0 0 0) 114 (36)

26
Real Series Results for the M7
  • Model seasonal (M7 lt 1)
  • (2 1 0) 286 (91)
  • (2 1 2) 277 (88)
  • (0 1 2) 281 (89)
  • (0 1 0) 278 (89)
  • (0 0 0) 104 (33)

27
Real Series Results for the Chi-sq test
  • Model seasonal (p lt 0.05)
  • (2 1 0) 301 (96)
  • (2 1 2) 293 (93)
  • (0 1 2) 301 (96)
  • (0 1 0) 283 (90)
  • (0 0 0) 78 (25)

28
Simulated Series
  • Simulated quarterly series
  • With strong seasonality
  • With no seasonality
  • With very little seasonality, the kind wed like
    to detect when looking for residual seasonality

29
Series with Strong Seasonality Series Found to
be Seasonal
  • Diag (2 1 0) (0 0 0)
  • D8 F 144 (100) 49 (34)
  • Chi-sq 144 (100) 0 ( 0)
  • AR10 Sp 144 (100) 144 (65)

30
Series with Strong Seasonality Results for S1
or S2 Peak
  • Model AR of Series with Peak
  • (2 1 0) 10 144 (100)
  • (2 1 0) 30 134 ( 93)
  • (0 0 0) 10 144 (100)
  • (0 0 0) 30 122 ( 85)

31
Nonseasonal Series Series Found to be Seasonal
  • Diag (2 1 0) (0 0 0)
  • D8 F 56 (39) 0 ( 0)
  • Chi-sq 90 (62) 0 ( 0)
  • AR10 Sp 57 (40) 51 (35)

32
Nonseasonal Series Results for S1 or S2 Peak
  • Model AR of Series with Peak
  • (2 1 0) 10 57 (40)
  • (2 1 0) 30 65 (45)
  • (0 0 0) 10 51 (35)
  • (0 0 0) 30 72 (50)

33
Series with Weak Seasonality Series Found to
be Seasonal
  • Diag (2 1 0) (0 0 0)
  • D8 F 111 (77) 0 ( 0)
  • Chi-sq 124 (86) 0 ( 0)
  • AR10 Sp 86 (60) 86 (60)

34
Monthly Series
  • Very limited study
  • With an AR(10) estimator for the spectrum
  • Trading day peaks not found
  • A few more false positives (peaks for nonseasonal
    series) found

35
Conclusions
  • An AR(10) estimator for the spectrum gives
  • Fewer false positives (peaks for nonseasonal
    series) than the default AR(30) estimator
  • More true positives (peaks for seasonal series)
    than the default AR(30) estimator

36
Conclusions (2)
  • The diagnostics are fairly stable between various
    seasonal models
  • However, there can be a lot of disagreement in
    the diagnostics when comparing runs with seasonal
    versus nonseasonal models
  • The practice of using M7/D8F to look for residual
    seasonality in seasonally adjusted series is very
    much dependent on whether or not the ARIMA model
    is seasonal

37
Future Research
  • There has been quite a bit of work looking at the
    six star rule for monthly series
  • Similar research might be useful for AR(10)
    estimators for quarterly series

38
Contact Information
  • Catherine Hood
  • Catherine Hood Consulting
  • 1090 Kennedy Creek Road
  • Auburntown, TN 37016-9614
  • Telephone (615) 408-5021
  • Email cath_at_catherinechhood.net
  • Web www.catherinechhood.net

39
