Title: Controller Systems


1
Controller Systems
  • Tufts EMID - Spring 2015

2
Typical Controller System
Sensors
Acquisition System (Arduino)
Mapping Software (Max)
Output (Reason)
3
Useful Resources
  • Fraden, A Handbook of Modern Sensors
  • sensorwiki.org
  • Datasheets for components

4
Parts Sources
  • mouser.com
  • digikey.com
  • sparkfun.com

5
What can we sense?
  • ON/OFF, momentary or toggle
  • Position, velocity, acceration, rotation
  • Temperature, light, sound
  • Pressure, touch, torque, bending, strain

6
Types of Sensors
  • Discrete - only can give a value of 0 (off) or 1
    (on)
  • Continuous - Resistors or current generators.
    Some can be connected directly to the Arduino.
    Others need buffering, amplification, and/or
    filtering to provide usable data

7
Switches
  • Discrete output
  • Toggle - on or off
  • Momentary - on or off when pressed
  • Rotary multiple-position
  • Can provide visual and tactile feedback

8
Potentiometers
Vref
  • Common types
  • Linear taper
  • Audio taper (logarithmic)
  • Rotary, linear, multiturn

Vout
GND
9
Soft Potentiometers
  • Linear
  • Circular

10
Other Variable Resistors
  • Photoresistors
  • Bend Sensors
  • Force-Sensing Resistors

11
Photoresistors/Photocells
  • Sense the absence or presence of light
  • Change resistance when amount of light changes

12
Bend Sensors
  • Resistance decreases when bent

13
Force-Sensitive Resistors
  • Resistance drops when pressed
  • Shorthand name FSR

14
Variable Resistors
Vref
R1 (variable)
  • Vout Vref R2/(R1R2)
  • If sensor range 10k to 35k?,
  • and R2 20k? then
  • Vout range .66Vref to .36Vref

Vout
R2
15
Accelerometers
  • Measure inclination (direction), acceleration in
    1, 2, or 3 axes

16
Distance Sensors
  • Infrared
  • Ultrasonic

17
Piezoelectric Materials
  • Sensitive to vibration
  • Excellent drum triggers, contact microphones

18
Capacitive Sensors
  • Detects changes in capacitance, often by
    measuring your body capacitance
  • Can detect proximity, distance, location,
    acceleration
  • Think Trackpads, Cell/Tablet Screens, Theremin

19
Other Sensors
  • EMG (Muscle Sensor)
  • Joysticks (X and Y axis variable resistors)
  • Gesture Recognizers
  • Rotary Encoders

20
Connecting Sensors
  • Using Arduino boards
  • Read in digital and analog signals
  • Connect via USB and can talk to MAX

21
Breadboards
  • Simple way to create circuits without soldering

22
Reading in Data in MAX
  • Using Arduino2MAX

23
Putting It All Together
Arduino2MAX
