Clustering Data Streams

• A presentation by George Toderici

2
Talk Outline

1. Goals of the paper
2. Notation reminder
3. Clustering With Little Memory
4. Data Stream Model
5. Clustering with Data Streams
6. Lower Bounds and Deterministic Algorithms
7. Conclusion

3
Goals of the paper

• Since the k-Median problem is NP-hard this paper
  attempts to create an approximation with the
  following constraints
• Minimize memory usage
• Minimize CPU usage
• Work both on metric spaces and the special case
  of Euclidean space

4
Talk Outline

1. Goals of the paper
2. Notation reminder
3. Clustering With Little Memory
4. Data Stream Model
5. Clustering with Data Streams
6. Lower Bounds and Deterministic Algorithms
7. Conclusion

5
Notation Reminder
O(g(n)) running time is upper bounded by
g(n) O(g(n)) running time is lower bounded by
g(n) o(g(n)) running time is asymptotically
negligible ?(g(n)) memory usage is upper
bounded by g(n) not commonly used Soft-Oh
6
Paper-specific Notation

• cij is the distance between points i and j
• di the number of points associated with median i
• NOTE Do not confuse c and d. Presumably the
  distance has been chosen to be cij because
  distance can be treated as a cost. It would
  have been more intuitive to have it called d
  from the word distance.

7
Talk Outline

1. Goals of the paper
2. Notation reminder
3. Clustering With Little Memory
4. Data Stream Model
5. Clustering with Data Streams
6. Lower Bounds and Deterministic Algorithms
7. Conclusion

8
Clustering with little memory

• Algorithm SmallSpace(S)
• Divide S into l disjoint pieces X1Xl
• For each Xi find O(k) centers in it. Assign each
  point to its closest center.
• Let X be the set of O(lk) centers obtained where
  each center is weighed by the number of points
  assigned to it
• Cluster X to find k centers

9
SmallSpace (2)
K
10
SmallSpace analysis

• Since we are interested in using as little memory
  as possible, l has to be chosen so that both each
  partition of S and X fit in main memory.
  However, no such l may exist if S is very large.
• We will use this algorithm as a starting point
  and improve it so that it will satisfy all
  requirements.

11
Theorem 1

• Given an instance of the k-median problem with a
  solution of cost C, where the medians may not
  belong to the set of input points, there exists a
  solution of cost 2C where all the medians belong
  to the set of input points (metric space
  requirement).

12
Theorem 1 Proof

• Consider the figure
• The distance from (4) closest to the true mean
  to any other point (i) in the data is bounded by
  cimcm4 triangle inequality
• Therefore, the maximum cost for the median will
  be at most two times the cost of the median
  clustering with no constraints (worst case)

13
Theorem 2

• Consider a set of n points partitioned into
  x1,,xl (disjoint sets). The sum of the optimum
  solution values for the k-median problem on the l
  sets of points is at most twice the cost of the
  optimum k-median problem solution for all n
  points.

14
Theorem 2 Proof

• This is Theorem 1, but on l clusters.
• Apply theorem 2 l times, and obtain a maximum
  cost which is two times the cost in the case when
  it is allowed to have medians which are not part
  of the data

15
Theorem 3 (SmallSize Step 2)

• If the sum of the costs of the l optimum
  k-median solutions for x1,,xl is C and if C is
  the cost of the optimum k-median solution on the
  entire set S, then there exists a solution of
  cost at most 2(CC) to a the new weighted
  instance X.

16
Theorem 3 Proof (1)

• Let i be a point in X (a median obtained by
  SmallSpaces)
• Let the point to which i is assigned to in the
  optimum continuous solution be ?(i), and the
  number of points assigned to i be di
• Then the cost of X is

17
Theorem 3 Proof (2)

• Let i be a point in the set S. then let i(i) be
  the median in X to which it was assigned by
  SmallSpace.
• Then the cost of X can be written as
• Let the median assigned to i in the optimal
  continuous solution on S be ?(i)

18
Theorem 3 Proof (3)

• Because ? is optimal for X, the cost is no more
  than
• The last sum evaluates to C C for the
  continuous case or 2(C C) in the metric space
  case
• Reminder The sum of the costs of the l optimum
  k-median solutions for x1,,xl is C and C is the
  cost of the optimum k-median solution on the
  entire set S

19
Theorem 4 (SmallSize step 2, 4)

• If we modify step 2 to use a bicriteria
  approximation algorithm (a,b) where at most ak
  medians are output with a cost of at most b times
  the optimal k-Median solutions, and then
• Modify Step 4 to run a c-approximation algorithm,
  then
• Theorem 4 The algorithm SmallSpace has an
  approximation factor of 2c(1b)2b not proven
  here

20
SmallerSpace

• Algorithm SmallerSpace(S,i)
• Divide S into l disjoint pieces X1Xl
• For each Xi find O(k) centers in it. Assign each
  point to its closest center.
• Let X be the O(lk) centers obtained in (2) where
  each center is weighed by the number of points
  assigned to it
• Call SmallerSpace(X, i-1)

21
SmallerSpace 2
A small factor is lost in the approximation with
each level of divide and conquer

• In general, if Memoryne, need 1/e levels,
  approximation factor 2O(1/e)
• If n1012 and M106, then regular 2-level
  algorithm
• If n1012 and M103 then need 4 levels,
  approximation factor 24

k

22
SmallerSpace Analysis

• Theorem 5 For a constant i, SmallerSpace(S,i)
  gives a constant factor approximation to the
  k-median problem.
• Proof The approximation at level j is
  Aj2Aj-1(2b1) 2b (Theorem 2,4) which has the
  solution Ajc(2(b1))j which is O(1) if j is
  constant.

23
SmallerSpace Analysis (2)

• Then, since all intermediate medians X must be
  stored in memory, the number of subsets l that we
  partition S into is limited.
• In fact, we need lk lt M, and such an l may not
  exist (where M is the memory size)

24
Talk Outline

1. Goals of the paper
2. Notation reminder
3. Clustering With Little Memory
4. Data Stream Model
5. Clustering with Data Streams
6. Lower Bounds and Deterministic Algorithms
7. Conclusion

25
Datastream model

• Datastream set of ordered points x1,,xi ,, xn
• Algorithm performance is measured as the number
  of passes on the data given the constraints of
  available memory
• Usually the number of points is extremely large
  so it is impossible to fit all of them in memory
• Usually once a point has been read it is very
  expensive to read it again. Most algorithms
  assume the data will not be available for a
  second pass.

26
Data Stream Algorithm

1. Input the first m points use a bicriterion
   algorithm to reduce these to O(k) (e.g., 2k)
   points. Weigh each intermediate median by the
   number of points assign to it. (depending on
   algorithm used this can take O(m2) or O(mk))
2. Repeat (1) until we have seen m2/(2k) of the
   original data points.
3. Cluster these m first-level medians into 2k
   second-level medians

27
Data Stream Algorithm (2)

• Maintain at most m level-i medians, and on seeing
  m, generate 2k level-i1 medians with the weight
  of the new median as the sum of the weights of
  the intermediate medians.
• When we have seen all data points or when we
  decide to stop we cluster all intermediate
  medians into k final medians

28
Data Stream Algorithm (3)
Level 2
M-gtK
2k

Level 3
Level i
M-gtK
M-gtK
2k
FinalK
2k



29
Data Stream Algorithm Analysis

• The algorithm requires O(log(n/m)log(m/k)) levels

• If k much smaller than m, and m O(n?) for ? lt
  1
• ?(n?) space
• O(n1 ?) run time
• up to a O(21/?) approximation factor (constant
  factor approximation)

30
Talk Outline

1. Goals of the paper
2. Notation reminder
3. Clustering With Little Memory
4. Data Stream Model
5. Clustering with Data Streams
6. Lower Bounds and Deterministic Algorithms
7. Conclusion

31
Randomized Algorithm

1. Draw a sample of size s (nk)1/2
2. Find k medians from these s points using a primal
   dual algorithm
3. Assign each of the original points to its closest
   median
4. Collect n/s points with the largest assignment
   distance
5. Find k medians from among these n/s points
6. At this point we have 2k medians

32
Randomized Algorithm Analysis

• The algorithm gives a O(1) approximation with 2k
  medians with constant probability.
• O(log n) passes for high probability results
• time and space
• Space can be improved to O((nk)1/2)

33
Full Algorithm

1. Input the first O(M/k) points then use the
   randomized algorithm to find 2k intermediate
   median points
2. Use a local search algorithm to cluster O(M)
   intermediate median points of level i to 2k
   medians of level i1
3. Use the primal dual algorithm to cluster the
   final O(k) medians into k medians

34
Full Algorithm (2)

• The full algorithm is still one pass (we call the
  randomized algorithm only once per input set)
• Step 1 is
• Step 2 is O(nk)
• Therefore, the final cost is

35
Talk Outline

1. Goals of the paper
2. Notation reminder
3. Clustering With Little Memory
4. Data Stream Model
5. Clustering with Data Streams
6. Lower Bounds and Deterministic Algorithms
7. Conclusion

36
Lower Bounds

• Consider a clustering where the distance between
  two points is 1 if they belong to the same
  cluster and 0 otherwise
• An algorithm is not constant factor if it does
  not discover a clustering of cost 0
• Finding such a clustering is equivalent to the
  following in a complete k-partite graph G for
  some k, find the k-partition of vertices of G
  into independent sets.
• The best algorithm to find that requires ?(nk)
  queries and therefore lower bounds any c.f.
  clustering algorithm

37
Deterministic Algorithms A1

1. Partition the n original points into p1 subsets
2. Apply the primal dual algorithm to each subset
   (O(an2) for each)
3. Apply it again to the p1k weighted points
   obtained at (2) to get the final k medians

38
A1 Details

• If we choose the number of subsets p1 (n/k)2/3
  we have
• O(n4/3k2/3) runtime and space
• 4c2 4c approximation factor by Theorem 4, where
  c is the approximation given by the primal-dual
  algorithm

39
Deterministic Algorithms A2

1. Split the dataset into p2 partitions
2. Apply A1 on each of them
3. Apply A1 on all the intermediate medians at (2)

40
A2 Details

• If we choose the number of subsets p1 (n/k)4/5
  in order to minimize the running time we have
• O(n16/15k14/15) runtime and space
• We can see a trend!

41
Deterministic Algorithm

• Create algorithm Ai that calls Ai-1 on pi
  partitions
• Then the complexity in both time and space of
  this algorithm will be

42
Deterministic Algorithm (2)

• The approximation factor grows with i, however
• We can set i?(log log log n) in order to get the
  exponent of n in the running time to be 1.

43
Deterministic Algorithm (2)

• This gives an algorithm running in
• space and time.

44
Talk Outline

1. Goals of the paper
2. Notation reminder
3. Clustering With Little Memory
4. Data Stream Model
5. Clustering with Data Streams
6. Lower Bounds and Deterministic Algorithms
7. Conclusion

45
Conclusion

• We have presented a variety of algorithms
  optimized to address the problem of clustering in
  systems where the amount of data is huge
• All the algorithms presented are just
  approximations to the k-means problem

46
References

1. Eric W. Weisstein. "Complete k-Partite Graph."
   From MathWorld--A Wolfram Web Resource.
   http//mathworld.wolfram.com/Completek-PartiteGrap
   h.html
2. http//theory.stanford.edu/nmishra/CS361-2002/lec
   ture9-nina.ppt
