Problem Solving as Search

1
Problem Solving as Search

• Foundations of Artificial Intelligence

2
Search and Knowledge Representation

• Goal-based and utility-based agents require
  representation of
• states within the environment
• actions and effects (effect of an action is
  transition from the current state to another
  state)
• goals
• utilities
• Problems can often be formulated as a search
  problem
• to satisfy a goal, agent must find a sequence of
  actions (a path in the state-space graph) from
  the starting state to a goal state.
• To do this efficiently, agents must have the
  ability to reason with their knowledge about the
  world and the problem domain
• which path to follow (which action to choose
  from) next
• how to determine if a goal state is reached OR
  how decide if a satisfactory state has been
  reached.

3
Introduction to Search

• Search is one of the most powerful approaches to
  problem solving in AI
• Search is a universal problem solving mechanism
  that
• Systematically explores the alternatives
• Finds the sequence of steps towards a solution
• Problem Space Hypothesis (Allen Newell, SOAR An
  Architecture for General Intelligence.)
• All goal-oriented symbolic activities occur in a
  problem space
• Search in a problem space is claimed to be a
  completely general model of intelligence

4
Problem-Solving Agents
function Simple-Problem-Solving-Agent(percept)

returns action inputs p, a percept
static s, an action sequence, initially empty
state, a description of current world
state g, a goal, initially null
problem, a problem formulation state
Update-State(state, p) if s empty then
g Formulate-Goal(state) problem
Formulate-Problem(state, g) s
Search(problem) endif action first(s) s
remainder(s) return action

• Assumptions on Environment
• Static formulating and solving the problem does
  not take any changes into account
• Discrete enumerating all alternative courses of
  action
• Deterministic actions depend only on previous
  actions
• Observable initial state is completely known

• The agent follows a simple formulate, search,
  execute design

5
Stating a Problem as a Search Problem
S

• State space S
• Successor function x in S ? SUCCESSORS(x)
• Cost of a move
• Initial state s0
• Goal test
• for state x in S
• ? GOAL?(x) T or F

6
Example (Romania)

• Initial Situation
• On Holiday in Romania currently in Arad
• Flight leaves tomorrow from Bucharest
• Formulate Goal
• be in Bucharest
• Formulate Problem
• states various cities
• operators drive between cities
• Find Solution
• sequence of cities
• must start at starting state and end in the goal
  state

7
Example (Romania)
8
Example Vacuum World

• Vacuum World
• Let the world be consist two rooms
• Each room may contain dirt
• The agent may be in either room
• initial both rooms dirty
• goal both rooms clean
• problem
• states each state has two rooms which may
  contain dirt (8 possible)
• actions go from room to room vacuum the dirt
• Solution
• sequence of actions leading to clean rooms

9
Problem Types

• Deterministic, fully-observable gt single-state
  problem
• agent has enough info. to know exactly which
  state it is in
• outcome of actions are known
• Deterministic, partially-observable gt
  multiple-state problem
• sensorless problem Limited/no access to the
  world state agent may have no idea which state
  it is in
• require agent to reason about sets of states it
  can reach
• Nondeterministic, partially-observable gt
  contingency problem
• must use sensors during execution percepts
  provide new information about current state
• no fixed action that guarantees a solution (must
  compute the whole tree)
• often interleave search, execution
• Unknown State Space gt exploration problem
  (online)
• only hope is to use learning (reinforcement
  learning) to determine potential results of
  actions, and information about states

10
Example Vacuum World

• Single-State
• start in 5. Solutions?
• Multiple-State
• start in 1,2,3,4,5,6,7,8
• e.g., Right goes to 2,4,6,8. Solutions?
• Contingency
• Start in 5
• e.g., Suck can dirty a clean carpet
• Local sensing dirt, location only. Solutions?

Goal states
11
Single-state problem formulation

• A problem is defined by four items
• initial state
• e.g., at Arad''
• operators (or successor function S(x))
• e.g., Arad gt Zerind Arad gt Sibiu
• goal test, can be
• explicit, e.g., x at Bucharest''
• implicit, e.g., NoDirt(x)
• path cost (additive)
• e.g., sum of distances, number of operators
  executed, etc.
• A solution is a sequence of operators leading
  from the initial state to a goal state

12
Selecting a state space

• Real world is absurdly complex
• state space must be abstracted for problem
  solving
• (Abstract) state set of real states
• (Abstract) operator complex combination of real
  actions
• e.g., Arad gt Zerind represents a complex set
  of possible routes, detours, rest stops, etc.
• For guaranteed realizability, any real state in
  Arad must get to some real state in Zerind
• (Abstract) solution set of real paths that are
  solutions in the real world
• Each abstract action should be easier than the
  original problem!

13
Example Vacuum World

• States? integer dirt and robot locations (ignore
  dirt amounts)
• Operators? Left, Right, Suck
• Goal Test? no dirt
• Path Cost? one per move
• What if the agent had no sensors the
  multiple-state problem

Goal states
14
Example The 8-Puzzle

• States? integer location of tiles
• Operators? move blank left, right, up, down
• Goal Test? goal state (given)
• Path Cost? One per move
• Note optimal solution of n-Puzzle problem is
  NP-hard

15
8-Puzzle Successor Function
16
State-Space Graph

• The state-space graph is a representation of all
  possible legal configurations of the problem
  resulting from applications of legal operators
• each node in the graph is a representation a
  possible legal state
• each directed edge is a representation of a
  possible legal move applied to a state (resulting
  in a new state of the problem)
• States
• representation of states should provide all
  information necessary to describe relevant
  features of a problem state
• Operators
• Operators may be simple functions representing
  legal actions
• Operators may be rules specifying an action given
  that a condition (set of constraints) on the
  current state is satisfied
• In the latter case, the rules are sometimes
  referred to as production rules and the system
  is referred to as a production system
• This is the case with simple reflex agents.

17
Vacuum World State-Space Graph

• State-space graph does not include initial or
  goal states
• Search Problem Given specific initial and goal
  states, find a path in the graph from an initial
  to a goal state
• An instance of a search problem can be
  represented as a search tree whose root note is
  the initial state

18
(No Transcript)
19
Solution to the Search Problem

• A solution is a path connecting the initial to a
  goal node (any one)
• The cost of a path is the sum of the edge costs
  along this path
• An optimal solution is a solution path of minimum
  cost
• There might be no solution !

20
(No Transcript)
21
State Spaces Can be Very Large

• 8-puzzle ? 9! 362,880 states
• 15-puzzle ? 16! 1.3 x 1012 states
• 24-puzzle ? 25! 1025 states

22
Searching the State Space

• Often it is not feasible to build a complete
  representation of the state graph
• A problem solver must construct a solution by
  exploring a small portion of the graph
• For a specific search problem (with a given
  initial and goal state) we can view the relevant
  portion as a search tree

23
Searching the State Space
24
Searching the State Space
Search tree
25
Searching the State Space
Search tree
26
Searching the State Space
Search tree
27
Searching the State Space
Search tree
28
Searching the State Space
Search tree
29
Portion of Search Space for an Instance of the
8-Puzzle Problem
30
Simple Problem-Solving Agent Algorithm

• s0 ? sense/read initial state
• GOAL? ? select/read goal test
• Succ ? select/read successor function
• solution ? search(s0, GOAL?, Succ)
• perform(solution)

31
Example Blocks World Problem

• World consists of blocks A, B, C, and the Floor
• Can move a block that is clear on top of
  another clear block or onto the Floor
• State representation using the predicate
  on(x,y)
• on(x,y) means the block x is on top of block y
• on(x, Floor) means block x is on the Floor
• on(_, x) means block x has nothing on it (it is
  clear)
• Can specify operators as a set of production
  rules
• 1. on(_, x) ? on (x, Floor)
• 2. on(_, x) and on(_, y) ? on(x, y)
• Initial state some initial configuration
• E.g., on(A, Floor) and on(C, A) and on(B, Floor)
  and on(_, B) and on(_, A)
• Goal state some specified configuration
• E.g., on(B,C) and on(A,B)

32
Blocks World State-Space Graph
on(_, x) ? on (x, Floor)
on(_, x) and on(_, y) ? on(x, y)
1
2
2
2
1
1
2
2
2
2
2
2
2
2
2
2
1
1
2
2
2
2
1
1
2
2
33
Blocks World A Search Problem
Search tree for the problem
A
A
B
C
B
C

• Notes
• Repeated states have been eliminated in diagram.
• The highlighted path represents (in this case)
  the only solution for this instance of the
  problem.
• The solution is a sequence of legal actions
  move(A, Floor) ? move(B, C) ? move(A, B).

34
Some Other Problems
35
8-Queens Problem
Place 8 queens in a chessboard so that no two
queens are in the same row, column, or diagonal.
A solution
Not a solution
36
Formulation 1

• States all arrangements of 0, 1, 2, ..., or 8
  queens on the board
• Initial state 0 queen on the board
• Successor function each of the successors is
  obtained by adding one queen in an empty square
• Arc cost irrelevant
• Goal test 8 queens are on the board, with no two
  of them attacking each other

? 64x63x...x53 3x1014 states
37
Formulation 2

• States all arrangements of k 0, 1, 2, ..., or
  8 queens in the k leftmost columns with no two
  queens attacking each other
• Initial state 0 queen on the board
• Successor function each successor is obtained by
  adding one queen in any square that is not
  attacked by any queen already in the board, in
  the leftmost empty column
• Arc cost irrelevant
• Goal test 8 queens are on the board

? 2,057 states
38
Path Planning
What is the state space?
39
Formulation 1
40
Optimal Solution
This path is the shortest in the discretized
state space, but not in the original continuous
space
41
Formulation 2
Visibility graph
42
Formulation 2
Visibility graph
43
Solution Path
The shortest path in this state space is also the
shortest in the original continuous space
44
Search Strategies

• Uninformed (blind, exhaustive) strategies use
  only the information available in the problem
  definition
• Breadth-first search
• Depth-first search
• Uniform-cost search
• Heuristic strategies use rules of thumb based
  on the knowledge of domain to pick between
  alternatives at each step

Graph Searching Applet http//www.cs.ubc.ca/labs/
lci/CIspace/Version4/search/index.html
45
Implementation of Search Algorithms
function General-Search(problem, Queuing-Fn)
returns a solution, or failure nodes
Make-Queue(Make-Node(Initial-Stateproblem))
loop do if nodes empty then
return failure nodes Remove-Front(nodes)
if Goal-Testproblem applied to Statenode
succeeds then return node else
nodes Queuing-Fn(nodes, Expand(node,
Operatorsproblem)) return

• A state is a representation of a physical
  configuration
• A node is a data structure constituting part of a
  search tree
• includes parent, children, depth, or path cost
• States dont have parents, children, depth, or
  path cost
• The Expand function creates new nodes, filling in
  various fields and using Operators (or
  SucessorFn) of the problem to create the
  corresponding states

46
Search Strategies

• A strategy is defined by picking the order of
  node expansion
• i.e., how expanded nodes are inserted into the
  queue
• Strategies are evaluated along the following
  dimensions
• completeness - does it always find a solution if
  one exists
• time complexity - number of nodes generated /
  expanded
• space complexity - maximum number of nodes in
  memory
• optimality - does it always find a least-cost
  solution
• Time and space complexity are measured in terms
  of
• b - maximum branching factor of the search tree
• d - depth of the least-cost solution
• m - maximum depth of the state space (may be )

47
Recall Searching the State Space
Search tree
Note that some states are visited multiple times
48
Search Nodes ? States
49
Search Nodes ? States
If states are allowed to be revisited,the search
tree may be infinite even when the state space is
finite
50
Data Structure of a Node
Depth of a node N length of path from root to
N (Depth of the root 0)
51
Node expansion

• The expansion of a node N of the search tree
  consists of
• Evaluating the successor function on STATE(N)
• Generating a child of N for each state returned
  by the function

52
Basic Search Procedure

• 1. Start with the start node (root of the search
  tree) and place in on the queue
• 2. Remove the front node in the queue and
• If the node is a goal node, then we are done
  stop.
• Otherwise expand the node ? generate its
  children using the successor function (other
  states that can be reached with one move)
• 3. Place the children on the queue according to
  the search strategy
• 4. Go back to step 2.

53
Search Strategies

• Search strategies differ based on the order in
  which new successor nodes are added to the queue
• Breadth-first ? add nodes to the end of the queue
• Depth-first ? add nodes to the front
• Uniform cost ? sort the nodes on the queue based
  on the cost of reaching the node from start node

54
Breadth-First Search
1
4
2
3
5
6
7
8
9
10
12
13
11
14
goal
55
Example (Romania)
56
Breadth-First Search

• Always expand the shallowest unexpanded node
• QueuingFN insert successor at the end of the
  queue

Arad
Arad
Zerind
Sibiu
Timisoara
57
Breadth-First Search
Arad
Zerind
Sibiu
Timisoara
Oradea
Arad
58
Breadth-First Search
Arad
Zerind
Sibiu
Timisoara
Rimnicu Vilcea
Oradea
Oradea
Fagaras
Arad
Arad
59
Breadth-First Search
Arad
Sibiu
Timisoara
Zerind
Rimnicu Vilcea
Oradea
Fagaras
Arad
Oradea
Lugoi
Arad
Arad
60
Depth d 4 Branching factor b 2
goal
No. of nodes examined through level 3 (d-1) 1
2 22 23 1 2 4 8 15
Avg. no. of nodes examined at level 4 (1 24)
/ 2 (min 1, max 24)
61
Breadth-First Search

• Space complexity
• Full tree at depth d uses bd memory nodes
• If you know there is a goal at depth d, you are
  done otherwise have to store the nodes at depth
  d1 as you generate them so might need bd1
  memory nodes
• Nodes examined (assume tree has depth d with a
  single goal node at that depth)
• for large b, this is O(bd) (the fringe dominates)

Number of internal nodes before reaching goal at
depth d
Average number of nodes examined at the fringe (
at depth d)
62
Properties of Breadth-First Search

• Complete?
• Yes, if b is finite
• Time Complexity?
• 1 b b2 b3 . . . bd O(bd)
• Space Complexity?
• O(bd) (keeps every node in memory)
• Optimal?
• Yes (if cost 1 per step) but, not optimal in
  general
• Note biggest problem in BFS is the space
  complexity

63
Breadth-First Search Time and Space Complexity

• Assume
• branching factor b10
• 1000 nodes/second
• 100 bytes/node

64
Depth-First Search
1
13
2
8
12
3
9
14
7
10
4
11
15
goal
6
5
65
Depth-First Search

• Always expand the deepestest unexpanded node
• QueuingFN insert successor at the front of the
  queue

Arad
Zerind
Sibiu
Timisoara
Oradea
Arad
66
Depth-First Search
Arad
Zerind
Sibiu
Timisoara
Arad
Oradea
Note that DFS can perform infinite cyclic
excursions. Need a finite, non-cyclic search
space, or repeated state-checking.
Zerind
Sibiu
Timisoara
67
Best case in Depth-First Search Goal node is on
the far left.
Depth d 4 Branching factor b 2
worst case
goal
Highlighted nodes are those that have to be kept
in memory.
In best case, we examine d 1 5 nodes. In
worst case, need all the nodes 1 2 4 8
16 (bd) 31
68
Depth-First Search

• Space complexity (assume tree has depth d with a
  single goal node at that depth)
• The most memory is needed at the first point we
  reach depth d
• Need to store b-1 nodes at each depth (siblings
  of the node already expanded) with one additional
  node at depth d (since it hasnt been expanded
  yet)
• Total space d(b-1) 1 (the 1 additional node
  is for the goal at depth d)
• Nodes examined (assume tree has depth d with a
  single goal node at that depth)
• Best case (goal is at far left) gt d 1 nodes
• Worst case gt
• Average case gt
• for large b, this O(bd) (the fringe dominates)

69
Properties of Depth-First Search

• Complete?
• No fails in infinite-depth spaces, spaces with
  loops
• need to modify the algorithm to avoid repeated
  states along paths
• Time Complexity?
• O(bm) terrible if m is much larger than d
• but, if solutions are dense, may be much faster
  that BFS
• Space Complexity?
• O(bm) (i.e., linear space)
• Optimal?
• No

70
Iterative Deepening

• Depth-Limited Search
• depth-first search with depth limit l
• Nodes at depth l have no successors

function Iterative-Deepening-Search(problem,
Queuing-Fn) returns a solution sequence inputs
problem for depth 0 to do result
Depth-Limited-Search(problem, depth) if
result ¹ cutoff then return result
end
71
Iterative Deepening
l 0
Arad
l 1 steps 1 and 2
Arad
Sibiu
Timisoara
Zerind
72
Iterative Deepening
Arad
Timisoara
Zerind
Sibiu
l 2 steps 1, 2, and 3
Oradea
Arad
73
Iterative Deepening
l 2 step 5
Arad
Sibiu
Timisoara
Zerind
Rimnicu Vilcea
Oradea
Fagaras
Arad
Oradea
Arad
Lugoi
Arad
74
Iterative Deepening

• Space complexity
• if the shallowest solution is at depth g, then
  the depth-first search to this depth will succeed
  (so Iterative Deepening will always return the
  shallowest solution). Since each of the
  individual searches are performed depth-first,
  the amount of memory required is same as
  depth-first search.
• Nodes examined (assume tree has depth d with a
  single goal node at that depth)

No. of nodes examined in the final (successful)
iteration (same as DFS)
(1)
For each of depths j 1, 2, , d-1, must examine
the entire tree
(2)
Total nodes examined in failing searches
75
Properties of Iterative Deepening

• Complete?
• Yes
• Time Complexity?
• Adding (1) and (2) from before gives
• Space Complexity?
• O(bd)
• Optimal?
• Yes (if cost 1 per step)
• Can be modified to explore uniform-cost search

O(bd)
76
Uniform-Cost Search

• Always expand the least-cost unexpanded node
• Queue insert in order of increasing path cost

Arad
75
118
140
Sibiu
Timisoara
Zerind
lt Zerind, Timisoara, Sibiu lt
77
Uniform-Cost Search
Arad
75
118
140
Sibiu
Timisoara
Zerind
7175
7575
Arad
Oradea
lt Timisoara, Sibiu, Oradea, Arad lt
78
Uniform-Cost Search
Arad
75
118
140
Sibiu
Timisoara
Zerind
7575
118118
7175
111118
Arad
Arad
Oradea
Lugoi
lt Sibiu, Oradea, Arad, Lugoi, Arad lt
79
Uniform-Cost Search
Arad
75
118
140
Sibiu
Timisoara
Zerind
7575
118118
7175
111118
Arad
Arad
Oradea
Lugoi
lt Sibiu, Oradea, Arad, Lugoi, Arad lt
80
Uniform Cost Search

• For the rest of the example, let us assume
  repeated state checking
• If a newly generated state was previously
  expanded, then discard the new state
• If multiple (unexpanded) instances of a state end
  up on the queue, we only keep the instance that
  has the least path cost from the start node and
  eliminate the other instances.

81
Uniform-Cost Search
Arad
75
118
140
Sibiu
Timisoara
Zerind
7175
111118
Oradea
Lugoi
lt Sibiu, Oradea, Lugoi lt
82
Uniform-Cost Search
Arad
75
140
118
Zerind
Sibiu
Timisoara
239
220
146
229
Fagaras
Rimnicu
Oradea
Lugoi
lt Oradea, Rimnicu, Lugoi, Fagaras lt
83
Uniform-Cost Search
Note Oradea only leads to repeated states.
Arad
75
140
118
Zerind
Sibiu
Timisoara
239
220
146
229
Fagaras
Rimnicu
Oradea
Lugoi
lt Rimnicu, Lugoi, Fagaras lt
84
Uniform-Cost Search
85
Uniform-Cost Search
Arad
75
140
118
Zerind
Sibiu
Timisoara
239
220
146
229
Rimnicu
Oradea
Fagaras
Lugoi
367
317
Craiova
Pitesti
lt Lugoi, Fagaras, Pitesti, Craiova lt
86
Uniform-Cost Search
Arad
75
140
118
Zerind
Sibiu
Timisoara
239
220
146
229
Rimnicu
Oradea
Fagaras
Lugoi
367
317
299
Craiova
Pitesti
Mehadia
lt Fagaras, Mehadia, Pitesti, Craiova lt
87
Uniform-Cost Search
Arad
140
118
75
Sibiu
Zerind
Timisoara
239
220
146
229
Rimnicu
Fagaras
Oradea
Lugoi
367
317
450
299
Craiova
Pitesti
Bucharest
Mehadia
lt Mehadia, Pitesti, Craiova, Bucharest lt
88
Uniform-Cost Search
Arad
118
140
75
Sibiu
Timisoara
Zerind
239
229
220
146
Rimnicu
Oradea
Fagaras
Lugoi
367
317
450
Craiova
Pitesti
Mehadia
299
Bucharest
Dobreta
374
lt Pitesti, Craiova, Dobreta, Bucharest lt
89
Uniform-Cost Search
Arad
118
140
75
Sibiu
Timisoara
Zerind
239
229
220
146
Rimnicu
Oradea
Fagaras
Lugoi
367
317
450
Craiova
Pitesti
Mehadia
299
Bucharest
455
418
Bucharest
Dobreta
374
Craiova
lt Craiova, Dobreta, Bucharest lt
90
Uniform-Cost Search
Arad
118
140
75
Sibiu
Timisoara
Zerind
239
229
220
146
Rimnicu
Oradea
Fagaras
Lugoi
367
317
450
Craiova
Pitesti
Mehadia
299
Bucharest
455
418
Bucharest
Dobreta
374
Craiova
lt Craiova, Dobreta, Bucharest lt
91
Uniform-Cost Search
Arad
118
140
75
Sibiu
Timisoara
Zerind
239
229
220
146
Rimnicu
Oradea
Fagaras
Lugoi
367
317
Craiova
Pitesti
Mehadia
299
418
Dobreta
374
Bucharest
Goes to repeated states with higher path costs
than previous visits to those states
lt Craiova, Dobreta, Bucharest lt
92
Uniform-Cost Search
93
Uniform-Cost Search
Arad
118
140
75
Sibiu
Timisoara
Zerind
239
229
220
146
Rimnicu
Oradea
Fagaras
Lugoi
367
317
Craiova
Pitesti
Mehadia
299
418
Dobreta
374
Bucharest
lt Bucharest lt
94
Uniform-Cost Search
Arad
118
140
75
Sibiu
Timisoara
Zerind
239
229
220
146
Rimnicu
Oradea
Fagaras
Lugoi
367
317
Craiova
Pitesti
Mehadia
299
418
Dobreta
374
Bucharest
lt Urziceni, Giurgiu lt
519
Pitesti
508
503
Fagaras
629
Giurgiu
Urziceni
95
Uniform-Cost Search
Arad
118
140
75
Sibiu
Timisoara
Zerind
239
229
220
146
Rimnicu
Oradea
Fagaras
Lugoi
367
317
Craiova
Pitesti
Mehadia
299
418
Dobreta
374
Bucharest
Solution Path Arad ? Sibiu ? Rimnicu ? Pitesti ?
Bucharest
Total cost 418
Compare this to Arad ? Sibiu ? Fagaras ?
Bucharest with total cost of 450
96
Properties of Uniform-Cost Search

• Complete?
• Yes, if b is finite (similar to Breadth-First
  search)
• Time Complexity?
• Number of nodes with g(n) cost of optimal
  solution
• Space Complexity?
• Number of nodes with g(n) cost of optimal
  solution
• Optimal?
• Yes, if the path cost never decreases along any
  path
• i.e., if g(Successor(n)) ³ g(n), for all
  nodes n
• What happens if we had operators with negative
  costs?
