P2P Over MANET

1
P2P Over MANET

• An Introduction to Mobile Resource Sharing

2
Introduction to MANETs

• Mobile Ad Hoc Network (MANET)
• Under research for the past 10 years
• Only a small amount of MANETs are currently used
  in the real world
• Autonomous system of mobile routers and nodes
• All elements reside on wireless domains
• Nodes can join and leave the network at any time
• Dynamic topology
• Wireless connectivity implements node mobility
• Primarily operates in the network layer (layer
  3), but can be implemented in other layers as
  well

3
MANET Interface

• Connecting point where nodes can attach1
• Allows MANETs to connect to each other
• Every MANET interface must have a unique
  identifier
• Neighborhood
• Time-varying asymmetric Reachability1

4
MANET Neighbors
5
MANET Asymmetric Readability
6
MANET Router (MR)

• Has one or more MANET interfaces
• May have zero or more non-MANET interfaces 1
• Hides MANET characteristics from all nodes that
  do not support MANET
• Only one MR is required to setup a MANET,
  however, the more the better

7
MANETs and Other Wireless Network Technologies

• IEEE 802.11 (WI-FI) can not be used to implement
  a MANET, they do not share characteristics
• WI-FI is just a wireless version of a wired
  network3
• The two main differences in WI-FI and MANETs
• WI-FI operates in the data-link layer (layer 2)
  and MANETs must exist in the network layer
• Access points are required for a WI-FI network to
  effectively work, which is a rule that is not
  bound to MANETs
• Bluetooth has been successfully used to
  implemented a MANET

8
MANETs and Existing Wired Networks

• Can be implemented as an overlay on top of any
  wired topology or network
• Routers which support intercommunication can have
  two or more interfaces including MANET interface
• Specific MANET routing protocols are used to
  route traffic across its network
• MANET packets are encapsulated in IP packets and
  vice versa
• In an MANET overlay, a node on the MANET network
  can communication with a node located on an IP
  network. This transformation is bi-directional

9
Asymmetric Reachability
10
Peer to Peer (P2P)

• An Overview of P2P will start here and continue
  for the next 3 to 5 slides

11
P2P Over MANET

• A mobile ad hoc network with a peer to peer
  overly
• The MANET will operate in the first four layers
  of the OSI model, while P2P will run in the
  fourth through seventh layer
• Both inhibit similar characteristics
• Next generation of client based networks

12
P2P Over MANET

• Can be implemented in more than one way
  considering that
• There is more than one MANET protocol
• P2P can be built as a structured, unstructured,
  data-centric, overlay, or hybrid architecture.
• Each P2P architecture has a multitude of
  protocols and characteristics which inhibit
  different features and constraints
• A structured P2P architecture works best with
  MANETs
• Structured P2P uses Distributed Hash Tables
  (DHT), which there are many to choose from with
  different characteristics i.e. Chord, Pastry,
  etc.

13
P2P Over MANET Protocol Stack
P2P
OSI
Application
Application
Presentation
Presentation
Session Layer
Session Layer
MANET
Transport
Transport
Transport
Network
Network
Data-link
Data-link
Physical
Physical
14
Homogeneous Characteristics of P2P and MANET

• Supports node churning2 consistency of nodes
  entering and leaving the network
• Traffic patterns closely resemble those caused by
  multi-hop broadcasting or multicasting 3
• Dynamic topology
• The ability for nodes to rearrange themselves
  when connecting to the network
• Fault tolerant resistant and transparent to
  errors
• Unique Identifiers are required to identify nodes

15
Why P2P Over MANET

• Put some good stuff to say here about the
  benefits of P2P Over MANET

16
P2P Over MANET Architectures

• The P2P Over MANET description of architectures
  starts here and will continue for the next 3 to 5
  slides.

17
Example of P2P Over MANET Architecture

• This slides starts the description of example and
  will continue for the next 4 to 6 slides

18
Typical Problems with P2P Over MANET

• Put some things that need to be fixed with P2P
  Over MANET here

19
Possible Applications for P2P Over MANET

• The applications for P2P Over MANET starts here
  and continues for maybe one more slide

20
References

• References will go here
