KNOWLEDGE-BASED SOLUTION TO DYNAMIC OPTIMIZATION
PROBLEMS USING CULTURAL ALGORITHMS

• by
• Saleh M. Saleem
• Computer Science Department
• Wayne Sate University
• Detroit, MI 48202
• sms_at_cs.wayen.edu

2
Outlines

• Introduction
• Applications in Dynamic Environments
• Current Approaches for dynamic optimization.
• Cultural Algorithm framework
• System Description
• Problem Generator DF1 description.
• Example runs
• Experiments setup
• System performance in static environments
• Experiments in Magnitude Dominant Environments
• Experiments in Frequency Dominant Environments
• System performance in deceptive environments
• Conclusion and Future work

3
Our general problem area

• In general we consider real-valued function
  optimization problems
• max (f(x)) - min (f(x))
• The problem is to find x to
• Maximize f(x), X ( X1, .., Xn) ? ?n

4
Introduction

• Over the years many approaches have been
  developed to track optimal solution in real-time
  dynamic environments.
• The motivation for this study is the fact that
  Cultural Algorithm (CA) naturally contains
  self-adaptive components that can make it an
  ideal model for dynamic environments.
• Our goal in this study is to evaluate the
  different types of knowledge required to track
  optimal solutions in real-time dynamic
  environments.
• In this presentation we will show that
• The search emerges into three main search phases.
• One knowledge source is more active than others
  depends upon the problem dynamic behaviors and
  the phase of search.
• Different knowledge sources interact
  symbiotically to solve a problem.
• The CA becomes more useful as the problem
  complexity increases.

5
Applications in Dynamic Environments

• Fraud detection in the AAA insurance claims
  Sternberg Reynolds 97. Used Cultural
  Algorithms in reengineering a rule-based fraud
  detection expert system when the perpetrators
  behind the fraudulent claims change their fraud
  producing strategies.
• Job shop scheduling Bierwirth 94, Lin 97.
• A new job arrives anytime and has to be
  integrated into the schedule.
• Changing peaks problem Morrison De Jong 99,
  Branke 99. Finding the highest peak in
  multi-dimensional landscape where the peaks
  parameters are changing over time.

6
Current Approaches in Optimizing Dynamic Problems

• Reinitializing approach Karr 95, 95b, Kidwell
  94, Pipe 94
• Adapting mutation Cobb 90, Gefenstette 92
• Self-Adaptation Reynolds Sternberg 97
• Memory support Trojanowski 97, Mori 96
• Modifying the selection operator Goldberg 87,
  Ghosh 98

7
The Reinitializing Approach

• Simple restart from scratch with every
  environmental change Karr 95, 95b, kidwell 94,
  pipe 94.
• Injecting some solutions from the old problem
  into the new initialized problem Louis 96, 97.

8
Adaptive Mutation

• Hyper-mutation Cobb 1990.
• Random-immigrants Gefenstette 1992.
• Standard mutation.
• A comparative study concludes that hyper-mutation
  performed best in slowly changing environments
  but with a big change, random-immigrants perform
  better Cobb 93.

9
Self-Adaptive Mutation

• Using Cultural Algorithms to influence the search
  in self-adaptive way. Reynolds Sternberg 97
• The belief space knowledge used to reason about
  and influence the mutation on the search space in
  self-adaptive way.
• The mutation direction and step size dynamically
  adjusted by the influence function to meet the
  need of the new search.

10
Memory Support

• Use memory to store the ancestors of an
  individual Trojanowski 1997
• Store the best individual in every generation and
  use them to generate offspring Mori 96

11
Modifying the Selection Operator

• To maintain diversity, Individuals in less
  populated area given boost in their performance
  score over those in crowded areas Goldberg
  1987.
• Taking the individuals age into account to
  maintain diversity Ghosh 1998.

12
Cultural Algorithms for Self-Adaptive Search

• Developed by R. Reynolds in 1979 as computational
  framework in which to describe evolution of
  social system Reynolds 95
• The CA is a dual inheritance evolutionary system
  derived from models of cultural evolution.
  Reynolds 93
• Any of the dynamic approaches discussed above can
  be used within Cultural Algorithm framework.

13
Previous Cultural Algorithms Applications in
Dynamic Environments

• Systems with offline historical dynamics
• Nazzal 1997, Generates archeological minimum
  spanning trees for resource networks on the
  valley of Oaxaca. The change occurs offline over
  long period of time.
• Sternberg 1997, Experiments on Fraud Detection
  when the perpetrators behind the fraudulent
  claims change their fraud producing strategies.
• Real-Time Dynamic Optimization
• Saleem 2000, Evaluates the contribution of the
  belief space knowledge for solving problems in
  dynamic environments.

14
Cultural Algorithms Components

• Belief space.
• Population space.
• Communication channels
• Acceptance function.
• Update function.
• Influence function.

15
Culture Algorithm framework
16
The Cultural Algorithm

• Initialize population Pop(0)
• Initialize belief Blf(0)
• Initial communication protocol
• t0
• Repeat
• Evaluate Pop(t)
• Communicate (Pop(t), Blf(t)) acceptance
  function
• Adjust (Blf(t))
• Communicate (Blf(t), Pop(t)) influence function

• tt1
• Select (Pop(t), Pop(t-1))
• Until (halting condition)

17
Belief Space Configuration

• The knowledge in the belief space represents
  generalizations of the properties of a good
  solution in the population space.
• The Belief Space contains
• Topographical Knowledge.
• History Knowledge
• Domain Knowledge.
• Normative Knowledge
• Situational Knowledge
• Basic method for selecting which knowledge will
  influence the variation operators.

18
Belief Space Representation
19
Situational Knowledge Chung97
S

where is the best individual in the
population at time t.
20
Domain Knowledge
21
Normative Knowledge Chung 97
22
Updating the Normative Knowledge Chung 97

• Lower bound
  Upper bound
• Range of variable xi at time t.
• A
• B C
• D
• E
• F

23
Updating the Normative Knowledge

• Chung97

24
History Knowledge


.
.

• The history knowledge was represented as a list
  (or window) of change events.
• When a change event occurs, the history knowledge
  stores the current best and the moving direction
  from the previous optimum.
• After each change event the history knowledge
  recomputed the average moving distance and
  direction over the events in the window size.
• The window size used in this study was 2.
• The history knowledge also detect stagnation in
  the population via checking progress in the best
  solution.
•

25
Update History Knowledge

• - ei-1.xj

26
Topographical Knowledge

• Example of landscape grid
• The topographical knowledge is a grid of cells
  mapping the problem landscape.
• Only those cells containing promising solutions
  are divided and further divided into smaller
  cells, as shown in the example above.

27
Topographical Knowledge Representation

The data structures representation of the
topographical knowledge represent the grid size
as a list of cells where each cell contains the
interval boundaries in each dimension, the best
founded solution in that cell, and pointers to
the cells children (if the cell was divided).
28
Updating Topographical Knowledge

• A cell is divided if it contains an accepted
  individual with a fitness value better than its
  current best.
• When environmental change occurs
• All links to children become nil.
• Best solutions in the original grid are
  reevaluated and cells are divided if their
  fitness values were improved.

29
The Acceptance Function

• The acceptance function determines which
  individuals and their behaviors can impact the
  belief space knowledge.
• The acceptance function here is determined as the
  top 25 of the population size.

30
Influence Function

• The influence function determines which knowledge
  will be applied to guide the problem solution.
• Depends on the nature of the problem environment,
  the influence function can be different for
  different problem domain.

31
Situational Knowledge Influence Function Chung97

• Best Exemplar

32
Normative Knowledge Influence function Chung97

• Current interval
• Lower upper boundary

33
Domain Knowledge Influence Function

• The domain knowledge influence function mutate
  individuals relative to the difference in the
  fitness value form the best-founded solution so
  far.
• When a change event occurs the step size will
  increase relative to the drop in the fitness
  value, ?

34
History Knowledge Influence Function

• The history knowledge influence function
  generates individuals relative to the average
  moving distance and direction.
• We use, hare, a roulette wheel with three
  different portion sizes to generate individuals
• Relative to the moving distance from previous
  optimum.
• Relative to the moving direction from previous
  optimum.
• Relative to the entire domain range.
• Note here, the highest percentage of generated
  individuals is in the overlap area between the
  moving distance and the moving direction, W3 in
  the next figure.

35
History Knowledge Influence Function (cont.)

In this study we use a 45 , ß 45 , f
10
36
Topographical Knowledge Influence Function

• Maintain a list of the best n cells in the grid,
  ( bestcells ).
• Use a roulette wheel with three different portion
  sizes to generate individuals
• Within the best cell in the grid, bestcells0.
• Within the best n cells in the gird, bestcells.
• Within any cell in the entire grid.

In this study we use a 45 , ß 45 , f
10
37
Influence Demon

• The influence demon determines which knowledge
  source to influence the search.
• The Influence demon uses a roulette wheel to
  randomly select an influence function relative to
  its average performance
• All influence operators are initialized with
  equal proportion of the wheel.
• Portion size is then adjusted according to

38
Problem Generator DF1 Morrison 99

• The problem is to find the highest peak in
  multi-dimensional multi-peaks N landscape in a
  real-time dynamic environments.

39
DF1 Dynamic Variables Morrison 99

• The dynamics variables in the cones-world
  environments are
• Height Hi ? H-base, H-baseH-range
• Slope Ri ? R-base, R-base R-range
• Location xi, yi ? -1, 1
• The performance function
• The fitness of any individual (x, y) is the max
  value on all cones, where N is the number of
  cones.

40
Specifying The Dynamics Morrison 99

• The problem generator provides a standard method
  to easily describe the dynamic behavior on each
  changing variable using the Logistic Function.
• where A specify the change Magnitude in each
  dynamic variable change height Ah, Slope Ar, and
  Location Ac.

41
The Logistic Function

• Examples
• When A 2.2, gives Y0.5455
• When A3.5, gives Y 0.3828, 0.5009, 0.8750

42
Embedding the DF1 into the CA framework
Acceptance
Influence
Function
Function
Evolutionary
Performance Operators
Function
Belief Space Update beliefs
DF1 Generator
Dynamics
Environment
Population Space
43
Example runs

• Here, we will discuss two example runs in static
  environment to demonstrate how the system
  behaves
• when the search converges to the optimum
  solution in the first example, and
• when the system initially converges to a false
  peak in the second example.

44
Problems Settings

• The two examples have the same problem setting of
  32 cones in a static environment where the
  height, slope and locations are randomly
  generated in the ranges between 5 and 20, 20 and
  30, -1 and 1 respectively.
• We consider the system to have found the optimum
  if the difference between the best solution and
  the optimum is less than or equal to 1E-10
  (0.0000000001).

45
First Example run

• Numbers 1 represents the normative knowledge, 2
  represents the situational knowledge, 3
  represents the domain knowledge, 4 represents the
  history knowledge, and 5 represents the
  topographical knowledge influence operator.
• As shown in the second figure, from left, the
  topographical knowledge operator (5) was the
  dominant operator at the beginning of the run
  until the best solution becomes close enough to
  the optimum (first figure) which is when the
  situational knowledge operator (2) becomes the
  dominant operator until the end of the run.

46
First Example run (cont.)

• This figure shows the initial roulette wheel
  assignments of 1/5 for the five operators used by
  the system.
• As shown the T operator wheel portion increases
  until around generation 11 when S and DS
  operators take the lead. The S and DS operators
  gain almost similar wheel percentages because of
  the indirect interaction between the knowledge
  structures.

47
First Example run (cont.)

• The above figure highlights different phases that
  the search takes in term of the type of knowledge
  structures used to guide the search. At the
  beginning of the run the T operators dominates
  the search in term of the number of selected
  solutions until around generation 9 when the
  number of selected solutions decreases for the
  benefit of the S operator.
• It suggests that the search takes two main
  phases.
• First when the T operator determines the most
  promising region that may contains the optimal
  solution. From the start until around generation
  9, (coarse-grained phase).
• The second phase when the S operator leads the
  search, as a fine-tuning operator, to search with
  in the suggested region by the T operator. From
  generation 10 until the end of the run,
  (fine-tuning phase).

48
First Example run (cont.)
These two figures show how different knowledge
structures indirectly influence each other. The
topographical knowledge range convergence helps
the normative knowledge interval to converge at
much faster rate than what we will see in the
next example.
49
Second Example run

• In this example the search initially converges to
  a false peak, as shown in first figure, above.
• The search begins as we have seen in the first
  example, T operator (5) leads the search at the
  beginning of the run until around generation 10
  when the search lead by situational (2) and
  Domain (3) operators before the search stagnate
  on a fitness value of 18.75.
• As shown in the second figure, the normative
  knowledge (1) generates the first best solution
  that shift the search to a new promising region.
• After that the topographical knowledge leads the
  search for a short period before Situational
  knowledge operator (2) dominates the search again
  and leads the search to the optimum solution.

50
Second Example run (Cont.)

• This figure shows the normative knowledge
  interval range.
• The normative knowledge converged initially to a
  false peak.
• When a stagnation situation is detected, it
  triggers the system it introduce diversity to the
  population causing the normative knowledge to
  increase its interval for backtracking the
  search.
• During the backtracking search, the normative
  knowledge completely controls the search and
  search for a new promising region within its
  interval.
• Note that the interval range did not converge as
  quickly as in the first example because normative
  knowledge here is not influenced by any other
  knowledge structures.
• The normative knowledge slowly converged around
  the new promising region.
• Note also, that the normative knowledge reduces
  the search space to the interval size, which
  suggest that it expedite the search for recovery.


51
Observations

• The runs exhibit three phases of search where in
  each phase different knowledge structures
  dominates the search. The phases are called the
  Coarse-grained phase where the search is for the
  most promising region (first phase), followed by
  the Fine-tuning phase, where the promising region
  is explored in more detail, and the Backtracking
  search which occurs when the population stagnates
  (stabilizes).
• The search phases are defined based on the
  improvement in the best solutions fitness value
• The Coarse-grained phase is when the improvement
  is gt c . (in our examples from start until
  generation 10)
• The Fine-tuning phase is when the improvement is
  ? c.
• The Backtracking phase is when the improvement is
  ? c/.
• the constant c here was 0.01 and the c/ was
  zero.

52
Experiments Framework

• The problems generated by the Problem Generator
  DF1 are classified in terms of
• Problem complexity
• Number of cones (1 to 100).
• Number of dimensions (1 to 10).
• Dynamic behaviors
• Shift magnitude.
• Same step size
• Small step size (1.05 1.80) ,
• Large step size (1.81 2.90) ,
• Different step size
• Few different step sizes (2.91 3.50)
• Chaotic step size (3.51 3.99).
• Changing frequency.
• High frequency ( lt 60)
• Medium frequency ( 61- 100)
• Low frequency ( gt 101)

53
Experiments Settings

• In this studys experiments the problems selected
  according to the categories above to generate
  problems in
• Static environments
• Exponentially increasing problem complexity (4,
  8, 16, 32, 64 cones environments)
• The run continues until a system reaches the
  optimum or to maximum of 1000 generations.
• Dynamic Magnitude dominant environments.
• Exponentially increasing problem complexity (4,
  8, 16, 32, 64 cones environments)
• Changing Heights, Slopes, and Locations for
• Large magnitude (selected randomly within the
  ranges in the table above)
• Low frequency (change occurs every 300
  generations)
• Every run contains 10 change events.

54
Experiments Settings (cont.)

• Dynamic Frequency dominant environments.
• Exponentially increasing problem complexity (4,
  8, 16, 32, 64 cones environments)
• Changing Heights, Slopes, and Locations for
• Low magnitude (selected randomly between 1.05 and
  1.80)
• High frequency (selected randomly between 20 and
  60)
• Every run contains 10 change events.
• Dynamic Deceptive environments.
• Experiments on four cones environment for
  deceptive and non-deceptive environments.
• Changing Locations for
• Large magnitude (selected randomly within the
  ranges in the table above)
• Low frequency (change occurs every 300
  generations)
• Every run contains 10 change events.

55
Experiments

• The experiments focus on
• The contribution of different knowledge
  structures to the problem solving process.
• Investigate how a system reacts to increases in
  problem complexity (scaling up the problem
  complexity).
• All systems are compared with a population-only
  evolutionary system (Evolutionary Programming) so
  that the impact of adding knowledge in the belief
  space can be assessed.
• The results of each experiment settings are the
  average of 20 runs for each system (CA and EP).

• The systems were implemented on Java 1.2,
  JBuilder environments.
• The experiments conducted on PC P-II 400 MHz, 128
  MB RAM, and windows 2000 operating system.

56
Static Environments

• Here we investigate the impact of increasing
  complexity on the problem solving for static
  environments.
• Also, we identify the contribution of the various
  types of knowledge structures to problem solving
  in each of the three search phases.

57
4 Cones Experiments
58
Table Description

• The above table presents the results for 20 runs.
• The columns are
• Run is the run sequence number.
• Gen is the number of generations for CA and EP.

• Difference gives the difference between the best
  and the optimal solution.
• CPUtime gives the execution time, in
  milliseconds.
• CA/EPtime gives the difference in CPU time for
  the CA over the population-only system.
• T gives the number of generations that the
  Topographical knowledge produced the best.
• H gives the number of generations that the
  History knowledge produced the best.
• DS gives the number of generations that the
  Domain knowledge produced the best.
• S gives the number of generations that the
  Situational knowledge produced the best.
• N gives the number of generations that the
  Normative knowledge produced the best.

59
Success ratio

• The success ratio for CA is much less sensitive
  to the problem complexity than EP.
• It is clear from the results that knowledge in
  the CA contributes to achieve a success ratio
  higher than population only system for all
  environments.
• The relative advantage of the knowledge-based
  approach improves as problem complexity
  increases.

60
CPU time

• The CA produced higher success ratio than the
  population-only model and CA consumed much less
  CPU time than the population only approaches.
• Also, CPU time taken by the CA rises more slowly
  than the population-only system with increasing
  problem complexity.

61
Observations

• Belief space knowledge contribution to the
  problem solving process increases the success
  ratio and decreases the required CPU time
  relative to the performance of Population-only
  system.
• The decrease in the CPU time suggests that belief
  space knowledge was significantly useful in
  expediting the search.
• The increase in the success ratio suggest that
  belief space knowledge was significantly useful
  in selecting the most promising region and
  recovering from false peaks.

62
Contribution of Different Knowledge Structures

• Now, we will look at the contribution of
  different knowledge structures in the
  Coarse-grained phase, the Fine-tuning phase, and
  the Backtracking phase across all environments,
  regardless of the complexity.
• The tables in each phase combine the runs from
  all of the environments.
• The tables show number of times that a knowledge
  structure produced the best solution in a
  generation (overall).
• Each cell represents the likelihood that an
  operator produces the best solution in one
  generation (raw) is followed by operator that
  produces the best in the next.

63
Coarse-grain phase

•  In this phase, as expected, the topographical
  knowledge operator is the dominant operator in
  guiding the search.
• Row FG, here, represents first transition
  sequence when population randomly initialized in
  generation zero. In 60 out of 100 runs, the
  first transition was to the topographical
  operator T.
• The Situational knowledge was the second
  contributor in that phase.
• The highest transition percentage from the T
  operator to a different operator was to the S
  operator 31 and the highest transition sequence
  from S operator to a different operator was to
  the T operator, 38.
• That suggests that the two knowledge structures
  work symbiotically.
• History knowledge was not productive here since
  the experiment lacked the dynamic information
  content that it can exploit.

64
Fine-Tuning Phase

• The dominant knowledge contributor, here, is the
  situational knowledge operator, S, 60.
• Since the domain knowledge operator behaves
  similar to the situational knowledge operator, it
  competes with the situational knowledge operator
  in producing the best. Thus, The D operator is
  the second contributor in this phase.

65
Backtracking Phase
66
Backtracking phase (cont.)

• Here, in this phase the normative knowledge, N,
  contribution increased, 25, from its percentage
  in coarse-grained and the fine-tuning phases.
• The normative knowledge produces the first best
  solution to brake stagnation in the search. The
  chart shows an example of how normative knowledge
  proceed during the backtracking search.
• The transition table shows that in 20 of the
  time T operator generates the best after N
  operator shifted the search to a new search
  space.
• Reversing direction from T to N (only 2.7)
  suggests the control of the search is transferred
  form normative to topographical knowledge
  operator.

67
Summary

• The experiments in static environments show that
• The Cultural system is less sensitive to the
  problem complexity than a population-only
  approach, in term of the solution quality and the
  excavation time.
• Different knowledge structures can work
  symbiotically to solve a problem.
• The dominant knowledge operators in the
  coarse-grained, the fine-tuning, and the
  backtracking phase are the topographical
  knowledge, situational knowledge, and the
  normative knowledge operators respectively.

68
Dynamic Environments withMagnitude Dominant
Environmental Changes

• The Experiments here investigate the contribution
  of different knowledge structures in environment
  with infrequent changes of high magnitude.
• The experiment settings were as we shown earlier

• Exponentially increasing problem complexity (4,
  8, 16, 32, 64 cones environments)
• Changing Heights, Slopes, and Locations for
• Large magnitude (selected randomly within the
  ranges in the table above)
• Low frequency (change occurs every 300
  generations)
• Every run contains 10 change events.

69
4 Cones Experiments
70
Table Description

• The above table presents the results for forty
  consecutive runs (20 runs for EP and 20 runs for
  CA).
• The tables columns are
• Run the run sequence number.
• AvrGen the average number of generations
  required by CA and EP.
• AvrDiffer the average difference of 10
  environmental changes between the best solution
  found by each system and the optimum solution.
• AvrCPUtime the average execution time per change
  event, in milliseconds. CA/EPt a percentage
  difference in the CPU time for the Cultural
  System over the population-only system.
• T, H, DS, S, N the number of generations for
  which each of the different CA knowledge
  structures produced the optimal solution
  (Topographical knowledge, T, History knowledge,
  H, Domain knowledge, DS, Situational Knowledge,
  S, and the Normative knowledge, N).

71
Success Ratio

• Even in dynamic environments, CA produced better
  solution quality and was shown to be less
  sensitive to increase in problem complexity than
  the population-only system.
• When the problem become dynamic CA shown to be
  even less sensitive than CA in static
  environments. The reason perhaps history
  knowledge becomes more useful in using its
  knowledge about previous environments.
•

72
CPU time

• The difference in CPU time between CA and
  population-only system becomes larger when the
  problem shifts from static to dynamic. It
  suggests that as the problem become more complex
  the belief space knowledge become more and more
  useful.
• The increase rate in CPU time as the problem
  become more complex shows that CA in dynamic
  environments is less sensitive than CA in a
  static one, especially when the problem becomes
  complex as in 64 cones.
•
•

73
Contribution of Different Knowledge Structures in
Dynamic Environments

• Now, we will look at the contribution of
  different knowledge structures in the
  Coarse-grained phase, the Fine-tuning phase, and
  the Backtracking phase.
• The tables in each phase are the summary results
  of a total of 100 runs in dynamic environments.
• The tables show the number of times and
  percentages that a knowledge structures have
  produced the best solution and the sequence of
  which influence operator generates the best in
  the next generation.

74
Coarse-grained phase
75
Observation

• The history knowledge shows increase in its
  contribution to produce best solution.
• The increase in the contribution of the history
  seems to affect the contribution of topographical
  knowledge more than any other knowledge source.
• The reason is perhaps the history and the
  topographical knowledge operators are both
  coarse-grained operators and thus they compete to
  generate the best solution.
• The other knowledge structure contributions are
  similar to that in static environments.

76
Fine-tuning phase
77
Observation

• The D operator becomes less of a contributor, as
  expected, in the fine-tuning phase.
• The reason perhaps, the D operator in static
  environments work in similar way as the S
  operator does as a fine-tuning operator, but in
  dynamic environments the D operator contributes
  in generating diversity to the population and
  become a diversity generator instead of a
  fine-tuning operator.
• Since the D and the S were both fine-tuning
  operators in the static environment, S is more
  dominant in the dynamic environments, Thus, The
  S contributions increases to adjust to the change
  in the D operator.
• The contributions of the other knowledge
  structures are the same as seen in static
  environments.

78
Backtracking Phase
79
Observation

• The backtracking search is needed when the
  prediction for most promising region by
  topographical and history knowledge failed.
• Thus, as expected, the contribution of H and T
  operators decreased a bit from their contribution
  in static environments.
• The D operator becomes more useful, as a
  variation generator in the backtracking phase.
• The normative knowledge operator N is the main
  contributor in this phase because N operator
  generates the best new individual after
  stagnation which shifts the search to explore a
  new search space, as we have shown in the second
  example run earlier.

80
Dynamic Environments withFrequency Dominant
Environmental Changes

• Here we investigate the affect of a high
  frequency of change coupled with low shift
  magnitude on CA versus EP performance in term of
  solution quality and execution time for
  exponentially increasing problem complexity.
• Also, another goal of this experiments is to
  investigate the contribution of different
  knowledge structures and whether they behave
  differently than what we have seen in previous
  experiments.
• The experiments settings were as we shown
  earlier
• Exponentially increasing problem complexity (4,
  8, 16, 32, 64 cones environments)
• Changing Heights, Slopes, and Locations for
• Low magnitude (selected randomly between 1.05 and
  1.80)
• High frequency (selected randomly between 20 and
  60)
• Every run contains 10 change events.

81
Success Ratio

• First figure, from on the left, shows that the CA
  produces much higher success ratio than the
  population-only system in all of the experiments.
• EP produced zero success ratios in all of the
  experiments, perhaps because EP requires at least
  105 generations to reach the optimum which is
  more time than allowed here.
• The second chart suggests that a higher frequency
  of change makes the problem harder than high
  magnitude and has the greatest affect on the CA
  success ratio.
• Although the success ratio is significantly lower
  than the previous two experiments the success
  ratio decreases almost linearly relative to the
  exponential increase in the problem complexity.

82
CPU time

• In the first figure the increase in problem
  complexity did not show a consistent increase in
  the CPU time perhaps because changes occur so
  frequently causing both systems to run to the
  maximum allowable time.
• Since the success ratio for the EP system was
  zero in all of the high frequency experiments,
  the CPU time for EP does not reflect the time
  required to reach optimum solution as in the
  previous experiments.
• The second figure suggest that the CPU time for
  CA in high frequency environments is less
  sensitive to increase in complexity than in high
  magnitude environments.

83
Contribution of Different Knowledge Structures in
High frequency Environments

• Now, we will look at the contribution of the
  different knowledge structures in the
  Coarse-grained phase, the Fine-tuning phase, and
  the Backtracking phase.
• The tables in each phase are the results of total
  100 run.
• The tables show the number of times and
  percentages that a knowledge structure has
  produced the best solution and the influence
  operators that generate the best in the next
  generation after a given operator has generated
  the best.

84
Coarse-grained Phase
85
Fine-tuning Phase
86
Backtracking phase

• The backtracking search has shifted the search
  five times into unexplored search space but it
  has not succeeded in reaching the optimum
  solution because of the time limitation.
• The results suggest that backtracking search is
  not as effective with very high frequency of
  change than with high magnitude low frequency
  changes.

87
Summary

• The results in the coarse-grained and the
  fine-tuning phases show that all the knowledge
  sources contribute in the same way as in high
  magnitude environments.
• This suggests that changes from high to low
  frequency of change does not change the
  contribution percentage of the belief space
  knowledge sources.
• The backtracking search was not useful in high
  frequency environments because of the time
  limitation which did not let the system continue
  to backtracking.
• In general the knowledge contribution in
  magnitude dominant environments and frequency
  dominant environments are shown to be almost the
  same in all phases except for the backtrack
  tracking phase.

88
Deceptive Environments

• The results of the comparative study between CA
  and self-adaptive EP motivate these experiments
  to see how the system behaves with problems in
  deceptive environments.
• Goldberg 1987 defines a problem to be deceptive
  if it contains two blocks A and B where the
  average fitness of A is greater than B even
  though B includes a solution that has a greater
  fitness value than any other solution in A.
• The experiment settings were as we shown earlier

• Experiments on four cones environments complexity
  for deceptive and non-deceptive environments.
• Changing Locations for
• Large magnitude (selected randomly within the
  ranges in the table above)
• Low frequency (change occurs every 300
  generations)
• Every run contains 10 change events.

89
Deceptive Environments Example
90
Experiments in Deceptive Environments

• To ensure generation of deceptive environments,
  we imposed some restrictions on the problem
  generator DF1.
• The slopes, and the heights were static but the
  locations were dynamic.
• The cones heights were 10.0, 13.0, 14.0, 11.0
  and the slopes were 20, 20, 70, 20 respectively,
  where cones number 1 and 3 centered in same
  location and assigned the same moving directions
  to generate deceptive environments with cone
  number 2.
• The following table gives the results of the 4
  cones experiments in deceptive environments.
• The CA success ratio was 93 versus 100 in
  problem complexity for magnitude dominant
  environments.
• The experiments show the increasing use of the
  backtracking search (44 times out of 200 runs).

91
4 Cones Experiments in Deceptive Environments
92
Experiments in Non-deceptive Environments

• Since the maximum success ratio that any system
  can attain is 100 and the CA success ratio in
  the four cones environments was 100 for the
  magnitude dominant environments, we will use the
  same environmental setting used there as our
  non-deceptive environmental setting for this
  experiment.
• To achieve a fair comparison between our
  experiments in deceptive and non-deceptive
  environments we set the slopes, and heights of
  the cones to be static but the locations were
  dynamic.
• The results, as expected, 100 success ratio with
  one instance of backtracking search.

93
4 Cones Experiments in Non-deceptive Environments
94
Coarse-grained phase in Non-deceptive Environments

• This chart compares knowledge sources
  contributions in magnitude dominant environments
  (Mag) where all cones variables are changing, and
  non-deceptive environments ( static H, S) where
  only the cones locations are changing.
• The Domain operator (D) shows significant
  improvement in the coarse grained phase when the
  heights and slopes were static.
• This improvement achieved, perhaps, because D
  operator generates step size relative to the drop
  in fitness value.
• This suggest that D operator is sensitive to the
  change in heights and slopes.
•

95
Coarse-grained phase in Deceptive versus
Non-deceptive Environments

• Although the deceptive experiments were static in
  heights and slopes, the contribution of the D
  operator was much less successful in
  non-deceptive environments.
• The reason perhaps, the step size generated by D
  operator in deceptive environments is too large.
• This also suggest that D operator is sensitive to
  the large differences in slopes.

96
Fine-tuning phase in Non-deceptive Environments

• Also, in the fine-tuning phase the D operator
  increase its contribution in non-deceptive
  environments (static S, H) relative to the
  magnitude dominate environments where all cones
  variables are dynamic.
• The increase in the D contribution, suggests that
  D operator works as a fine-tuning operator for
  dynamic environments with static heights and
  slopes.

97
Fine-tuning phase in Deceptive versus
Non-deceptive Environments

• The main difference in knowledge contribution for
  the fine-tuning phase is still the domain
  knowledge operator.
• The differences also, suggest that the D operator
  is sensitive to the large difference in slopes.

98
Backtracking phase in Deceptive Environments

• The backtracking phase in deceptive environments
  shows an increase in the contribution of T, H, S,
  and N operators and decrease in the contribution
  of D operator from their contribution levels in
  the backtracking phase for magnitude dominant
  environments.
• The D operator contribution in deceptive
  environments is only for generating diversity.

99
Observations

• The backtracking search using normative knowledge
  was successful in recovering from 31 false peak
  convergences, out of 44 total.
• That suggests that a major player in the systems
  success is the role of the normative knowledge in
  the backtracking search.
• Backtracking means going back to the basics (or
  going back to the basic interval schemata in the
  normative knowledge). It is analogous for
  rethinking to solve a problem in human society
  when the current method fails to solve it.
  Conservatives usually advocate going back to the
  basics and searching for a solution based on
  basic principles.
• The normative knowledge backtrack the search and
  search within its interval to shift the search to
  a new unexplored search space, as shown in the
  following example in deceptive environments.

100
Example Run in Deceptive Environments
101
Example (cont.)
102
Conclusion

• The goal was to investigate the role that
  knowledge plays in guiding the search of an
  evolutionary population in dynamic environments.
  The results compared against those of a
  population-only adaptive systems.
• The five categories of knowledge taken together
  are effective in all of the classes of dynamic
  environments tested, magnitude dominant,
  frequency dominant, and deceptive environments.
• However, each has a different role to play in the
  problem solving process.
• In the coarse-grained phase the topographical
  knowledge operator was the main contributor in
  determining the region containing the most
  promising solution.
• In the fine-tuning phase the situational
  operator is the main contributor for exploring
  local search.
• In the backtracking phase the normative
  knowledge operator is the main contributor in
  backtracking the search and recovering the search
  from a false peak.

103
Conclusion (cont.)

• Each of these phases emerged in all experiments,
  but depending upon the problem dynamics certain
  phase were more prevalent than others in problem
  solving (e.g. backtracking increased in deceptive
  environments).
• The knowledge sources interact with each other in
  terms of the population space in the sense that
  one knowledge structure generates patterns that
  are then exploited by others. This produces
  sequences of symbiotic operators (T?S, N?S, N?T,
  H?S, H?T) , and therefore the problem solving
  phases.
• The CA approach was less sensitive than
  population-only approach to scaling of the
  problem complexity in terms of the problem
  success ratio and the CPU time.
• Also, the results suggest some social
  manifestation of these results (e.g. the notion
  of back to the basics)

104
Future Work

• Future work for this study is to investigate
  whether the success ratios produced by the
  Cultural Algorithms using EP as the population
  model in different types of environments can be
  generalized to other population-only models, when
  a different population model is used such as GA
  or ES.
• Another interesting study is to modify and expand
  this model of Cultural Algorithms for
  optimization and search to applications like the
  stock market.

105
The End

• Thank you for your time.

106
Conclusion

• Experiments in the CA problem solving process
  emerged into three phases of searches
  coarse-grained, fine-tuning, and the backtracking
  phases where the topographical, situational, and
  normative knowledge structures are the most
  problem solving contributors in these phases
  respectively.
• The topographical knowledge shown to be useful in
  detecting the most promising region and avoiding
  the need for backtracking search.
• The history knowledge is useful in detecting a
  stagnation situation in the search and
  contributing to guiding the search in the
  coarse-grained phase in dynamic environments.
• The domain knowledge operator contribute to the
  search in different roles
• Work as a fine-tuning operator in static
  environments.
• If the locations only are dynamic the operator
  contributes in more significant role in both the
  coarse-grained phase and the fine-tuning phase.
• The domain operator is sensitive to large
  difference in slopes.
• In completely dynamic environments where all
  variables are changing, the domain operator works
  as a diversity generator.

107
Conclusion (cont.)

• The situational knowledge operator (S) works
  allows as a fine-tuning operator.
• The normative knowledge operator (N) is a major
  player in contribution to the system success
  ratio.
• The N operator backtrack and recover the search
  when other knowledge sources leads the search to
  a false peak.
• It is, as we said, analogous for the
  conservatives rethinking and going back to the
  basics to solve a problem in human society when
  the current method fails to solve it.
• Throughout all of the experiments, here, using
  knowledge shows that it can produce significant
  improvement over population-only systems in term
  of the solution quality and execution time.
• The CA system is less sensitive to the increase
  in problem complexity than population-only
  system.

108
Observations

• The runs exhibit three phases of search where in
  each phase different knowledge structures
  dominates the search. The phases are called the
  Coarse-grained phase where the search is for the
  most promising region (first phase), followed by
  the Fine-tuning phase, where the promising region
  is explored in more detail, and the Backtracking
  search which occurs when the population stagnates
  (stabilizes).
• The examples also, suggested that
• The first 10 generations represent the
  Coarse-grained phase.
• Backtracking phase start when a stagnation
  situation is detected until 10 generations after
  normative knowledge produces the new best.
• Fine-tuning phase follows the the coarse-grained
  and the backtracking phases.
