Title: A Negotiation Architecture for Fluid Documents


1
A Negotiation Architecture for Fluid Documents
2
From UIST 98
  • http//www.acm.org/pubs/citations/proceedings/uist
    /288392/p123-chang/

3
Never enough screen space
  • This paper looks at making fluid documents
  • dynamically change the allocation of space (and
    other saliency resources) between primary and
    secondary materials
  • Architecture to implement this
  • based on negotiation of (potentially conflicting)
    requirements

4
Fluid documents
  • Assumes primary and secondary material
  • footnotes, annotations, or hyperlinks
  • Provides a nice mechanism for presenting
    secondary material on demand

5
What the system does
  • Mediate salience (visual prominence) of primary
    and secondary material
  • Allow user to smoothly change focus between them
  • Animation important
  • Specific techniques for modifying and sharing
    salience

6
Video Demonstration
  • From UIST 98 video proceedings

7
Advantages
  • Good use of space (user driven)
  • Minimal shift of attention
  • Close to primary
  • In context
  • Attempts to disturb primary presentation as
    little as possible
  • Smooth transitions between views
  • Lightweight interactive control

8
Initially primary material is focus
  • Takes most of space
  • Captures most of users attention
  • Secondary represented by small visual cue only

9
Shifting focus
  • Shifting focus to secondary material increase
    salience
  • Increase size
  • Move to prominent place
  • Boldface
  • etc.

10
Primary material must adjust
  • Reduce salience
  • Examples
  • Decrease size
  • Move away from center
  • Fade to a lighter shade

11
Negotiation process to decide who will do what
  • Four Steps
  • 1) Start with only visual cue (anchor) for
    supporting material
  • 2) Reader indicates interest in supporting,
    triggering shift
  • 3) Negotiate salience properties
  • 4) Animate to new state

12
Initial Visual Cue
  • Can follow various conventions
  • Underlined most common
  • Also footnote marker
  • Could also present small preview
  • Anything that represents the secondary material
    in small and unobtrusive way

13
UI for Expressing Interest
  • Needs to be lightweight
  • Stated (but not obtained) goal just as easy as
    looking at it
  • System uses rollover dwell
  • Roll away and display reverts
  • Click to hold secondary material open

14
Adjusting Material
  • Most of work here
  • Skip for a second

15
Animated transition
  • Short (1/2 second)
  • overlaps reaction time
  • Smooth changes
  • maintain continuity
  • maintain perception of object constancy
  • this is a critical property

16
Adjusting Material
  • Primary and secondary adjust display to change
    saliency and shift focus
  • Biggest aspect provide space for secondary
  • Also pick displays that fit the space have
    right saliency

17
Providing space
  • Several approaches (for text)
  • Block movement (splitting)
  • Deformation
  • change interline spacing, warp
  • Outside allocation
  • place secondary away from anchor
  • visually connect (line)

18
Providing space
  • More approaches (for text)
  • Overlay
  • Reuse of space
  • May have extra space left over from some other
    space allocation
  • Combing techniques
  • e.g., move interline space
  • e.g., interline space overlay

19
Multiple expansions (and nesting)
  • May require changes in all participants
  • Negotiation gets harder
  • Algorithm will deal with this piece-wise to keep
    simple

20
Negotiation
  • Primary and secondary material may be of
    different types with different kinds of display
    capabilities
  • All examples are text, but the architecture
    handles general things
  • Two parts dont have specific knowledge of all
    other types built in

21
Negotiation -- GChar Objects
  • Uses a GChar object
  • Graphical Characteristics
  • Describes desired/proposed/granted display
    properties
  • Always includes space, but normally also includes
    other salience properties (e.g., color)
  • Exact properties are display type dependent

22
Negotiation -- GChar Objects
  • Primary Secondary may be different display
    types
  • Again encapsulated -- one type does not know
    about every other type
  • would make new types very hard
  • How do they communicate capabilities and
    requirements?

23
Negotiation -- GChar Objects
  • Solution is to use hierarchical classes of GChar
    objects
  • All subclass of GChar
  • which has only size information
  • Specific display types add additional information
    to specific subclasses
  • e.g. text adds color and font info
  • Communicate via closest superclass of the GChars
    that two objects use

24
Negotiation -- GChar Objects
  • Two kinds of GChar objects used
  • Specific / Exact (SpecificGChar)
  • used for specific proposal / result
  • Range (RangedGChar)
  • use to communicate acceptable bounds for various
    properties

25
Negotiation -- Proposal Objects
  • Proposal object has (at least)
  • SpecificGChar
  • for preferred state
  • RangedGChar
  • for acceptable range
  • These always include space aspects
  • May also include other aspects
  • e.g. color, font properties

26
Negotiation Objects
  • Process of negotiation represented by a
    Negotiation object
  • Used to represent result
  • Drives animation return animation
  • Used as basis for future negotiation
  • Basically a cache

27
Encapsulation of Negotiation
  • Each material object has a list of possible
    presentation strategies
  • Typically a prioritized list
  • Each can evaluate a RangedGChar
  • can it do it
  • what is closest / best that fits it
  • Display strategy info remains encapsulated in
    each object

28
Encapsulation of Negotiation
  • Each potential primary object (essentially all)
    also has set of space-making strategies
  • Similar story on capabilities and encapsulation

29
Negotiation Steps
  • Four steps in negotiation
  • Initial proposal (by secondary)
  • Guideline selection (by primary)
  • Presentation strategy choice (sec)
  • Space-making strategy choice (prim)

30
Negotiation -- Initial Proposal
  • Secondary indicates to primary that it would like
    to expand
  • Submits a Proposal object
  • SpecificGChar a priori preferred size salience
    properties
  • RangedGChar sizes and properties it can do
    display with

31
Negotiation -- Guideline Selection
  • Primary determines which subclass of GChar to use
  • Considers its set of space making strategies
  • Tentatively picks one
  • Typical policy one with most space
  • Tries to provide most flexibility

32
Negotiation -- Guideline Selection
  • Sends a proposal back
  • Ranged the guidelines
  • max space that can be given
  • property ranges with most leeway
  • Specific a specific recommendation
  • takes into account preferred state of both
    primary and secondary
  • important for expressing properties

33
Negotiation -- Presentation Strategy Choice
  • Secondary picks a final presentation strategy
  • Original choice may work
  • May have to consider its list of possible
    presentations to find one
  • Fits within space given
  • As close as possible to suggested properties

34
Negotiation -- Presentation Strategy Choice
  • Secondary sends back proposal with final choice
  • Specific GChar only

35
Negotiation -- Space-Making Strategy Choice
  • Based on final choice of secondary, primary picks
    a space-making strategy
  • May be tentative choice
  • May be able to do better if secondary did not use
    all its space, etc.
  • Strategy does placement

36
Negotiation
  • Critical details of decision algorithms embedded
    in objects
  • Allows type specific strategies, but still
    fitting in general framework
  • Set of strategies for each type
  • Neither dictates, but not symmetrical
  • E.g., secondary never knows about primarys
    presentation (size, etc.)

37
Negotiation
  • Multi-level negotiations handled pair-wise
  • Negotiation with grandparent is handled inside
    guideline and space choice steps of parent
  • Negotiation with grandchildren similarly handled
    inside initial and presentation choice steps
    of child

38
Negotiation
  • Negotiation stops after one round of four steps
  • can fail ? fallback strategy
  • e.g., separate window
  • claimed rare because primaries build to provide
    wide ranges
  • Could renegotiate based on knowledge of needs
  • still limited rounds ? fail ? fallback strategy

39
Recap
  • Good use of space
  • Keeps disruption of attention to a minimum
  • Negotiation makes best use of available resources
  • Architecture encapsulates details ? allows
    extension

40
