Title: Region C Water Planning Group


1
Region C Water Planning Group Media Briefing
  • September 10, 2009

2
Welcome Introductions
  • Jim Parks, Chair, Region C Water Planning Group
    (RCWPG)
  • Jody Puckett, Vice Chair, RCWPG
  • Tom Gooch, Lead Consultant, Freese Nichols
  • Colby Walton and Jennifer Engstrand, Public
    Participation Consultants, Cooksey Communications

3
Agenda
  • History Texas Water Development Board and
    Planning
  • Regional Water Planning Process
  • 2007 State Water Plan
  • Current (2006) Region C Water Plan
  • Development of 2011 Region C Water Plan
  • QA
  • Please feel free to ask questions throughout
    the presentation!

4
Background and History
  • Texas Water Development Board
  • and Planning

5
The Big Picture Texas Rainfall
6
History TWDB and Planning
  • In Texas, planning driven by drought
  • Texas Water Development Board (TWDB) founded in
    1957 (1950-57 drought)
  • 200 million water development fund
  • Formal planning process
  • State plans from Austin in 1961, 1968, 1984,
    1990, 1992, 1997
  • Early plans emphasized reservoirs

7
Regional Water Planning Process
8
Regional Water Planning Process
  • Senate Bill 1 - Texas Legislature in 1997
  • Spurred by 1996 drought
  • Population projected to double by 2060
  • Bottom up water planning process
  • Texas Water Development Board
  • Adopted rules
  • Set out 16 regions
  • Named initial planning group members

9
Regional Water Planning Areas
10
Regional Water Planning Process
  • 50-year planning period
  • Project population and water demand
  • Existing supply
  • Evaluate need for additional water
  • Recommend strategies
  • Water right permitting and TWDB funding use plans

11
2007 State Water Plan
12
Historical and Projected Population
50
45
40
35
30
Texas Population (Millions)
25
20
15
10
5
0
1900
1910
1920
1930
1940
1950
1960
1970
1980
1990
2000
2010
2020
2030
2040
2050
2060
Year
Year
Historical
Projected
13
Population Growth Rate
14
Projected Demand
15
Projected Demand
16
Projected Supply
17
Historical Groundwater Level Declines
Water level decline in feet less than 50 or
undetermined 50 to 100 100 to 200 200 to 300 300
to 400 400 to 500 500 to 800 greater than 800
18
Needs
  • Texas does not have enough water today to meet
    future demand during times of drought

19
Potential Shortages
20
Strategies - Process
  • Regions identified 4,500 strategies
  • Evaluated strategies based on
  • Water quantity and reliability
  • Financial costs
  • Impacts to environment and agriculture
  • Impacts to water quality
  • Other factors such as regulatory requirements,
    time required to implement, etc.
  • 9 million acre-feet per year in new supplies
    recommended

21
New Supplies2007 State Water Plan In
Acre-Feet/Year
22
Costs
  • Total capital costs 30.7 billion

23
Costs of Not Implementing Plan
  • Businesses and workers 9.1 billion in 2010,
    98.4 billion in 2060
  • Lost local and state taxes 466 million in 2010,
    5.4 billion in 2060
  • About 85 percent of the states population will
    not have enough water by 2060 in drought of record

24
Water Conservation
  • In 2007 State Water Plan
  • Municipal Conservation 600,000 ac-ft/yr
  • 47 Region C, 16 Region H
  • Irrigation Conservation 1,400,000 ac-ft/yr
  • 32 Region M, 24 Region O, 21 Region A, 10
    Region K
  • Implementation continues

25
Water Supply Issue Reuse
  • Differing approaches to reuse
  • Direct before return to stream easy to permit
  • Indirect returned to stream and rediverted
    difficult to permit
  • Important part of future water supply
  • Should be encouraged

26
Reuse in the 2006 Regional Plans
  • Projected for 1.66 million acre-feet/year by 2060
  • Slight majority in Region C
  • Significant amounts in Regions D, H, K and L
  • Some reuse in 14 of 16 regions

27
Major Existing Interbasin Transfers
28
Major Proposed Interbasin Transfers
29
2006 Region C Water Plan
30
Water Supply for the Metroplex
  • Region C 16-county area
  • Collin, Cooke, Dallas, Denton, Ellis, Fannin,
    Freestone, Grayson, Henderson (Trinity Basin
    portion only), Jack, Kaufman, Navarro, Parker,
    Rockwall, Tarrant and Wise
  • 1/4 of Texas population
  • 1/12 of Texas water use in 2000

31
Region C - Geography
32
Region C Water Supplies
  • 90 is surface water (vs. groundwater)
  • The primary rivers supplying water to the region
    Trinity River, Red River, Sabine River and
    Sulphur River
  • 35 wholesale water providers and 351 water user
    groups (WWPs and WUGs)
  • 3 largest wholesale providers supply 75 (Dallas
    WU, Tarrant RWD, North Texas MWD)
  • ½ of the water used is returned to streams and
    lakes as treated effluent
  • Reuse could be a significant source of supply
  • A small but growing fraction is currently
    reclaimed and reused

33
Region C Currently Available Supplies and
Projected Demands
34
Region C Water Supply Critical
  • Rapid population growth
  • Water supply critical to way of life, continued
    prosperity, protection of ecology and wildlife
  • Without additional water supply in Region C
  • 2060 population reduced by over 1 million (7.7)
  • 2060 employment reduced by nearly 700,000 jobs
    (17)
  • 2060 annual regional income reduced by 58.8
    billion (21)

35
Meeting Region Cs 2060 Demand
  • Under the existing plan, Region Cs 2060 sources
    of supply would be as follows
  • 31 from currently available, connected supplies
    (surface and groundwater)
  • 26 from new water conservation and reuse
  • 23 from new connections to existing sources
  • 18 from development of new reservoirs
  • Additional supply from development of regional
    systems, system operation of reservoirs and use
    of groundwater

36
Region Cs 2060 Supplies
37
Meeting Region Cs Demand
38
Largest Region C Suppliers Dallas Water
Utilities
  • Supplies many other communities
  • Current supply Lakes Ray Roberts, Lewisville,
    Ray Hubbard and Tawakoni
  • Planned supplies
  • Conservation
  • Reuse
  • Existing Lakes Fork, Palestine, Wright Patman
  • New Lake Fastrill

39
Dallas Planned Supplies
40
Largest Region C Suppliers Tarrant Regional
Water District
  • Supplies Fort Worth, Arlington, many others
  • Current supply Lakes Bridgeport, Eagle
    Mountain, Cedar Creek, Richland-Chambers
  • Planned supplies
  • Conservation
  • Reuse
  • Existing Toledo Bend Lake and Oklahoma supplies
  • New Marvin Nichols Reservoir

41
TRWDs Planned Supplies
42
Largest Region C Suppliers North Texas
Municipal Water District
  • Supplies communities north and east of Dallas
  • Current supply Lakes Lavon, Chapman, and
    Texoma, and reuse
  • Planned supplies
  • Conservation
  • Additional reuse
  • Existing Toledo Bend, Texoma, Oklahoma water
  • New Marvin Nichols and Lower Bois dArc Reservoirs

43
NTMWDs Planned Supplies
44
Development of 2011 Region C Water Plan
  • Current Issues and Next Steps in the Planning
    Process

45
Status of Planning Process
  • First Region C Water Plan 2001
  • Second Region C Water Plan 2006
  • Now working on 2011 Region C Water Plan
  • Special studies to examine emerging water supply
    issues
  • Water Conservation and Reuse Study
  • Toledo Bend Study (with Region I)
  • Direct and Indirect Reuse Study
  • Studies Pertaining to Localized Areas
  • Ellis, Johnson, southern Dallas, southern Tarrant
  • Parker Wise Counties

46
Planning Schedule
  • RCWPG public meetings
  • Sept. 28, 2009
  • Nov. 9, 2009
  • Jan. 2010
  • Mar. 2010
  • April 1, 2010 Initially Prepared Plan to TWDB
  • Summer 2010 Public hearings on IPP
  • Aug. 1, 2010 TWDB comments due
  • Oct. 1, 2010 final Region C Water Plan due
  • Dec. 31, 2010 TWDB Regional Plan review
  • Jan. 5, 2012 State Water Plan published

47
Next Steps in Planning
  • Reviewing updated population, demand projections
  • Evaluating potentially feasible water management
    strategies
  • Examining current issues

48
Current Issues in Planning
  • Implementing water conservation and reuse
  • Pursuing water from Oklahoma
  • Developing of selected new reservoirs
  • Drought response

49
Current Issues Implementing Water Conservation
  • North Texas often cited as water hogs
  • Comparisons difficult because no standard measure
    (GPCD not standardized)
  • Relatively high per capita municipal use
  • Low per capita overall use
  • Very little agricultural use
  • Low per capita industrial use

50
GPCD Background
  • Gallons Per Capita Day (GPCD)
  • GPCD is a metric that has been used to track and
    compare water usage among cities in Texas
  • No Standard Methodology
  • Texas Commission on Environmental Quality (TCEQ)
    Method
  • Texas Water Development Board (TWDB)
    Method
  • Water Conservation Implementation Task Force (SB
    1094) Method
  • Water Conservation Advisory Council
    (SB 3 HB 4) Method

51
Why is it Important to Accurately Measure Water
Usage/Conservation Progress?
  • TCEQ must consider before issuing permit for new
    water supply
  • TWDB must consider before providing State funding
  • Planners must consider whether savings can be
    relied upon for future water supply
  • Suppliers must consider to assess value of
    investment in water efficiency strategies

52
Factors Affecting GPCD Calculation
  • Water Usage Volume
  • Population Related Usage
  • Single Family Residential
  • Multi-Family Residential
  • Commercial Water Usage
  • Institutional Water Usage
  • Recreational/Public Water Usage
  • Active Conservation Programs
  • Water Use Accounting
  • Regional Economic Condition
  • Climate
  • Availability of Water Supply
  • Self-Supplied Users
  • Water Pricing
  • Amount of Reuse/Recycle

53
Factors Affecting GPCD Calculation
  • Population
  • Service Area Population
  • Accuracy of Population Count
  • Timeliness of Data
  • Commuter Influx
  • Growth vs. Mature Cities
  • Regional Economic Condition

54
Municipal Per Capita Water UseYear 2000
55
Municipal Per Capita Water UseYear 2006
56
Total Per Capita Water UseYear 2000
57
Most Recent 5-Year Trailing Net Municipal Per
Capita Water Use (2006 Plan)
Source 2006 Region C Water Plan
Modified Version
58
Most Recent 5-Year Trailing Net Municipal Per
Capita Water Use by Category (2006 Plan)
Source 2006 Region C Water Plan
59
Implementing Water Conservation Major Projects
  • Conservation awareness programs
  • Dallas Water Utilities and Tarrant Regional Water
    District Save Water, Nothing Can Replace It
  • DWU 12 billion gallons saved in 2006
  • TRWD 10 billion gallons saved in 2006
  • North Texas Municipal Water District Water IQ
    Program
  • NTMWD 10 billion gallons saved in 2006

60
Major Reuse Projects
  • Reuse projects totaling more than 730,000
    acre-feet/year developed or in-progress
  • NTMWD East Fork Raw Water Supply Project
  • TRWD George Shannon Wetlands
  • Upper Trinity Regional Water District reuse of
    Lake Chapman water
  • Garland/Forney reuse for power plant
  • Grapevine/Dallas County Park Cities Municipal
    Utility District
  • Dallas contract for return flows
  • Various others

61
Year 2060 Reuse Supplies
P
A
B
O
N
M
L
K
J
I
H
C
G
F
E
D
62
(No Transcript)
63
Current Issues Sourcing of Water from Oklahoma
  • TRWD, City of Dallas, Upper Trinity RWD and NTMWD
    jointly pursuing deal to pump water from Oklahoma
  • Water from Kiamichi River, Cache Creek and Beaver
    Creek basins
  • 2001 Oklahoma moratorium on out-of-state sales
  • TRWD challenged moratorium in federal court
  • TRWD taking lead on negotiations with Oklahoma
  • Aug. 2008 City of Irving signed agreement to
    purchase water from Hugo Lake in Oklahoma

64
Current Issues New Reservoirs
  • Last major new reservoirs in area about 20 years
    ago
  • Currently difficult to permit new reservoirs
  • 4 major new reservoirs in Region C Plan
  • Compare to 30 developed over last 50 years
  • New reservoirs less than 20 of 2060 supply
  • Sometimes least expensive and best option
  • Special study commission formed to examine Region
    C and D supply issues

65
Current Drought Conditions
66
Public Involvement
  • Attend public meetings, provide comments
  • Participate in Summer 2010 public hearing(s) on
    Initially Prepared Plan, provide comments on
    draft plan
  • Copies of IPP will be available in at least one
    major public library in each of the 16 Region C
    counties
  • IPP also available on Region C website
  • Meeting agendas and planning documents at
    www.regioncwater.org
  • Sign up to receive the semi-annual Region C
    newsletter

67
Closing Thoughts
  • Conservation is essential
  • Reuse should be encouraged
  • Additional new supplies are needed
  • Environmental flow needs are an issue
  • Interbasin transfers are essential

68
Closing Thoughts
  • New reservoirs are also needed
  • Current drought in Central Texas emphasizes
    importance of water supply, ample surplus
  • Public is a vital part of water planning
  • Now is the time for the public to take notice

69
QA and Contact Info
  • Jim Parks, RCWPG Chair
  • jparks_at_ntmwd.com, 972-442-5405
  • Tom Gooch, Freese Nichols
  • tcg_at_freese.com, 817-735-7314
  • Colby Walton, Cooksey Communications
  • colby_at_cookseypr.com, 972-580-0662 x23
  • TWDB Website
  • www.twdb.state.tx.us/home/index.asp
  • Region C Website
  • www.regioncwater.org
Write a Comment
User Comments (0)
About PowerShow.com
