XML Data Management 8. XQuery

1
XML Data Management 8. XQuery

• Werner Nutt

2
Requirements for an XML Query Language

• David Maier, W3C XML Query Requirements
• Closedness output must be XML
• Composability wherever a set of XML elements is
  required, a subquery is allowed as well
• Support for key operations
• selection
• extraction, projection
• restructuring
• combination, join
• fusion of elements

3
Requirements for an XML Query Language

• Can benefit from a schema, but should also be
  applicable without
• Retains the order of nodes
• Formal semantics
• structure of results should be derivable from
  query
• defines equivalence of queries
• Queries should be representable in XML
• ? documents can have embedded queries

4
How Does One Design a Query Language?

• In most query languages, there are two aspects to
  a query
• Retrieving data (e.g., from where in SQL)
• Creating output (e.g., select in SQL)
• Retrieval consists of
• Pattern matching (e.g., from )
• Filtering (e.g., where )
• although these cannot always be clearly
  distinguished

5
XQuery Principles

• Data Model identical with the XPath data model
• documents are ordered, labeled trees
• nodes have identity
• nodes can have simple or complex types
  (defined in XML Schema)
• A query result is an ordered list/sequence of
  items
• (nodes, values, attributes, etc., but not lists)
• special case the empty list ()

6
XQuery Principles (cntd)

• XQuery can be used without schemas, but
  can be checked against DTDs and XML schemas
• XQuery is a functional language
• no statements
• evaluation of expressions
• function definitions
• modules

7
The Recipes DTD (Reminder)

• lt!ELEMENT recipes (recipe)gt
• lt!ELEMENT recipe (title, ingredient,
  preparation, nutrition)gt
• lt!ELEMENT title (PCDATA)gt
• lt!ELEMENT ingredient (ingredient,
  preparation?)gt
• lt!ATTLIST ingredient
• name CDATA REQUIRED
• amount CDATA IMPLIED
• unit CDATA IMPLIEDgt
• lt!ELEMENT preparation (step)gt
• lt!ELEMENT step (PCDATA)gt
• lt!ELEMENT nutrition EMPTYgt
• lt!ATTLIST nutrition
• calories CDATA REQUIRED
• fat CDATA REQUIREDgt

8
A Query over the Recipes Document
lttitlesgt for r in doc("recipes.xml")//recip
e return r/title lt/titlesgt returns
lttitlesgt lttitlegtBeef Parmesan with Garlic
Angel Hair Pastalt/titlegt lttitlegtRicotta
Pielt/titlegt lt/titlesgt


9
Query Features
lttitlesgt for r in doc("recipes.xml")//recipe
return r/title lt/titlesgt
doc(String) returns input document
Sequence of results,one for each variable binding
10
An Equivalent Stylesheet Template

• ltxsltemplate match"/"gt
• lttitlesgt
• ltxslfor-each select"//recipe"gt
• ltxslcopy-of select"title"/gt
• lt/xslfor-eachgt
• lt/titlesgt
• lt/xsltemplategt

11
Features Summary

• The result is a new XML document
• A query consists of parts that are returned as is
• ... and others that are evaluated (everything in
  ... )
• Calling the function doc(String) returns
  an
  input document
• XPath is used to retrieve node sets and values
• Iteration over node sets for
  binds a variable to all nodes in a node set
• Variables can be used in XPath expressions
• return returns a sequence of results,
  one for each binding
  of a variable

12
XPath is a Fragment of XQuery

• doc("recipes.xml")//recipe1/title
• returns
• lttitlegtBeef Parmesan with Garlic Angel Hair
  Pastalt/titlegt
• doc("recipes.xml")//recipeposition()lt3
  /title
• returns
• lttitlegtBeef Parmesan with Garlic Angel Hair
  Pastalt/titlegt,
• lttitlegtRicotta Pielt/titlegt,
• lttitlegtLinguine alla Pescadoralt/titlegt

an element
a list of elements
13
Beware Attributes in XPath

• doc("recipes.xml")//recipe1/ingredient1
  /_at_name
• ? attribute name "beef cube steak"
• string(doc("recipes.xml")//recipe1
  /ingredient1/_at_name)
• ? "beef cube steak"

an attribute, represented as a constructor for
an attribute node (not in Saxon)
a value of type string
14
Beware Attributes in XPath (cntd.)

• ltfirst-ingredientgtstring(doc("recipes.xml")//rec
  ipe1 /ingredient1/_at_name)
  lt/first-ingredientgt
• ? ltfirst-ingredientgtbeef cube steaklt/first-ingred
  ientgt

an element with string content
15
Beware Attributes in XPath (cntd.)

• ltfirst-ingredientgtdoc("recipes.xml")//recipe1
  /ingredient1/_at_name
• lt/first-ingredientgt
• ? ltfirst-ingredient name"beef cube steak"/gt

an element with an attribute

• Note The XML that we write down is only the
  surface structure of the data model that is
  underlying XQuery

16
Beware Attributes in XPath (cntd.)

• ltfirst-ingredient
• oldName"doc("recipes.xml")//recipe1
  /ingredient1/_at_name"gtBeeflt/first-i
  ngredientgt
• ? ltfirst-ingredient oldName"beef cube steak"gt
• Beef
• lt/first-ingredientgt

17
Constructor Syntax

• For all constituents of documents, there are
  constructors
• element first-ingredient
• attribute oldName
• string(doc("recipes.xml")//recipe1

  /ingredient1/_at_name),
• "Beef"
• equivalent to the notation on the
  previous slide

18
Iteration with the For-Clause

• Syntax for var in xpath-expr
• Example for r in doc("recipes.xml")//recipe
  return string(r)
• The expression creates a list of bindings for a
  variable var
• If var occurs in an expression exp,
  then exp is evaluated for
  each binding
• For-clauses can be nested

for r in doc("recipes.xml")//recipefor v in
doc("vegetables.xml")//vegetable return ...
19
What Does This Return?

• for i in (1,2,3)for j in (1,2,3) return
  element concat("x",i j) i j

20
Nested For-clauses Example

• ltmy-recipesgt
• for r in doc("recipes.xml")//recipe
• return
• ltmy-recipe title"r/title"gt
• for i in r//ingredient
• return
• ltmy-ingredientgt
• string(i/_at_name)
• lt/my-ingredientgt
• lt/my-recipegt
• lt/my-recipesgt

Returns my-recipes with titles as attributes
and my-ingredients with names as text content
21
The Equivalent Stylesheet Template

• ltxsltemplate match"/"gt
• ltmy-recipesgt
• ltxslfor-each select".//recipe"gt
• ltmy-recipe title"title"gt
• ltxslfor-each select"ingredient"gt
• ltmy-ingredientgt
• ltxslvalue-of select"_at_name"/gt
• lt/my-ingredientgt
• lt/xslfor-eachgt
• lt/my-recipegt
• lt/xslfor-eachgt
• lt/my-recipesgt
• lt/xsltemplategt

22
The Let Clause

• Syntax let var xpath-expr
• binds variable var to a list of nodes,
  with the nodes in document order
• does not iterate over the list
• allows one to keep intermediate results for reuse
  (not
  possible in SQL)
• Example
• let oorecps doc("recipes.xml")//recipe
  .//ingredient/_at_name"olive oil"

23
Let Clause Example
ltcalory-contentgt let oorecps
doc("recipes.xml")//recipe
.//ingredient/_at_name"olive oil" for r in
oorecps return ltcaloriesgt r/title/text()
" " string(r/nutrition/_at_calories)
lt/caloriesgtlt/calory-contentgt
Note the implicit string concatenation
Calories of recipes with olive oil
24
Let Clause Example (cntd.)

• The query returns
• ltcalory-contentgt
• ltcaloriesgtBeef Parmesan 1167lt/caloriesgt
• ltcaloriesgtLinguine alla Pescadora
  532lt/caloriesgt
• lt/calory-contentgt

25
The Where Clause

• Syntax where ltconditiongt
• occurs before return clause
• similar to predicates in XPath
• comparisons on nodes
• for node equality
• ltlt and gtgt for document order
• Example

for r in doc("recipes.xml")//recipe where
r//ingredient/_at_name"olive oil" return ...
26
Quantifiers

• Syntax some/every var in ltnode-setgt
  satisfies ltexprgt
• var is bound to all nodes in ltnode-setgt
• Test succeeds if ltexprgt is true for some/every
  binding
• Note if ltnode-setgt is empty, then
  some is false and all is
  true

27
Quantifiers (Example)

• Recipes that have some compound ingredient
• Recipes where every top level ingredient is
  non-compound

for r in doc("recipes.xml")//recipe where some
i in r/ingredient satisfies i/ingredient
return r/title
for r in doc("recipes.xml")//recipe where every
i in r/ingredient satisfies
not(i/ingredient) return r/title
28
Element Fusion

• To every recipe, add the attribute calories!
• ltresultgt
• let rs doc("recipes.xml")//recipe
• for r in rs return
• ltrecipegt
• r/nutrition/_at_calories
• r/title
• lt/recipegt
• lt/resultgt

29
Element Fusion (cntd.)

• The query result
• ltresultgt
• ltrecipe calories"1167"gt
• lttitlegtBeef Parmesan with Garlic Angel Hair
  Pastalt/titlegt
• lt/recipegt
• ltrecipe calories"349"gtlttitlegtRicotta
  Pielt/titlegtlt/recipegt
• ltrecipe calories"532"gtlttitlegtLinguine
  Pescadorolt/titlegtlt/recipegt
• ltrecipe calories"612"gtlttitlegtZuppa
  Ingleselt/titlegtlt/recipegt
• ltrecipe calories"8892"gt
• lttitlegtCailles en Sarcophageslt/titlegt
• lt/recipegt
• lt/resultgt

30
Fusion with Mixed Syntax

• We mix constructor and XMLSyntax
• element result
• let rs doc("recipes.xml")//recipe
• for r in rs return
• ltrecipegt
• attribute calories r/nutrition/_at_calories

• r/title
• lt/recipegt

31
The Same with Constructor Syntax Only

• element result
• let rs doc("recipes.xml")//recipe
• for r in rs return
• element recipe
• attribute calories r/nutrition/_at_calories,

• r/title

32
Join

• Pair every ingredient with the recipes where it
  is used!
• let rs doc("recipes.xml")//recipe
• for i in rs//ingredient
• for r in rs
• where r//ingredient/_at_namei/_at_name
• return
• ltusedingt
• i/_at_name
• r/title
• lt/usedingt

33
Join (cntd.)

• The query result
• ltusedin name"beef cube steak"gt
• lttitlegtBeef Parmesan with Garlic Angel Hair
  Pastalt/titlegt
• lt/usedingt,
• ltusedin name"onion, sliced into thin rings"gt
• lttitlegtBeef Parmesan with Garlic Angel Hair
  Pastalt/titlegt
• lt/usedingt,
• ltusedin name"green bell pepper, sliced in
  rings"gt
• lttitlegtBeef Parmesan with Garlic Angel Hair
  Pastalt/titlegt
• lt/usedingt

34
Join Exercise

• Return all pairs of ingredients such that
• the ingredients have the same name,
• but occur with different amounts
• and return
• the recipes where each of them is used
• together with the amount being used in those
  recipes,
• while returning every pair only once.
• Could a query for these ingredients be expressed
  in XPath?

35
Document Inversion

• For every ingredient, return all the recipes
  where it is used!
• ltresultgt
• let rs doc("recipes.xml")//recipe
• for i in rs//ingredient
• return
• ltingredientgt
• i/_at_
• rs.//ingredient/_at_namei/_at_name/title
• lt/ingredientgt
• lt/resultgt

36
Document Inversion (cntd.)

• The query result
• ltresultgt ltingredient amount"1"
  name"Alchermes liquor" unit"cup"gt
  lttitlegtZuppa Ingleselt/titlegt lt/ingredientgt
• ltingredient amount"2" name"olive oil"
  unit"tablespoon"gt lttitlegtBeef Parmesan with
  Garlic Angel Hair Pastalt/titlegt
  lttitlegtLinguine Pescadorolt/titlegt
• lt/ingredientgt

37
Eliminating Duplicates

• The function distinct-values(Node Set)
• extracts the values of a sequence of nodes
• creates a duplicate free list of values
• Note the coercion nodes are cast as values!
• Example
• let rs doc("recipes.xml")//recipereturn
  distinct-values(rs//ingredient/_at_name)
• yields
• xdtuntypedAtomic("beef cube steak"),
• xdtuntypedAtomic("onion, sliced into thin
  rings"),
• ...

by the Galaxengine
38
Avoiding Multiple Results in a Join

• We want that every ingredient is listed only
  once
• Eliminate duplicates using distinct-values!
• ltresultgtlet rs doc("recipes.xml")//recipe
  for in in distinct-values(
  rs//ingredient/_at_name) return ltrecipes
  with"in"gt rs.//ingredient/_at_namein/tit
  le lt/recipesgt lt/resultgt

39
Avoiding Multiple Results (cntd.)

• The query result
• ltresultgt ltrecipes with"beef cube steak"gt
  lttitlegtBeef Parmesan with Garlic Angel Hair
  Pastalt/titlegt lt/recipesgt
• ltrecipes with"onion, sliced into thin
  rings"gt lttitlegtBeef Parmesan with Garlic
  Angel Hair Pastalt/titlegt lt/recipesgt...
  ltrecipes with"salt"gt lttitlegtLinguine
  Pescadorolt/titlegt lttitlegtCailles en
  Sarcophageslt/titlegt
• lt/recipesgt
• ...

40
The Order By Clause

• Syntax order by expr ascending
  descending
• for iname in doc("recipes.xml")//_at_name order
  by iname descending return string(iname)
• yields
• "whole peppercorns","whole baby clams","white
  sugar",...

41
The Order By Clause (cntd.)

• let rs doc("recipes.xml")//_at_namefor r in
  rsorder by r/nutrition/_at_caloriesreturn
  r/title
• In which order will the titles come?

42
The Order By Clause (cntd.)

• The interpreter must be told whether the values
• should be regarded as numbers or as strings

  (alphanumerical sorting is default)
• for r in rsorder by number(r/nutrition/_at_calor
  ies)return r/title
• Note
• The query returns titles ...
• but the ordering is according to calories, which
  do not appear in the output
• Also possible in SQL! What if combined with
  distinct-values?

43
FLWOR Expresssions (pronounced flower)

• We have now seen the main ingredients of XQuery
• For and Let clauses, which can be mixed
• a Where clause imposing conditions
• an Order by clause, which determines the order of
  results
• a Return clause, which constructs the output.
• Combining these yields FLWOR expressions.

44
Conditionals

• if (expr) then expr else expr
• Example
• let is doc("recipes.xml")//ingredientfor i
  in isnot(ingredient)let u if
  (not(i/_at_unit)) then attribute unit
  "pieces" else ()
• creates an attribute unit"pieces" if none
  existsand an empty item list otherwise

45
Conditionals (cntd.)

• We use the conditional to construct variants of
  ingredients
• let is doc("recipes.xml")//ingredientfor i
  in isnot(ingredient) let u if
  (not(i/_at_unit)) then attribute
  "unit" "pieces" else
  ()returnltingredientgt i/_at_ ult/ingredientgt

46
Conditionals (cntd.)

• The query result
• ltingredient name"beef cube steak" amount"1.5"
  unit"pound"/gt,
• ...
• ltingredient name"eggs" amount"12"
  unit"pieces"/gt,

47
Exercises

• Write queries that produce
• A list, containing for every recipe the recipe's
  title element and an element with the number of
  calories
• The same, ordered according to calories
• The same, alphabetically ordered according to
  title
• The same, ordered according to the fat content
• The same, with title as attribute and calories as
  content.
• A list, containing for every recipe the top level
  ingredients, dropping the lower level ingredients

48
Sample Solution 1

• A list, containing for every recipe the recipe's
  title element and an element with the number of
  calories
• ltresultgt
• for r in doc("recipes.xml")//recipe
• return
• (r/title,
• ltcaloriesgt
• number(r//_at_calories)
• lt/caloriesgt)
• lt/resultgt

The results returned are 2-element lists. The
list constructor is ( . , . )
49
Sample Solution 6

• ltresultsgt for r in doc("recipes.xml")//recipe
  return ltrecipegt attribute title
  r/title, for i in r/ingredient
  return if (not(i/ingredient)) then
  i else ltingredientgt
  i/_at_ lt/ingredientgt lt/recipegt
  lt/resultsgt

50
Aggregation

• Aggregation functions count, sum, avg, min, max
• Example The number of recipes with olive oil
• let doc doc("recipes.xml)returnltnumbergt
  count(doc//recipe .//ingredient/_at_name
  "olive oil")lt/numbergt

51
Grouping and Aggregation

• For each recipe, the number of simple
  ingredients
• for r in doc("recipes.xml")//recipereturnltnumb
  ergt attribute title r/title/text()
  count(r//ingredientnot(ingredient))lt/numbergt

52
Grouping and Aggregation (cntd.)

• The query result
• ltnumber title"Beef Parmesan with Garlic Angel
  Hair Pasta"gt
  11lt/numbergt,
• ltnumber title"Ricotta Pie"gt12lt/numbergt,
• ltnumber title"Linguine Pescadoro"gt15lt/numbergt,
• ltnumber title"Zuppa Inglese"gt8lt/numbergt,
• ltnumber title"Cailles en Sarcophages"gt30lt/numbergt


53
Grouping and Aggregation (cntd.)

• A list, containing for every ingredient, the
  number of occurrences of that ingredient
• let d doc("recipes.xml")
• let is distinct-values(d//ingredient/_at_name)
• return
• ltresultgt
• for i in is
• order by i
• return
• ltingredient name"i"gt
• count(d//ingredient_at_namei)
• lt/ingredientgt
• lt/resultgt

54
Nested Aggregation

• The recipe with the maximal number of calories!
• let rs doc("recipes.xml")//recipelet
  maxCal max(rs//_at_calories)for r in
  rswhere r//_at_calories maxCalreturn
  string(r/title)
• returns
• "Cailles en Sarcophages"

55
User-defined Functions

• declare function localfac(n as xsinteger) as
  xsinteger
• if (n 0)
• then 1
• else n localfac(n - 1)
• localfac(10)

FunctionDeclaration
FunctionCall
56
Example Nested Ingredients

• declare function localnest(n as xsinteger,
  content as xsstring)
• as element()
• if (n 0)
• then element ingredientcontent
• else element ingredientlocalnest(n -
  1,content)
• localnest(3,"Stuff")

57
What Does this Function Return?

• declare function localdepth(n as node())
• as xsinteger
• if (fnempty(n/))
• then 1
• else let cdepths
• for c in n/ return localdepth(c)
• return fnmax(cdepths) 1

58
Exercise

• Write a function
• localelement-copy
• that
• takes as input a node ( XML tree)
• produces as output a copy of the tree, but
  without the attributes
