Compiler Run-time Organization Lecture 7

1
Compiler Run-time OrganizationLecture 7
2
What we have covered so far

• We have covered the front-end phases
• Lexical analysis
• Parsing
• Semantic analysis
• Next are the back-end phases
• Optimization
• Code generation
• Lets take a look at code generation . . .

3
Run-time environments

• Before discussing code generation, we need to
  understand what we are trying to generate
• There are a number of standard techniques for
  structuring executable code that are widely used

4
Outline

• Management of run-time resources
• Correspondence between static (compile-time) and
  dynamic (run-time) structures
• Storage organization

5
Run-time Resources

• Execution of a program is initially under the
  control of the operating system
• When a program is invoked
• The OS allocates space for the program
• The code is loaded into part of the space
• The OS jumps to the entry point (i.e., main)

6
Memory Layout
Other Space
7
Notes

• By tradition, pictures of machine organization
  have
• Low address at the top
• High address at the bottom
• Lines delimiting areas for different kinds of
  data
• These pictures are simplifications
• E.g., not all memory need be contiguous

8
What is Other Space?

• Holds all data for the program
• Other Space Data Space
• Compiler is responsible for
• Generating code
• Orchestrating use of the data area

9
Code Generation Goals

• Two goals
• Correctness
• Speed
• Most complications in code generation come from
  trying to be fast as well as correct

10
Assumptions about Execution

• Execution is sequential control moves from one
  point in a program to another in a well-defined
  order
• When a procedure is called, control eventually
  returns to the point immediately after the call
• Do these assumptions always hold?

11
Activations

• An invocation of procedure P is an activation of
  P
• The lifetime of an activation of P is
• All the steps to execute P
• Including all the steps in procedures P calls

12
Lifetimes of Variables

• The lifetime of a variable x is the portion of
  execution in which x is defined
• Note that
• Lifetime is a dynamic (run-time) concept
• Scope is a static concept

13
Activation Trees

• Assumption (2) requires that when P calls Q, then
  Q returns before P does
• Lifetimes of procedure activations are properly
  nested
• Activation lifetimes can be depicted as a tree

14
Example

• class Main
• int g() return 1
• int f() return g()
• void main() g() f()

Main
15
Notes

• The activation tree depends on run-time behavior
• The activation tree may be different for every
  program input
• Since activations are properly nested, a stack
  can track currently active procedures

16
Example

• class Main
• int g() return 1
• int f() return g()
• void main() g() f()

Main
Stack Main f g
17
Revised Memory Layout
18
Activation Records

• The information needed to manage one procedure
  activation is called an activation record (AR) or
  frame
• If procedure F calls G, then Gs activation
  record contains a mix of info about F and G.

19
What is in Gs AR when F calls G?

• F is suspended until G completes, at which
  point F resumes. Gs AR contains information
  needed to resume execution of F.
• Gs AR may also contain
• Gs return value (needed by F)
• Actual parameters to G (supplied by F)
• Space for Gs local variables

20
The Contents of a Typical AR for G

• Space for Gs return value
• Actual parameters
• Pointer to the previous activation record
• The control link points to AR of caller of G
• Machine status prior to calling G
• Contents of registers program counter
• Local variables
• Other temporary values

21
Example

• class Main
• int g() return 1
• int f(int x)
• if (x 0) return g()
• else return f(x - 1) ()
• void main() f(3) ()
• AR for f

result
argument
control link
return address
22
Stack After Two Calls to f
23
Notes

• Main has no argument or local variables and its
  result is never used its AR is uninteresting
• () and () are return addresses of the
  invocations of f
• The return address is where execution resumes
  after a procedure call finishes
• This is only one of many possible AR designs
• Would also work for C, Pascal, FORTRAN, etc.

24
The Main Point

• The compiler must determine, at compile-time, the
  layout of activation records and generate code
  that correctly accesses locations in the
  activation record
• Thus, the AR layout and the code generator must
  be designed together!

25
Example

• The picture shows the state after the call to 2nd
  invocation of f returns

26
Discussion

• The advantage of placing the return value 1st in
  a frame is that the caller can find it at a fixed
  offset from its own frame
• There is nothing magic about this organization
• Can rearrange order of frame elements
• Can divide caller/callee responsibilities
  differently
• An organization is better if it improves
  execution speed or simplifies code generation

27
Discussion (Cont.)

• Real compilers hold as much of the frame as
  possible in registers
• Especially the method result and arguments

28
Globals

• All references to a global variable point to the
  same object
• Cant store a global in an activation record
• Globals are assigned a fixed address once
• Variables with fixed address are statically
  allocated
• Depending on the language, there may be other
  statically allocated values

29
Memory Layout with Static Data
30
Heap Storage

• A value that outlives the procedure that creates
  it cannot be kept in the AR
• Class foo() return new Class
• The Class value must survive deallocation of
  foos AR
• Languages with dynamically allocated data use a
  heap to store dynamic data

31
Notes

• The code area contains object code
• For most languages, fixed size and read only
• The static area contains data (not code) with
  fixed addresses (e.g., global data)
• Fixed size, may be readable or writable
• The stack contains an AR for each currently
  active procedure
• Each AR usually fixed size, contains locals
• Heap contains all other data
• In C, heap is managed by malloc and free

32
Notes (Cont.)

• Both the heap and the stack grow
• Must take care that they dont grow into each
  other
• Solution start heap and stack at opposite ends
  of memory and let the grow towards each other

33
Memory Layout with Heap
34
Data Layout

• Low-level details of machine architecture are
  important in laying out data for correct code and
  maximum performance
• Chief among these concerns is alignment

35
Alignment

• Most modern machines are (still) 32 bit
• 8 bits in a byte
• 4 bytes in a word
• Machines are either byte or word addressable
• Data is word aligned if it begins at a word
  boundary
• Most machines have some alignment restrictions
• Or performance penalties for poor alignment

36
Alignment (Cont.)

• Example A string
• Hello
• Takes 5 characters (without a terminating \0)
• To word align next datum, add 3 padding
  characters to the string
• The padding is not part of the string, its just
  unused memory

37
Code Generation Overview

• Stack machines
• The MIPS assembly language
• A simple source language
• Stack-machine implementation of the simple
  language

38
Stack Machines

• A simple evaluation model
• No variables or registers
• A stack of values for intermediate results
• Each instruction
• Takes its operands from the top of the stack
• Removes those operands from the stack
• Computes the required operation on them
• Pushes the result on the stack

39
Example of Stack Machine Operation

• The addition operation on a stack machine

40
Example of a Stack Machine Program

• Consider two instructions
• push i - place the integer i on top of the
  stack
• add - pop two elements, add them and put
• the result back on the stack
• A program to compute 7 5
• push 7
• push 5
• add

41
Why Use a Stack Machine ?

• Each operation takes operands from the same place
  and puts results in the same place
• This means a uniform compilation scheme
• And therefore a simpler compiler

42
Why Use a Stack Machine ?

• Location of the operands is implicit
• Always on the top of the stack
• No need to specify operands explicitly
• No need to specify the location of the result
• Instruction add as opposed to add r1, r2
• Þ Smaller encoding of instructions
• Þ More compact programs
• This is one reason why Java Byte codes use a
  stack evaluation model

43
Optimizing the Stack Machine

• The add instruction does 3 memory operations
• Two reads and one write to the stack
• The top of the stack is frequently accessed
• Idea keep the top of the stack in a register
  (called accumulator)
• Register accesses are faster
• The add instruction is now
• acc acc top_of_stack
• Only one memory operation!

44
Stack Machine with Accumulator

• Invariants
• The result of computing an expression is always
  in the accumulator
• For an operation op(e1,,en) push the accumulator
  on the stack after computing each of e1,,en-1
• After the operation pop n-1 values
• After computing an expression the stack is as
  before

45
Stack Machine with Accumulator. Example

• Compute 7 5 using an accumulator

acc
stack

46
A Bigger Example 3 (7 5)

• Code Acc
  Stack

acc 3 3
ltinitgt push acc
3 3, ltinitgt acc 7
7 3,
ltinitgt push acc 7
7, 3, ltinitgt acc 5
5 7, 3, ltinitgt acc
acc top_of_stack 12 7, 3,
ltinitgt pop
12 3, ltinitgt acc acc
top_of_stack 15 3, ltinitgt pop
15
ltinitgt
47
Notes

• It is very important that the stack is preserved
  across the evaluation of a sub-expression
• Stack before the evaluation of 7 5 is 3,
  ltinitgt
• Stack after the evaluation of 7 5 is 3, ltinitgt
• The first operand is on top of the stack

48
From Stack Machines to MIPS

• The compiler generates code for a stack machine
  with accumulator
• We want to run the resulting code on the MIPS
  processor (or simulator)
• We simulate stack machine instructions using MIPS
  instructions and registers

49
Simulating a Stack Machine

• The accumulator is kept in MIPS register a0
• The stack is kept in memory
• The stack grows towards lower addresses
• Standard convention on the MIPS architecture
• The address of the next location on the stack is
  kept in MIPS register sp
• The top of the stack is at address sp 4

50
MIPS Assembly

• MIPS architecture
• Prototypical Reduced Instruction Set Computer
  (RISC) architecture
• Arithmetic operations use registers for operands
  and results
• Must use load and store instructions to use
  operands and results in memory
• 32 general purpose registers (32 bits each)
• We will use sp, a0 and t1 (a temporary
  register)

51
A Sample of MIPS Instructions

• lw reg1 offset(reg2)
• Load 32-bit word from address reg2 offset into
  reg1
• add reg1 reg2 reg3
• reg1 reg2 reg3
• sw reg1 offset(reg2)
• Store 32-bit word in reg1 at address reg2
  offset
• addiu reg1 reg2 imm
• reg1 reg2 imm
• u means overflow is not checked
• li reg imm
• reg imm

52
MIPS Assembly. Example.

• The stack-machine code for 7 5 in MIPS

• acc 7
• push acc
• acc 5
• acc acc top_of_stack
• pop

li a0 7 sw a0 0(sp) addiu sp sp -4 li a0
5 lw t1 4(sp) add a0 a0 t1 addiu sp sp 4

• We now generalize this to a simple language

53
A Small Language

• A language with integers and integer operations
• P D P D
• D def id(ARGS) E
• ARGS id, ARGS id
• E int id if E1 E2 then E3
  else E4
• E1 E2 E1 E2
  id(E1,,En)

54
A Small Language (Cont.)

• The first function definition f is the main
  routine
• Running the program on input i means computing
  f(i)
• Program for computing the Fibonacci numbers
• def fib(x) if x 1 then 0 else
• if x 2 then 1
  else
• fib(x - 1)
  fib(x 2)

55
Code Generation Strategy

• For each expression e we generate MIPS code that
• Computes the value of e in a0
• Preserves sp and the contents of the stack
• We define a code generation function cgen(e)
  whose result is the code generated for e

56
Code Generation for Constants

• The code to evaluate a constant simply copies it
  into the accumulator
• cgen(i) li a0 i
• Note that this also preserves the stack, as
  required

57
Code Generation for Add

• cgen(e1 e2)
• cgen(e1)
• sw a0 0(sp)
• addiu sp sp -4
• cgen(e2)
• lw t1 4(sp)
• add a0 t1 a0
• addiu sp sp 4
• Possible optimization Put the result of e1
  directly in register t1 ?

58
Code Generation for Add. Wrong!

• Optimization Put the result of e1 directly in
  t1?
• cgen(e1 e2)
• cgen(e1)
• move t1 a0
• cgen(e2)
• add a0 t1 a0
• Try to generate code for 3 (7 5)

59
Code Generation Notes

• The code for is a template with holes for
  code for evaluating e1 and e2
• Stack machine code generation is recursive
• Code for e1 e2 consists of code for e1 and e2
  glued together
• Code generation can be written as a
  recursive-descent of the AST
• At least for expressions

60
Code Generation for Sub and Constants

• New instruction sub reg1 reg2 reg3
• Implements reg1 reg2 - reg3
• cgen(e1 - e2)
• cgen(e1)
• sw a0 0(sp)
• addiu sp sp -4
• cgen(e2)
• lw t1 4(sp)
• sub a0 t1 a0
• addiu sp sp 4

61
Code Generation for Conditional

• We need flow control instructions
• New instruction beq reg1 reg2 label
• Branch to label if reg1 reg2
• New instruction b label
• Unconditional jump to label

62
Code Generation for If (Cont.)

• cgen(if e1 e2 then e3 else e4)
• cgen(e1)
• sw a0 0(sp)
• addiu sp sp -4
• cgen(e2)
• lw t1 4(sp)
• addiu sp sp 4
• beq a0 t1 true_branch

false_branch cgen(e4) b end_if true_branch
cgen(e3) end_if
63
The Activation Record

• Code for function calls and function definitions
  depends on the layout of the activation record
• A very simple AR suffices for this language
• The result is always in the accumulator
• No need to store the result in the AR
• The activation record holds actual parameters
• For f(x1,,xn) push xn,,x1 on the stack
• These are the only variables in this language

64
The Activation Record (Cont.)

• The stack discipline guarantees that on function
  exit sp is the same as it was on function entry
• No need for a control link
• We need the return address
• Its handy to have a pointer to the current
  activation
• This pointer lives in register fp (frame pointer)

65
The Activation Record

• Summary For this language, an AR with the
  callers frame pointer, the actual parameters,
  and the return address suffices
• Picture Consider a call to f(x,y), The AR will
  be

FP
old fp
y
AR of f
x
SP
66
Code Generation for Function Call

• The calling sequence is the instructions (of both
  caller and callee) to set up a function
  invocation
• New instruction jal label
• Jump to label, save address of next instruction
  in ra
• On other architectures the return address is
  stored on the stack by the call instruction

67
Code Generation for Function Call (Cont.)

• cgen(f(e1,,en))
• sw fp 0(sp)
• addiu sp sp -4
• cgen(en)
• sw a0 0(sp)
• addiu sp sp -4
• cgen(e1)
• sw a0 0(sp)
• addiu sp sp -4
• jal f_entry

• The caller saves its value of the frame pointer
• Then it saves the actual parameters in reverse
  order
• The caller saves the return address in register
  ra
• The AR so far is 4n4 bytes long

68
Code Generation for Function Definition

• New instruction jr reg
• Jump to address in register reg

cgen(def f(x1,,xn) e) move fp sp
sw ra 0(sp) addiu sp sp -4 cgen(e)
lw ra 4(sp) addiu sp sp z lw fp
0(sp) jr ra

• Note The frame pointer points to the top, not
  bottom of the frame
• The callee pops the return address, the actual
  arguments and the saved value of the frame
  pointer
• z 4n 8

69
Calling Sequence. Example for f(x,y).

• Before call On entry Before
  exit After call

FP
SP
SP
70
Code Generation for Variables

• Variable references are the last construct
• The variables of a function are just its
  parameters
• They are all in the AR
• Pushed by the caller
• Problem Because the stack grows when
  intermediate results are saved, the variables are
  not at a fixed offset from sp

71
Code Generation for Variables (Cont.)

• Solution use a frame pointer
• Always points to the return address on the stack
• Since it does not move it can be used to find the
  variables
• Let xi be the ith (i 1,,n) formal parameter of
  the function for which code is being generated
• cgen(xi) lw a0 z(fp) ( z
  4i )

72
Code Generation for Variables (Cont.)

• Example For a function def f(x,y) e the
  activation and frame pointer are set up as
  follows

old fp

• X is at fp 4
• Y is at fp 8

y
x
return
FP
SP
73
Summary

• The activation record must be designed together
  with the code generator
• Code generation can be done by recursive
  traversal of the AST
• Production compilers do different things
• Emphasis is on keeping values (esp. current stack
  frame) in registers
• Intermediate results are laid out in the AR, not
  pushed and popped from the stack

74
End of Lecture

• Next Lecture Chapter 5
• Names
• Bindings
• Type Checking
• Scopes
