Carts independent

1
Il Calamaro

• Carts independent

2
Introduction

• Overview Goals
• Design Philosophy
• Design and Fabrication
• Hull
• Propulsion
• Control
• Life Support System
• Safety
• Testing and Training
• Journal and Budget
• Closing

3
Overview Goals
4
Design Philosophy
5
Hull Construction
6
Hull Construction Buoyancy Trim
7
Hull Construction - Windows
8
Propulsion

• Early brainstorming sessions led to basic
  foundation of current propulsion design
• Pilot in prone position, resting on two
  symmetrical 1 ¼ aluminum shafts braised to a
  t-bar underneath
• The two shafts contain eight ft long aluminum
  pushrods that slide within
• Pedalblock attached to t-bar, attached to
  pushrods by cable

9
Control

• Dive planes
• Inspired by nature
• NACA airfoil 0012 cut into blueboard with
  polystyrene wedged between and covered with
  fiberglass
• 3/8 in threaded steel rod bent to 90 degrees and
  embedded in plane with epoxy resin
• Rods enter the hull 1/3 from nose and below the
  midline
• Rods attach to ½ in aluminum electrical conduit
  bent to 22 degrees to form a handlebar

• Stabilizers
• Design
• 4 stabilizers fixed to the hull at the rear of
  the vessel, spaced at 90 degrees

10
Life Support

• VO2 max testing at University of Maryland for
  both pilots
• Testing suggested 40 cubic ft tank sufficient to
  meet ISR regulations for each run
• Submarine includes
• 63 cubic ft tank with octopus attachment
• 13 cubic ft pony bottle with single regulator
  attachment

11
Safety Components
Beacon
Emergency Buoy
Pedals/Shoes
Emergency Hatch Release
Harness Release
12
Testing Training
13
Acknowledgements Donors Supports
Bryans Road Building Supply Staff
Knights of Columbus, JFK Council, Accokeek, MD
Lowes
Russ Elkins
Carl Gotzmer
Bike Doctor Waldorf, MD
St. Marys Sodality, Clinton MD
Hans Haucke
OceanMarine
Fredrick Jeffrey Frese
Carts-Ingram Family
NaviSafe
Jimmy Walls Mid-Atlantic Foam
Joe Blue
Chris Satterwaite
Ray Rye
Tony Gayle Carts
Raytheon
Ferris Apiaries Marbury, MD
Charles County Parks and Recreation
Chris and David McDonald
Josh Urban
John Hollyfield
Professor James Hagberg, Staff and UMCP Grad
Students
Marianne Retrum
Anne-Marie Ramsey
John Balazek
14
Journal Budget
Category Amount Spent
Development 375
Hull 1185
Windows Hatch 50
Propulsion 1300
Buoyancy Trim 220
Steering 30
Life Support 750
Emergency Systems 65
Race Day Logistics 1000
Documentation 30
Calamaro.qlubb.com
Calamaro.weebly.com
15
Questions?
