Mutations chapters 8 and 12

1
Mutationschapters 8 and 12
2
What Are Mutations?

• Changes in the nucleotide sequence of DNA
• May occur in somatic cells (arent passed to
  offspring)
• May occur in gametes (eggs sperm) and be passed
  to offspring

3
Types of Mutations
4
Chromosome Mutations

• May Involve
• Changing the structure of a chromosome
• The loss or gain of part of a chromosome

5
CROSSING OVER
when the DNA from one chromosome becomes
attached to another chromosome - usually this
occurs on HOMOLOGOUS CHROMOSOMES during PROPHASE
I of MEIOSIS GENETIC RECOMBINATION- change in
the genes or at least the location of genes
6
Chromosome Mutations

• Five types exist
• Deletion
• Inversion
• Translocation
• Nondisjunction
• Duplication

7
Deletion

• Due to breakage
• A piece of a chromosome is lost

8
Inversion

• Chromosome segment breaks off
• Segment flips around backwards
• Segment reattaches

9
Duplication

• Occurs when a gene sequence is repeated

10
Translocation

• Involves two chromosomes that arent homologous
• Part of one chromosome is transferred to another
  chromosomes

11
Translocation
12
Nondisjunction

• Failure of chromosomes to separate during meiosis
• Causes gamete to have too many or too few
  chromosomes
• Disorders
• Down Syndrome three 21st chromosomes
• Turner Syndrome single X chromosome
• Klinefelters Syndrome XXY chromosomes

13
LAW OF INDEPENDENT ASSORTMENT

• during meiosis I- one homologous chromosome
  travels to each cell. The chromosomes are chosen
  at random but the odds you get all 23 from the
  same parent is unlikely.

14
(No Transcript)
15
Chromosome Mutation Animation
16
(No Transcript)
17
Gene Mutations

• Change in the nucleotide sequence of a gene
• May only involve a single nucleotide
• May be due to copying errors, chemicals, viruses,
  etc.

18
Types of Gene Mutations

• Include
• Point Mutations
• Substitutions
• Insertions
• Deletions
• Frameshift

19
Point Mutation

• Change of a single nucleotide
• Includes the deletion, insertion, or substitution
  of ONE nucleotide in a gene

20
Point Mutation

• Sickle Cell disease is the result of one
  nucleotide substitution
• Occurs in the hemoglobin gene

21
Frameshift Mutation

• Inserting or deleting one or more nucleotides
• Changes the reading frame like changing a
  sentence
• Proteins built incorrectly

22
Frameshift Mutation

• Original
• The fat cat ate the wee rat.
• Frame Shift (a added)
• The fat caa tet hew eer at.

23
Amino Acid Sequence Changed
24
Gene Mutation Animation
25
FYI
26
Normal Male
2n 46
27
Normal Female
2n 46
28
Male, Trisomy 21 (Downs)
2n 47
29
Female Downs Syndrome
2n 47
30
Klinefelters Syndrome
2n 47
31
Turners Syndrome
2n 45
