Using Relational Databases and SQL

1
Using Relational Databases and SQL
Lecture 6 Midterm Review

• Department of Computer Science
• California State University, Los Angeles

2
Administrative

• Midterm is next Thurs at the regular class time
• How to get extra credit
• Come to my office hours or send me email
• I will write some questions that specifically
  address the areas where you need more work

3
Midterm Format

• 10 Problems
• Similar to Labs?
• 3 short answer
• 1 one-paragraph answer?
• 2 SQL to English
• 4 English to SQL

4
Midterm Rules

• No laptops lab machines only.
• If you have not used the command line tools or
  workbench on the lab machines, learn how to do
  this before you leave today.
• Internet Reference sources OK (Wiki, CSNS,
  MySQL). You will definitely need the lyric
  database diagram.
• No messaging, cell phones, or any other medium
  with a live human at the other end
• Printed lecture notes, cheat sheets OK.
• Lecture notes on computer OK, but I recommend you
  print out the most important pages
• Don't communicate with anyone
• Don't ask for hints

5
Review What is a Database?

• A structured collection of persistent data
• Structured using a database model
• Examples
• Airlines, Banks
• Stores
• Universities

6
Review Physical/Logical Separation

• Previous to the relational model, one had to
  write a program that traversed pointers at the
  physical level to extract data from a database
  (think like programming in assembly language)
• By abstracting the physical level and writing a
  program at the logical level instead (think like
  programming in Java), extracting data from a
  database became much easier
• First proposed by Dr. Edgar Frank Codd.

7
Relational Model

• Proposed by Edgar F. Codd (circa 1969)?
• Database is a collection of tables (relations)
• Relational model is very mathematical
• Dominant database model
• Thanks to Larry Ellison, founder of Oracle, who
  was first to aggressively market a commercial
  relational database product (Ellison is currently
  the 4th richest person in the world)

8
Database Schemas

• The definition of the database, where you define
• Tables
• Relationships
• Constraints
• Stored Functions and Procedures
• Views
• Indexes
• Schemas are typically represented by a schema
  diagram

9
Database Management Systems (DBMS)?
10
SQL

• Stands for Structured Query Language
• A (mostly) non-procedural, domain-specific
  language (not like C or C)?
• An open ANSI standard
• Supported by most major DBMS
• Some variations in implementations
• Used by programmers, managers, and database
  administrators

11
Primary Keys

• A primary key is a column name where all values
  must be unique a primary key value is a value
  that is used to uniquely identify every record in
  a table (for example, what would happen to our
  school database if more than one person were
  allowed to have the same CIN number, or if more
  than one person were allowed to have the same SSN
  number?)
• Primary keys are used to protect database data
  from anomalies

12
Foreign Keys

• A foreign key is a column name whose data
  contains the primary key values of another table
• For example, ArtistID in the Titles table
  contains values that come from the Artists table
  (the ArtistID column in the Artists table, for
  which it is the primary key)
• Foreign keys are also used to protect our
  database data from anomalies for example, in the
  Titles table, what if we had an ArtistID of 100
  in there? Who is ArtistID 100? Which artist is it?

13
SQL Data Types

• Dates
• '2005-02-14', '1973-08-13'
• Dates are in 'YEAR-MONTH-DAY' string format
• Boolean
• TRUE
• FALSE
• NULL

14
AND, OR, and NOT

• Examples
• -- Display all member names from California or
  Texas.SELECT FirstName, LastName FROM
  MembersWHERE Region'CA' OR Region'TX'
• -- Display all titles whose genre is not
  alternative.SELECT FROM TitlesWHERE NOT
  (Genre 'alternative')
• -- Display all member names from California or
  Texas who have a sales ID of 2.SELECT FirstName,
  LastName FROM MembersWHERE (Region'CA' OR
  Region'TX') AND SalesID2

15
AND, OR, and NOT

• Be careful of parentheses
• SELECT FirstName, LastName FROM MembersWHERE
  (Region'CA' OR Region'TX') AND SalesID2
• SELECT FirstName, LastName FROM MembersWHERE
  Region'CA' OR Region'TX' AND SalesID2
• OUCH! 2nd query does not return the right result.

16
Using NOT Correctly

• If the intention is to negate the result of the
  boolean expression in the WHERE clause, always
  surround the expression with parentheses.
• Example
• Do the following two queries return the same
  result?
• SELECT FROM ArtistsWHERE NOT TRUE AND FALSE
• SELECT FROM ArtistsWHERE NOT (TRUE AND FALSE)

17
IS NULL

• Do not use conditional operators to compare NULL
• NULL is a special keyword, not a specific value
• Why? Consider
• SELECT (NULL NULL) -- NULL
• SELECT (NULL IS NULL) -- TRUE
• To determine if something is NULL
• Use the IS NULL keyword
• To determine if something is not NULL
• Use the IS NOT NULL keyword

18
CASE Examples

• -- List all track titles and their length in
  minutes. If the length of the track title is less
  than 3 minutes, display Short Track otherwise,
  display Long Track.
• SELECT TrackTitle, LengthSeconds/60, CASE WHEN
  LengthSeconds/60 lt 3 THEN 'Short Track'
  ELSE 'Long Track'ENDFROM Tracks

19
CASE Examples

• List all track titles and their length in
  minutes. If the length of the track title is less
  than 3 minutes, display Short Track less than
  4 minutes, display Medium Track otherwise,
  display Long Track.
• SELECT TrackTitle, LengthSeconds/60,CASEWHEN
  LengthSeconds/60 lt 3 THEN 'Short Track'WHEN
  LengthSeconds/60 lt 4 THEN 'Medium Track' ELSE
  'Long Track'ENDFROM Tracks

20
Column Aliases

• Last CASE example had a really long column name.
• To get rid of that we can use column aliases
• SELECT expression AS alias FROM
• Example
• SELECT TrackTitle, LengthSeconds/60,CASEWHEN
  LengthSeconds/60 lt 3 THEN 'Short Track'WHEN
  LengthSeconds/60 lt 4 THEN 'Medium Track' ELSE
  'Long Track'END AS 'Track Description'FROM
  Tracks

21
SELECT DISTINCT

• Use when you want to remove duplicate results
• Example
• Display a list of unique countries that all
  members come from.
• SELECT Country FROM Members // WRONG!!!
• SELECT DISTINCT Country FROM Members//
  CORRECT!!!

22
Join Types

• Use a join (choose one from several join types)
• SELECT ArtistName, TitleFROM Artists NATURAL
  JOIN Titles
• SELECT ArtistName, Title FROM Artists JOIN
  Titles USING(ArtistID)
• SELECT ArtistName, Title FROM Artists A INNER
  JOIN Titles T ON A.ArtistID T.ArtistID
• SELECT ArtistName, Title FROM Artists A, Titles
  TWHERE A.ArtistID T.ArtistID

23
Cartesian Product Example

• Given these two tables, what is the Cartesian
  Product?
• A SELECT FROM Artists
• B SELECT FROM Titles
• Use a CROSS JOIN, which is the simplest type of
  join in SQL, to get the Cartesian Product
• A x B SELECT FROM Artists CROSS JOIN Titles

24
Natural Joins

• In a natural join, no join condition is specified
• Join condition is determined automatically by
  name
• Syntax
• SELECT attribute_listFROM A NATURAL JOIN B
• Example
• SELECT FROM Artists NATURAL JOIN Titles

25
Problems with Natural Joins

• Try the following
• SELECT FROM Members NATURAL JOIN SalesPeople
• Does it produce the expected results?
• Yes, but its not the join condition you wanted
• Wanted (match members with their supervisors)
• Members.SalesID SalesPeople.SalesID
• Natural join uses (crazy stuff)
• Members.SalesID SalesPeople.SalesID AND
  Members.FirstName SalesPeople.FirstName
  ANDMembers.LastName SalesPeople.LastName
• Rarely use natural joins

26
Named Column Joins

• To solve the problem with natural joins, you may
  override the attribute names that a natural
  join chooses by using a named column join
• Also called JOIN USING syntax
• Syntax
• SELECT attribute_listFROM A JOIN B
  USING(column_name)
• SELECT attribute_listFROM A JOIN B USING(name1,
  name2, )

27
More on Named Column Joins

• The following two queries are equivalent
• SELECT FROM Artists NATURAL JOIN Titles
• SELECT FROM Artists JOIN Titles USING(ArtistID)
• Same thing, except that in a named column join,
  YOU specify the COMMON attribute used for the
  join condition

28
More on Named Column Joins

• Remember this join that produced bad results?
• SELECT FROM Members NATURAL JOIN SalesPeople
• Thats because its equivalent to
• SELECT FROM Members JOIN SalesPeopleUSING(First
  Name, LastName, SalesID)
• To fix, use this instead
• SELECT FROM Members JOIN SalesPeople
  USING(SalesID)

29
Inner Joins

• In an inner join, you explicitly write a full
  join condition expression in an ON clause
• Useful when meaningful, comparable attribute
  names arent named the same way (i.e.
  People.PersonID and Spouses.HusbandID)
• Syntax
• SELECT attribute_listFROM A INNER JOIN B ON
  join_condition

30
Inner Join Example

• Examples
• SELECT FROM Artists A INNER JOIN Titles T ON
  A.ArtistID T.ArtistID
• SELECT FROM SalesPeople P INNER JOIN Studios S
  ON P.SalesID S.SalesID -- SORRY!!! -D
• -- A named column join cant do this one!SELECT
  / uses Movie Archive Database /FROM
  People P INNER JOIN Spouses S ON P.PersonID
  S.HusbandID

31
Equi-Joins

• Equivalent to an inner join, but with a different
  syntax
• Uses a comma separated list of tables in the FROM
  clause instead of the JOIN clause
• Join condition is specified in the WHERE clause
• Syntax
• SELECT attribute_listFROM A, BWHERE
  join_condition

32
Equi-Join Examples

• Examples
• SELECT FROM Artists A, Titles TWHERE
  A.ArtistID T.TitleID
• SELECT FROM Members M, Studios SWHERE
  M.SalesID S.SalesID

33
Inner Joins

• In an inner join, you explicitly write a full
  join condition expression in an ON clause
• Useful when meaningful, comparable attribute
  names arent named the same way (i.e.
  People.PersonID and Spouses.HusbandID)
• Syntax
• SELECT attribute_listFROM A INNER JOIN B ON
  join_condition

34
Typical Self Joins
1 List all employees (first and last names) who
are supervised by no one. Select FirstName,
LastName from employee E where E.SuperVisorID
is null Self-join not needed yet
35
Typical Self Joins
2 List all employees whose supervisors are
supervised by no one.
36
Typical Self Joins
2 List all employees whose supervisors are
supervised by no one. SELECT E.FirstName,
E.LastName FROM Employee E JOIN Employee S ON
E.SupervisorID S.EmployeeID WHERE
S.SupervisorID IS NULL
37
Typical Self Joins
3 What does this one get us? SELECT
E.FirstName, E.LastNameFROM Employee E JOIN
Employee S ON E.SupervisorID S.EmployeeID JOIN
Employee SS ON S.SupervisorID
S.EmployeeIDWHERE SS.SupervisorID IS NULL
38
Self Joins for Pairs of Records

• List all pairs of titles for which both titles
  were recorded at the same studio
• Naïve solution
• Select T1.Title, T2.Title from Titles T1 join
  Titles T2 on T1.StudioID T2.StudioID
• What will we get?
• Somewhat better solution
• Select T1.Title, T2.Title from Titles T1 join
  Titles T2 on T1.StudioID T2.StudioID where
  T1.Title ltgt T2.Title
• What will we get?

39
Self Joins for Pairs of Records

• List all pairs of titles for which both titles
  were recorded at the same studio
• The right solution
• Select T1.Title, T2.Title from Titles T1 join
  Titles T2 on T1.StudioID T2.StudioID where
  T1.Title lt T2.Title

40
Outer Join Types

• Left Join
• Every record from the left (first) table will
  always be listed at least once
• If a matching record is found in the right
  (second) table, it is listed normally (same as
  inner join)?
• If there are no matching records to be found in
  the right (second) table (zero-matching records),
  the record from the left table is still reported,
  albeit it is associated with NULL values in the
  right table.
• Right Join
• Same as left join, but swapping left and right

41
Outer Join Syntax

• SELECT attribute_listFROM table1 LEFT JOIN
  table2ON join_condition
• NATURAL JOIN syntax
• SELECT attribute_listFROM table1 NATURAL LEFT
  JOIN table2
• JOIN USING syntax
• SELECT attribute_listFROM table1 RIGHT JOIN
  table2 USING(attribute)

42
Inner Joins vs. Outer Joins
Select Artistname, Title From Artists A Inner
Join Titles T ON A.ArtistIDT.ArtistID   Artistna
me Title
--------------------------------
---------------------------- The Neurotics
Meet the Neurotics Confused
Smell the Glove The Bullets
Time Flies The Neurotics
Neurotic Sequel Sonata
Sonatas Louis Holiday
Louis at the Keys
43
Inner Joins vs. Outer Joins
Select Artistname, Title From Artists A Left
Join Titles T ON A.ArtistIDT.ArtistID   Artistna
me Title
---------------------------------
----------------------------- The Neurotics
Meet the Neurotics The Neurotics
Neurotic Sequel Louis Holiday
Louis at the Keys Word
NULL Sonata
Sonatas The Bullets
Time Flies Jose MacArthur
NULL Confused Smell the
Glove The Kicks
NULL Today NULL 21
West Elm NULL Highlander
NULL
44
Extracting Unmatched Data From Outer Joins

• To extract the zero-matching results from an
  outer join, you must test the primary key (from
  the opposite side of the outer join) for NULL
• For example, for A LEFT JOIN B, to extract the
  records in A that have no matches in B, you must
  test the primary key in B (the right table) for
  NULL in the WHERE clause

45
Extracting Unmatched Data From Outer Joins

• List all artists and the titles they have
  recorded, including those who have not recorded
  anything
• Select A.ArtistName, T.Title from Artists A left
  join Titles T using (ArtistID)
• Review is null
• List only artists who have not recorded anything
• Select A.ArtistName, T.Title from Artists A left
  join Titles T using (ArtistID) where T.Title is
  null

46
What is a Function?

• Portion of prewritten code in MySQL used to
  perform a very specific task
• A function in SQL consists of
• Zero or more input values
• A named function identifier
• One output value
• Functions in SQL are useful for
• Formatting and extracting data
• Mathematical computing, converting data
• Review the functions from the notes and know how
  to find info in MySQL documentation

47
Strings and String Functions

• Unlike strings in Java, C, C, and C, SQL
  strings use indexes that start from 1
• 's t e v e n' 1 2 3 4 5 6 (SQL indexes) 0 1 2
  3 4 5 (C indexes)
• To extract 'even' from 'steven' we must start at
  position 3 and extract 4 characters
• SELECT SUBSTRING('steven', 3, 4)

48
About Dates

• You can do math on date values, using the
  INTERVAL keyword
• select entrydate, adddate(entrydate, interval 10
  year) from artists
• select entrydate, subdate(entrydate, interval 10
  year) from artists
• Valid intervals are DAY, MONTH. YEAR
• SELECT DATEDIFF(entrydate, '2007-12-31 235959')
  from artists

49
Control Flow Functions

• IF(condition, true_expr, false_expr)?
• select if(M.LastName 'sanders', 'yes', 'no')
  from Members M
• ISNULL(expr1)?
• CASE WHEN ISNULL(expr1) THEN expr2ELSE expr1 END
• NULLIF(expr1, expr2)?
• CASE WHEN expr1 expr2 THEN NULLELSE expr1 END
• More information on control flow functions can be
  found here.

50
Functions and Column Aliases

• Column aliases can be used in any of the
  following clauses
• GROUP BY
• HAVING (MySQL yes, PostgreSQL no)
• ORDER BY
• You cannot refer to column aliases in the
  following clauses
• SELECT
• FROM
• WHERE

51
Functions and Column Aliases

• Therefore, if you have a long function expression
  and want to use it in the WHERE clause too, using
  a column alias wont work
• You must manually duplicate the expression (by
  copying and pasting it) into the WHERE clause
