Outline

• Group communication systems
• Ordered multicast
• Techniques to implement ordered multicast
• Group membership service
• Agreed and safe delivery
• Checkpointing and recovery
• Reference
• Reliable distributed systems, by K. P. Birman,
  Springer Chapter 14-16

3
Group Communication System

• Services provided by the GCS
• Membership service who is up and who is down
• Deals with failure detection and more
• Reliable, ordered, multicast service
• FIFO, causal, total
• Virtual synchrony service
• Virtual synchrony synchronizes membership change
  with multicasts
• GCS is often used to build fault tolerant systems

4
Reliable Multicast

• Reliable multicast the message is targeted to
  multiple receivers, and all receivers receive the
  message reliably
• Positive or negative acknowledgement
• Need to avoid ack/nack implosion
• Distinguish receiving from delivery!

Application
Delivering
Middleware
Receiving
5
Ordered Reliable Multicast

• Ordered reliable multicast if many messages are
  multicast by many senders, in what order the
  messages are delivered at the receivers?
• First in first out (FIFO)
• Causal the causal relationship among msgs
  preserved
• Total all msgs are delivered at all receivers
  in the same order

6
FIFO Ordered Multicast

• FIFO or sender ordered multicast
• Messages are delivered in the order they were
  sent (by any single sender)

a
e
p q r s
b
c
d
delivery of c to p is delayed until after b is
delivered
7
Causally Ordered Multicast

• Causal or happens-before ordering
• If send(a) ? send(b) then deliver(a) occurs
  before deliver(b) at common destinations

a
p q r s
b
8
Causally Ordered Multicast

• Causal or happens-before ordering
• If send(a) ? send(b) then deliver(a) occurs
  before deliver(b) at common destinations

a
p q r s
b
c
delivery of c to p is delayed until after b is
delivered
9
Causally Ordered Multicast

• Causal or happens-before ordering
• If send(a) ? send(b) then deliver(a) occurs
  before deliver(b) at common destinations

a
e
p q r s
b
c
delivery of c to p is delayed until after b is
delivered
e is sent (causally) after b
10
Causally Ordered Multicast

• Causal or happens-before ordering
• If send(a) ? send(b) then deliver(a) occurs
  before deliver(b) at common destinations

a
e
p q r s
b
c
d
delivery of c to p is delayed until after b is
delivered
delivery of e to r is delayed until after bc are
delivered
11
Totally Ordered Multicast

• Total ordering
• Messages are delivered in same order to all
  recipients (including the sender)

a
e
p q r s
b
c
d
all deliver a, b, c, d, then e
12
Implementing Total Ordering

• Use a token that moves around
• Token has a sequence number
• When you hold the token you can send the next
  burst of multicasts
• Use a sequencer to order all multicast
• Message is first multicast to all, including the
  sequencer then the sequencer determines the
  order for the message and informs all
• Or send to the sequencer and the sequencer
  multicast with total order information
• Each sender can take turn to serve as the
  sequencer

13
Group membership service

• Input
• Process join events
• Process leave events
• Apparent failures
• Output
• Membership views for group(s) to which those
  processes belong

14
Issues?

• The service itself needs to be fault-tolerant
• Otherwise our entire system could be crippled by
  a single failure!
• Hence Group Membership Service (GMS) must run
  some form of protocol (GMP)

15
Approach

• Assume that GMS has members p,q,r at time t
• Designate the oldest of these as the protocol
  leader
• To initiate a change in GMS membership, leader
  will run the GMP
• Others cant run the GMP they report events to
  the leader

16
GMP Example
p
q
r

• Example
• Initially, GMS consists of p,q,r
• Then q is believed to have crashed

17
Unreliable Failure Detection

• Recall that failures are hard to distinguish from
  network delay
• So we accept risk of mistake
• If p is running a protocol to exclude q because
  q has failed, all processes that hear from p
  will cut channels to q
• Avoids messages from the dead
• q must rejoin to participate in GMS again

18
Basic GMP

• Someone reports that q has failed
• Leader (process p) runs a 2-phase commit protocol
• Announces a proposed new GMS view
• Excludes q, or might add some members who are
  joining, or could do both at once
• Waits until a majority of members of current view
  have voted ok
• Then commits the change

19
GMP Example
Proposed V1 p,r
Commit V1
p
q
r
OK
V0 p,q,r
V1 p,r

• Proposes new view p,r -q
• Needs majority consent p itself, plus one more
  (current view had 3 members)
• Can add members at the same time

20
Special Concerns?

• What if someone doesnt respond?
• P can tolerate failures of a minority of members
  of the current view
• New first-round overlaps its commit
• Commit that q has left. Propose add s and drop
  r
• P must wait if it cant contact a majority
• Avoids risk of partitioning

21
What If Leader Fails?

• Here we do a 3-phase protocol
• New leader identifies itself based on age ranking
  (oldest surviving process)
• It runs an inquiry phase
• The adored leader has died. Did he say anything
  to you before passing away?
• Note that this causes participants to cut
  connections to the adored previous leader
• Then run normal 2-phase protocol but terminate
  any interrupted view changes leader had initiated

22
GMP Example
p
Proposed V1 r,s
Commit V1
Inquire -p
q
r
OK
OK nothing was pending
V0 p,q,r
V1 r,s

• New leader first sends an inquiry
• Then proposes new view r,s -p
• Needs majority consent q itself, plus one more
  (current view had 3 members)
• Again, can add members at the same time

23
Safe and Agreed Delivery

• For totally ordered reliable multicast, there are
  two delivery policies
• Safe delivery a message is delivered only when
  all correct processes have received it
• Agreed delivery a message is delivered as long
  as it is the next message in total order

24
Safe and Agreed Delivery

• Safe delivery guarantees the uniformity of
  multicast
• If a message is delivered to any process, it is
  delivered by all correct processes
• Agreed delivery does not
• It is possible that a message is delivered in one
  (or more) process, but is not delivered by some
  correct process

25
Checkpointing and Recovery

• Faults occur over time. How to ensure a fault
  tolerant system remain operational for extensive
  period of time?
• Recover failed replicas, or replace failed
  replicas with new one gt Recovery is needed
• How to recover a failed replica or install a new
  replica?
• Checkpointing a correct replica and transfer the
  state to the recovering replica

26
Checkpointing

• Checkpointing the act of taking a snapshot of an
  entity so that we can restore it later
• A replica is a process running in an operating
  system. The state of a process
• Processes' memory, stack and registers
• Threads
• Open or mmap'ed files
• Current working directory
• Interprocess communication
• Semaphores, shared memory, pipes, sockets
• Dynamic Load Libraries

27
Checkpointing

• Many tools are available to perform checkpointing
  transparently or semi-transparently
• http//www.checkpointing.org/
• Condor, libckpt, etc.
• Checkpoints taken in general are not portable
• Checkpoint size might be big

28
Checkpointing of Application State

• Sometimes it is more efficient to save and store
  the application state only
• Checkpoints can be very portable and compact in
  size
• class Counter int counter Counter(int
  initVal) counter initVal void
  increment() counter void decrement()
  counter-- void setState(int c) counter
  c int getState() return counter

29
Logging

• Logging of messages
• Checkpointing in general is expensive
• Logging of messages is cheaper
• gt we can periodically do checkpointing, or do
  checkpointing on demand and log all messages in
  between
• Logging of other non-deterministic activities
• Access order to shared data

30
Roll-Forward Recovery

• With replication in space, it is possible to
  recover a fault while the system is progressing
  ahead
• Roll-forward recovery is made possible by
• Checkpointing of replica state
• Logging of incoming messages
• Reliable, totally ordered group communication
  system

31
Roll-Forward Recovery

• We want to ensure the newly admitted replica to
  have a consistent state with others when it
  starts
• Steps of adding a new replica into a group (with
  on-demand checkpointing)
• A recovered (or a new) replica joins a group
• A join message is multicast in total order
• On receiving the join message, it is put into
  incoming message queue and wait for processing
• When the join message is at the head of the
  queue, a checkpoint is taken and it is
  transferred to the new replica

32
Roll-Forward Recovery

• At the new replica, it starts queueing messages
  after it receives the join messages (sent by
  itself)
• When the checkpoint is received by the new
  replica, its state is restored using the received
  checkpoint (the checkpoint is delivered out of
  order!)
• The queued messages are delivered in order, at
  the new replica
• Other replicas do not stop and wait for the new
  replica
• Steps of adding a new replica into a group with
  periodic checkpointing is similar

33
Steps of Roll-Forward Recovery
34
Steps of Roll-Forward Recovery
35
Steps of Roll-Forward Recovery
36
Steps of Roll-Forward Recovery
37
Roll-backward Recovery

• Roll-backward recovery is used for systems
  relying on replication in time for fault
  tolerance
• When a failure occurs, roll back using the most
  recent checkpoint (and retry)

38
Roll-backward Recovery in a Distributed System

• Performing roll-backward recovery in a
  distributed system is non-trivial
• Need to solve the distributed snapshot problem
• It is easy to perform a local checkpoint of a
  process, but in a distributed system, when one
  process rolls back, other processes must also
  roll back to a consistent state

39
Distributed Snapshot Problem

• Goal Determine the global system state
• e.g. the total amount of money
• Assumptions
• Each process records its own state
• No shared clock/memory
• Imagine that a group of photographers taking
  snapshots of different portions and trying to
  combine to get the overall picture

40
Distributed Snapshot

• A distributed snapshot reflects a state in which
  the distributed system might have been
• What constitute a consistent global state?
• If we have recorded that process P has received a
  message from another process Q, then we should
  also have recorded that process Q had actually
  sent the message
• The reverse condition (Q has sent a message that
  P has not yet received) is allowed

41
Distributed Snapshot

• A pair of mutually consistent checkpoints

42
Distributed Snapshot

• A missing message
• gt need to log messages (i.e.,consider channel
  state in addition to process state)

43
Distributed Snapshot

• An orphan message
• The two checkpoints are definitely not consistent

44
Chandy and Lamport's Algorithm

• Assumptions
• FIFO, unidirectional, reliable channels (A
  bidirectional channel is modelled as two
  unidirectional channels)
• No process fails during the snapshot
• System state consists of process state and
  channel state (messages sent but not received)
• Any process P can initiate taking a distributed
  snapshot

45
Chandy and Lamport's Algorithm

• P starts by recording its own local state and
  sends a marker along each of its outgoing
  channels
• When Q receives a marker through channel C, its
  action depends on whether it had already recorded
  its local state
• Not yet recorded
• It records its local state, and sends the marker
  along each of its outgoing channels
• It starts recording incoming messages on OTHER
  channels
• Already recorded the marker on C indicates that
  the channels state should be recorded
• All messages received before this marker and
  after Q recorded its own state

46
Chandy and Lamport's Algorithm

• Q is finished when it has received a marker along
  each of its incoming channels
• The recorded local state as well as the state it
  recorded for each incoming channel, can be
  collected and sent to the process that initiated
  the snapshot
• The global state can be subsequently constructed

47
Chandy and Lamport's Algorithm
C1
M
C2
Process Q receives a marker for the first time
(from C1) and records its local state
Q records all incoming message on C2 (and other
incoming channels except C1, if any)
Q receives a marker for its incoming channel C2
and finishes recording the state of the incoming
channel C2
