The contraction of the Heart

1
The contraction of the Heart

• Reverend Dr. David C.M. Taylor
• School of Medicine
• dcmt_at_liverpool.ac.uk
• http//www.liv.ac.uk/dcmt

2
Learning outcomes

• By the end of this lecture you should be able to
  discuss
• The histology of cardiac muscle
• The role of myosin, actin, troponin and
  tropomyosin
• The importance of calcium for contraction
• Starlings law
• Cellular and molecular events underlying cardiac
  contraction and relaxation
• The role of Na, K and Ca2 in cardiac
  contractility

3
Structure of muscle
Chapter 13 p 147 in Preston and Wilson
(2013) Chapter 9 p 437 in Naish and Court (2014)
4
Histology
5
The sarcomere
Actin filaments
Myosin filaments
Z line
Chapter 12 p 136 in Preston and Wilson
(2013) Chapter 9 p 437 in Naish and Court (2014)
6
In more detail
Troponin-tropomyosin complex
actin
myosin binding site
myosin
7
In the presence of Calcium

• Tropomyosin shifts to expose the myosin binding
  site
• Myosin binds to binding site
• ATP is used to provide the energy to flex the
  myosin head
• The muscle shortens

8
The order of events

• The muscle depolarises
• Excitation spreads over the sarcolemma and into
  the T-tubules (there are fewer T-tubules than in
  skeletal muscle)
• L-type Ca2 channels open (dihidropyridine
  receptors), increasing sarcoplasmic Ca2 levels
• Ca2 induces Ca2 release from the sarcoplasmic
  reticulum
• Ca2 binds to tropomyosin
• Tropomyosin shifts to expose the myosin binding
  site
• Myosin binds to binding site
• ATP is used to provide the energy to flex the
  myosin head
• The muscle shortens

Chapter 13 p 147 in Preston and Wilson
(2013) Chapter 9 p 437 in Naish and Court (2014)
9
Then

• The heart does not remain contracted, but
  relaxes. This is caused by the activity of the
  SERCA
• The SERCA is a Sarcoplasmic/Endoplasmic Reticulum
  Calcium ATPase
• So energy is used to draw Ca2 back into the
  sarcoplasmic reticulum.
• And the myosin is released from the actin
  filaments

Chapter 13 p 150 in Preston and Wilson
(2013) Chapter 9 p 440 in Naish and Court (2014)
10
Na, K and Ca2

• The principles are exactly the same as for
  neurones
• But the action potentials last much longer
• And Ca2 ions are more important
• Na and K regulate the rate of contraction
• Ca2 regulates the force of contraction
• The more Ca2, for whatever reason, the greater
  the force of contraction
• All three are regulated by the autonomic nervous
  system

11
The action potential (revision)
Fully permeable to Na(40mV)
40mV
Resting membrane potential(-70mV)
-55mV
-70 mV
Fully permeable to K (-90mV)
1mS
12
The action potential (revision)
VANC close
Fully permeable to Na(40mV)
40mV
VANC open
gNa
gK
Resting membrane potential(-70mV)
stimulus
-55mV
-70 mV
Fully permeable to K (-90mV)
1mS
13
Pacemaker activity

• The rhythm of the pump is provided by the
  pacemaker activity of some specialized muscle
  cells in the wall of the right atrium - the
  sinoatrial node
• There is a steady inward current of both Na and
  Ca2
• Which causes a gradual depolarisation

14
Factors affecting stroke volume
Preload
Afterload
Contractility
15
Preload

• increased end-diastolic volume stretches the
  heart
• cardiac muscles stretch and contract more
  forcefully
• Frank-Starling Law of the heart

16
Starlings Law
2.2 ?m
3.8 ?m
1.8 ?m
100 80 60 40 20
Tension developed
40 60 80 100 120 140 160
Percentage sarcomere length (100 2.2 ?m)
