Earth

1
PLAY
SCIENCE
Earth
Battleship
From RegentsEarth.com
2
How to play Earth Science Battleship
Divide the class into two teams, Red and Purple.
Choose which team goes first.
The main screen is divided into 49 boxes. The
first team chooses a box by letter and number, E4
for instance.
Each team or the team captain must be told which
squares hide their ships. (see notes below this
slide)
Click on the Q at the center of the square.
Be careful to click only on the Q. A question
will appear.
IF the team answers the question correctly, click
on return to board. This will take you back to
the main game board.
Now click anywhere else in the box (except the
Q). The box will disappear and you find out if
you hit and destroyed one of the enemy ships.
If the team did not answer the question correctly
simply return to the main board and allow the
other team to choose a box and answer a question.
The first team to successfully sink all four of
the other teams ships wins.
The RED team must sink purple ships and the
PURPLE team must sink red ships.
(if youre playing at home to review, click on
answer for the correct response)
Get out your reference tables. Lets play!
3
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
4
Question A1
Click timer to start 1 min. countdown.
What is the most important source of energy for
all Earth processes?
ANSWER
The Sun
Back to main board
5
Question A2
Click timer to start 1 min. countdown.
By what method is energy transferred from the
light bulb to the cans?
ANSWER
Radiation
Back to main board
6
Question A3
Click timer to start 1 min. countdown.
What kind of energy is represented by A in the
diagram?
ANSWER
Short wave visible light
Back to main board
7
Question A4
Click timer to start 1 min. countdown.
What kind of energy is represented by B in the
diagram?
ANSWER
Long wave infrared
Back to main board
8
Question A5
Click timer to start 1 min. countdown.
Which gas or gases in our atmosphere act in
the same way as the glass in this
greenhouse? (Any one will do)
ANSWER
CO2, Water vapor, methane, CFCs
Back to main board
9
Question A6
Click timer to start 1 min. countdown.
Infrared radiation given off by the Earth is
known as..................
ANSWER
Terrestrial radiation
Back to main board
10
Question A7
Click timer to start 1 min. countdown.
By what method is heat energy transferred
from side A to side B?
ANSWER
Conduction
Back to main board
11
Question B1
Click timer to start 1 min. countdown.
Which location is a heat sink for location D?
ANSWER
Location B
Back to main board
12
Question B2
Click timer to start 1 min. countdown.
A rock is ejected from a volcano. As the rock
moves from location A to location B, it will have
more ........... and less ....... (fill in
the blanks)
ANSWER
More Pe and less Ke
Back to main board
13
Question B3
Click timer to start 1 min. countdown.
Which diagram correctly shows the movement of
air in this system?
1
3
2
4
ANSWER
Choice 4
Back to main board
14
Question B4
Click timer to start 1 min. countdown.
When this closed system finally reaches
equilibrium what will be the temperature on both
sides of the metal dividing wall?
ANSWER
45C
Back to main board
15
Question B5
Click timer to start 1 min. countdown.
The graph shows the rate at which 4 different
materials increased in temperature when exposed
to the same heat source. When the heat source is
removed which material will cool at the greatest
rate and explain why.
ANSWER
Lead will cool fastest because it has the
smallest specific heat.
Back to main board
16
Question B6
Click timer to start 1 min. countdown.
How much energy will be released when a gram of
water vapor condenses into liquid water?
ANSWER
2260 Joules
Back to main board
17
Question B7
Click timer to start 1 min. countdown.
A student added 100 joules of heat energy to each
of 10g samples of copper, granite, dry air,
and iron. Which sample will experience the
greatest temperature increase?
ANSWER
Copper
Back to main board
18
Question C1
Click timer to start 1 min. countdown.
Which method of heat transfer is shown in
the diagram?
ANSWER
Convection
Back to main board
19
Question C2
Click timer to start 1 min. countdown.
By which method is energy transferred from the
Sun to Saturn?
ANSWER
Radiation
Back to main board
20
Question C3
Click timer to start 1 min. countdown.

90 of solar energy is in the form of........
ANSWER
Visible light
Back to main board
21
Question C4
Click timer to start 1 min. countdown.
By which method is heat transferred through the
gold bar?
ANSWER
Conduction
Back to main board
22
Question C5
Click timer to start 1 min. countdown.
If a material is a good radiator of energy it
must also be a good....................
ANSWER
Absorber
Back to main board
23
Question C6
Click timer to start 1 min. countdown.
List two characteristics of a good absorber of
electromagnetic energy.
ANSWER
Dark color, rough surface
Back to main board
24
Question C7
Click timer to start 1 min. countdown.
Which two materials could be both a heat source
and a heat sink in this system?
ANSWER
Air and basalt
Back to main board
25
Question D1
Click timer to start 1 min. countdown.
Which letter represents air with the
greatest density?
ANSWER
Location E
Back to main board
26
Question D2
Click timer to start 1 min. countdown.
How many Joules of heat energy would be needed to
change 10g of ice at 0C into liquid water at 0C?
ANSWER
3,334 Joules
Back to main board
27
Question D3
Click timer to start 1 min. countdown.
Which method of heat transfer depends on density
differences?
ANSWER
Convection
Back to main board
28
Question D4
Click timer to start 1 min. countdown.
Which of the processes in illustration
would release the greatest amount of energy
into the environment?
ANSWER
Condensation
Back to main board
29
Question D5
Click timer to start 1 min. countdown.
Between which two points is the greatest amount
of energy being added to this system. Note The
order of your answer is important.
ANSWER
Between points D and E
Back to main board
30
Question D6
Click timer to start 1 min. countdown.
According to the chart, the best absorber of
insolation is.........
ANSWER
Water (Sun overhead)
Back to main board
31
Question D7
Click timer to start 1 min. countdown.
If all of the energy lost by the hot cup is
gained by the cold cup what will be the
temperature of both cups after they
reach equilibrium?
ANSWER
25C
Back to main board
32
Question E1
Click timer to start 1 min. countdown.
Which line on the graph represents the
relationship between the Fahrenheit and Celsius
temperature scales?
ANSWER
Line A
Back to main board
33
Question E2
Click timer to start 1 min. countdown.
Which graph represents the probable relationship
between the temperatures of the two cups over the
20 minutes of this experiment?
ANSWER
Choice 3
Back to main board
34
Question E3
Click timer to start 1 min. countdown.
Between which two locations is water
freezing? Note The order of your answer is
important.
ANSWER
From C to B
Back to main board
35
Question E4
Click timer to start 1 min. countdown.
What is the freezing point of water in K?
ANSWER
Back to main board
273C
36
Question E5
Click timer to start 1 min. countdown.
Which of the following is the lowest temperature?
1) 42F 2) 11C 3) 283K
ANSWER
Choice 1
Back to main board
37
Question E6
Click timer to start 1 min. countdown.
What was the rate of temperature decrease of the
hot water from time 4 to time 9? Your answer must
include proper units.
ANSWER
2C/min
Back to main board
38
Question E7
Click timer to start 1 min. countdown.
Which is smallest, a degree Fahrenheit, a
degree Celsius or a degree Kelvin?
ANSWER
A F
Back to main board
39
Question F1
Click timer to start 1 min. countdown.
Which process requires the addition of energy to
water?
1) Freezing 2) Condensation 3) Evaporation
4) Cooling
ANSWER
Evaporation
Back to main board
40
Question F2
Click timer to start 1 min. countdown.
If equal amounts of heat energy was added to each
of the 4 samples, which would show the smallest
change of temperature?
ANSWER
The water
Back to main board
41
Question F3
Click timer to start 1 min. countdown.
ANSWER
Choice 1
Back to main board
42
Question F4
Click timer to start 1 min. countdown.
Which would reflect the greatest amount of
insolation?
1) The ocean 2) A forest 3) A glacier 4)
A plowed field
ANSWER
A glacier
Back to main board
43
Question F5
Click timer to start 1 min. countdown.
As compared to the wavelengths of solar
radiation, the wavelength of terrestrial
radiation is.........
1) Longer 2) Shorter 3) The same
ANSWER
Longer
Back to main board
44
Question F6
Click timer to start 1 min. countdown.
Equal amounts of heat energy are added to 50g
samples of ice, dry air, copper, and granite.
Which material will experience the greatest
increase in temperature?
ANSWER
Copper
Back to main board
45
Question F7
Click timer to start 1 min. countdown.
How many Joules of heat energy will be
released when 100g of water freezes?
ANSWER
33,400 Joules
Back to main board
46
Question G1
Click timer to start 1 min. countdown.
A thirsty student poured some water into a glass
filled with ice cubes. She stirred the water-ice
mixture thoroughly and, before the ice melted she
sipped the water. What was the temperature of the
water in F?
ANSWER
32F
Back to main board
47
Question G2
Click timer to start 1 min. countdown.
By what process does light pass through window
glass?
ANSWER
Radiation
Back to main board
48
Question G3
Click timer to start 1 min. countdown.
The letters represent processes that can occur
when water changes phase. Which process requires
the addition of 2260 Joules?
ANSWER
Process C, vaporization
Back to main board
49
Question G4
Click timer to start 1 min. countdown.
Which cross section shows the most likely
directions of surface winds that will develop at
a shore location on a hot summer afternoon?
ANSWER
Back to main board
Choice 2
50
Question G5
Click timer to start 1 min. countdown.
Which cross section shows the most likely pattern
of air movement in the Earths atmosphere?
ANSWER
Back to main board
Choice 2
51
Question G6
Click timer to start 1 min. countdown.
At first both cans increased in temperature but
eventually the increase stopped even though the
light bulb remained on. What condition must
have caused the cans to remain at a constant
temperature?
ANSWER
Back to main board
They reached radiative balance
52
Question G7
Click timer to start 1 min. countdown.
What term describes a material that is
an exceptionally poor conductor of heat?
ANSWER
Insulator
Back to main board
