FORCES

1
FORCES

• There once was a man with no arms

2
1) Forces are a push or pull that

• changes an objects state of motion.
• Forces cause objects to accelerate

3
2) Aristotle Aristotle

• Greek
• natural philosopher
• EARTH ,WIND,
• FIRE, WATER.
• Natural motion
• forced
• motion

4
3) Galileo Galilei(1564-1642)

• Inertia, friction
• No force
• needed for
• motion

5
4) Sir Isaac Newton (1642-1727)

• Father of Physics
• 3 Laws of motion
• Law of Gravitation
• EM color spectrum
• Calculus

6
5) The four natural forces are

• 1) Strong nuclear force
• 2) Electromagnetic
• 3) Weak nuclear force
• 4) Gravity
• Gravity is the weakest of all natural forces.

7
Newtons 1st Law of Motion is the Law of INERTIA
it states

• 7) that objects in motion remain in motion at a
  constant velocity and
• objects at rest remain at rest unless.
• acted on by an unbalanced force.

8
INERTIA is

• Mass (means lazy in Latin)
• Mass is the amount of inertia an object
  possesses.
• Name an object with a lot of inertia

9
9) Examples of inertia

• the earth, sun, Betelgeuse
• Name an object with a small amount of inertia

10

• b) electron, proton, or neutron
• Name an object with a small amount of inertia a
  large volume.

11

• Blimp / hot air balloon
• Name an object with a large amount of inertia a
  small volume.

12

• Neutron star

13
10) Can you lift, move or shake 1000 kg object in
space? (2200 lbs)

• NO!
• It is weightless but still has inertia.

14
Newtons 2nd Law of Motion
15
The Law of Acceleration

• Acceleration is proportional to force.
• Acceleration is inversely proportional to mass.
• 11) Force
• mass x acceleration

16
F m x a
What would a force triangle look like?
17
F is measured in kgxm/s214) kgxm/s2 is called a
newton 12) Dyne (dyn), kilopond (kp)English?
pound (lbs), poundal(pdl)
18
(No Transcript)
19
13) A net force is the sum of all forces acting
on an object.

• positive negative

20
13) Balanced unbalanced forces
21
15) Weight is a force!!!

• Weight is not mass! The force of weight is caused
  by gravity.
• Gravity accelerates all objects at a rate of
  9.8m/s2

22
The symbol for the acceler-ation due to gravity
is g g 9.8 m/s2 on earth

• w m x g

23
Weight weight mass x gravitys
accelerationTidesBay of FundyOrbitsPerturbatio
ns
24
16) Newtons 3rd Law
25

• The Law of Interactions
• For every action force there is an
• _______ _____ reaction force.
• 17. Forces always occur in pairs. One is the
  action force the other is the reaction force.
  Equal opposite

26
Bat ball
27
Boy wagon

• bird

28
Rocket in space
29
Bullet rifle
30
Ball falling to earth
31
19) They are equal!

• 20) They occur on 2 different objects at exactly
  the same moment in time.

32
(No Transcript)
33
Nobel Prize in Chemistry

• Each prize includes a
• check for 1.4 million,
• a diploma and a medal, which will be awarded by
  Sweden's King Carl XVI Gustaf at a ceremony in
  Stockholm on Dec. 10.

34
Gravity
35
1) I fain no hypothesis.

• There is a force of attraction between all
  objects in the universe that is proportional to
  the product of the masses and inversely related
  to the squared distance separating the center of
  masses.

36
Universal Law of Gravitation

• 2) F G m1xm2 / r2
• where F is the magnitude of the
  gravitational force between the two point masses
• G is the gravitational constant
• Note G 6.67 x 10-11 N m2/kg2
• m1 is the mass of the first point mass
• m2 is the mass of the second point mass
• r is the distance between the two point masses

37

• Falling All objects fall at
• 9.8 m/s2 on earth

38

• Weight ? on earth w m x g

39

• Orbits shapes of stars, planets moons

40
Orbits Perturbations
41
Planet X New Member of our Solar System

• The planet was discovered by the Samuel Oschin
  Telescope at the Palomar Observatory near San
  Diego, Calif., on Jan. 8, 2005.

42

• Tides

43
15 A) Gravity causes projectile motion

• A projectile is any object which once projected
  continues in motion by its own inertia and is
  influenced only by the downward force of gravity.
• Rocks, arrows, darts, bullets, etc
• Not jets, rockets, birds, missiles

44
B) Aerodynamic, curved path, no external forces
other than gravity.

• C)

45





• The paths of projectiles.
• This shape is called a PARABOLA

46
Label the diagram

47
Circular Motion
48
8) CenTRIP-etal force is the force directed
towards the center of curved path.

• Centripetal means "center seeking" force.

49
(No Transcript)
50

• 10) Straight line. No centripetal Force, no
  turning Straight line motion only.
• If the rope were to break the ball would travel
  in a
• straight line

51
11) No or a small amount of gravity acting on an
object.

• 12) Spin an object at a rate of 9.8 m/s2

52
(No Transcript)
53

• Artificial

54

• Natural

55
14) Military, communication, GPS, weather

• 15) Orbits decay

56
FRICTION - slip happens!
57

• Where did the physics student fall in the
  library?
• What do you call Star Wars jokes that rub you
  the wrong way?
• 2 cats slide off the roof which hits the ground
  first?
• Lighten up, friction can be a drag. (all puns are
  intended)

58
16) Friction is the force that opposes motion.

• Friction is caused by the close contact of 2
  surfaces.

59
17) Friction is electromagnetic
60
18) 2 types of friction

• friction between two substances when both are at
  rest. Must be overcome before moving an object.

61
Kinetic or Dynamic friction

• Friction when an object is moving. This friction
  resists changes in motion.
• Kinetic friction can be described 3 ways.

62

• A) Sliding

63

• b) Rolling friction

64

• c) Fluid friction

65
19) Is friction useful?

• yes, walking, grip, heat

66
19) Is friction harmful?

• Yes abrasion, heat, machine wear

67
20) To increase friction

• More weight or pressure
• More surface area (rougher)
• Change surface material
• (rubber, latex, or nylon)

68
20) To decrease friction.

• Less weight or pressure.
• Smoother (polished) surfaces.
• Change type of friction.
• Use glass, metal, or teflon
• LUBRICATE!!!!

69
(No Transcript)
70
21) Yes, friction opposes motion, causes negative
acceleration, requires more force.

• What about air? Aerodynamics

71

• Weight-gravity, thrust-engine, drag-fluid
  friction, lift-Bernoulli's principle
