Energy Diagrams: Drawing it Out

1
Energy Diagrams Drawing it Out
2
Why are we learning this?

• Energy diagrams show how a reaction works.
• Energy diagrams display
• The energy of reactants and products
• The energy needed for a reaction to occur
• The energy absorbed or released due to reaction

3
Energy Diagram Parts

• Potential Energy of the reactants
• Potential Energy of the products
• Activation Energy E the amount of energy
  required to reach the transition state or
  activated complex from the reactant
• Transition State, Ts (Activated Complex) when
  bonds break and form and reactants become
  products
• Enthalpy, DH science word for heat, Energy of
  products energy of reactants

4
Potential and Kinetic Energy Changes during a
Collision Endothermic    Reactants Activated
Complex Products
5
Potential and Kinetic Energy Changes during a
Collision Endothermic    Reactants Activated
Complex Products
6
Potential and Kinetic Energy Changes during a
Collision Endothermic    Reactants Activated
Complex Products
7
Potential and Kinetic Energy Changes during a
Collision Endothermic    Reactants Activated
Complex Products
8
Potential and Kinetic Energy Changes during a
Collision Endothermic    Reactants Activated
Complex Products         Potential
Energy
9
Potential and Kinetic Energy Changes during a
Collision Endothermic    Reactants Activated
Complex Products         Potential
Energy
10
Potential and Kinetic Energy Changes during a
Collision Endothermic    Reactants Activated
Complex Products         max Potential
Energy high    low
11
Potential and Kinetic Energy Changes during a
Collision Endothermic    Reactants Activated
Complex Products         max Potential
Energy high    low     Kinetic
Energy
12
Potential and Kinetic Energy Changes during a
Collision Endothermic    Reactants Activated
Complex Products         max Potential
Energy high    low     Kinetic
Energy high min low
13
Potential and Kinetic Energy Changes during a
Collision Endothermic    Reactants Activated
Complex Products         max Potential
Energy high    low   Uphill-
endothermic!   Kinetic Energy high
min low
14
Putting Pieces Together

• Transition State, Ts

Activation Energy of forward reaction, EF EF Ts
- Reactants
Reactants
Enthalpy of forward reaction, DHF
Products
DHF Products - Reactants
Energy
Reaction
15
Putting Pieces Together

• Transition State, Ts

Activation Energy of reverse reaction, ER ER Ts
- Products
Reactants
Enthalpy of forward reaction, DHR
Products
DHR Reactants - Products
Energy
Reaction
16
Types of Energy Diagrams

• Endothermic the reaction absorbs heat so DH is
  positive
• The reactants have less potential energy than the
  products

A - - - B
AB
DH gt 0
A B
17
Types of Energy Diagrams

• Exothermic the reaction releases heat so DH is
  negative
• The reactants have more potential energy than the
  products

A - - - B
A B
DH lt 0
AB
18
Types of Energy Diagrams

• Catalysts lower the activation energy of a
  reaction by finding an alternate route. However,
  the change in heat, or enthalpy is the same.

Blue without Catalyst Green with Catalyst
A - - - B
A B
DH lt 0
AB
19
Try it together
250
Use the numbers to find What is EF? What is
DHF? What is DHR? What is ER?
200
150
100
50
20
Pick the slow and fast reaction
Slow
Fast- low Ea
