Client/server

1
Client/server
2
The (simple) Client/Server Connection using
Stream Sockets The Server

• 5 steps to building the server
• Create a ServerSocket object registers an
  available TCP/IP port and a maximum queue length

• ServerSocket servernew ServerSocket(port,queuele
  n)
• This is called the handshake point. If the queue
  is full the connection is refused. The process
  is known as binding a server to a port. Only
  one application at a time can be bound to a
  particular port.

3
Simple Server continued Step 2

• 2. The server listens, or blocks for a client
  connection
• Socket connection server.accept()
• The socket connection makes possible interaction
  with the client via I/O streams. The server
  interacts with a client at a different port than
  the handshake point, which makes possible
  multi-threaded servers (ie.,after connection is
  established, the server can spawn a thread to
  process this client and go on listening for
  another.

4
Simple Server continued Step 3

• 3. The server gets I/O connections associated
  with the client socket. I/O across the
  connection is not really much different than
  other java i/o.
• ObjectInputStream input new ObjectInputStream(co
  nnection.getInputStream())
• ObjectOutputStream output new
  ObjectOutputStream(connection.getOutputStream())
• The servers output stream is the clients input
  stream, and visa versa.

5
Simple Server continued

• 4. Process the connection this phase is
  application-specific and might involve a single
  message being sent, complicated objects being
  exchanged, a loop, whatever.
• 5. Close the connection by invoking close()
  method on the streams.

6
The (simple) Client/Server Connection using
Stream Sockets The Client

• 4 steps to building the client
• 1. Establish a connection to the server
• Socket connection new Socket(serverIP,port)
• A connection is returned if this step is
  successful, otherwise an IOException is thrown.
  Notice, the client needs to know where the server
  is (the servers IP) while the server doesnt
  know in advance the clients address.

7
Simple Client continued Step 2

• 3. The client gets I/O connections associated
  with the socket.
• ObjectInputStream input new ObjectInputStream(co
  nnection.getInputStream())
• ObjectOutputStream output new
  ObjectOutputStream(connection.getOutputStream())
• Other stream types can be used to wrap around
  these for manipulation different object types.
  Any serializable object can be passed via the IO
  connection.

8
Simple Client continued

• 3. Processing phase
• 4. Close the connection by invoking close()
  method on the streams. This is application
  specific- the client needs to know when the
  server is done so as to avoid an IOException
  (EOFException) trying to read past EOF mark.

9
server code (in slide notes)

• http//employees.oneonta.edu/higgindm/internet
  programming/Server.html

10
Client code

• http//employees.oneonta.edu/higgindm/internet20p
  rogramming/Client.html

11
ServerTest app

• http//employees.oneonta.edu/higgindm/internet20p
  rogramming/ServerTest.html
• import javax.swing.JFrame
• public class ServerTest
• public static void main( String args )
• Server application new Server() //
  create server
• application.setDefaultCloseOperation(
  JFrame.EXIT_ON_CLOSE )
• application.runServer() // run server
  application
• // end main
• // end class ServerTest

12
Clienttest.java app feeds a urlhttp//employees.
oneonta.edu/higgindm/internet20programming/Client
Test.html

• import javax.swing.JFrame
• public class ClientTest
• public static void main( String args )
• Client application // declare client
  application
• // if no command line args
• if ( args.length 0 )
• application new Client( "137.141.19.2"
  ) // connect to localhost
• else
• application new Client( args 0 )
  // use args to connect
• application.setDefaultCloseOperation(
  JFrame.EXIT_ON_CLOSE )
• application.runClient() // run client
  application
• // end main

13
Compile and run

• Compile 4 java files. Run ServerTest, then
  ClientTest
• Exercise modify clienttest code so a url is
  entered on the command line.
• Run the client and server on different machines
• Hint You can use
• c\ipconfig \all
• to show a machines ip, if you can get to the
  command prompt
• Loop back URL is 127.0.0.1

14
Server window
15
Client window
16
Some communication
17
Client closes connection
18
Connectionless Client/server communication via
datagrams

• While the connection-based client/server model is
  similar to the telephone, the datagram model is
  more like the post office.
• The message is posted in sequential numbered
  packets and re-assembled at the target location.
• Messages may arrive jumbled, or not at all.
• This example uses the UserDatagramProtocol (UDP)
  between client and server.

19
Server structure in datagram communication

• DatagramSocket socket//use this datatype
• try
• socket new DatagramSocket(5000)// specify port
• catch(SocketException se)
• Wait for packets
• Byte datanew byte100
• while(true)//forever loop
• try
• Datagram receivepacketnew DatagramPacket(data,
  data.length)
• socket.recieve(receivepacket)
• catch(IOException e)

20
Datagram server continued

• //Send packet to clientalso inside try catch for
  ioexception
• Datagram sendpacketnew DatagramPacket(receivepack
  et.getData(),receivepacket.getLength(),receivepack
  et.getAddress(),receivepacket.getPort())
• socket.send(sendpacket)

21
Datagram (packet) server

• The server uses two DatagramPackets one to send
  and one to receive packets.
• This application uses java.net classes
• java.net.DatagramPacket and java.net.DatagramSocke
  t
• DatagramSocket is created in a try block where
  the server is bound to a port. Processing on the
  serverside involves an infinite loop waiting for
  packets. Clients must specify the server port
  when sending packets.
• Datagram method receive() blocks until a packet
  is received then stores the packet info in its
  Datagram argument.
• Methods are called to display senders IP, port,
  message length and the message itself.

22
Packets 4 files

• http//employees.oneonta.edu/higgindm/internet20p
  rogramming/PacketServer.html
• http//employees.oneonta.edu/higgindm/internet20p
  rogramming/PacketClient.html
• http//employees.oneonta.edu/higgindm/internet20p
  rogramming/PacketServerTest.html
• http//employees.oneonta.edu/higgindm/internet20p
  rogramming/PacketClientTest.html

23
PacketClient frame
24
PacketServer frame
25
Threaded client/server

• Some background
• LockSwingUtilities.invokeLater()
• Scanner
• Executor for threads
• Synchronization using Locks

26
Scanner

• Scanner is replacing StringTokenizer. It is
  similar, versatile and easy to use.
• Deitel pg 59 has an example.
• import java.util.Scanner
• Scanner inputnew Scanner(System.in)
• int x
• xinput.nextInt()

27
SwingUtilities.invokeLater()

• Having multiple threads manipulate GUI content
  may not give expected results. Better to have
  the event-dispatching thread queue requests to
  display answers, change colors, and so on, and
  handle them in order. Here is a method to do it
• SwingUtilities.invokeLater(
• new Runnable()
• public void run()
• thread does stuff to GUI
• )

28
Executor service for running threads

• Recommended thread construction in jdk1.5 is
• public class mythread extends Runnable
• public void run()
• //loop or whatever
• try
• Thread.sleep(sometime)
• the rest of it
• catch(InterruptedException e)

29
Executor service for running threads

• Executor Service example Deitels text pg 1059
• import java.util.concurrent.
• Thread a new Thread()//not recommended
• //should be
• RunnableThingy a new RunnableThingy()
• Thread b new Thread()//as above
• ExecutorService threadExExecutors.newFixedThreadP
  ool(2)
• //can run just two threads
• threadEx.execute(a)
• threadEx.execute(b)
• theadEx.shutdown()

30
Executor service for running threads

• Runnables are managed and executed by a class
  that implements Executor interface. This has one
  method, (execute).
• An executor manages a thread pool.
• Executor assigns each runnable object to a thread
  in the pool. If there are none it may make a new
  thread (newCachedThreadPool) or queue the
  runnable for the next available thread as in the
  fixed thread pool.

31
Synchronization using Lock

• Example in Deitel text pg 1071
• This is fairly similar to providing synchronized
  methods.
• import java.util.concurrent.locks.

32
Synchronization using Lock

• import java.util.concurrent.locks.Lock
• import java.util.concurrent.locks.ReentrantLock
• import java.util.concurrent.locks.Condition
• public class SynchronizedBuffer implements Buffer
• // Lock to control synchronization with this
  buffer
• private Lock accessLock new ReentrantLock()
• // conditions to control reading and writing
• private Condition canWrite
  accessLock.newCondition()
• private Condition canRead accessLock.newCondi
  tion()
• private int buffer -1 // shared by producer
  and consumer threads
• private boolean occupied false

33
Synchronization using Lock set

• public void set( int value )
• accessLock.lock() // lock this object
• try
• while ( occupied )
• System.out.println( "Producer tries
  to write." )
• displayState( "Buffer full. Producer
  waits." )
• canWrite.await()// wait until buffer
  is empty
• // end while
• buffer value // set new buffer value
• // producer cannot store new value until consumer
  retrieves current value
• occupied true
• displayState( "Producer writes "
  buffer )
• // signal thread waiting to read from
  buffer
• canRead.signal()
• // end try
• catch ( InterruptedException exception )
• exception.printStackTrace()
  // end catch
• finally
• accessLock.unlock() // unlock this
  object

34
Synchronization using Lock get

• public int get()
• int readValue 0 // initialize value
  read from buffer
• accessLock.lock() // lock this object
• // output thread information and buffer
  information, then wait
• try // while no data to
  read, place thread in waiting state
• while ( !occupied )
• System.out.println( "Consumer tries
  to read." )
• displayState( "Buffer empty. Consumer
  waits." )
• canRead.await() // wait until buffer
  is full
• // end while
• // indicate that producer can store
  another value
• // because consumer just retrieved
  buffer value
• occupied false
• readValue buffer // retrieve value
  from buffer
• displayState( "Consumer reads "
  readValue )
• // signal thread waiting for buffer to
  be empty
• canWrite.signal()
• // end try
• // if waiting thread interrupted, print
  stack trace

35
Threaded client/server code links below and in
slide notes

• http//employees.oneonta.edu/higgindm/internet20p
  rogramming/TicTacToeServerTest.html
• http//employees.oneonta.edu/higgindm/internet20p
  rogramming/TicTacToeServer.html
• http//employees.oneonta.edu/higgindm/internet20p
  rogramming/TicTacToeClient.html
• http//employees.oneonta.edu/higgindm/internet20p
  rogramming/TicTacToeClientTest.html

36
TicTacToeServer

• In notes

37
TicTacToe client
38
Compile run

• Compile the 4 files. Run TicTacToeServerTest
  first. You need to run 2 clients (players).
• A window opens for the server and a board appears
  for each client.

39
Client boards after play
40
Exercises

• Modify the client to connect to a server on
  another machine.
• Fix the server so it can tell when the game
  ends.

41
Socket project

• Modify the threaded client server to play your
  choice
• Hexapawn on 4X4 or larger board
• Dominoes
• Othello
• A simple card game War, or maybe 21
• First option may be easiest. Othello also isnt
  too hard. Make sure the server recognizes whose
  move it is, allows only correct moves, and knows
  when the game is over (or when a client
  terminates).
