Controlling Gene Expression

1
Controlling Gene Expression

• Timothy G. Standish, Ph. D.

2
All Genes Cant be Expressed At The Same Time

• Some genes are needed for the function of all
  cells all the time. These genes are called
  constitutive genes and are expressed by all
  cells.
• Other genes are only needed by certain cells or
  at specific times. The expression of these
  inducible genes is tightly controlled in most
  cells.
• For example, beta cells in the pancreas make the
  protein insulin by expressing the insulin gene.
  If neurons expressed insulin, problems would
  result.

3
Operons Are Groups Of Genes Expressed By
Prokaryotes

• The genes grouped in an operon are all needed to
  complete a given task
• Each operon is controlled by a single control
  sequence in the DNA
• Because the genes are grouped together, they can
  be transcribed together then translated together

4
The Lac Operon

• Genes in the lac operon allow E. coli bacteria
  to metabolize lactose
• Lactose is a sugar that E. coli is unlikely to
  encounter, so it would be wasteful to produce the
  proteins needed to metabolize it unless necessary
• Metabolizing lactose for energy only makes sense
  when two criteria are met
• Other more readily metabolized sugar (glucose) is
  unavailable
• Lactose is available

5
The Lac Operon - Parts

• The lac operon is made up of a control region and
  four genes
• The four genes are
• LacZ - b-galactosidase - An enzyme that
  hydrolizes the bond between galactose and glucose
• LacY - Codes for a permease that lets lactose
  across the cell membrane
• LacA - Transacetylase - An enzyme whose function
  in lactose metabolism is uncertain
• Repressor - A protien that works with the control
  region to control expression of the operon

6
The Lac Operon - Control

• The control region is made up of two parts
• Promoter
• These are specific DNA sequences to which RNA
  Polymerase binds so that transcription can occur
• The lac operon promoter also has a binding site
  for another protein called CAP
• Operator
• The binding site of the repressor protein
• The operator is located down stream (in the 3
  direction) from the promoter so that if repressor
  is bound RNA Polymerase cant transcribe

7
The Lac OperonWhen Glucose Is Present But Not
Lactose
Come on, let me through
RNA Pol.
No way Jose!
8
The Lac OperonWhen Glucose And Lactose Are
Present
Great, I can transcribe!
RNA Pol.
Lac
This lactose has bent me out of shape
Some transcription occurs, but at a slow rate
9
The Lac OperonWhen Lactose Is Present But Not
Glucose
Bind to me Polymerase
Yipee!
RNA Pol.
Lac
This lactose has bent me out of shape
10
The Lac OperonWhen Neither Lactose Nor Glucose
Is Present
Bind to me Polymerase
Come on, let me through!
RNA Pol.
STOP Right there Polymerase
11
The Trp Operon

• Genes in the trp operon allow E. coli bacteria
  to make the amino acid tryptophan
• Enzymes encoded by genes in the trp operon are
  all involved in the biochemical pathway that
  converts the precursor chorismate to tryptophan.
• The trp operon is controlled in two ways
• Using a repressor that works in exactly the
  opposite way from the lac operon repressor
• Using a special attenuator sequence

12
The TryptophanBiochemical Pathway
13
The Trp OperonWhen Tryptophan Is Present
Foiled Again!
RNA Pol.
STOP Right there Polymerase
14
Attenuation

• The trp operon is controlled both by a repressor
  and attenuation
• Attenuation is a mechanism that works only
  because of the way transcription and translation
  are coupled in prokaryotes
• Therefore, to understand attenuation, it is first
  necessary to understand transcription and
  translation in prokaryotes

15
Transcription And Translation In Prokaryotes
16
The Trp Leader and Attenuator
Met-Lys-Ala-Ile-Phe-Val
- AAGUUCACGUAAAAAGGGUAUCGACA-AUG-AAA-GCA-AUU-UUC-G
UA- Leu-Lys-Gly-Trp-Trp-Arg-Thr-Ser-STOP CUG-AAA-
GGU-UGG-UGG-CGC-ACU-UCC-UGA-AACGGGCAGUGUAUU CACC
AUGCGUAAAGCAAUCAGAUACCCAGCCCGCCUAAUGAGCGGGCUUUU
Met-Gln-Thr-Gln-Lys-Pro
UUUU-GAACAAAAUUAGAGAAUAACA-AUG-CAA-ACA-CAA-AAA-CCG

trpE . . . Terminator
17
The mRNA Sequence Can Fold In Two Ways
Terminator haripin
18
The Attenuator When Starved For Tryptophan
RNA Pol.
Help, I need Tryptophan
19
The Attenuator When Tryptophan Is Present
RNA Pol.
RNA Pol.
20
Control Of Expression In Eukaryotes

• Some of the general methods used to control
  expression in prokaryotes are used in eukaryotes,
  but nothing resembling operons is known
• Eukaryotic genes are controlled individually and
  each gene has specific control sequences
  preceding the transcription start site
• In addition to controling transcription, there
  are additional ways in which expression can be
  controlled in eukaryotes

21
Eukaryotes Have Large Complex Geneomes

• The human genome is about 3 x 109 base pairs or
  1 m of DNA
• Because humans are diploid, each nucleus contains
  6 3 x 109 base pairs or 2 m of DNA
• That is a lot to pack into a little nucleus!

22
Eukaryotic DNA Must be Packaged

• Eukaryotic DNA exhibits many levels of packaging
• The fundamental unit is the nucleosome, DNA wound
  around histone proteins
• Nucleosomes arrange themselves together to form
  higher and higher levels of packaging.

23
Highly Packaged DNA Cannot be Expressed

• The most highly packaged form of DNA is
  heterochromatin
• Heterochromatin cannot be transcribed, therefore
  expression of genes is prevented
• Chromosome puffs on some insect chomosomes
  illustrate where active gene expression is going
  on

24
Only a Subset of Genes is Expressed at any Given
Time

• It takes lots of energy to express genes
• Thus it would be wasteful to express all genes
  all the time
• By differential expression of genes, cells can
  respond to changes in the environment
• Differential expression, allows cells to
  specialize in multicelled organisms.
• Differential expression also allows organisms to
  develop over time.

25
Control of Gene Expression
Packaging
Transportation
26
Logical Expression Control Points

• DNA packaging
• Transcription
• RNA processing
• mRNA Export
• mRNA masking/unmasking and/or modification
• mRNA degradation
• Translation
• Protein modification
• Protein transport
• Protein degradation

The logical place to control expression is before
the gene is transcribed
27
A Simple Eukaryotic Gene
Transcription Start Site
3 Untranslated Region
5 Untranslated Region
Introns
3
5
Int. 2
Int. 1
Exon 2
Exon 3
Exon 1
Terminator Sequence
Promoter/ Control Region
Exons
RNA Transcript
28
Enhancers
Many bases
TF
TF
TF
29
Eukaryotic mRNA
3 Untranslated Region
5 Untranslated Region
3
5
G
AAAAA
Exon 2
Exon 3
Exon 1
Protein Coding Region
3 Poly A Tail
5 Cap

• RNA processing achieves three things
• Removal of introns
• Addition of a 5 cap
• Addition of a 3 tail
• This signals the mRNA is ready to move out of the
  nucleus and may control its life span in the
  cytoplasm

30
(No Transcript)
