Using wavelets on the XBOX360

1
Using wavelets on the XBOX360

• For current and future games
• San Francisco, GDC 2008

Mike Boulton Senior Software Engineer Rare/MGS mb
oulton_at_microsoft.com
2
Introduction

• Fixed compression methods such as DXT are
  becoming antiquated
• Distribution of data density becoming less
  uniform as complexity increases
• Why cant compression efforts be focused where it
  matters most?
• Wavelets can help!

3
What are wavelets?

• Wavelets are mathematical functions formed from
  scaled and translated copies of a few basis
  functions
• The advantage is their ability to localize
  functions in both frequency and space
• Fourier just frequency
• Point basis just space
• There are lots of common wavelet bases

4
Why 2D Haar?

• This talk will focus on 2D Haar wavelets
• Haar is the simplest basis set
• In general, this means more basis terms and/or
  blocky artefacts
• But also easiest to implement ?
• Blocky nature of bases is less of a problem for
  operations such as integration
• What do the wavelets look like?

5
2D Haar continued...

• Three basis wavelet functions, plus solid
  scaling function
• White represents 1, black -1

6
The wavelet advantage

• Local coverage allows windowed changes
• Compared with spherical harmonics, which have
  global cover
• This means that local changes only involve local
  bases
• Mip-map chains not required for image
  decompression
• Truly variable compression
• Can focus efforts where it counts

7
Usage examples

• Real-time shader image decompression
• Lighting
• Static shadow maps
• Displacement maps over large areas
• Easy dynamic texture packing
• Geometry representations
• ...many more!

8
Talk focus

• Real-time shader image decompression
• Real-time on XBOX360 GPU
• 500Hz for full-screen 720p monochrome
  decompression
• Double-product integration for relighting
• Real-time (ish!) on XBOX360 GPU
• Other applications
• E.G. geometry representation
• If time!

9
Real-time image decompression

• Image broken up into 16x16 texel blocks
• Each block compressed into wavelet sub-tree
• Texture at 1/16th resolution stores scaling
  coefficient and offset to start of sub-tree
• Why?
• Decompression performance should be independent
  of main image resolution
• Each sub-tree fits inside a texture cache tile,
  so no traversal cache thrashing
• Can unroll traversal loop in shader for perf. gain

10
Real-time image decompression continued...

• Given a (u,v) coordinate, pixel shader traverses
  appropriate sub-tree for final value
• Mip-map chain not required
• Obtained as by-product of traversal
• Intermediate memory not required
• All decompression performed directly in the pixel
  shader
• Dynamic predication works well
• Good vector coherency if minification avoided

11
Real-time image decompression continued...

• How is the wavelet tree represented?
• Stored breadth-first in a line texture
• Multiple ways to pack the data
• Example ARGB8
• r, g, b stores windowed wavelet basis
  coefficients
• a stores linear offset to child of node, if one
  exists
• If no child exists, we jump to an empty node
• Wait for the rest of the pixel vector to finish
• Can use wider data formats
• E.g. U16, F32

12
Real-time image decompression continued...
Uncompressed with mipmaps 2MB _at_ 1578fps
13
Real-time image decompression continued...
Wavelet compressed, cut-off 0.05, 249KB _at_ 579fps
14
Real-time image decompression continued...
Wavelet compressed, cut-off 0.08, 157KB _at_ 622fps
15
Real-time image decompression continued...

• Notice how areas of high contrast have their
  detail preserved, and areas of lower contrast are
  smoothed out
• Can use a different notion of importance!

16
Real-time image decompression continued...

• Has advantages over fixed DXT-like compression
  schemes
• Can be lossless in areas you need it to be
• Particularly important for data textures, such
  as SH coefficients
• Will do a much better job for images with areas
  of low contrast
• Again, higher-order SH terms are a good example
• But most surface-parameterised data is likely to
  be like this
• Can use focus ability to increase the area of
  parameterisation

17
Real-time image decompression continued...

• (Video)

18
Double-product integration

• Another good application is relighting
• Work by Ng, Ramamoorthi and Hanrahan
• Diffuse BRDF
• We represent both the transfer function (with
  cosine) and the environment as wavelet trees in a
  texture

19
Double-product integration continued...

• Here we need to traverse only the intersection of
  both trees
• So if one is simple, should get good performance
• Parallel GPU traversal needs to know how to jump
  over bits of either tree not contained in the
  intersection
• If a node has a child, store linear offset to
  sibling or ancestor (could be root)
• Then we can jump over whole child branch if the
  other tree has no children at that point

20
Double-product integration continued...

• Performance is a function of the size of the
  intersection between both trees
• Plus other factors such as cache behaviour
• Loads of other interesting ideas
• Transfer function wavelet trees have a tendency
  to be quite similar in localised patches
• Clustering scheme would help further
• Could store representative tree for each patch,
  and then a (smaller) residual tree per texel of
  patch

21
Double-product integration continued...

• (Video)

22
Other applications

• Wavelets can be used to define surface
  deformations
• As a dynamic displacement map
• Can keep memory overhead constant by removing
  oldest high-frequency terms for new deformation
  terms
• Windowed nature of wavelets makes applying
  localised deformations simple
• Can easily modify e.g. moment of inertia
