Project - Designing a Virtual Environment

1
Project - Designing a Virtual Environment

• Erik Brisson
• ebrisson_at_bu.edu

2
Designing a Virtual Environment

• General Issues
• Theme / story / message
• Audience
• Physical space / venue
• Available technology
• Development constraints

3
Designing a Virtual Environment

• Design Issues
• Overall design vision, visual/aural theme
• Kind of space (interior, exterior, etc)
• Navigability
• Scale
• Methodology
• Tools

4
Landscape Plans
Used without permission from http//www.medwaycoo
pbank.com/main/color_landscape_plan.jpg
5
Landscape Plans
Used without permission from http//www.smartdraw
.com/examples/preview/index.aspx?exampleResidenti
al_-_10
6
World as set of simple objects
7
Grid on ground plane
8
Top-down view
9
Plan drawing on graph paper
10
Add axes for Cartesian coordinates
11
Plan drawing on graph paper
12
Plan drawing on graph paper
13
Specifying horizontal quadrilaterals
Horizontal square (x0,y0) (2,2) (x1,y1)
(4,2) (x2,y2) (4,4) (x3,y3) (2,4) On ground
(height h 0) hquad, x0, y0, x1, y1, x2, y2,
x3, y3, h hquad, 2, 2, 4, 2, 4, 4, 2, 4, 0
14
Plan drawing on graph paper
15
Specifying vertical rectangles
Vertical rectangle base line segment
endpoint0 (x0,y0) endpoint1 (x1,y1)
height h vrect, x0, y0, x1, y1, h vrect, 2,
5, 4, 5, 2 vrect, 4, 5, 4, 7, 2 vrect, 4, 7,
2, 7, 2 vrect, 2, 7, 2, 5, 2
16
Plan drawing on graph paper
17
Specifying cylinders
Vertical cylinder base circle center
(x0,y0) base circle radius r height
h vcyl, x0, y0, r, h vcyl, 0, 2, 0.5, 3
18
Plan drawing on graph paper
19
Plan drawing on graph paper
20
Specifying cones
Vertical cone base circle center (x0,y0)
base circle radius r height h vcone,
x0, y0, r, h vcone, 2, -5, 1, 2
21
The remaining rectangles
vrect, -1.5, -3, 0, -3, 2 vrect, 0, -3, 2, -1,
2 vrect, 2, -1, 0.5, -1, 2 vrect, 0.5, -1, -1.5,
-3, 2 hquad, 2, -5, 4, -3, 2, -1, 0, -3, 2
22
The description file
hquad, 2, 2, 4, 2, 4, 4, 2, 4, 0 vrect, 2, 5,
4, 5, 2 vrect, 4, 5, 4, 7, 2 vrect, 4, 7, 2,
7, 2 vrect, 2, 7, 2, 5, 2 vcyl, 0, 2, 0.5,
3 vcone, 2, -5, 1, 2 vrect, -1.5, -3, 0, -3,
2 vrect, 0, -3, 2, -1, 2 vrect, 2, -1, 0.5, -1,
2 vrect, 0.5, -1, -1.5, -3, 2 hquad, 2, -5, 4,
-3, 2, -1, 0, -3, 2
23
Project workflow
hquad, 2, 2, 4, 2, 4, 4, 2, 4, 0 vrect, 2, 5,
4, 5, 2 vrect, 4, 5, 4, 7, 2 vrect, 4, 7, 2,
7, 2 vrect, 2, 7, 2, 5, 2 vcyl, 0, 2, 0.5,
3 vcone, 2, -5, 1, 2 vrect, -1.5, -3, 0, -3,
2 vrect, 0, -3, 2, -1, 2 vrect, 2, -1, 0.5, -1,
2 vrect, 0.5, -1, -1.5, -3, 2 hquad, 2, -5, 4,
-3, 2, -1, 0, -3, 2
24
Texture mapping the cylinder
25
Texture mapping the cone?
