Castle

1
Castle Intelligent Weapon Control System

• THE SOLUTION

2
FEATURES OF CASTLE DEFENCE SYSTEMS

• Made of durable reinforced steel

• Systematic Storage of Mass Weapon

• Automatic Lock System

• Security integration by using Advanced Biometric
  Fingerprint Technology

• User friendly management software to avoid
  fraudulence and allow traceability.

• External Alarm for Intruder detection

RFID SIGNAL

• Multiple reports including Late Return,
  Missing Firearm, etc

• RFID chip embedded

3
DISTINCTIVE FEATURES OF CASTLE DEFENCE SYSTEMS
UNIQUE ID
Finger Zoom xx

• BIOMETRIC TECHNOLOGY

OUTER LAYER SKIN

• REVOLUTIONARY TECHNOLOGY

• Detection beneath the surface of the skin
• (Saline Layer)

SALINE LAYER
4
SYSTEM CONFIGURATION - CENTRALIZATION
Networking LAN/ WAN
Site A
(HEAD QUARTER )
PC Terminal (Remote Monitoring)
PC Terminal (Remote Monitoring)
Site B
Site C
5
SYSTEM CONFIGURATION
SITE A
SITE C
SITE B
6
OVERVIEW OF SYSTEM COMPONENTS
Castle Intelligent Weapon Control System
7
Main Components CASS M16
1 Emergency Release
2 Metal Shutter
2(A B) Status Indicator (LED)
3 Base Slot
4 Backup Battery
4

8
Main Components InnerScan?
1 Graphic Liquid Crystal Display (LCD) The reader allows an attractive display of clear blue screen. It is also programmed with user-friendly Icons to assist usage.
2 16 Keys Silicon Keypad The keypad allows higher security requirements of users by having combined mode of accessibility (e.g. Keypad Fingerprint).
3 Trueprint Technology The technology verifies users identity through the scanning of the users inner layer (saline layer) of their finger. It is not affected by injury/contamination to finger thereby suitable to Professions constantly facing this problem.
4 Housing The housing is made from ABS Casing The housing is made from ABS Casing
5 System Features Card Reading Distance Mifare 5cm Proximity 8cm
5 System Features Fingerprint Template 6000 bytes/ template
5 System Features Fingerprint capture time ? 1 second
9
Main Components Alarm Spray
No Item
1. Antenna To release and transmit remote control signal
2. Spray Opening To discharge the inflammatory agent tactical defense system)
3. Tubular Cam Lock To mount the alarm spray to the alarm spray mounting bracket
4. Operation switch To select operation mode
5. Siren Hole To enable sirens sound to effectively heard
6. System Status LED To indicate the alarm spray activation status (ON/OFF)
7. PIR/ Microwave Sensor To sense person (intruder) within the sensor range
8. PIR/ Microwave Status LED To indicate the PIR/ Microwave detection status
9. Guide Opening To allow the bracket guide insertion
10. Power Adapter Socket To allow adapter to power the Alarm Spray Unit
10
How It Works
Castle Intelligent Weapon Control System
11
Registration
STEP 1
Register Armourer
Scan Fingerprint
STATUS UNLOCKED
Army Personal Tag
Weapon User
OR/AND
Amourer
Amourer Personal Tag
Scan Fingerprint
12
Weapon Collection
STEP 2
Personnel Collect Weapon
STATUS UNLOCKED
Weapon Management Software Status Unlocked
13
Weapon Security Control
STEP 3
Personnel Collects Weapon in control zone
027888 Soldier 2 (IO) Wrong time zone
14
Emergency Release
STEP 4
Armourer Retrieves Weapon during emergency
Emergency Release Key
15
SUMMARY
CASTLE INTELLIGENT WEAPON CONTROL SYSTEM
16
Prevent unauthorized personnel from obtaining
firearms
User-friendly Software
Reduce and simplify workload for staff
Remote Monitoring (LAN, WAN enabled
Centralized control and monitoring for IWCS
Easy management and control firearm distribution
Easy storage of all log files in hard disk, CD,
etc
Minimize human error
Intruder detection
Easy cross reference/ back racking
Introduce new individual weapon locking method
Increase security by using inner layer skin
Biometric fingerprint technology
Real time security monitoring
Multiple reports including Late Return, Missing
Firearm, etc
17
(continued..)

• Intelligent Weapon Control System (Rack)
• Standard rack for 8 weapons
• Handle up to 8000 weapon per location
• Back to back or top bottom rack stacking to
  reduce storage space.
• External Alarm Integration with Defence Alarm
  Spray
• TCP/IP Enable
• Remote access enable you to check weapon or rack
  status.
• Built-in backup battery last up to 48 hours
• Emergency release all weapon
• Highest security adapting InnerScan Fingerprint
  reader which capture the image beneath the skin.
• Intelligent Weapon Control System (Reader)
• Duress Alarm Ready
• Dual Finger Mode for armourer and troops or
  officer

RFID
18
The end

• Q A
• Session

19
Thank you Visit our website
www.castle.com.my for more information.
