Geometry 3.1

1

• Geometry 3.1
• Big Idea Identify pairs of lines and angles

2
Vocabulary

• Parallel Lines
• Two lines that do not intersect and are coplanar.

3

• Skew Lines
• Two lines that do not intersect and are not
  coplanar.

4

• Parallel Planes
• Two planes that do not intersect.
• Ex plane RSTU plane WXYZ

5

• Note a small triangle (like an arrow, pointed
  in one direction of a line) is used to indicate
  that lines are parallel (our book uses red color
  to denote this) the arrow is on each line, not
  at the end

6
Postulates

• Postulate 13Parallel Postulate
• If there is a line and a point not on the line,
  then there is exactly one line through the point
  to the given line.
• ? P
• m

7

• Postulate 14Perpendicular Lines
• If there is a line and a point not on the line,
  then there is exactly one line through the point
  - to the given line.
• ? P
• m

8
More Vocabulary

• Transversal
• A line that intersects 2 or more coplanar lines
  at different points.

9

• Corresponding Angles on same side of transversal
  with same relationship (on top or on bottom) to
  other 2 lines (2 6), others?

10

• Alternate Interior Angles
• Angles that lie between the 2 lines on opposite
  sides of the transversal (3 5), others?

11

• Alternate Exterior Angles
• Angles that lie outside the 2 lines on opposite
  sides of the transversal.
• (2 8), others?

12

• Consecutive Interior Angles
• Angles that lie between the 2 lines on the same
  side of the transversal.(4 5 ),others?

13
Example Identify all pairs of angles of the
given type.

• Corresponding
• Alternate Interior
• Alternate Exterior
• Consecutive interior
• Vertical

2
1
3
4
6
7
5
8
