CSCE 212 Chapter 6 Enhancing Performance with Pipelining

1
CSCE 212Chapter 6Enhancing Performance with
Pipelining

• Instructor Jason D. Bakos

2
Pipelining
3
MIPS Pipeline

• Basic idea
• Execute multiple instructions in parallel
• Split instruction execution into 5 stages
• Instructions execute in assembly-line

fetch
decode
execute
memory
write back
op/func
ctrl/NOOP
control
MemoryDataIn
address
A
MemRead MemWrite Address MemoryOut MemoryIn
PC
RegFile
rs/rt
ALU
R
B
SE/imm SE/imm4
4
SHAMT
A, B registers control for execute/memory/wb rs/
rt/rd
instruction register
R register control for memory/wb rs/rt/rd
MDR register control for wb rs/rt/rd
4
Pipelined MIPS
5
Pipelined MIPS
6
Pipelined Control
7
Pipelined Control
8
Pipelined Control
9
MIPS ISA

• MIPS pipeline stages
• Fetch (F)
• read next instruction from memory, increment
  address counter
• assume 1 cycle to access memory
• Decode (D)
• read register operands, resolve instruction in
  control signals, compute branch target
• Execute (E)
• execute arithmetic/resolve branches
• Memory (M)
• perform load/store accesses to memory, take
  branches
• assume 1 cycle to access memory
• Write back (W)
• write arithmetic results to register file

10
Hazards

• Hazards are data flow problems that arise as a
  result of pipelining
• Limits the amount of parallelism, sometimes
  induces penalties that prevent one instruction
  per clock cycle
• Structural hazards
• Two operations require a single piece of hardware
• Structural hazards can be overcome by adding
  additional hardware
• Control hazards
• Conditional control instructions are not resolved
  until late in the pipeline, requiring subsequent
  instruction fetches to be predicted
• Flushed if prediction does not hold (make sure no
  state change)
• Branch hazards can use dynamic prediction/speculat
  ion, branch delay slot
• Data hazards
• Instruction from one pipeline stage is
  dependant of data computed in another pipeline
  stage

11
Hazards

• Data hazards
• Register values read in decode, written during
  write-back
• RAW hazard occurs when dependent inst. separated
  by less than 2 slots
• Examples
• ADD 2,X,X (E) ADD 2,X,X (M) ADD 2,3,4
  (W)
• ADD X,2,X (D)
• ADD X,2,X (D)
• ADD X,2,3 (D)
• In most cases, data generated in same stage as
  data is required (EX)
• Data forwarding
• ADD 2,X,X (M) ADD 2,X,X (W) ADD 2,3,4
  (out-of-pipe)
• ADD X,2,X (E)
• ADD X,2,X (E)
• ADD X,2,3 (E)

12
Load Hazards

• Stalls required when data is not produced in same
  stage as it is needed for a subsequent
  instruction
• Example
• LW 2, 0(X) (M)
• ADD X, 2 (E)
• When this occurs, insert a bubble into EX
  state, stall F and D
• LW 2, 0(X) (W)
• NOOP (M)
• ADD X, 2 (E)
• Forward from W to E

13
Data Hazards Forwarding
14
Data Hazards Stalling for Load Hazard
15
Control Hazards

• Need to make a branch decision based on data that
  has yet to be produced
• add 2,3,4
• beqz 2,loop
• Which stage is branch resolved?
• Approaches
• stall
• insert bubbles after all branches
• always predict untaken
• if taken, instructions entering DEC and EX (and
  MEM?) transfer as NOOPs
• branch delay slot
• instruction following branch is always executed
• dynamic branch predictors

16
Control Hazards

• Instructions are fetched every clock cycle
• Branch decisions happen in the EX stage
• Solutions
• Assume branch not taken (performs a flush of IF,
  ID, EX by inserting a nop into the pipeline
  registers on the clock edge)
• Reduce the delay by moving the branch decision up
• Requires additional hardware (comparators, etc.)
• Might increase cycle time, since register read
  and resolution are now in series and must be
  performed in half a cycle to allow for parallel
  register writes!
• Requires forwarding and stall hardware for new
  data hazards

17
Example
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

• add 6,5,2
• lw 7,0(6)
• addi 7,7,10
• add 6,4,2
• sw 7,0(6)
• addi 2,2,4
• blt 2,3,loop
• add 6,5,2

8 instructions, 15 - 4 cycles, CPI 11/8
18
Moving up Branch Resolution
19
Moving up Branch Resolution
20
Scheduling the Branch Delay Slot
21
Dynamic Branch Prediction

• Assume taken/not-taken (static)
• Loops have branches that are usually taken
• When wrong, we flush pipeline stages
• Deeper pipelines have higher branch penalties
  (misprediction penalty)
• Solution
• Look up address of branch to check if branch was
  previously taken
• One-bit schemes
• Two-bit schemes (must be wrong twice to change
  prediction)
