Geologic Time Notes

1
Geologic Time
2
Why is this statement false The caveman had
dinosaur for breakfast.?

• man and dinosaurs
• never lived at the same time

3
Laws of geologic history

• SuperpositionOldest rocks on the bottom of an
  undisturbed sequence of rock
• Law of original horizontalityAll rocks are
  initially deposited in flat (horizontal) rows
• Cross-cutting relationshipsObjects which
  cross-cut rocks are younger than the rocks
  themselves (ex fault or intrusion)

4
Superposition
5
Using superposition, label the strata below from
oldest to youngest.
youngest
oldest
6
Horizontality
All rock layers are originally deposited in flat
(horizontal) layers
7
Faults are always (older, younger) than the
rocks they cut through.
Cross-cutting relationships
8
(No Transcript)
9
Which is older F or S How do you know?
F cuts through S S must have been there first
(it's older)
10
Uniformitarianism
These laws are based on the assumption that the
forces at work today are the same forces at work
in history uniformitarianism.
11
If a geologist finds an igneous sill, how can she
determine if the sill is an intrusion or an
extrusion?
12
(No Transcript)
13

Is H an intrusion or extrusion?How can you
tell?
14

H is an intrusion.Contact metamorphism on top
15
On to the next question...
16
What is an unconformity? How does it complicate
the relative dating of rock layers?

• a buried erosional surface

• a part of the rock record
• is missing

17
Using the diagram to the left, identify where the
unconformity is located by drawing an arrow and
writing the word unconformity next to it.
18
What are
Index fossils?
19
What characteristics must fossils have in order
to be good index fossils?

• lived over a large geographic area (large
  horizontal distribution)
• lived for a short period of time (small vertical
  distribution)

20
In the diagram below, a geologist has matched up
rock layers based on index fossils.
In geology, this is referred to as CORRELATION
21
On to the next question...
22
Absolute Age
Why are radioactive isotopes useful in
determining the absolute age of a rock?
their half-lives are constant
23
Absolute Age

• What can be done to change the
• half-life of a radioactive isotope?
• Why is this important?

NOTHING!
it is reliable to calculate age
24
Draw the generic graph for the half-life of a
radioactive isotope.
stable atoms
unstable atoms
25
Absolute Age

• What radioactive isotope could be
• used to determine the absolute
• age of material that was recently living?
• carbon-14

26
Please answer the two questions on page 7 of
your Notes
What is the half life of uranium-238? 4.5 x
109 4,500,000,000 4.5 billion years choice (c)

27
If there is a 100g sample of C14, how many grams
of C14 would remain after three half-lives?
How long would this take? Show all work.

?
?
?
100g
50g
25g
12.5g
3 half-lives x (5.7 x 103) 1.71 x 104
17,100 years
