Linear Motion

1
Linear Motion
2
Time

• Time a useful measurement of changes in motion
  or events all or part of the past, present, and
  future.
• For most cases time is measured in seconds.

3
Displacement
http//hypertextbook.com/physics/mechanics/displac
ement/

• Displacement change in position (includes
  direction!)
• Distance- total path length traveled in moving
  from one location to another

Determine the distance the displacement in the
diagram
Total distance is 11 meters, but displacement is
3 meters
4
Positive or Negative can be used to show
direction!

• Usually symbolizes up, right, north, east,
  forward
• - Usually symbolizes down, left, south, west,
  backwards

5
Motion a change in position

• Speed - how much distance an object covers per
  unit time
• distance is commonly measured in meters (m)
• time is commonly measured in seconds (s)

6
Equation

• v average speed
• d distance
• t time

v velocity and is used to represent average
speed in this basic equation
7
Unit of Measure

• Since distance is measured in meters (m) and time
  is measured in seconds (s) we can determine the
  units for speed...
• distance time in units would be m s or m/s
• The unit for speed is therefore m/s or meters per
  second!

8
Speed VS. Velocity

• Velocity is your speed and the direction you are
  moving in.
• velocity speed direction
• ex 45 m/s, North
• 10 m/s, towards the mall

9
The shape of a Position (distance) VS. Time Graph

• Constant Velocity
  (positive)
• Changing Velocity
  (positive)
• acceleration

10
Position vs. time Graph
Distance (m)

• Constant positive velocity to top of point,
  moving AWAY from the origin
• and then constant negative velocity as the object
  moves towards the origin

11
Distance vs time graph

• A-B constant positive velocity
• B-C increasing velocity and decreasing velocity
• D at rest D-E increasing velocity

12

• We will begin with the next slide in a day or two

13
Which of the above graphs best fits the situation
to the right?
14
Motion Graphs

• Motion Graphs

15

• Acceleration- rate of change in velocity

1. Which car (red, green, or blue) experiences the
   greatest acceleration?
2. Consider the position-time graph at the right.
   Each one of the three lines on the position-time
   graph corresponds to the motion of one of the
   three cars in the graphic above. Match the
   appropriate line to the particular color of car.

16
(No Transcript)
17
(No Transcript)
18
Graph Interpretation

• 1.Describe the motion based on the graph.
• 2. What WORD best describes the slope of the
  graph?

19
VERTICAL MOTION!
Whats the difference? Why does the leaf float
but yet the water drop falls?

• What do you know about falling objects?
• Do heavier objects fall faster than lighter
  objects?
• Effect of Mass on Falling Object

20
BUT WAIT.

• All things dont fall at the same speed?
• WHY

21
Do heavier objects fall faster?

• Feather Hammer On Moon!

No air resistance
Real scenario
22
http//visual.physics.tamu.edu/vp218/LabManual/Fig
23
Free Fall, Acceleration due to Gravity

• The position of the free-falling object at
  regular time intervals, every 0.1 second, is
  shown.
• The distance which the ball travels every
  interval of time increases.

24
Free Fall

• Motion under the influence of gravity only
• The force of gravity accelerates ALL objects
  towards earth at 9.81m/s²

25
oopsnow what?

• What happens as Wile E. Coyote falls?
• time
• speed
• acceleration
• distance

http//www.studyphysics.ca/newnotes/20/unit02_circ
ulargravitation/chp07_2d/lesson26.htm
26
The FALL of Wile E.Coyote at 1 s. intervals
Time (s) Speed (m/s) Accel. (m/s2) Dist. (m)
0
1
2
3
4
5
27
Imagine throwing a ball straight up into the air
with an initial velocity of 40 m/s and it returns
to your hand

• Diagram the situation.
• Describe the motion at each second.
• In other words
• is the speed increasing or decreasing?
• is the ball moving up or down?
• Estimate the velocity and acceleration at each
  second!
• Up Down
