CprE / ComS 583 Reconfigurable Computing

1
CprE / ComS 583Reconfigurable Computing
Prof. Joseph Zambreno Department of Electrical
and Computer Engineering Iowa State
University Lecture 5 FPGA Arithmetic
2
Quick Points

• HW 1 due Thursday at 1200pm
• Any comments?

3
Recap

• Cluster size of N 6-8 is good, K 4-5

4
LUT Mapping Techniques
5
LUT Mapping Techniques (cont.)
6
LUT Mapping Techniques (cont.)
7
Outline

• Recap
• Motivation
• Carry / Cascade Logic
• Addition
• Ripple Carry
• Carry Bypass
• Carry Select
• Carry Lookahead
• Basic Multipliers

8
Motivation

• Traditional microprocessors, DSPs, etc. dont use
  LUTs
• Instead use a w-bit Arithmetic and Logic Unit
  (ALU)
• Carry connections are hard-wired
• No switches, no stubs, short wires

(2)
(1) AND2 OR2 XOR2
A
B
Cin
3-LUT
3-LUT
Sum
Cout / Cin
A
B
(2) ADD SUB CMP
3-LUT
3-LUT
Sum
Cout
9
Adder Delays

• Assuming a ripple-carry adder
• 32-bit ALU delay 6ns
• 32-cascaded 4-LUTs 32 x 2.5ns 80ns
• Motivates extra hardware to accelerate carry
  operations

Compare 32-bit ALU (0.6?)
4-LUT delay
16 ns
Area optimized
2.0 ns
Logic delay
6 ns
Delay optimized
0.5 ns
Single channel delay
2.5 ns
per bit
10
Altera Flex 8000 Carry Chain
11
Xilinx XC4000 Carry Chain
12
Cascades

• Large fanin operations (reductions)
• Decoding
• Matching
• Completion detection
• Many-to-one reductions
• Combining logic is simple
• Makes use of dedicated paths

13
Altera Cascade Logic

• LE delay 2.4 ns
• Cascade delay 0.6 ns

14
Why Look at Arithmetic?

• Parallelization
• Specialization
• Architecture
• Size
• Inputs
• Adder problem delay grows linearly with bit
  width
• Solutions for larger adders
• Pipelining
• Carry bypass
• Carry select

15
Adder Pipelining

• Not as practical in ASIC world (registers are
  expensive)
• Registers essentially free in FPGA logic blocks

A1
B1
A2
B2
A3
B3

Cout
S1

Cout
S2

S3
Cout
16
Carry Bypass Adders

• If all the propagates are 1 (P0P1P2P3 1) then
  Cout3 Cin
• Pi Ai xor Bi
• Skip all the carry logic
• Inexpensive

A0
B0
A1
B1
A2
B2
A3
B3
Cout0
Cout1
Cout2




Cin
Cout3
0 1
P0P1P2P3
17
Carry Bypass Performance

• Small hardware cost
• 16-bit add 4 CLB overhead
• 32-bit add 9 CLB overhead
• Delay growth still linear, smaller slope

Ripple Carry
Carry Bypass
Delay
N-bit Adder
18
Carry Select Adders

• Precompute addition value for (Cin 0) case and
  (Cin 1) case
• Use mux to select between two with actual Cin
  value
• Cost of this approach?

A0
B0
A1
B1
A2
B2
A3
B3




Cin
A4
B4
A5
B5
A6
B6
A7
B7




0
S4-7
0

1




1
A4
B4
A5
B5
A6
B6
A7
B7
19
Linear Carry-Select

• Adder delay w, mux delay 1

A31-24
A23-16
A15-8
A7-0
B31-24
B23-16
B15-8
B7-0




0
0
0
0




1
1
1
1
t8
t8
t8
t8
t8
t8
t8
t8
t9
t10
t11
t12
S31-24
S23-16
S15-8
S7-0
20
Square-Root Carry Select

• Each carry arrives when the corresponding sum is
  ready

A31-30
A29-22
A21-15
A14-9
A8-4
A3-0
B31-30
B29-22
B21-15
B14-9
B8-4
B3-0






0
0
0
0
0
0






1
1
1
1
1
1
t4
t4
t5
t5
t6
t6
t7
t7
t8
t8
t5
t6
t7
t8
t9
t10
S31-30
S29-22
S21-15
S14-9
S8-4
S3-0
21
Constant Addition

• If one operand is constant
• More speed?
• Less hardware?

A0
0
A1
A2
A3
1
0
1
HA
FA
FA
FA
C3
S0
S1
S2
S3
22
Multiplication

• Shift and add operations
• Need N bit adder, M cycles

42 101010 Multiplicand (N bits) x 10
x 1010 Multiplier (M bits) 000000
101010 Partial products
000000 101010 420 111001110 Product
(NM bits)
23
Array Multiplier
X0
X1
X2
X3
Y0

• Area N x M cells
• Delay O(NM)

Y1
X1
X2
X0
X3




Y2
X1
X2
X0
X3




Y3
X1
X2
X0
X3




Z0
Z1
Z2
24
Carry-Save
X0
X1
X2
X3
Y0
Y1
X1
X2
X0
X3




Y2




Y3




Z0
Z1
Z2
25
Multiplier Pipelining

• Register cost
• Multiplicand (N bits/stage x M stages)
• Multiplier (M2 M) / 2 bits
• Early output values (M2 M) / 2 bits
• Total M x (N M 1) bits
• Critical path max
• DFF FA setup
• Bottom-level adder

26
Constant Multiplier
Y00

• Can greatly reduce the number of adders
• Removes all and gates

Y11
X1
X2
X0
X3
Y20
Y31
X1
X2
X0
X3




Z0
Z1
Z2
27
LUT-based Constant Multipliers

• k-LUT can perform constant multiply of k-bit
  number
• Break operand into k-bit quantities
• Example 8-bit x 8-bit constant, k4

10101011 x NNNNNNNN
AAAAAAAAAAA (N 1011 (LSN)) BBBBBBBBBBBBBBB
(N 1010 (MSN)) SSSSSSSSSSSSSSS Product
28
Summary

• Latency overhead of programmable logic
• Several approaches to reducing design latency
• Fast carry
• Cascade
• Hardwired connections
• Multiplier optimization goals different from
  adder
• Other techniques
• Logarithmic v. linear (Wallace Tree multiplier)
• Data encoding (Booths multiplier)
