New Bellow Breather

1
(No Transcript)
2
New Bellow Breather Isolates equipment from the
atmosphere

• Application for bellow breather in industry
• Pumps, fin-fan gearboxes, oil reservoirs, power
  transformers etc.
• In areas where moist, dust in the form of coal
  and sand is a source of contamination of the
  lubrication oil this breather will stop ingress
  and add quantum life to machinery.

3
Components of bellow breather
Breathing opening
80 mic Filter at Breathing opening
Bellow or bladder
One way valve releasing at 1000 Pa
Sight glass for silica gell
10 mic Filter
Connection for Pump, gearbox, oil reservoir ,
transformer etc.
Demister section
4
Features

• The air leaving the rotating equipment contains
  water vapour and also oil is sometimes splashed
  out the vent point.
•  The purpose of the demister section is to
  prevent the oil drops to reach the filter
  membrane and clogs the pores. The water vapour
  will go through the demister section and will be
  absorbed by the absorbent granules. As the
  equipment breath during heat cycles the inner
  moist is absorbed by the absorbent material
  .During the breathing stage the equipment remains
  totally isolated from the atmosphere. This is
  been achieved by the bellow moving up and down to
  allow for volume changes.

5
Basic operation exhale
6
Basic operation inhale
7
Basic operation cooling down
8
Safe operation in extreme conditions
9
(No Transcript)
10
(No Transcript)
11
Summary on Bellow Breather

• Prevention of oil contamination.
• No cleaning of transformer oil needed.
• Continuous improvement on MTBF.
• Prevent bearing failure on fin fan coolers.
• Keep gearbox internally dry at cooling towers
  conditions.
• Costs saving on maintenance budgets.
