Operating System Principles

1
Operating System Principles

• Ku-Yaw Chang
• canseco_at_mail.dyu.edu.tw
• Assistant Professor, Department of Computer
  Science and Information Engineering
• Da-Yeh University

2
Chapter 5 Process Scheduling

• CPU scheduling or Process scheduling
• The basis of multiprogrammed OSs
• Make the computer more productive
• Switch the CPU among processes
• We introduce
• The basic scheduling concepts
• Several different CPU-scheduling algorithms
• Select an algorithm for a particular system

3
Chapter 5 Process Scheduling

1. Basic Concepts
2. Scheduling Criteria
3. Scheduling Algorithms
4. Multiple-Processor Scheduling
5. Thread Scheduling

1. Operating System Examples
2. Algorithm Evaluation
3. Summary
4. Exercises

4
5.1 Basic Concepts

• Several processes are kept in memory at one time
• When a process has to wait, the OS takes the CPU
  away from that process, and gives the CPU to
  another process.
• Almost all computer resources are scheduled
  before use.
• CPU is one of the primary resources
• CPU scheduling is central to OS design

5
5.1.1 CPU-I/O Burst Cycle

• An observed property of processes
• Process execution consists of a cycle of
• CPU execution
• I/O wait
• Process execution begins with a CPU burst.
• followed by an I/O burst, then another CPU burst,
  then another I/O burst, and so on

6
Alternating sequence ofCPU and I/O bursts
7
Histogram of CPU-burst durations
8
5.1.1 CPU-I/O Burst Cycle

• Measure CPU bursts
• An I/O bound program
• Many short CPU bursts
• A CPU bound program
• A few very long CPU bursts
• Help select an appropriate CPU-scheduling
  algorithm

9
5.1.2 CPU Scheduler

• Whenever the CPU becomes idle
• Select one of the processes in the ready queue to
  be executed
• Carried out by the short-term scheduler, also
  called CPU scheduler
• A ready queue may be implemented as
• A FIFO queue
• A priority queue
• A tree
• An unordered linked list

10
5.1.3 Preemptive Scheduling

• CPU scheduling decisions may take place when a
  process
• Switch from running to waiting state
• Switch from running to ready state
• Switch from waiting to ready state
• Terminate
• Scheduling only under 1 and 4 is nonpreemptive
  (or cooperative)
• Otherwise is preemptive
• Incur a cost

11
5.1.4 Dispatcher

• Dispatcher module gives control of the CPU to the
  process selected by the short-term scheduler
• switching context
• switching to user mode
• jumping to the proper location in the user
  program to restart that program
• Dispatch latency
• time it takes for the dispatcher to stop one
  process and start another running.

12
Chapter 5 Process Scheduling

1. Basic Concepts
2. Scheduling Criteria
3. Scheduling Algorithms
4. Multiple-Processor Scheduling
5. Thread Scheduling

1. Operating System Examples
2. Algorithm Evaluation
3. Summary
4. Exercises

13
5.2 Scheduling Criteria

• CPU utilization (max)
• keep the CPU as busy as possible
• Throughput (max)
• number of processes that complete their execution
  per time unit
• Turnaround time (min)
• amount of time to execute a particular process
• Waiting time (min)
• amount of time a process has been waiting in the
  ready queue
• Response time (min)
• amount of time it takes from when a request was
  submitted until the first response is produced,
  not output (for time-sharing environment)

14
Chapter 5 Process Scheduling

1. Basic Concepts
2. Scheduling Criteria
3. Scheduling Algorithms
4. Multiple-Processor Scheduling
5. Thread Scheduling

1. Operating System Examples
2. Algorithm Evaluation
3. Summary
4. Exercises

15
5.3 Scheduling Algorithms

• Dealing the problem of deciding which of the
  processes in the ready queue to be allocated the
  CPU
• First-Come, First-Served Scheduling
• Shortest-Job-First Scheduling
• Priority Scheduling
• Round-Robin Scheduling
• Multilevel Queue Scheduling
• Multilevel Feedback-Queue Scheduling

16
5.3.1 First-Come, First-Served Scheduling

• The process that requests the CPU first is
  allocated the CPU first.
• The simplest CPU-scheduling algorithm
• Implementation with a FIFO queue
• Add to the tail of the queue
• Remove from the head to the queue
• The code is simple to write and understand
• Average waiting time is often quite long.

17
5.3.1 First-Come, First-Served Scheduling

• Process Burst Time
• P1 24
• P2 3
• P3 3
• Suppose that the processes arrive in the order
  P1 , P2 , P3 The Gantt Chart for the schedule
  is
• Waiting time for P1 0 P2 24 P3 27
• Average waiting time (0 24 27) / 3 17

18
5.3.1 First-Come, First-Served Scheduling

• Suppose that the processes arrive in the
  order
• P2, P3, P1
• The Gantt chart for the schedule is
• Waiting time for P1 6 P2 0 P3 3
• Average waiting time (6 0 3) / 3 3
• Much better than previous case

19
5.3.1 First-Come, First-Served Scheduling

• Convoy effect
• All the other processes wait for one big process
  to get off the CPU
• Results in lower CPU and device utilization
• If the shorter processes were allowed to go first
• FCFS is non-preemptive
• Once the CPU has been allocated to a process,
  that process keeps the CPU until it releases the
  CPU.
• Particular troublesome in time-sharing system
• Each user needs to get a share of the CPU at
  regular intervals

20
5.3.2 Shortest-Job-First Scheduling

• When the CPU is available, it is assigned to the
  process that has the smallest next CPU burst.
• Associate each process with the length of the
  latters next CPU burst
• Not its total length
• Another term shortest next CPU burst
• FCFS scheduling is used to break the tie
• Provably optimal
• Minimum average waiting time for a given set of
  processes
• Real difficulty
• Knowing the length of the next CPU burst
• Used frequently in long-term scheduling

21
5.3.2 Shortest-Job-First Scheduling

• Process Burst Time
• P1 6
• P2 8
• P3 7
• P4 3
• The Gantt Chart for the schedule is
• Waiting time for P1 3 P2 16 P3 9 P4
  0
• Average waiting time (3 16 9 0) / 4 7
• Using FCFS scheme ( 0 6 14 21) / 4 10.25

22
5.3.2 Shortest-Job-First Scheduling

• To approximate SJF scheduling
• To predict its value
• Use the length of previous CPU bursts
• exponential average

23
Prediction of the length of the next CPU burst
24
Examples ofExponential Averaging

• ? 0
• ?n1 ?n
• Recent history does not count.
• ? 1
• ?n1 tn
• Only the actual last CPU burst counts.
• If we expand the formula, we get
• ?n1 ? tn(1 - ?) ? tn-1
• (1 - ? )j ? tn-j
• (1 - ? )n1 ?0
• Since both ? and (1 - ?) are less than or equal
  to 1, each successive term has less weight than
  its predecessor.

25
5.3.2 Shortest-Job-First Scheduling

• Two schemes
• Nonpreemptive
• Allow the current running process to finish its
  CPU burst
• Preemptive
• If a new process arrives with CPU burst length
  less than remaining time of current executing
  process, preempt.
• Called as Shortest-Remaining-Time-First (SRTF)

26
Example of Preemptive SJF

• Process Arrival Time Burst Time
• P1 0 8
• P2 1 4
• P3 2 9
• P4 3 5
• Preemptive SJF
• Average waiting time ( (10-1) (1-1) (17-2)
  (5-3)) / 4 6.5

27
5.3.3 Priority Scheduling

• The CPU is allocated to the process with the
  highest priority.
• A priority is associated with each process
• Fixed range of number, such as 0 to 7
• We use low numbers to represent high priority
• Equal-priority processes are scheduled in FCFS
  order
• SJF is a special case of the general
  priority-scheduling algorithm
• The priority is the inverse of the predicted next
  CPU burst

28
Example of priority scheduling

• Process Burst Time Priority
• P1 10 3
• P2 1 1
• P3 2 4
• P4 1 5
• P5 5 2
• Priority scheduling
• Average waiting time ( 6 0 16 18 1 ) /
  5 8.2

29
5.3.3 Priority Scheduling

• Priorities can be defined
• Internally
• Use some measurable quantity
• Time limits, memory requirements
• Externally
• Set by criteria external to OS
• importance, political factors
• Priority scheduling can be
• Preemptive
• Nonpreemptive
• Major problem
• Indefinite blocking or starvation
• Solution aging
• Gradually increase the priority of processes that
  wait for a long time

30
5.3.4 Round-Robin Scheduling

• A small unit of time, called a time quantum ( or
  time slice) is defined.
• Generally from 10 to 100 milliseconds
• The ready queue is treated as a circular, FIFO
  queue.
• The CPU scheduler goes around the ready queue
• Allocate the CPU to each process for a time
  interval of up to 1 time quantum.
• Designed especially for time-sharing systems
• Two cases
• CPU burst less than 1 time quantum
• The process release the CPU voluntarily
• CPU burst longer than 1 time quantum
• Context switch will be executed

31
Example of round-robin scheduling

• Process Burst Time
• P1 24
• P2 3
• P3 3
• Round-robin scheduling
• A time-quantum of 4 milliseconds
• Average waiting time ( 6 4 7 ) / 3 5.66
• Often quite long
• RR scheduling is preemptive.

32
5.3.4 Round-Robin Scheduling

• n processes in the ready queue and the time
  quantum is q
• Each process gets 1/n of the CPU time in chunks
  of at most q time units at once
• No process waits more than (n-1)q time units
• Performance
• Depend heavily on the size of the time quantum
• q is very large the same as the FCFS policy
• q is very small called processor sharing
• q must be large with respect to context switch,
  otherwise overhead is too high.

33
A smaller time quantumincreases context switches
34
5.3.4 Round-Robin Scheduling

• Turnaround time also depends on the size of the
  time quantum.
• Rule of thumb
• 80 percent of the CPU burst shouldbe shorter
  thanthe time quantum

35
5.3.5 Multilevel Queue Scheduling

• Processes are classified into different groups
• Foreground (or interactive) processes
• Background (or batch) processes
• Multilevel queue-scheduling algorithm
• Partition the ready queue into several separate
  groups
• Each group has its own scheduling algorithm
• Scheduling among the queues
• Fixed-priority preemptive scheduling
• Possibility of starvation
• Time-slice between the queues
• A certain portion of the CPU time

36
Multilevel Queue Scheduling
37
5.3.6 Multilevel Feedback Queue

• A process can move between the various queues
• Use too much CPU time move to a lower-priority
  queue
• Wait too long move to a higher-priority queue
• This form of aging prevents starvation
• Multilevel-feedback-queue scheduler defined by
• number of queues
• scheduling algorithms for each queue
• method used to determine when to upgrade a
  process
• method used to determine when to demote a process
• method used to determine which queue a process
  will enter when that process needs service

38
Example ofMultilevel Feedback Queue

• Three queues
• Q0 time quantum 8 milliseconds
• Q1 time quantum 16 milliseconds
• Q2 FCFS
• Scheduling
• A new job enters queue Q0 which is served FCFS.
  When it gains CPU, job receives 8 milliseconds.
  If it does not finish in 8 milliseconds, job is
  moved to queue Q1.
• At Q1 job is again served FCFS and receives 16
  additional milliseconds. If it still does not
  complete, it is preempted and moved to queue Q2.

39
Multilevel feedback queues

• The most general and complex scheme

Q0
Q1
Q2
40
Chapter 5 Process Scheduling

1. Basic Concepts
2. Scheduling Criteria
3. Scheduling Algorithms
4. Multiple-Processor Scheduling
5. Thread Scheduling

1. Operating System Examples
2. Algorithm Evaluation
3. Summary
4. Exercises

41

• Be skipped

42
Chapter 5 Process Scheduling

1. Basic Concepts
2. Scheduling Criteria
3. Scheduling Algorithms
4. Multiple-Processor Scheduling
5. Thread Scheduling

1. Operating System Examples
2. Algorithm Evaluation
3. Summary
4. Exercises

43
5.5.1 Contention Scope

• Process-contention scope (PCS)
• Competition for the CPU takes place among threads
  belonging to the same process
• Many-to-one and many-to-many models
• System-contention scope (SCS)
• Competition for the CPU takes place among all
  threads in the system
• One-to-one model

44
Chapter 5 Process Scheduling

1. Basic Concepts
2. Scheduling Criteria
3. Scheduling Algorithms
4. Multiple-Processor Scheduling
5. Thread Scheduling

1. Operating System Examples
2. Algorithm Evaluation
3. Summary
4. Exercises

45

• Be skipped

46
Chapter 5 Process Scheduling

1. Basic Concepts
2. Scheduling Criteria
3. Scheduling Algorithms
4. Multiple-Processor Scheduling
5. Thread Scheduling

1. Operating System Examples
2. Algorithm Evaluation
3. Summary
4. Exercises

47
Summary

• P.181 to 182

48
Chapter 5 Process Scheduling

1. Basic Concepts
2. Scheduling Criteria
3. Scheduling Algorithms
4. Multiple-Processor Scheduling
5. Thread Scheduling

1. Operating System Examples
2. Algorithm Evaluation
3. Summary
4. Exercises

49
Exercises

• 5.2
• 5.3
• 5.4
• 5.5
• 5.7

50
The End
