Title: Chapter 9 Optics (Section 4)


1
Chapter 9Optics(Section 4)
2
9.4 Lenses and Images
  • In Section 9.2, we described how curved mirrors
    are used in astronomical telescopes and other
    devices to redirect light rays in useful ways.
  • Microscopes, binoculars, cameras, and many other
    optical instruments use specially shaped pieces
    of glass called lenses to alter the paths of
    light rays.
  • As was the case with mirrors, the key to making
    glass or other transparent substances redirect
    light is the use of curved surfaces (interfaces)
    rather than flat (planar) ones.

3
9.4 Lenses and Images
  • Suppose we grind a block of glass so that one end
    takes the shape of a segment of a sphere as shown
    in cross section in the figure.

4
9.4 Lenses and Images
  • Let parallel rays strike the convex spherical
    surface at various points above and below the
    line of symmetry (called the optical axis) of the
    system.
  • If one applies the law of refraction at each
    point to determine the angle of refraction of
    each ray, the results shown in the figure.
  • In particular, rays traveling along the optical
    axis emerge from the interface undeviated.

5
9.4 Lenses and Images
  • Rays entering the glass at points successively
    above or below the optical axis are deviated ever
    more strongly toward the optical axis.
  • The result is to cause the initially parallel
    bundle of rays to gradually converge togetherto
    become focusedinto a small region behind the
    interface.
  • This point is called the focal point and is
    labeled F in the figure.

6
9.4 Lenses and Images
  • The figure shows the behavior of parallel rays
    refracted across a spherical interface that,
    instead of bowing outward, curves inward.
  • In this case, the emergent rays diverge outward
    as though they had originated from a point F to
    the left of the interface.

7
9.4 Lenses and Images
  • The ability to either bring together or spread
    apart light rays is the basic characteristic of
    lenses, be they camera lenses, telescope lenses,
    or the lenses in human eyes.

8
9.4 Lenses and Images
  • In most devices the light rays must enter and
    then leave the optical element (lens) that
    redirects them.
  • Common lenses have two refracting surfaces
    instead of one, with one surface typically in the
    shape of a segment of a sphere and the second
    either spherical as well or flat (planar).

9
9.4 Lenses and Images
  • The effect on parallel light rays passing through
    both surfaces is similar to that in the previous
    examples with one refracting surface.
  • A converging lens causes parallel light rays to
    converge to a point, called the focal point of
    the lens.

10
9.4 Lenses and Images
  • The distance from the lens to the focal point is
    called the focal length of the lens.
  • A more sharply curved lens has a shorter focal
    length.
  • Conversely, if a tiny source of light is placed
    at the focal point, the rays that pass through
    the converging lens will emerge parallel to each
    other. This is the principle of reversibility
    again.

11
9.4 Lenses and Images
  • A diverging lens causes parallel light rays to
    diverge after passing through it.
  • These emergent rays appear to be radiating from a
    point on the other side of the lens.
  • This point is the focal point of the diverging
    lens.

12
9.4 Lenses and Images
  • The distance from the lens to the focal point is
    again called the focal length, but for a
    diverging lens it is given as a negative number,
    15 centimeters, for example.
  • If we reverse the process and send rays
    converging toward the focal point into the lens,
    they emerge parallel.

13
9.4 Lenses and Images
  • For both types of lenses there are two focal
    points, one on each side.
  • Clearly, if parallel light rays enter a
    converging lens from the right side in the
    figure, they will converge to the focal point to
    the left of the lens.

14
9.4 Lenses and Images
  • Whether a lens is diverging or converging can be
    determined quite easily
  • If it is thicker at the center than at the edges,
    it is a converging lens
  • if it is thinner at the center, it is a diverging
    lens.

15
9.4 Lenses and ImagesImage Formation
  • The main use of lenses is to form images of
    things.
  • First, lets consider the basics of image
    formation when a symmetric converging lens is
    used.
  • Our eyes, most cameras (both still and video),
    slide projectors, movie projectors, and overhead
    projectors all form images this way.

16
9.4 Lenses and ImagesImage Formation
  • The figure illustrates how light radiating from
    an arrow, called the object, forms an image on
    the other side of the lens.
  • One practical way of demonstrating this would be
    to point a flashlight at the arrow so that light
    would reflect off the arrow and pass through the
    lens.
  • The image could be projected onto a piece of
    white paper placed at the proper location to the
    right of the lens.

17
9.4 Lenses and ImagesImage Formation
  • Although each point on the object has countless
    light rays spreading out from it in all
    directions, it is simpler to consider only three
    particular rays from a single pointthe arrows
    tip.
  • These rays are called the principal rays.
  • 1. The ray that is initially parallel to the
    optical axis passes through the focal point (F)
    on the other side of the lens.

18
9.4 Lenses and ImagesImage Formation
  • 2. The ray that passes through the focal point
    (F) on the same side of the lens as the object
    emerges parallel to the optical axis.
  • 3. The ray that goes exactly through the center
    of the lens is undeviated because the two
    interfaces it encounters are parallel.

19
9.4 Lenses and ImagesImage Formation
  • Note that the image is not at the focal point of
    the lens. Only parallel incident light rays
    converge to this point (assuming an ideal lens).

20
9.4 Lenses and ImagesImage Formation
  • We could draw principal rays from each point on
    the object, and they would converge to the
    corresponding point on the image.
  • This kind of image formation occurs when you take
    a photograph or view a slide on a projection
    screen.

21
9.4 Lenses and ImagesImage Formation
  • In the latter case, light radiating from each
    point on the slide converges to a point on the
    image on the screen.
  • Note that the image is inverted (upside down).
  • Thats why you load slides in the tray or
    carousel upside down if you want their images to
    be right side up.

22
9.4 Lenses and ImagesImage Formation
  • The distance between the object and the lens is
    called the object distance, represented by s, and
    the distance between the image and the lens is
    called the image distance, p.
  • By convention (with the light traveling from left
    to right), s is positive when the object is to
    the left of the lens, and p is positive when the
    image is to the right of the lens.

23
9.4 Lenses and ImagesImage Formation
  • If we place the object at a different point on
    the optical axis, the image would also be formed
    at a different point. In other words, if s
    changes, then so does p.
  • Using a lens with a different focal length for
    fixed s would also cause p to change.
  • For example, the image would be closer to the
    lens if the focal length were shorter.

24
9.4 Lenses and ImagesImage Formation
  • The following equation, known as the lens
    formula, relates the image distance p to the
    focal length f and the object distance s.

25
9.4 Lenses and ImagesExample 9.3
  • In a slide projector, a slide is positioned 0.102
    meter from a converging lens that has a focal
    length of 0.1 meter.
  • At what distance from the lens must the screen be
    placed so that the image of the slide will be in
    focus?

26
9.4 Lenses and ImagesExample 9.3
  • The screen needs to be placed a distance p from
    the lens, where p is the image distance for the
    given focal length and object distance. So

27
9.4 Lenses and Images Example 9.3
  • If the slide-to-lens distance is increased to
    0.105 meter (about a 3 change), the distance to
    the screen (p) would have to be reduced to 2.1
    meters (more than a factor of 2.4 reduction in
    distance).
  • If the lens is replaced by one that has a shorter
    focal length, the distance to the screen would
    have to be reduced as well.

28
9.4 Lenses and ImagesImage Formation
  • The images formed in the manner just described
    are called real images.
  • Such images can be projected onto a screen.
  • We see the image on the screen because the light
    striking the screen is diffusely reflected to our
    eyes.

29
9.4 Lenses and ImagesImage Formation
  • A simple magnifying glass is a converging lens,
    but the image that it forms under normal use is
    not a real imageit cant be projected onto a
    screen.
  • We see the image by looking into the lens, just
    as we see a mirror image by looking into the
    mirror.
  • This type of image is called a virtual image,
  • similar to the image formed by a concave mirror

30
9.4 Lenses and ImagesImage Formation
  • The figure shows how an image is formed in a
    magnifying glass.
  • In this case, the object is between the focal
    point F and the lens, so the object distance s
    is less than the focal length f of the lens.

31
9.4 Lenses and ImagesImage Formation
  • Note that the image is enlarged and that it is
    upright.
  • It is also on the same side of the lens as the
    object, which means that p is negative.

32
9.4 Lenses and ImagesExample 9.4
  • A converging lens with focal length 10
    centimeters is used as a magnifying glass.
  • When the object is a page of fine print 8
    centimeters from the lens, where is the image?

33
9.4 Lenses and ImagesExample 9.4
  • The negative value for p indicates that the image
    is on the same side of the lens as the object.
  • Therefore, it is a virtual image and must be
    viewed by looking through the lens.

34
9.4 Lenses and ImagesImage Formation
  • A virtual image is also formed when you look at
    an object through a diverging lens.
  • In this case, the image is smaller than the
    object, as it is with a convex mirror.

35
9.4 Lenses and ImagesMagnification
  • One of the most useful properties of lenses is
    they can be used to produce images that are
    enlarged (larger than the original object) or
    reduced (smaller than the original object).
  • In either case, the magnification, M, of a
    particular configuration is the height of the
    image divided by the height of the object.

36
9.4 Lenses and ImagesMagnification
  • If the image is twice the height of the object,
    the magnification is 2.
  • If the image is upright, the magnification is
    positive.
  • If the image is inverted, the magnification is
    negative (because the image height is negative).

37
9.4 Lenses and ImagesMagnification
  • The magnification that one gets with a particular
    lens changes if the object distance is changed.
  • Because of the simple geometry, the magnification
    also can be written in an alternate, equivalent
    form as minus the image distance divided by the
    object distance.

38
9.4 Lenses and ImagesMagnification
  • From this we can conclude that
  • If p is positive (image is to the right of the
    lens and real), M is negative the image is
    inverted.

39
9.4 Lenses and ImagesMagnification
  • If p is negative (image is to the left of the
    lens and virtual), M is positive the image is
    upright.

40
9.4 Lenses and ImagesExample 9.5
  • Compute the magnification for the projector in
    Example 9.3 and for the magnifying glass in
    Example 9.4.
  • In the first case in Example 9.3, s 0.102
    meters and p 5.1 meters.
  • Therefore

41
9.4 Lenses and ImagesExample 9.5
  • The image is 50 times as tall as the object, but
    it is inverted (because M is negative).
  • A slide that is 35 millimeters tall has an image
    on the screen that is 1,750 millimeters (1.75
    meters) tall.
  • When s is 0.105 meters, p is 2.1 meters, and the
    magnification is 20.

42
9.4 Lenses and ImagesMagnification
  • In Example 9.4, s 8 cm and p 40 cm.
    Consequently
  • The image of the print seen in the magnifying
    glass is five times as large as the original, and
    it is upright (because M is positive).

43
9.4 Lenses and ImagesMagnification
  • Telescopes and microscopes can be constructed by
    using two or more lenses together.
  • The figure shows a simple telescope consisting of
    two converging lenses.

44
9.4 Lenses and ImagesMagnification
  • The real image formed by lens 1 becomes the
    object for lens 2.
  • The light that could be projected onto a screen
    to form the image for lens 1 simply passes on
    into lens 2.

45
9.4 Lenses and ImagesMagnification
  • In essence, lens 2 acts as a magnifying glass and
    forms a virtual image of the object.
  • In this telescope, the image is magnified but
    inverted.
  • Replacing lens 2 with a diverging lens yields a
    telescope that produces an upright image.

46
9.4 Lenses and ImagesAberrations
  • In real life, lenses do not form perfect images.
  • Suppose we carefully apply the law of refraction
    to a number of light rays, all initially parallel
    to the optical axis, as they pass through a real
    lens that has a surface shaped like a segment of
    a sphere.

47
9.4 Lenses and ImagesAberrations
  • We would find that the lens exhibits the same
    flaw we saw in Section 9.2 with spherically
    shaped curved mirrors spherical aberration.
  • Rays striking the lens at different points do not
    cross the optical axis at the same place.

48
9.4 Lenses and ImagesAberrations
  • In other words, there is no single focal point.
  • This causes images formed by such lenses to be
    somewhat blurred.
  • Lens aberrations of this type can be corrected,
    but this process is complicated and often
    necessitates the use of several simple lenses in
    combination.

49
9.4 Lenses and ImagesAberrations
  • Another type of aberration shared by all simple
    lenses even when used under ideal conditions is
    chromatic aberration.
  • A lens affected by chromatic aberration, when
    illuminated with white light, produces a sequence
    of more or less overlapping images, varying in
    size and color.

50
9.4 Lenses and ImagesAberrations
  • If the lens is focused in the yellow-green
    portion of the EM spectrum where the eye is most
    sensitive, then all the other colored images are
    superimposed and out of focus, giving rise to a
    whitish blur or fuzzy overlay.
  • For a converging lens, the blue images would form
    closer to the lens than the yellow-green images,
    whereas the reddish images would be brought to a
    focus farther from the lens than the yellow-green
    ones.

51
9.4 Lenses and ImagesAberrations
  • The cause of chromatic aberration has its roots
    in the phenomenon of dispersion.
  • The remedy for this problem, originally thought
    to be insoluble by none other than Newton
    himself, was discovered around 1733 by C. M. Hall
    and later (in 1758) developed and patented by
    John Dolland, a London optician.
  • It involves using two different types of glass
    mounted in close proximity.

52
9.4 Lenses and ImagesAberrations
  • The figure shows a common configuration called a
    Fraunhofer cemented achromat (meaning not
    colored).
  • The first lens is made of crown glass, the second
    of dense flint glass.
  • These materials are chosen because they have
    nearly the same dispersion.

53
9.4 Lenses and ImagesAberrations
  • To the extent to which this is true, the excess
    convergence exhibited by the first lens at bluish
    wavelengths is compensated for by the excess
    divergence produced by the second lens at these
    same wavelengths.
  • Similar effects occur at the other wavelengths in
    the visible spectrum, permitting cemented
    doublets of this type to correct more than 90
    percent of the chromatic aberration found in
    simple lenses.
Write a Comment
User Comments (0)
About PowerShow.com
