CprE / ComS 583 Reconfigurable Computing

1
CprE / ComS 583Reconfigurable Computing
Prof. Joseph Zambreno Department of Electrical
and Computer Engineering Iowa State
University Lecture 12 Systolic Computing
2
Recap Multi-FPGA Systems

• Crossbar topology
• Devices A-D are routing only
• Gives predictable performance
• Potential waste of resources for near-neighbor
  connections

3
Recap Logic Emulation

• Emulation takes a sizable amount of resources
• Compilation time can be large due to FPGA compiles

4
Recap Virtual Wires

• Overcome pin limitations by multiplexing pins and
  signals
• Schedule when communication will take place

5
Outline

• Recap
• Introduction and Motivation
• Common Systolic Structures
• Algorithmic Mapping
• Mapping Examples
• Finite impulse response
• Matrix-vector product
• Banded matrix-vector product
• Banded matrix multiplication

6
Systolic Computing

• systole (sist?-le) n. the rhythmic
  contraction of the heart, especially of the
  ventricles, by which blood is driven through the
  aorta and pulmonary artery after each dilation or
  diastole
• Greek systole, from systellein to contract,
  from syn- stellein to send
• systolic (sis-tõlik) adj.
• Data flows from memory in a rhythmic fashion,
  passing through many processing elements before
  it returns to memory.
• Kung, 1982

7
Systolic Architectures

• Goal general methodology for mapping
  computations into hardware (spatial computing)
  structures
• Composition
• Simple compute cells (e.g. add, sub, max, min)
• Regular interconnect pattern
• Pipelined communication between cells
• I/O at boundaries

x

x
min
x
x
c
8
Motivation

• Effectively utilize VLSI
• Reduce Von Neumann Bottleneck
• Target compute-intensive applications
• Reduce design cost
• Simplicity
• Regularity
• Exploit concurrency
• Local communication
• Short wires (small delay, less area)
• Scalable

9
Why Study?

• Original motivation specialized accelerator for
  an application
• Model/goals is a close match to reconfigurable
  computing
• Target algorithms match
• Well-developed theory, techniques, and solutions
• One big difference Kungs approach targeted
  custom silicon (not a reconfigurable fabric)
• Compute elements needed to be more general

10
Common Systolic Structures

• One-dimensional linear array

• Two-dimensional mesh

11
Hexagonal Array
Squared-up representation

• Communicates with six nearest neighbors

12
Binary Tree

• H-Tree Representation

13
Mapping Approach

• Allocate PEs
• Schedule computation
• Schedule PEs
• Schedule data flow
• Optimize
• Available Transformations
• Preload repeated values
• Replace feedback loops with registers
• Internalize data flow
• Broadcast common input

14
Example Finite Impulse Response

• A Finite Impulse Response (FIR) filter is a type
  of digital filter
• Finite response to an impulse eventually
  settles to zero
• Requires no feedback

for (i1 iltn i) for (j1 j ltk j)
yi wj xij-1
15
FIR Attempt 1

• Parallelize the outer loop

for (i1 iltn i) in parallel for (j1
j ltk j) sequential yi wj
xij-1
wj
y1
xj
y1
wj
y2
xj1
y2
wj
yn
xnj-1
yn
16
FIR Atttempt 1 (cont.)

• Broadcast common inputs

for (i1 iltn i) in parallel for (j1
j ltk j) sequential yi wj
xij-1
17
FIR Attempt 1 (cont.)

• Retime to eliminate broadcast

for (i1 iltn i) in parallel for (j1
j ltk j) sequential yi wj
xij-1
18
FIR Attempt 1 (cont.)

• Broadcast common values

for (i1 iltn i) in parallel for (j1
j ltk j) sequential yi wj
xij-1
19
FIR Attempt 2

• Parallelize the inner loop

for (i1 iltn i) sequential for (j1 j
ltk j) in parallel yi wj xij-1
w1
yi
xi
yi
w2
yi
xi1
yi
wk
yi
xik-1
yi
20
FIR Attempt 2 (cont.)

• Internalize data flow

for (i1 iltn i) sequential for (j1 j
ltk j) in parallel yi wj xij-1
21
FIR Attempt 2 (cont.)

• Allocation schedule

for (i1 iltn i) sequential for (j1 j
ltk j) in parallel yi wj xij-1
22
FIR Attempt 2 (cont.)

• Preload repeated values

for (i1 iltn i) sequential for (j1 j
ltk j) in parallel yi wj xij-1
23
FIR Attempt 2 (cont.)

• Broadcast common values

for (i1 iltn i) sequential for (j1 j
ltk j) in parallel yi wj xij-1
24
FIR Attempt 2 (cont.)

• Retime to eliminate broadcast

for (i1 iltn i) sequential for (j1 j
ltk j) in parallel yi wj xij-1
25
FIR Summary

• Sequential
• Memory bandwidth per output 2k1
• O(k) cycles per output
• O(1) hardware

• Systolic
• Memory bandwidth per output 2
• O(1) cycles per output
• O(k) hardware

xi
x
x
x
x
w1
w2
w3
w4




yi
26
Example Matrix-Vector Product
for (i1 iltn i) for (j1 jltn j)
yi aij xj
27
Matrix-Vector Product (cont.)
t 4
a41
a23
a23
a14

t 3
a31
a22
a13


t 2
a21
a12



t 1
a11




x1
x2
x3
x4
xn
y1
t n

y2
t n1
y3
t n2
y4
t n3
28
Banded Matrix-Vector Product
q
p
for (i1 iltn i) for (j1 jltpq-1
j) yi aij-q-i xj
29
Banded Matrix-Vector Product (cont.)
t 5
a23

a32

t 4

a22

a31
t 3
a12

a21

t 2

a11


t 1




yi
t 1
x1
t 2

ain
yout
yin
t 3
x2
t 4

xin
xout
t 5
x3
30
Banded Matrix Multiplication
31
Banded Matrix Multiplication (cont.)
t 7
c41


c22


c14
t 6

c31



c32

cout
t 5


c21

c12


t 4



c11



bin
ain
F
aout
bout

a12

a13


a11

cin






a21

t 5

a31
t 4

t 3

t 2
t 1
32
Summary

• Systolic structures are good for
  computation-bound problems
• Models costs in VLSI systems
• Minimize number of memory accesses
• Emphasize local interconnections (long wires are
  bad)
• Candidate algorithms
• Makes multiple use of input data (ex n inputs,
  O(n3) computations
• Concurrency
• Simple control flow, simple processing elements
