Intro to Web Search

1
Intro to Web Search

• Michael J. Cafarella
• December 5, 2007

2
Searching the Web

• Web Search is basically a database problem, but
  no one uses SQL databases
• Every query is a top-k query
• Every query plan is the same
• Massive numbers of queries and data
• Read-only data
• A search query can be thought of in SQL terms,
  but the engineered system is completely different

3
Nutch Hadoop A case study

• Open-source, free to use and change
• Nutch is a search engine, can handle 200M pages
• Hadoop is backend infrastructure, biggest
  deployment is a 2000 machine cluster
• There have been many different search engine
  designs, but Nutch is pretty standard and easy to
  learn from

4
Outline

• Search basics
• What are the elementary steps?
• Nutch design
• Link database, fetcher, indexer, etc
• Hadoop support
• Distributed filesystem, job control

5
Search document model

• Think of a web document as a tuple with several
  columns
• Incoming link text
• Title
• Page content (maybe many sub-parts)
• Unique docid
• A web search is really SELECT FROM docs WHERE
  docs.text LIKE userquery AND docs.title LIKE
  userquery AND ORDER BY relevance
• Where relevance is very complicated

6
Search document model (2)

• Three main challenges to processing a query
• Processing speed
• Result relevance
• Scaling to many documents

7
Processing speed

• You could grep, but each query will need to touch
  each document
• Key to fast processing is the inverted index
• Basic idea is for each word, list all the
  documents where that word can be found

8
as
billy
cities
friendly
give
mayors
nickels
seattle
such
words
9
Query such as
docs
docid0
docid1
docid2
dociddocs-1

as
billy
cities
friendly
give
mayors
nickels
seattle
such
words

1. Test for equality
2. Advance smaller pointer
3. Abort when a list is exhausted

docs
docid0
docid1
docid2
dociddocs-1

322
Returned docs
10
Result Relevance

• Modern search engines use hundreds of different
  clues for ranking
• Page title, meta tags, bold text, text position
  on page, word frequency,
• A few are usually considered standard
• tfidf(t, d) freq(t-in-d) / freq(t-in-corpus)
• Link analysis link counting, PageRank, etc
• Incoming anchor text
• Big gains are now hard to find

11
Scaling to many documents

• Not even the inverted index can handle billions
  of docs on a single machine
• Need to parallelize query
• Segment by document
• Segment by search term

12
Scaling (2) doc segmenting
Docs 1-2M
Docs 2-3M
Docs 3-4M
Docs 4-5M
Docs 0-1M
Ds 1.2M, 1.7M
britney
Ds 2.3M, 2.9M
Ds 3.1M, 3.2M
britney
Ds 4.4M, 4.5M
britney
britney
britney
Ds 1, 29
1.2M, 4.4M, 29,
britney
13
Scaling (3)

• Segment by document, pros/cons
• Easy to partition (just MOD the docid)
• Easy to add new documents
• If machine fails, quality goes down but queries
  dont die
• Segment by term, pros/cons
• Harder to partition (terms uneven)
• Trickier to add a new document (need to touch
  many machines)
• If machine fails, search term might disappear,
  but not critical pages (e.g., yahoo.com/index.html
  )

14
Intro to Nutch

• A search engine is more than just the query
  system. Simply obtaining the pages and
  constructing the index is a lot of work

15
WebDB
16
Moving Parts

• Acquisition cycle
• WebDB
• Fetcher
• Index generation
• Indexing
• Link analysis (maybe)
• Serving results

17
WebDB

• Contains info on all pages, links
• URL, last download, failures, link score,
  content hash, ref counting
• Source hash, target URL
• Must always be consistent
• Designed to minimize disk seeks
• 19ms seek time x 200m new pages/mo
• 44 days of disk seeks!

18
Fetcher

• Fetcher is very stupid. Not a crawler
• Divide to-fetch list into k pieces, one for
  each fetcher machine
• URLs for one domain go to same list, otherwise
  random
• Politeness w/o inter-fetcher protocols
• Can observe robots.txt similarly
• Better DNS, robots caching
• Easy parallelism
• Two outputs pages, WebDB edits

19
WebDB/Fetcher Updates
URL http//www.about.com/index.html
LastUpdated 3/22/05
ContentHash MD5_sdflkjweroiwelksd
Edit DOWNLOAD_CONTENT
URL http//www.yahoo/index.html
ContentHash MD5_toewkekqmekkalekaa
URL http//www.cnn.com/index.html
LastUpdated Never
ContentHash None
Edit DOWNLOAD_CONTENT
URL http//www.cnn.com/index.html
ContentHash MD5_balboglerropewolefbag
URL http//www.cnn.com/index.html
LastUpdated Today!
ContentHash MD5_balboglerropewolefbag
URL http//www.flickr/com/index.html
LastUpdated Never
ContentHash None
URL http//www.yahoo/index.html
LastUpdated 4/07/05
ContentHash MD5_toewkekqmekkalekaa
Edit NEW_LINK
URL http//www.flickr.com/index.html
ContentHash None
URL http//www.yahoo.com/index.html
LastUpdated Today!
ContentHash MD5_toewkekqmekkalekaa
Fetcher edits
WebDB
2. Sort edits (externally, if necessary)
1. Write down fetcher edits
3. Read streams in parallel, emitting new database
4. Repeat for other tables
20
Indexing

• Iterate through all k page sets in parallel,
  constructing inverted index
• Creates a searchable document like we saw
  earlier
• URL text
• Content text
• Incoming anchor text
• Inverted index provided by the Lucene open source
  project

21
Administering Nutch

• Admin costs are critical
• Its a hassle when you have 25 machines
• Google has maybe gt100k
• Files
• WebDB content, working files
• Fetchlists, fetched pages
• Link analysis outputs, working files
• Inverted indices
• Jobs
• Emit fetchlists, fetch, update WebDB
• Run link analysis
• Build inverted indices

22
Administering Nutch (2)

• Admin sounds boring, but its not!
• Really
• I swear
• Large-file maintenance
• Google File System (Ghemawat, Gobioff, Leung)
• Nutch Distributed File System
• Job Control
• Map/Reduce (Dean and Ghemawat)
• Result Hadoop, a Nutch spinoff

23
Nutch Distributed File System

• Similar, but not identical, to GFS
• Requirements are fairly strange
• Extremely large files
• Most files read once, from start to end
• Low admin costs per GB
• Equally strange design
• Write-once, with delete
• Single file can exist across many machines
• Wholly automatic failure recovery

24
NDFS (2)

• Data divided into blocks
• Blocks can be copied, replicated
• Datanodes hold and serve blocks
• Namenode holds metainfo
• Filename ? block list
• Block ? datanode-location
• Datanodes report in to namenode every few seconds

25
NDFS File Read
Datanode 0
Datanode 1
Datanode 2
Namenode
Datanode 3
Datanode 4
Datanode 5
crawl.txt
(block-33 / datanodes 1, 4) (block-95 / datanodes
0, 2) (block-65 / datanodes 1, 4, 5)

1. Client asks datanode for filename info
2. Namenode responds with blocklist, and location(s)
   for each block
3. Client fetches each block, in sequence, from a
   datanode

26
NDFS Replication
Datanode 0 (33, 95)
Datanode 1 (46, 95)
Datanode 2 (33, 104)
(Blk 90 to dn 0)
Namenode
Datanode 3 (21, 33, 46)
Datanode 4 (90)
Datanode 5 (21, 90, 104)

1. Always keep at least k copies of each blk
2. Imagine datanode 4 dies blk 90 lost
3. Namenode loses heartbeat, decrements blk 90s
   reference count. Asks datanode 5 to replicate
   blk 90 to datanode 0
4. Choosing replication target is tricky

27
Map/Reduce

• Map/Reduce is programming model from Lisp (and
  other places)
• Easy to distribute across nodes
• Nice retry/failure semantics
• map(key, val) is run on each item in set
• emits key/val pairs
• reduce(key, vals) is run for each unique key
  emitted by map()
• emits final output
• Many problems can be phrased this way

28
Map/Reduce (2)

• Task count words in docs
• Input consists of (url, contents) pairs
• map(keyurl, valcontents)
• For each word w in contents, emit (w, 1)
• reduce(keyword, valuesuniq_counts)
• Sum all 1s in values list
• Emit result (word, sum)

29
Map/Reduce (3)

• Task grep
• Input consists of (urloffset, single line)
• map(keyurloffset, valline)
• If contents matches regexp, emit (line, 1)
• reduce(keyline, valuesuniq_counts)
• Dont do anything just emit line
• We can also do graph inversion, link analysis,
  WebDB updates, etc

30
Map/Reduce (4)

• How is this distributed?
• Partition input key/value pairs into chunks, run
  map() tasks in parallel
• After all map()s are complete, consolidate all
  emitted values for each unique emitted key
• Now partition space of output map keys, and run
  reduce() in parallel
• If map() or reduce() fails, reexecute!

31
Map/Reduce Job Processing
TaskTracker 0
TaskTracker 1
TaskTracker 2
JobTracker
TaskTracker 3
TaskTracker 4
TaskTracker 5
grep

1. Client submits grep job, indicating code and
   input files
2. JobTracker breaks input file into k chunks, (in
   this case 6). Assigns work to ttrackers.
3. After map(), tasktrackers exchange map-output to
   build reduce() keyspace
4. JobTracker breaks reduce() keyspace into m chunks
   (in this case 6). Assigns work.
5. reduce() output may go to NDFS

32
Conclusion

• http//www.nutch.org/
• Partial documentation
• Source code
• Developer discussion board
• Lucene in Action by Hatcher, Gospodnetic
• http//www.hadoop.org/
• Or, take 490H
