MQX RTOS

1
MQX RTOS

•


•
  by
  Liao,Hsiao-Win

2
Features Benefits I

• Powerful
• Microkernel Architecture designed for
  embedded systems
• Designed for single-CPU and multi-CPU targets
• True real-time performance and small
  footprint
• Includes MQX Host Tools

3
Features Benefits II

• Flexible
• Delivered in full source
• Enables MQX Embedded Stacks, Networking
  Components,and Platform Enhancements
• Tightly Integrated
• Task-Aware Debugging with MetaWare and
  CodeWarrior tools
• Proven
• Shipping in thousands of designs

4
New Features

• Multiple memory pools
• MMU support
• Higher resolution for timers
• Lightweight components
• Task restarts
• Callout futions

5
Advantage I

• Small
• ? MQX RTOSs small size conserves memory space
  and reduces power consumption.
• Portable
• ? The MQX RTOS supports popular embedded
  architectures including ARC.,ARMR, Freescale.
  68K/ColdFire., IBMR/Freescale./AMCC PowerPC.,
  MIPSR and Intel XScaleR
• ? Supports single-processor and mutiprocessor
  designs

6
Advantage II

• Configurable and Scalable
• ? The minimum RTOS configuration requires only 8
  of 25 available components other components are
  linked in only if used by the application.
• High Performance
• ? Time-critical services have been optimized for
  speed and deterministic performance, ensuring
  fast context switch and low-level interrupt times

7
What can be configured?

• Processor register file type and size,
  interrupts, endianness, reset state
• Caches I and/or D, size, ways, line length
• Closely Coupled Memory I and/or D, size
• Additional instructions many optional general
  purpose and DSP instructions
• ARC XY Advanced DSP subsystem memory size,
  banks, ports
• Timers
• Bus BVCI, AMBA/AHB
• Debug JTAG, actionpoints

8
ARC's configurability is the freedom to

• Add components to provide required features
• Add components to increase performance
• Remove unneeded components
• Configure components for maximum efficiency in a
  specific application

9
MQX RTOS Component Diagram
10

11
The ARChitect processor configurable tool
12
Memory Management

• Default variable sized memory allocation and
  de-allocation
• A simpler lightweight memory manager
• MQX offers fixed size buffer management an
  partitions component
• MQX supports the use of multiple memory pools to
  allow separate control of on-chip and off-chip
  memory resource

13
Processor and Board Support

• MQX RTOS is currently available on a full range
  of leading 32-bit embedded processors, including
  ARC, ARM, ColdFire, MIPS, and PowerPC
  processors from ARC, Atmel, AMCC, ARM. Freescale,
  Cirrus Logic, IBM, Intel, Oki, Phytec, and
  Samsung, among others.
• Board Support Packages are available for
  evaluation, development and production boards
  from processor suppliers, ADI Engineering,
  Analogue Micro, Avnet, Arrow, Embedded Planet,
  Logic Product Development, and TQ Components,
  among others.

14
Configurable Cores

• ARC 600 Family
• ARC 605 Core
• ARC 610D Core
• ARC 625D Core
• ARC 700 Family
• ARC 710D Core
• ARC 725D Core
• ARC 750D Core
• ARC XY Advanced DSP Subsystem

15
(No Transcript)
