Belief Propagation: An Extremely Rudimentary Discussion

1
Belief PropagationAn Extremely Rudimentary
Discussion

• McLean Pavel

2
The Problem

• When we have a tree structure describing
  dependencies between variable, we want to update
  our probability distributions based on evidence
• Trees are nice to work with, as the probability
  distribution can be expressed as the product of
  edge marginals divided by the product of
  separator node marginals
• Simple case if risk of heart disease depends on
  your fathers risk of heart disease, what can you
  say about your own risk if you know your
  grandfathers risk?
• Essentially, given a prior distribution on the
  tree, find the posterior distribution given some
  observed evidence

3
The Solution

• Belief Propagation is an algorithm to incorporate
  evidence into a tree distribution
• Non-iterative method it only requires two passes
  through the tree to get an updated distribution

4
The Algorithm

• First, incorporate evidence for each observed
  variable, find one edge that it is a part of, and
  set all entries in the edge table that do not
  correspond to the observed value to zero
• Next, choose some edge as a root
• Collect evidence in from every direction to the
  root
• Normalize the root edge table
• Distribute evidence out in every direction from
  the root

5
Okay, but what do you mean by collect evidence?

• Well, we want to propagate evidence through the
  system
• This is fairly simple for singly-linked items
  just update marginal based on joint, then update
  the next joint based on that marginal, and so on
• So if we observed x, Txy becomes Txy, then we
  get Ty by summing Txy over all x
• Then, Tyz (Tyz)(Ty/Ty)

x
y
6
And if we have multiply linked items?

• Then its slightly (but only slightly) more
  complicated
• Now if we observe x1 and x2, we get Tx1y and
  Tx2y
• We then calculate T1y and T2y (the equivalents of
  Ty from before, but each using only the
  information from one of the Xs)
• Now, Tyz(Tyz)(T1y/Ty)(T2y/Ty)
• See Pavels handout for a complete workthrough
  using this graph, and a justification of the
  calculation of Tyz

x1
y
z
x2
7
But youve got two different marginals for Y!
That cant be right!

• Patience. All will work out in time.
• After we have finished collecting evidence, we
  normalize our root table in this case, the root
  would be Tyz
• Now we distribute evidence this is the same
  process as collecting evidence, but in the
  opposite direction
• Note that now we are only ever having a single
  input edge going to any given node, so we can
  come up with proper marginals
• When weve finished distributing evidence, we
  will have a probability distribution over the
  tree that reflects the incorporated evidence.
