Query Processing in Connectivity-Challenged Environments

1
Query Processing in Connectivity-Challenged
Environments

• Priyanka Puri
• Sharma Chakravarthy
• Gururaj Poornima
• Mohan Kumar
• Information Technology Laboratory
• Computer Science and Engineering Department
• The University of Texas at Arlington, Arlington,
  TX 76009
• Email sharma_at_cse.uta.edu
• URL http//itlab.uta.edu/sharma

2

• This effort is supported by AFRL under Contract
  Number FA8750-09-2-0199
• Sanjay Madria and Raytheon (Waseem Naqvi) are
  also involved in this project

3
Query Processing

• Has been addressed in the context of centralized
  DBMSs
• Has been addressed in the context of distributed
  DBMSs
• Cost-based plan generation is typically used
• So, is there anything more/new to do?

4
UAV 4
UAV 2
UAV 3
UAV 1
UAV 5

• Ground Controller 2

Ground Controller n
Ground Controller 1
5

• Ground Controller 2

Ground Controller 1
6
Currently

• Data is dumped into a central server and queried
• Bandwidth, QoS issues are not addressed
• No collaboration among nodes
• No continuous query processing, notification,
  fusion, context usage, and real- or near
  real-time support

7
Proposed long-term Architecture
Limited Resources Mobility Heterogeneity Disconnec
tions
Network of computing nodes Unmanned vehicles,
Sensors, Robots, PCs , Servers, Ground
Controlling devices
Queries, Tasks, Requests, Continuous Queries
Publish/Subscribe

SOA Distributed Middleware Task planning Join
computation Composition pub/sub Context-aware N
otification Resource Management Data management
Context/ Knowledge Base
Fault Tolerance Services
Local fusion/Materialization
Publish Subscribe Capability
Query Capability
Raw Data / fused data /data from other nodes
8

• Query Processing

9
MyObjects Table at each node
Timestamp Node_id Longitude Latitude Obj_type Obj_desc Object_ptr
8 bytes 4 bytes 4 bytes 4 bytes 8 chars Varchar (64) Pointer (8 bytes)


Total width 100 bytes

Cardinality (number of tuples) , Selectivity,
replication site of data are known (part of meta
data)
10
Query Plan Format
Operation 1 Param Operand1 Operand1 Loc Operand2 Operand 2 Location Result Name Result Loc
Operation 2 Param Operand1 Operand1 Loc Operand1 Operand2 Loc Result Name Result Loc

Operation n Param Operand1 Operand1 Loc Operand1 Operand2 Loc Result Name Result Loc
11
Operations in Plan format
Operation Param Operand1 Operand1 Loc Operand2 Operand 2 Loc Result Name Result Loc
Select A gt 100 R1 1 Null Null R1 1
Project A1, A3, A4 R1 1 Null Null R1 1
Move Null R1 1 Null Null R 2
Copy Null R1 1 Null Null R14 4
SemiJoin A C R 2 R2 2 SR1 2
Join B D R12 2 R2 2 JR1 2
12
Plan using Semijoin chains

• SELECT c1 R1
• MOVE R11 To Site2
• SELECT c2 R2
• SJ R11 R21 J1
• MOVE J1 To Site3
• SELECT c3 R3
• SJ J1 R31 J2
• MOVE J2 To Site2
• SJ J2 R21 J3
• MOVE J3 To Site1
• SJ J3 R11 J4
• COPY R To Site7 J
• Total Cost 14720 32000 46720

R1 1000
R2 5000
R3 3000
1
2
3
select project
select project
select project
R213000
lat
R11800
R31600
long
J11200
J2240
Cost3200
Cost4800
long,nodeid
7
Cost1920
J31200
lat,nodeid
Cost4800
J4320
J
Cost32000
13
Semi-join/join plan generation

• We are developing algorithms for generating the
  plan space and pruning it for generating best
  (or good) plan for each input query (expressed
  as a join query)
• It is a cost-based algorithm based on System R
  and SDD approaches extended to include
  connectivity and bandwidth issues
• The complexity of plan generation is kn n is
  number of joins and k is the number of
  alternatives for each join.
• Assuming less than 5 joins in a query
• Integrate replication into the algorithm

14
Plan Generation Alternatives

• A Query Plan (QP) is a numbered sequence of
  operations for executing a Query
• A QP includes how data is moved as part of
  execution
• Plan generation alternatives
• Static Plan generated once and executed in a
  distributed manner
• Dynamic plan generated incrementally at each
  node as the query progresses using current
  connectivity information
• Parallel plan partial plans are executed in
  parallel
• Interactive plan get some estimate by asking
  nodes that has relevant data

15
Static plan

• The physical plan generated will have node
  information for data propagation.
• This will be mapped to actual connectivity by
  the physical layer for execution
• It is possible that no connectivity exists by the
  time execution is performed for a generated query
  plan
• In that case, either a new plan can be generated
  (using the same algorithm, but using current meta
  data) or an alternative approach can be used to
  incrementally modify the plan

16
Dynamic plan

• Generate plan for the first join and defer the
  rest of the plan
• Join plans are generated one at a time
• Current connectivity information can be used
• Result size estimation will also be more accurate
• Query execution and (partial) plan generation are
  intertwined
• Does not increase the complexity of plan
  generation or plan execution (compared to static)

17
Parallel plan

• All local operations/computations (select,
  project, and even some joins) can be done in
  parallel
• Join plans are still generated one at a time
• Increases message/information exchange
• Current connectivity information can be used
• Result size estimation will also be more accurate
• Deal with responses and plan generation and
  execution may be slightly more complicated than
  the previous cases

18
Interactive plan

• When a query comes in, send out requests for
  local processing and get processing time and size
  information
• Use the above to generate partial plans
• Join plans are still generated using information
  obtained interactively
• Increases message/information exchange
• Current connectivity information can be used
• Result size estimation will also be more accurate
• Combines Dynamic and parallel execution in an
  interactive manner

19
Replication Issues

• Algorithm for Replication
• Single copy replication that minimizes the data
  transmission cost and maximizes the number of
  paths (to deal with connectivity)
• Algorithm for Replication utilization
• Given a replication, determine the utility of
  that replica in terms of query evaluation cost
  for a reasonable load
• Reconcile the above two to come up with a
  replication strategy that balances the competing
  tradeoffs

20
