HydroFly Flywheel

1
HydroFly Flywheel
Gavin Abo Nate Stout Nathan Thomas
2
Hydrofly

• Two Teams
• Flywheel
• Fuel Cell
• Adam Lint
• Chris Cockrell
• Daniel Hubbard

3
Sponsors Mentors

• Brian Johnson
• Herb Hess
• Satish Samineni

4
Design Review IIFinal Design Review Outline

• I. Introduction
• II. Objectives
• III. Design Functionality
• IV. Schedule
• V. Budget
• VI. Questions

5
I. Introduction

• Why is the project being done?
• -To correct short voltage sags (a few seconds)
  to maintain a stable voltage to critical
  loads.
• Why is this important?
• -The shutdown of critical loads due to short
  voltage sags can be costly.

6
II. Primary Objective

• Interface a flywheel to the AMPS with the ability
  to correct for voltage sags occurring on the
  AMPS.
• Implement the design by Satish Samineni

7
Secondary Objectives

• Spin a flywheel
• Communicate between converters
• Operate each converter with its own PWM
• Provide power to AMPS
• Operation Manual

8
III. Design Functionality

• Organizational Chart
• Block Diagram
• Overall Circuit Schematic
• Sub Circuit Schematics
• Programming
• Assembled
• Documentation
• Specifications

9
Organizational Chart
10
Block Diagram
11
Circuit Schematic
12
Series Transformer Diagram
13
DC link startup power supply
Generates positive DC voltage
Generates negative DC voltage
14
The Programming

• What we have programmed
• Matrix math capabilities
• Space Vector PWM scheme
• Sag detector and corrector

• What we still have to program
• Phase Locked Loop
• Modify already programmed code to work with the
  measured inputs

15
Assembled

• What has been assembled
• Capacitor shorting bars
• Utility Cart

• What needs assembled
• DC link charging supply
• LEMS
• Safety Cover
• Transformer

16
Documentation

• Test plan
• Functional test plan
• Specification test plan
• Operators Manual
• Poster

17
Specifications
18
IV. Schedule
19
V. Budget
20
VI. Questions
http//www.ece.uidaho.edu/hydrofly/website
