RISK INSPECTION

1
RISK INSPECTION PROCESSING CLAIM WITH LOSS
MINIMISATION

• A PRESENTATION
• By
• AJAY K. JAIN

2
INSPECTION OF MOTOR O.D. RISK

• SEGMENT OF THE VEHICLE.
• CLASS OF VEHICLE.
• PURPOSE/ USES OF THE VEHICLE.
• PRESENCE OF THE VEHICLE IN THE MARKET.
• REPAIRING NETWORK OF THE VEHICLE.
• AVAILABILITY OF SPARE PARTS
• AGE/ CONDITION OF THE VEHICLE.
• FITMENT OF SAFETY EQUIPMENT.

3
INSPECTION OF MOTOR O.D. RISK

• PAST CLAIM EXPERIENCE.
• CONDITION OF WIRING.
• INSPECTION/ VALUATION BY A COMPETENT PERSON.
• IMPORTANCE OF AGGREGATE NUMBERS.
• CONSIDERATION OF VALUE OF FABRICATED PARTS
  SEPARATELY MAINLY IN COMMERCIAL VEHICLES.
• ANATOMY OF VEHICLE.

4
AT THE TIME OF CLAIM INTIMATION FOR SPOT SURVEY

• GUIDE LINES FOR CLAIM PROCESSOR TO MINIMISE
  LIABILITIES-
• Deputation of a competent Surveyor
• The survey should be conducted within 6 hours.
• Police report/ Mutual settlement report should be
  mandatory for all trucks/commercial vehicles.
• Guide the surveyor to take proper/ accurate
  photographs of damaged vehicle and its documents.

• There must be at least one photograph which
  should display the load details.
• Written statement of insureds representative
  should be collected by the spot surveyor.
• All AGGREGATE NUMBERS should be noted down by
  the spot surveyor.
• The spot surveyor should comment on the
  requirement of towing the vehicle.
• Ask the spot surveyor to take down clear
  observations.
• Submission of spot survey reports within 48
  hours.

5
AT THE TIME OF CLAIM INTIMATION FOR FINAL SURVEY

• GUIDE LINES FOR CLAIM PROCESSORS
• Complete claim documents including police report
  and court release order should be collected prior
  to deputation of a Surveyor.
• A letter/affidavit should be taken from the
  insured describing how he brought his vehicle to
  the workshop.
• Clear-cut policy for the value of spare parts
  purchased from authorized stockiest/ local
  market.
• Advise the insured to purchase all major spare
  parts from authorized stockiest for better
  performance of the vehicle.
• Depute a competent Surveyor.

6
DURING REPAIRS/ AFTER CONDUCTING THE FINAL SURVEY

• GUIDE LINES FOR CLAIM PROCESSORS
• To collect an online status report within 48
  hours from the surveyor including photographs.
• To discuss the assessment portion with surveyor
  by keeping LINE OF IMPACT in mind and visit the
  vehicle if required.
• Always encourage the surveyor to allow child
  parts/bare assemblies subjected to the
  availability of those parts. Consult parts
  catalogue if required.
• Always check that whether the subjected part is
  an original fitment of that insured vehicle or
  not?
• The labor charges should be calculated/assessed
  on LUMP SUM basis in case of major losses by
  the surveyor.
• IDV of fabricated parts like cabin, body etc.
  should be calculated separately and their losses
  should be assessed accordingly.
• Approve the claim timely subjected to the policy
  terms and conditions.
• Ask the surveyor to note down the AGGREGATE
  NUMBERS of damaged/replaced parts during re
  inspection.
• To distinguish between actual losses and
  CONSEQUENTIAL LOSSES.

7
LINE OF IMPACT A PRACTICAL ASPECT

• FRONT CENTER IMPACT
• FRONT RIGHT IMPACT
• FRONT LEFT IMPACT
• FRONT UPPER IMPACT
• FRONT UNDER CHASSIS IMPACT
• RHS IMPACT
• LHS IMPACT
• REAR IMPACT
• OVERTURING IMPACT

8
LINE OF IMPACT

• Try to find out the initial/starting point of
  impact.
• Then judge the direction of impact as per the
  nature and the cause of losses.
• Locate the end point up to which the impact has
  affected the vehicle.
• Insurers are only liable to pay the losses that
  occur in between the starting point and end
  point.
• Knowledge of the LOCATION OF PARTS.

9
FRONT RIGHT IMPACT

• SOME PHOTOGRAPHS
• PARTS WHICH MAY BE DAMAGED ARE AS UNDER-
• Head lamp (for all)
• Fender/cowl panel (for all)
• Condenser (for cars)
• Steering box (for all)
• Alternator (for all)
• Timing portion (for cars)
• A.C. Compressor (for cars)
• Turbo charger (for all)
• Brake booster (for all)
• Coolant bottles and other fitting items (for
  cars)
• Apron/wheel house (for LMV)
• Cowl panel (for LMV)
• Door post pillar (for LMV)
• W/s glass (for all)
• Instrument panel (for all)

10
FRONT CENTER IMPACT

• SOME PHOTOGRAPHS
• PARTS WHICH MAY BE DAMAGED ARE AS UNDER-
• Front bumper (for all)
• Silencer (for Tata 4018/3516)
• Front grill (for all)
• Front member (for LMV)
• Condenser/Intercooler (LMV/HTV)
• Radiator (for all)
• Fan (for all)
• Viscous assy./ Water body (for all)
• Engine with gear differential assy./ Engine
  block (for cars/ for jeep trucks)
• Engine mounting (for all)
• Engine cross member (for all)
• Flywheel/clutch/gear housings (Jeep and HTV)
• Gear cross member (Jeep and HTV)
• Propeller shaft (Jeep and HTV)
• Differential assy.(Jeep and HTV)

11
FRONT UNDER CHASSIS IMPACT

• Some photographs
• Parts which may be damaged are as under-
• Front bumper (for all)
• Front cross member (for all)
• Oil pan (for all)
• Front suspension parts (for all)
• Front axle (for all)
• Steering rack and pinion (for LMV)
• Floor panel (for LMV)
• Silencer assy. (for all)
• Rear suspension (for all)
• Rear axle (for all)
• Fuel tank (for LMV)

12
FRONT UPPER IMPACT

• Some photographs
• Parts which may be damaged are as under-
• Front member (for LMV)
• Cowl/cabin (for trucks)
• Bonnet (for LMV)
• Head lamps (for LMV)
• Air cleaner (for all)
• Battery (for LMV)
• Cowl panel/dash panel (for all)
• Wiper motor/arm/blades/links (for all)
• W/s glass (for all)
• Front pillars/side bodies (for all)
• Roof panel (for all)
• Instrument panel and fitting items (for all)

13
FRONT LEFT IMPACT

• SOME PHOTOGRAPHS
• PARTS WHICH MAY BE DAMAGED ARE AS UNDER-
• Front bumper (for all)
• Chassis (for LTV and HTV)
• Head lamp (for all)
• Fender/cowl panel (for all)
• Radiator (for LMV)
• Air cleaner (for HTV)
• Fuel Injection pump (for Jeep and HTV)
• Timing portion (for Jeep and HTV)
• Air Compressor (for HTV)
• Battery (for LMV)
• Fuse box and other fitting items (LMV and LTV)
• Apron/wheel house (for LMV and LTV)
• Cowl panel (for all)
• Door post pillar (for LMV and LTV)
• W/s glass (for all)
• Floor panel
• Steering oil container (for HTV)

14
RHS IMPACT

• Some photographs
• Parts which may be damaged are as under-
• Complete RHS fender to quarter panel (for LMV)
• RHS front/rear suspension parts (for all)
• RHS cabin/cowl/load body (for HTV)
• RHS doors (for LMV)
• RHS Pillars/side body panel (for LMV/ HTV)
• RHS Floor assy. (for LMV)
• Roof panel (for LMV/HTV)
• Seats (for LMV)

15
LHS IMPACT

• Some photographs
• Parts which may be damaged are as under-
• Complete LHS fender to quarter panel (for LMV)
• LHS front/ rear suspension parts (for all)
• LHS cabin/cowl/load body (for HTV)
• LHS doors (for LMV)
• LHS Pillars/side body panel (for LMV)
• LHS Floor assy. (for LMV)
• Roof panel (for LMV)
• Seats (for LMV)

16
REAR IMPACT

• Some photographs
• Parts which may be damaged are as under-
• Rear bumper (for all)
• Rear member (for LMV)
• Rear cross member (for jeep and HTV)
• Back door (for LMV)
• Back door glass (for LMV)
• Dala (for HTV)
• Support planks and structure (for HTV)
• Door shockers (for LMV)
• Chassis frame (for jeep and HTV)
• Floor panel (for LMV)
• Quarter panels (for LMV)
• Roof panel (for LMV)
• Fuel tank (for LMV)

17
OVERTURNING IMPACT

• Some photographs
• Parts which may be damaged are as under-
• Body shell/ cabin/ cowl/ load body (for all)
• Engine damages-
• Actual losses due to proximate cause
• Consequential losses

18
CONSEQUENTIAL LOSSES

• Parts which are not damaged due to direct impact
  or proximate cause are consequential losses.
• Parts generally damaged due to consequences of
  the loss-
• Engine Assy.
• Gear Assy.
• Differential Assy.
• Tyre
• Drive shafts (in LMV)
• The parts damaged due to consequences can be
  easily distinguished from the nature of damages
  they attain. For example deep scratch marks on
  drive shafts, damaged or burnt teeth of gears,
  wear tear on tyres and seizure of engine.

19
KNOWING ABOUT THE ENGINE

• Assembling an engine
• Working of an engine

20
MODES OF SETTLEMENT

• Repairing basis
• Total loss basis
• Net of salvage basis
• Cash loss basis
• Replacement of vehicle

21
HAVE A NICE DAY
Thank you
